Projective Geometry Based on slides by Peter Corke Homogeneous coordinates Cartesian homogeneous homogeneous Cartesian lines and points are duals Pin-hole model in homogeneous form Perspective transformation, with the pesky

SLIDE 1

Projective Geometry

Based on slides by Peter Corke

SLIDE 2

SLIDE 3

SLIDE 4

Homogeneous coordinates

homogeneous → Cartesian
Cartesian → homogeneous

lines and points are duals

SLIDE 5

Pin-hole model in homogeneous form

Perspective transformation, with the pesky divide by

Z, is linear in homogeneous coordinate form.

SLIDE 6

3D to 2D scaling/zoomi ng

SLIDE 7

Central projection model

SLIDE 8

Change of coordinates

scale from metres to pixels
shift the origin to top left

corner

SLIDE 9

Complete camera model

intrinsic parameters extrinsic parameters camera matrix

SLIDE 10

Camera matrix

Mapping points from the world to an image (pixel)

coordinate is simply a matrix multiplication using homogeneous coordinates

SLIDE 11

Scale invariance

SLIDE 12

Normalized camera matrix

Since scale factor is arbitrary we can fix the value of
ne element, typically C(3,4) to one.

SLIDE 13

Points on a plane

all points on the plane have Z=0

SLIDE 14

Planar homography

Once again the scale factor is arbitrary
8 unique numbers in the homography matrix
Can be estimated from 4 world points and their

corresponding image points

homography matrix

SLIDE 15

Perspective rectification

>> H = homography(p1, p2) H= 1.4003 0.3827 -136.5900 - 0.0785 1.8049 -83.1054 - 0.0003 0.0016 1.0000

SLIDE 16

>> homwarp(H, im, 'full')

Perspective rectification

SLIDE 17

Warping

SLIDE 18

Name
