Preparation of Economy Wide - Material Flows Accounts using - - PowerPoint PPT Presentation

Jim West

International Study Tour– Black Mountain – September 2013 CSIRO ECOSYSTEM SCIENCES

Preparation of Economy Wide - Material Flows Accounts using International Data.

Disclaimer and request

Out of material and energy flows accounting, and emissions accounting, the focus here will be on materials flows because:

• Energy flows largely are already effectively accounted for in the

IEA or EIA databases (or can be trivially derived from them).

• Emissions data has come directly from that available directly

from the World Bank’s WDI database

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 2 |

from the World Bank’s WDI database In contrast, the work we’ve done on material flows has been quite major, and having individual countries become involved would improve it still further. PLEASE FEEL FREE TO ASK QUESTIONS AS WE GO

What is Economy Wide – Material Flows Accounting (EW- MFA) ?

EW-MFA deal with material inputs and outputs from a national economy, using physical rather than monetary terms. Covers domestic extraction of materials from the natural environment (excluding water and air), and international trade of materials. Only flows crossing the system boundary between the environment and the economy are counted. “Hidden” flows are not counted.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 3 |

and the economy are counted. “Hidden” flows are not counted. The key final metric is Domestic Material Consumption (DMC), arrived at via Domestic Extraction (DE) , and Physical Trade Balance (PTB). PTB = Imports – Exports

DMC = DE + PTB

How do we compile EW-MFA accounts?

Refer to the Eurostat EW-MFA Compilation Guide (2012) for how these statistics should be compiled at national level. This is the “Standard”, (that said, some departures may be

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 4 |

said, some departures may be forced, or warranted for other reasons)

What use is EW-MFA ?

The “Guide” says that it is “to describe the interaction of the domestic economy with the natural environment and the rest of the world economy (ROW) in terms of flows of materials. Determine how much “stuff” needs to be extracted from the environment to support a certain material standard of living. Determine how much waste needs to be sunk back into the

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 5 |

Determine how much waste needs to be sunk back into the environment (even infrastructure eventually ends up as waste). ** Provide basic information necessary to determine Resource Efficiency**

Improved RE = Lower Environmental Impacts (ceteris paribus)

Examples 1: National level DMC trajectories in the Asia-Pacific region

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 6 |

Individual trajectories in Latin America do not fit the classic pattern of socio-metabolic transitions well

Contrasting socio-metabolic transitions for two world regions - ISIE Ulsan 2013 | Jim West, Heinz Schandl 7 |

Examples 2: World regional level trajectories for DMC, material intensity, and GDP/capita

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 8 |

How suited to purpose is DMC? Depends on commodity.

For allocating responsibility for resources “use” and resource efficiency:

Minerals : Poor - Reasonable. Less biased against resource producers / exporters than TMI (which includes hidden flows),

• r DE alone, but material footprint far superior.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 9 |

Fossil Fuels : Good (though misses embodied energy)

For determining where environmental loads accrue efficiency:

• Good. Captures where much of the material and energy

intensive processing takes place. Better than MF, but less comprehensive than TMI.

DMC Vs. Material Footprint.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 10 |

From: Wiedmann, Schandl, Lenzen, Moran, Suh, West, and Kanemoto. (2013). “The material footprint of nations”. Proceedings of the National Academy of Sciences.

Using international data sets for EW-MFA

“The Guide” is aimed at best practice for compilation of EW-MFA accounts by individual countries, preferably by national statistical agencies. CSIRO EW-MFA databases needed to cover many countries, had to rely on comprehensive international databases. Inevitable that some quality lost due to use of generalized international coefficients rather than nation specific ones.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 11 |

coefficients rather than nation specific ones. However (we believe) that some our modelling used is superior to the default options suggested in the guide (notably for biomass and metal

• res). Also much less biased towards industrialized nations.

Note: beware some misleading wording in “The Guide” e.g. mis- statement of ore grades.

Key material categories.

Ultimately, four materials categories were defined, with further detail within these in 11 sub-categories. Similar to “The Guide” top level divisions, but not identical

Category Sub-category Biomass Crops Crop residues Grazed biomass

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 12 |

Wood Fossil fuels Coal Petroleum Natural gas Metal ores and industrial minerals Ferrous ores Non-ferrous ores Industrial minerals Construction minerals Construction minerals

Compilation level often more detailed.

Initial compilation of DE done into 35 categories, conform to The Guide’s categories at 2 to 4 digit level.

Country EWMFACat EWMFAName 1970 1971 1972 Australia A.1.1.1 Cereals 12904533 14840092 10781927 Australia A.1.1.10 Other crops 20979 20536 17861 Australia A.1.1.2 Roots and tubers 763149 775769 824603 Australia A.1.1.3 Sugar crops 17644800 19390500 18928300 .. .. .. .. .. .. Australia A.1.2.1 Crop residues (used) 22236442 24991770 21413062

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 13 |

Australia A.1.2.1 Crop residues (used) 22236442 24991770 21413062 Australia A.1.2.2.2 Grazed biomass 57746580 61653104 70415892 Australia A.1.3.1 Timber (Industrial roundwood 5989240 6295400 6044480 Australia A.1.3.2 Wood fuel and other extraction 1796720 1798338 1799840 Australia A.2.1 Iron Ores 51186080 62096904 64398144 Australia A.2.2.1 Copper ores - gross ore 16037299 18289790 19558434 Australia A.2.2.2 Nickel ores - gross ore 538510.5 848992.9 1138581 .. .. .. .. .. .. Australia A.3.1.4 Chemical and fertilizer minerals 174269.8 241905.1 264879.8 .. .. .. .. .. .. Australia A.4.2.2 Natural gas 1029096 1532984 2208486

Main raw data sources for DE estimation.

Colour indicates degree of confidence in estimates (green high, red low)

Sub-category Main Raw Data source Post Processing

Crops FAO Crop Production Statistics Minimal Crop residues FAO Crop Production Statistics Moderate modelling Grazed biomass FAO Food balance sheets Extensive modelling, large assumptions Wood FAO Forestry Minor modelling

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 14 |

Coal IEA (and EIA) Minimal Petroleum IEA (and EIA) Minimal Natural gas IEA (and EIA) Minimal (Energy to weight conversion) Ferrous ores USGS, UN Industrial Commodities Minimal, moderate assumptions Non-ferrous ores USGS, UN Industrial Commodities Simple modelling, large assumptions Industrial minerals USGS, UN Industrial Commodities Simple modelling, large assumptions Construction minerals USGS, UN Industrial Commodities Moderate modelling, large assumptions

Main raw data sources for Trade estimation.

Colour indicates degree of confidence in estimates (green high, red low)

Sub-category Main Raw Data source Post Processing

Crops FAO Trade Statistics Minimal Crop residues FAO Trade Statistics , UN Comtrade Minimal Grazed biomass FAO Trade Statistics , UN Comtrade Minimal Wood FAO Forestry Minimal

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 15 |

Wood FAO Forestry Minimal Coal IEA (and EIA) Minimal Petroleum IEA (and EIA) Minimal Natural gas IEA (and EIA) Minimal (Energy to weight conversion) Ferrous ores UN Comtrade Minimal Non-ferrous ores UN Comtrade Minimal Industrial minerals UN Comtrade Minimal Construction minerals UN Comtrade Minimal

Raw data is only a very rough starting point for some categories of material - 1

EW-MFA is interested in determining the quantity of raw material as extracted from the environment Fossil fuel statistics are excellent, and most mass is retained in traded products.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 16 |

Basic crop data is good and generally in the units / on the basis we require. Forestry data also reasonably good, roundwood basis is what we want, and weight conversions not too difficult.

In Contrast:

Raw data is only a very rough starting point for some categories of material - 2

Statistics on Metals usually on contained metal or concentrates basis. We want ore. Statistics on crop residues need to be calculated from crops produced. We are only interested in that portion that enters economy. Statistics here are poor. Construction materials are rarely well recorded. The best we can do is

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 17 |

Construction materials are rarely well recorded. The best we can do is get the figure for cement (which is recorded), and apply factors to that. Grazed biomass is almost never recorded. The figure is calculated from complex modelling based on other figures, some of which are poorly determined.

DMC and the problem of double counting.

Double counting can be a major problem in determining DMC. A compromise between missing major flow volumes and double counting was reached. We used different scopes for DE and Trade. For DE, only primary materials as extracted from the environment were counted, as double counting of mass occurs when we include

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 18 |

counted, as double counting of mass occurs when we include processed goods. e.g. Crude oil extracted + gasoline refined = double counting For Trade, products which had undergone considerable processing were included in volumes e.g. exports of roundwood + wood chips + paper are independent. Elaborately transformed, multi-material items are excluded (of necessity).

Example 1 - Grazed biomass - complex modelling, many assumptions.

No nation measures how much grass its herds eat. HOWEVER: Production of animal products is generally well recorded - FAO. Portion of crops and fishmeal going to animal feed is recorded (to some degree) – FAO. Studies have been undertaken on the feed energy required to produce

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 19 |

Studies have been undertaken on the feed energy required to produce different animal products (most notably Wirsenius 2000). (Animal products x required feed energy/kg) – feed energy supplied from crops = “Feed Gap” Missing energy required for ruminant products must (we hope) come from grass.

Grazed biomass (cont.) - Hierarchically model different animals’ claims on feed crops.

Country Item MJ/kg Afghanistan Cattle meat 499 Afghanistan Cow milk, whole, fresh 13.82 Afghanistan Eggs Primary + (Total) 53 Afghanistan Goat meat 998 Afghanistan Goat milk, whole, fresh 27.64 .. .. .. Albania Cattle meat 160 Albania Cow milk, whole, fresh 9.95 Albania Eggs Primary + (Total) 42

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 20 |

Albania Eggs Primary + (Total) 42 Crop NEmCattle NEgCattle TotNExCattle DEPig MEPig MEChicken wheat_grains 9.35 6.49 15.85 16.3 15.6 14.7 rice_grains 9.35 6.49 15.85 16.3 15.6 14.7 maize_grains 9.35 6.49 15.85 16.4 15.7 15 .. .. .. .. .. .. .. sorghum_grains 8.59 5.82 14.42 15.5 14.9 15 cassava_tubers 8.16 5.43 13.6 14.5 13.9

Example 2 – Metal ores - simple modelling, huge assumptions.

Statistics on Metals usually on contained metal or concentrates basis. We want ore tonnages. Conceptually very simple, Ore = contained metal / grade Unfortunately:

• Ore grades can vary enormously between deposits and countries.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 21 |

• Ore grades can vary enormously between deposits and countries.
• poly-metallic deposits –> coupled production -> double counting*.
• Trade data does not distinguish well between metal ores,

concentrates.

*In a sense, there is no fully satisfactory answer to the coupled production problem. The Guide’s allocation by value is perhaps as good as any.

What can be done by individual countries to improve EW- MFA.

• Compile key mining statistics by commodity, especially tonnes and

grade of ore (mine by mine).

• Better record production of construction aggregates.
• Report mineral imports / exports in more disaggregated form i.e.

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 22 |

• Report mineral imports / exports in more disaggregated form i.e.

separate ores from concentrates, and attach a weighted average metal content to each.

• Determine what non-grazed feeds are actually received by

individual classes of animal.

Links and further reading.

CSIRO and UNEP REEO reports and online material flows databases :

http://www.csiro.au/Outcomes/Climate/Adapting/Resource-Efficiency-Asia-Pacific.aspx www.csiro.au/AsiaPacificResourceFlows, www.csiro.au/LatinAmericaCaribbeanResourceFlows (see also the technical annexes linked from these pages)

“The Guide”: just Google “Eurostat EW-MFA Compilation Guide” to get latest. Context setting:

Preparation of Economy Wide - Material Flows Accounts using International Data. – Black Mountain – September 2013 | Jim West 23 |

Context setting: Krausmann, F., S. Gingrich, N. Eisenmenger, K.-H. Erb, H. Haberl, and

• M. Fischer-Kowalski. 2009. Growth in global materials use, GDP and population during the

20th century. Ecological Economics 68: 2696 - 2705.

DMC and Trade issues: Schandl, H. and J. West. 2012. Material Flows and Material

Productivity in China, Australia, and Japan. Journal of Industrial Ecology 16(3): 352-364.

Material Footprint: Wiedmann, T. O., H. Schandl, M. Lenzen, D. Moran, S. Suh, J.

West, and K. Kanemoto. 2013. The material footprint of nations. Proceedings of the National Academy of Sciences.
