Ben Eckart, NVIDIA Research, Learning and Perception Group, 3/20/2019

GPU-ACCELERATED 3D POINT CLOUD PROCESSING WITH HIERARCHICAL GAUSSIAN MIXTURES

2

3D POINT CLOUD DATA

Basic data type for unstructured 3D data Emergence of commercial depth sensors has made it ubiquitous

2

3

POINT CLOUD PROCESSING CHALLENGES

Points are non-differentiable, non-probabilistic Large amounts of often noisy data Often spatially redundant, wide ranging density variance

4

PREVIOUS APPROACHES

What have people done before?

Discrete Approaches Voxel Grids/Lists, Octrees, TSDFs Though efficient, they inherit the same non- differentiable, non-probabilistic problems as point clouds

OctoMap

5

PREVIOUS APPROACHES

What have people done before?

Continuous Approaches Gaussian Mixture Models, Gaussian Processes Though theoretically attractive, in practice tend to be too slow for many applications GMM Gaussian Process

Proposal: Hierarchical Gaussian Mixture

GMM J=8 GMM J=8 GMM J=8 GMM J=8 GMM J=8 GMM J=8

GMM J=8

GMM J=8 GMM J=8

GMM J=8

GMM J=8

GMM J=8 GMM J=8 GMM J=8 GMM J=8 “Level 2” GMM “Level 3” “Level 4”

Goals: Efficiency benefits of hierarchical structures like Octree Theoretical benefits of a probabilistic generative model

Talk Overview

• Background

– Theory of generative modeling for point clouds

• Single-Layer Model (GMMs)

– GPU-Accelerated Construction Algorithm – Benefits: Compact and Data-Parallel – Limitations: Scaling with model size, lack of memory coherence

• Hierarchical Models (HGMMs)

– GPU-Accelerated Construction Algorithm – Benefits: Fast and Parallelizable on GPU – Application: Registration

8

STATISTICAL / GENERATIVE MODELS

Interpret point cloud data (PCD) as an iid sampling of some unknown latent spatial probabilistic function Generative property: Full joint probability space is represented

Model

• Given a set of parameters describing the model, find the

parameters that best “explain” the data (Maximum Data Likelihood)

Modeling as an MLE Optimization

Model Data

Parametric Model as a Modified GMM

Interpret point cloud data as an iid sampling from a small number (J << N)

• f Gaussian and Uniform Distributions:

GMM for Point Clouds: Intuition

Point samples representing pieces of the same local geometry could be aggregated into clusters with the local geometry encoded inside the covariance of that cluster.

12

SOLVING FOR THE MLE GMM PARAMETERS

Typically done via the Expectation Maximization (EM) Algorithm

E Step M𝚰 Step

Update 𝚰

𝚰𝒋𝒐𝒋𝒖

𝚰𝒈𝒋𝒐𝒃𝒎

Point Cloud

EM Algorithm

Update point-cluster associations

E Step: A Single Point

Z

zi

For each point z, we want to find the relative likelihood (expectation) of it having been generated by each cluster

𝑃(𝑂)

Z

We calculate the probability of each point with respect to each J Gaussian cluster. The expected associations are denoted by the NxJ matrix γ

zi 𝑃(𝐾)

E Step: Expectation Vector

15

M STEP: CLOSED FORM WEIGHTED SUMS

For the GMM case, the M Step has closed form solutions given the NxJ matrix γ:

“Probabilistic generalization

• f K-Means Clustering”

GPU Data Parallelism

GMM Model Limitations

• Each point needs to access all J

cluster parameters in CUDA (poor memory locality and linear scaling with J)

• NxJ expectation matrix mostly sparse

(thus wasted computation)

• Static number of Gaussians that

must be set a priori

zi 𝑃(𝐾)

18

HIERARCHICAL GAUSSIAN MIXTURE

Suppose we restrict J to be only 8 Gaussians The model would fit entirely in shared memory for each CUDA threadblock, removing need for global memory accesses The expectation matrix will be dense (Nx8)

18

19

HIERARCHICAL GAUSSIAN MIXTURE

After convergence of the J=8 GMM, we can use the Nx8 expectation matrix as a partition function Each point is partitioned via its maximum expectation Now we have 8 partitions of roughly size N/8

19

20

HIERARCHICAL GAUSSIAN MIXTURE

We can now run the algorithm recursively on each partition Each partition contains ~N/8 points that will be modeled as another J=8 GMM Note that this will produce 64 clusters in total

20

21

PARALLEL PARTITIONING USING CUDA

Given each point's max expectation and associated cluster index, we can "invert" this index using parallel scans to group together point ID's having same partition #: [0 0 1 0 1 1 1 2 0 2 2 2] ➔ [[0 1 3 8] [2 4 5 6] [7 9 10 11]] Now we can run a 2D cuda kernel where Dimension 1: index into original point cloud Dimension 2: cluster of the parent e.g. 3 clusters, 12 points, 2 threads/threadblock ➔ grid size of (2, 3)

Cluster 1 Cluster 2 Cluster 3

22

HGMM COMPLEXITY

Even though we now have 64 clusters, we only need to query 8 clusters for each point (avoiding the computation of all NxJ (sparse) expectations) Due to the 2D cuda grid and indexing structure, this segmentation of the points into 64 clusters is the exact same complexity/speed as the

• riginal "simple" J=8 GMM.

Thus, we can keep increasing the complexity of the model eightfold while incurring only a linear time penalty

23

HGMM ALGORITHM

Small EM algorithms (8 clusters at a time) are recursively performed on increasingly smaller partitions of the point cloud data E Step: Associate points to clusters M Step: Update mixture means, covariances, and weights Partition Step: Before each recursion step, new point partitions are determined by maximum likelihood point-cluster associations from last E Step

24

HGMM DATA STRUCTURE

GMM J=8 GMM J=8 GMM J=8 GMM J=8 GMM J=8 GMM J=8

GMM J=8

GMM J=8 GMM J=8

GMM J=8

GMM J=8

GMM J=8 GMM J=8 GMM J=8 GMM J=8 “Level 2” GMM “Level 3” “Level 4”

Efficiency benefits of hierarchical structures like Octree Theoretical benefits of a probabilistic generative model

25

E Step Performance

Compactness vs Fidelity

27

COMPACTNESS VS FIDELITY

Reconstruction Error (PSNR) vs Model Size (kB)

20 kB

28

MODELING LARGE POINT CLOUDS

HGMM Level 6: <12 MB Volume created from stochastically sampled Marching Cubes Visualization is real-time: ~20 fps on Titan X Endeavor Snapshots: ~80 GB of Point Cloud Data each

29

ENDEAVOR DATA: BILLIONS OF POINTS

30

APPLICATION: RIGID REGISTRATION

Point-sampled surfaces displaced by some rigid transformation Recover translation, rotation that best overlaps point clouds

31

Goal: Maximize data likelihood over T given some probability model θ MLE over Space of Rotations, Translations

Registration as EM with HGMM

Outdoor Urban Velodyne Data

• Velodyne VLP-16

– ~15k pts/frame – ~10 frames/sec

• Frame-to-Frame

model-building and registration with

• verlap estimation

HGMM-Based Registration

• Average Frame-

to-Frame Error: 0.0960

Robust Point-to-Plane ICP

• Average Frame-

to-Frame Error: 0.1519

• best result on

libpointmatcher

35

Speed vs Accuracy Trade-Off

Test: Random transformations of point cloud pairs while varying the subsampling rate. Less subsampling yields better accuracy, but slower speeds. Bottom left is fastest and most accurate. Our proposed methods are red/teal/black.

Our Proposed Methods

36

HGMM COMING TO ISAAC

~350 fps on Titan Xp ~30 fps on Xavier Error: ~0.05° yaw (median, 4 Hz updates)

37

DRIVEWORKS (Future Release) With Velodyne HDL-64E: ~300 FPS on Titan Xp ~30 FPS on Xavier

38

DNN-BASED STEREO DEPTH MAPS

39

FINAL REMARKS

HGMM’s have many nice properties for modeling point clouds:

Efficient: Fast to compute via CUDA/GPU, even scaling to billions of points Multi-Level: Can well-model the data distribution at multiple levels simultaneously Probabilistic: allows Bayesian optimization for applications like registration Compact and Continuous: no voxels and no aliasing artifacts, easy to transform

40

QUESTIONS?

42

REGISTRATION FROM DNN-BASED STEREO

Noisy point cloud output is well-suited for HGMM representation

43

Frame-to-frame registration from point cloud data only (no depth maps), subsampled to 2000 points, first 100 frames. Histograms of average Euler angle error per frame shown. GMM- Based ICP-Based Proposed

Stanford Lounge Dataset (Kinect)

44

Noise Handling

• Test: Random (uniform)

noise injected at increasing amounts

• Result: Mixture

component “stick” to areas of geometrically coherent, dense areas, disregarding areas of noise

46

SAMPLING FOR PROBABILISTIC OCCUPANCY

Ƹ 𝑞 = 𝑀Σ𝑞 + 𝜈 ∀ 𝜈, Σ ∈ Θ

47

MESHING UNDER NOISE

48

ADAPTIVE MULTI- SCALE

49

MULTI-SCALE MODELING

Multilevel cross-sections can be adaptively chosen for robustness

50

E Step: Parallelized Tree Search

Point-model associations are found through parallelized adaptive tree search in CUDA. Complexity() is defined to be , but other suitable heuristics are possible.

Adaptive Thresholding Finds the Most Appropriate Scale to Associate Point Data to the Point Cloud Model

51

The resulting form (1) is a weighted sum-of-squared Mahalanobis distances, further reduced to (2) by writing in terms of sufficient statistics M𝑘

{0,1}.

We seek the transformation that maximizes the expected joint log-likelihood of our data and latent associations wrt the posterior over our current association estimates.

M-Step: Mahalanobis Estimation

Lastly, covariance eigendecomposition produces an equivalent weighted point-to-plane distance measure (3), which we can solve efficiently with least squares.

(3 ) (1) (2)
