Private Forests Monitoring Unit Update Oregon Board of Forestry, 5 September 2018 Marganne Allen Manager, Forest Health and Monitoring Paul Clements Training Coordinator Adam Coble Monitoring Specialist Ariel Cowan AGENDA ITEM A

slide-1
SLIDE 1

Private Forests Monitoring Unit Update

Oregon Board of Forestry, 5 September 2018

Adam Coble Monitoring Specialist Paul Clements Training Coordinator Ariel Cowan Monitoring Specialist Marganne Allen Manager, Forest Health and Monitoring

AGENDA ITEM A Attachment 02 Page 1 of 49

slide-2
SLIDE 2

Why Monitor?

Do Check Plan

  • Expectations

– Statute, Rule, Policy – Agency best practice

  • Emphasis

–Collaboration –Continuous learning –Adapting to new science –Rules

  • Riparian
  • Landslides, Public Safety
  • Pesticides

References: ORS 527.710(7), OAR 629-635-0110, OAR 629-623-0000(4), OAR 629-620-0700, Forestry Program for Oregon

AGENDA ITEM A Attachment 02 Page 2 of 49

slide-3
SLIDE 3

Living the Strategy: Priority Work Topics

Implementation

  • Roads
  • Harvesting
  • Riparian
  • Pesticides
  • Reforestation

Effectiveness

  • Riparian
  • Wood recruit.
  • Stream temp &

shade

All projects: High – medium priority topics Priority

AGENDA ITEM A Attachment 02 Page 3 of 49

slide-4
SLIDE 4

Monitoring Update

  • Implementation

– Compliance Audit: 2013-2017 effort (2017 focus) – Up next: Reforestation Study

  • Effectiveness

– Western OR streamside protections review – Siskiyou streamside protections review

AGENDA ITEM A Attachment 02 Page 4 of 49

slide-5
SLIDE 5

Forest Practices Compliance Monitoring - 2017

AGENDA ITEM A Attachment 02 Page 5 of 49

slide-6
SLIDE 6

Eastern Oregon Area Southern Oregon Area NW Oregon Area

Distribution

  • f Sites

2017: 100 sites statewide, stratified based

  • n ODF Area and Ownership Class

(Process began in 2013 …)

AGENDA ITEM A Attachment 02 Page 6 of 49

slide-7
SLIDE 7

Rule Divisions subject to this study are: Written Plans of Operation – Various Divisions

  • Road Construction & Maintenance
  • Harvesting
  • Vegetation Retention along

Streams

  • Protection of Significant Wetlands
  • Protection of “Other Wetlands”
  • Operations Near Waters of the State

AGENDA ITEM A Attachment 02 Page 7 of 49

slide-8
SLIDE 8

CONTRACTOR Gathers Field Data Electronic download to ODF ODF Analyzes Data for Compliance

PROCESS

COMPLIANT NON - COMPLIANT

DATA POINT

ODF : Quality Control Sampling of Data at Sites

AGENDA ITEM A Attachment 02 Page 8 of 49

slide-9
SLIDE 9

Non-Compliance = (At the sample point)

a) Rule was applicable at the sample point, b) Rule not implemented properly c) Sediment deposition to waters observed –

  • r other damage, or administrative

requirements not met

AGENDA ITEM A Attachment 02 Page 9 of 49

slide-10
SLIDE 10

As found inside the unit boundary

AGENDA ITEM A Attachment 02 Page 10 of 49

slide-11
SLIDE 11

25,600 observations on 100 sites

2017 Sample…

AGENDA ITEM A Attachment 02 Page 11 of 49

slide-12
SLIDE 12

2017 Results 100 sites, 57 rules Overall compliance: 98 %

AREA COMPLIANCE

Eastern Oregon

98%

Northwest Oregon

98%

Southern Oregon

97%

LANDOWNER TYPE

Private Non-Industrial

96%

Private Industrial

98%

Other

98%

AGENDA ITEM A Attachment 02 Page 12 of 49

slide-13
SLIDE 13

2017- Scale of Impacts from Non Compliance Amount of Sediment Delivery

48 7 1 49 9 10 20 30 40 50 60 Trace-1 1.1-10 10.1-100 >100

Number of cases Sediment Delivery (cubic yards) Roads Skid trails

65%

  • ccurrence in

Small Type N Streams. 36 Units had Sediment Delivery to Streams. 35 Units with Water had no delivery. 29 Units had no water.

AGENDA ITEM A Attachment 02 Page 13 of 49

slide-14
SLIDE 14

Over Time - Rule Division Level Compliance 2013 -2017

75 83 92 68

20 40 60 80 100

2013 2014 2016 2017

P e r c e n t C o m p l i a n c e

Written Plans of Operation – Several Rule Divisions (2017 – 68%)

AGENDA ITEM A Attachment 02 Page 14 of 49

slide-15
SLIDE 15

Over Time - Rule Division Level Compliance 2013 -2017

97 98 98 98 20 40 60 80 100 2013 2014 2016 2017

P e r c e n t C o m p l i a n c e

Road Construction & Maintenance (2017 - 98%)

AGENDA ITEM A Attachment 02 Page 15 of 49

slide-16
SLIDE 16

Roads – Ongoing need at stream crossings to disconnect road drainage from stream

AGENDA ITEM A Attachment 02 Page 16 of 49

slide-17
SLIDE 17

AGENDA ITEM A Attachment 02 Page 17 of 49

slide-18
SLIDE 18

Over Time - Rule Division Level Compliance 2013 -2017

95 93 96 96 20 40 60 80 100 2013 2014 2016 2017

Harvesting Practices

P e r c e n t C o m p l i a n c e

AGENDA ITEM A Attachment 02 Page 18 of 49

slide-19
SLIDE 19

Harvesting - Small Type N Streams - awareness / avoidance

AGENDA ITEM A Attachment 02 Page 19 of 49

slide-20
SLIDE 20

Over Time - Rule Division Level Compliance 2013 -2017

98 99 99 96 20 40 60 80 100 2013 2014 2016 2017

P e r c e n t C o m p l i a n c e

Vegetation Retention Along Streams – (2017 – 96%)

AGENDA ITEM A Attachment 02 Page 20 of 49

slide-21
SLIDE 21

Vegetation Retention Along Streams –trends high.

.

AGENDA ITEM A Attachment 02 Page 21 of 49

slide-22
SLIDE 22

100 94 20 40 60 80 100 2013 2014 2016 2017

Significant Wetlands (>8 acres) (2017 – 94%)

Over Time - Rule Division Level Compliance 2013 -2017

P e r c e n t C o m p l i a n c e

AGENDA ITEM A Attachment 02 Page 22 of 49

slide-23
SLIDE 23

Wetlands > 8 acres

AGENDA ITEM A Attachment 02 Page 23 of 49

slide-24
SLIDE 24

72 83 98 89 20 40 60 80 100 2013 2014 2016 2017

P e r c e n t C o m p l i a n c e

Over Time – Rule Division Level Compliance 2013 -2017

Protection for Other Wetlands (2017 – 89%)

AGENDA ITEM A Attachment 02 Page 24 of 49

slide-25
SLIDE 25

PROTECT OTHER WETLANDS (<8 acres)

AGENDA ITEM A Attachment 02 Page 25 of 49

slide-26
SLIDE 26

Over Time - Rule Division Level Compliance 2013 -2017

99 98 99 99 20 40 60 80 100 2013 2014 2016 2017

Operations Near Waters of the State

P e r c e n t C o m p l i a n c e

AGENDA ITEM A Attachment 02 Page 26 of 49

slide-27
SLIDE 27

Operations Near Waters of the State – (Channel Relocation)

AGENDA ITEM A Attachment 02 Page 27 of 49

slide-28
SLIDE 28

2017 - Ongoing Needs for Improvement

  • Small Type N: 65% of instances of sediment delivery
  • Small wetlands
  • Road drainage & filtration near stream crossings
  • Placement of Road Materials on Steep Slopes
  • Culvert Sizing – 50 year flows
  • Temporary Stream Crossing removal and stabilize

AGENDA ITEM A Attachment 02 Page 28 of 49

slide-29
SLIDE 29

2013 -2018 Compliance Audit – Contract Complete

2017

  • Contractor completed last sites in March

2018 and beyond

  • Analysis of all contract data (2013-2017)
  • Reforestation study

Ongoing

  • Outreach and education plan

AGENDA ITEM A Attachment 02 Page 29 of 49

slide-30
SLIDE 30

Thanks Are in Order -

Barnes & Associates, Inc. was contractor for data acquisition, did excellent work. Stakeholder Support from various organizations and individual partners, including:

AGENDA ITEM A Attachment 02 Page 30 of 49

slide-31
SLIDE 31

NEXT… Reforestation Study

Division 610 – Forest Practices Reforestation Rules

AGENDA ITEM A Attachment 02 Page 31 of 49

slide-32
SLIDE 32

Upcoming 2019 - Reforestation Study

  • 100 Sites statewide –
  • Proportional to Area of Notifications
  • Notifications for “Clear Cut”

completed by 12/16

  • Private contractor for data gathering
  • Largely based on existing

stocking protocol

  • Review herbicide records of applications if existing

AGENDA ITEM A Attachment 02 Page 32 of 49

slide-33
SLIDE 33

2019 Reforestation Study

Next Steps:

  • Select Sites from Database
  • Landowner Permissions
  • Screen Sites
  • List RFP in ORPIN
  • Award Contract
  • Field Work begin in 2019
  • Planning for five iterations

AGENDA ITEM A Attachment 02 Page 33 of 49

slide-34
SLIDE 34

QUESTIONS?

Compliance Audit

AGENDA ITEM A Attachment 02 Page 34 of 49

slide-35
SLIDE 35

Effectiveness Monitoring

Streamside Protections Reviews (Board direction)

  • 1. Western Oregon
  • 2. Siskiyou

Potential Board responses

  • FPA works as designed
  • FPA may not meet stated objectives
  • Additional study warranted
  • No action needed

AGENDA ITEM A Attachment 02 Page 35 of 49

slide-36
SLIDE 36

Temperature Shade Desired Future Condition (DFC)

Topics & Geography

Small & Medium Fish Streams

AGENDA ITEM A Attachment 02 Page 36 of 49

slide-37
SLIDE 37

Background on Desired Future Conditions

“…to grow and retain vegetation so that,

  • ver time, average conditions across the

landscape become similar to those of mature streamside stands.”

  • Mature streamside stands

– Often conifer dominated – Stand age: avg. 120 years – Provide multiple functions

  • Desired Future Condition (DFC):

AGENDA ITEM A Attachment 02 Page 37 of 49

slide-38
SLIDE 38

Western OR Streamside Protections Review:

Are FPA rules effective in achieving the goals for desired future conditions and large wood?

Siskiyou Region

Desired Future Conditions Large Wood

  • W. Oregon Desired Future

Conditions Systematic review Field data analysis Modeling analysis - TBD

  • W. Oregon

Large Wood Field data analysis Modeling analysis??

Western Oregon

Systematic review

AGENDA ITEM A Attachment 02 Page 38 of 49

slide-39
SLIDE 39

Why use Systematic Reviews? Protocol: Rigor & repeatability

  • Search methods
  • Literature inclusion criteria
  • Data extraction and synthesis

Methodical input from interested parties

Western OR Streamside Protections Review

AGENDA ITEM A Attachment 02 Page 39 of 49

slide-40
SLIDE 40

Western OR Streamside Protections Review: Systematic Review

DFC

  • Forest management and desired future condition (DFC)
  • Range of DFC conditions
  • Species composition
  • Regeneration

Large Wood

  • Forest management and large wood recruitment
  • Range of large wood
  • What is considered ‘abundant large wood’?

AGENDA ITEM A Attachment 02 Page 40 of 49

slide-41
SLIDE 41

RipStream Protocol Questions

  • 1. Trends in overstory & understory
  • 2. Trends in regeneration
  • 3. Large wood recruitment to streams &

riparian areas RipStream study

  • 33 sites (Coast Range), Small & Medium F

streams

  • Pre- and post-harvest data

Western OR Streamside Protections Review: Field Data Analysis

AGENDA ITEM A Attachment 02 Page 41 of 49

slide-42
SLIDE 42

In process: determining scope and role of modeling analysis

Western OR Streamside Protections Review: Modeling

AGENDA ITEM A Attachment 02 Page 42 of 49

slide-43
SLIDE 43

Siskiyou Streamside Protections Review

Desired Future Condition Temperature & Shade

Siskiyou Region

Desired Future Condition Science Review Temp./Shade Science Review Contextual Info:

  • Fish status/trend
  • Water quality eval.

AGENDA ITEM A Attachment 02 Page 43 of 49

slide-44
SLIDE 44

What are the effects of near-stream forest management

  • n stream temperature and shade?
  • Meets DEQ water quality standards?
  • Shade similar to that of mature streamside stands?

Siskiyou Streamside Protections Review: Systematic Review

AGENDA ITEM A Attachment 02 Page 44 of 49

slide-45
SLIDE 45

What are the effects of near-stream forest management

  • n desired future conditions of riparian forests?
  • Range of DFC conditions in Siskiyou mature streamside stands
  • Understory & overstory comparison
  • Regeneration composition

Siskiyou Streamside Protections Review: Systematic Review

AGENDA ITEM A Attachment 02 Page 45 of 49

slide-46
SLIDE 46
  • DEQ

–TMDL –Temperature, shade, riparian forest information

  • ODFW

–Fish status & trend –Shade, riparian forest information

Siskiyou Streamside Protections Review: Contextual Information

AGENDA ITEM A Attachment 02 Page 46 of 49

slide-47
SLIDE 47

Western OR and Siskiyou Reviews: Status

  • Timelines developed
  • Conversations with:

–Stakeholders and Tribes –Local ODF staff –DEQ and ODFW

  • RipStream data: analytic methods (Western OR)
  • Draft protocols (Siskiyou and Western OR)

AGENDA ITEM A Attachment 02 Page 47 of 49

slide-48
SLIDE 48

Review Timelines: Board Meetings

  • Siskiyou

–Update & preliminary results – Winter/Spring 2019 –Completion – Spring/Summer 2019

  • Western Oregon

–Update & preliminary results – Spring/Summer 2019 –Completion – Fall 2019/Winter 2020

AGENDA ITEM A Attachment 02 Page 48 of 49

slide-49
SLIDE 49

Questions?

Marganne.Allen@Oregon.gov (503) 945-7240 Paul.R.Clements@Oregon.gov (503) 945-7475 Adam.Coble@Oregon.gov (503) 945-7317 Ariel.D.Cowan@Oregon.gov (503) 945-7332

AGENDA ITEM A Attachment 02 Page 49 of 49
