Predicting perturbation effects in large-scale systems from observational data

Marloes Maathuis Seminar f¨ ur Statistik, ETH Z¨ urich, Switzerland

Joint work with

Marloes Maathuis, ETH Z¨ urich 2 / 29

Peter B¨ uhlmann Diego Colombo Markus Kalisch

Research question

Marloes Maathuis, ETH Z¨ urich 3 / 29

• In short: Can we learn perturbation effects without doing

perturbation experiments?

Research question

Marloes Maathuis, ETH Z¨ urich 3 / 29

• In short: Can we learn perturbation effects without doing

perturbation experiments?

• Concretely: Can we learn the gene regulatory network of yeast from
• bservational data?
• Predict perturbation effects between all pairs of genes
• Identify pairs of genes between which there is a large effect

Why use observational data?

Marloes Maathuis, ETH Z¨ urich 4 / 29

• Thousands of perturbation experiments needed to estimate all

perturbation effects ⇒ time consuming and expensive

Why use observational data?

Marloes Maathuis, ETH Z¨ urich 4 / 29

• Thousands of perturbation experiments needed to estimate all

perturbation effects ⇒ time consuming and expensive

• Questions:
• Does observational data provide some information on

perturbation effects?

• Can this information be used to guide and prioritize perturbation

experiments?

Definition of perturbation effect

Marloes Maathuis, ETH Z¨ urich 5 / 29

• Consider the effect of gene i on gene j.

Let Xi and Xj be the expression levels of the genes.

• If we experimentally change Xi, what happens to Xj?

Definition of perturbation effect

Marloes Maathuis, ETH Z¨ urich 5 / 29

• Consider the effect of gene i on gene j.

Let Xi and Xj be the expression levels of the genes.

• If we experimentally change Xi, what happens to Xj?
• Hypothetical experiment:

Genetically modified such that Xi ≈ a Genetically modified such that Xi ≈ a + 1

Definition of perturbation effect

Marloes Maathuis, ETH Z¨ urich 5 / 29

• Consider the effect of gene i on gene j.

Let Xi and Xj be the expression levels of the genes.

• If we experimentally change Xi, what happens to Xj?
• Hypothetical experiment:

do(Xi = a) do(Xi = a + 1)

Definition of perturbation effect

Marloes Maathuis, ETH Z¨ urich 5 / 29

• Consider the effect of gene i on gene j.

Let Xi and Xj be the expression levels of the genes.

• If we experimentally change Xi, what happens to Xj?
• Hypothetical experiment:

do(Xi = a) do(Xi = a + 1)

• Perturbation effect of gene i on gene j:

E(Xj|do(Xi = a + 1)) − E(Xj|do(Xi = a)) (value of a drops out if the system is linear)

Estimating perturbation effects from observational data

Marloes Maathuis, ETH Z¨ urich 6 / 29

• It is easy to estimating associations from observational data.

But association is not causation!

• Pearl (2003):
• “An associational concept is any relationship that can be defined

in terms of the joint distribution of observed variables.”

Estimating perturbation effects from observational data

Marloes Maathuis, ETH Z¨ urich 6 / 29

• It is easy to estimating associations from observational data.

But association is not causation!

• Pearl (2003):
• “An associational concept is any relationship that can be defined

in terms of the joint distribution of observed variables.”

• “A causal concept [such as a perturbation effect] is any

relationship that cannot be defined from the distribution alone (...) Any claim invoking causal concepts must be traced to some premises that invoke such concepts; it cannot be inferred or derived from statistical associations alone.”

Estimating perturbation effects from observational data

Marloes Maathuis, ETH Z¨ urich 6 / 29

• It is easy to estimating associations from observational data.

But association is not causation!

• Pearl (2003):
• “An associational concept is any relationship that can be defined

in terms of the joint distribution of observed variables.”

• “A causal concept [such as a perturbation effect] is any

relationship that cannot be defined from the distribution alone (...) Any claim invoking causal concepts must be traced to some premises that invoke such concepts; it cannot be inferred or derived from statistical associations alone.”

• An assumption that is often made: data were generated by a known

directed acyclic graph (DAG)

Directed acyclic graph (DAG)

Marloes Maathuis, ETH Z¨ urich 7 / 29

X2 X1 X3

• Nodes represent random variables and edges represent conditional

independence relationships

• The DAG encodes causal assumptions:
• Edge X2 → X1: X2 may have a direct causal effect on X1
• No edge X1 X3: X1 cannot have a direct causal effect on X3

(but X1 and X3 will be correlated!)

Pearl’s intervention-calculus / do-calculus

Marloes Maathuis, ETH Z¨ urich 8 / 29

X2 X1 X3

• The perturbation effect of X1 on X3:

E(X3|do(X1 = a + 1)) − E(X3|do(X1 = a))

Pearl’s intervention-calculus / do-calculus

Marloes Maathuis, ETH Z¨ urich 8 / 29

X2 X1 X3

• The perturbation effect of X1 on X3:

E(X3|do(X1 = a + 1)) − E(X3|do(X1 = a))

• The do-operator stands for a hypothetical experiment. So

E(X3|do(X1 = a)) is not the usual conditional expectation! In the example:

• E(X3|X1 = a) = E(X3)
• E(X3|do(X1 = a)) = E(X3)

Pearl’s intervention-calculus / do-calculus

Marloes Maathuis, ETH Z¨ urich 8 / 29

X2 X1 X3

• The perturbation effect of X1 on X3:

E(X3|do(X1 = a + 1)) − E(X3|do(X1 = a))

• The do-operator stands for a hypothetical experiment. So

E(X3|do(X1 = a)) is not the usual conditional expectation! In the example:

• E(X3|X1 = a) = E(X3)
• E(X3|do(X1 = a)) = E(X3)
• Pearl’s do-calculus uses the DAG to write expressions involving the

do-operator in terms of pre-intervention conditional distributions

Pearl’s intervention-calculus / do-calculus

Marloes Maathuis, ETH Z¨ urich 9 / 29

X2 X1 X3

• Summary: If the DAG is given, one can estimate perturbation effects

(or causal effects) from observational data

Main points in this talk

Marloes Maathuis, ETH Z¨ urich 10 / 29

• Present IDA (Intervention calculus when the DAG is Absent)
• Requires observational data
• generated from an unknown DAG
• multivariate Gaussian
• no hidden confounders
• potentially high-dimensional system
• Returns (summary measures of) estimated set of possible causal

effects

• Consistent in sparse high-dimensional settings
• Validation on yeast data

What to do when the DAG is unknown?

Marloes Maathuis, ETH Z¨ urich 11 / 29

• A DAG encodes conditional independence relationships
• So given all conditional independence relationships of the data, can

we infer the DAG?

What to do when the DAG is unknown?

Marloes Maathuis, ETH Z¨ urich 11 / 29

• A DAG encodes conditional independence relationships
• So given all conditional independence relationships of the data, can

we infer the DAG?

• Almost...

What to do when the DAG is unknown?

Marloes Maathuis, ETH Z¨ urich 11 / 29

• A DAG encodes conditional independence relationships
• So given all conditional independence relationships of the data, can

we infer the DAG?

• Almost... several DAGs can encode the same conditional

independence relationships. They form an equivalence class, described by a CPDAG.

What to do when the DAG is unknown?

Marloes Maathuis, ETH Z¨ urich 11 / 29

• A DAG encodes conditional independence relationships
• So given all conditional independence relationships of the data, can

we infer the DAG?

• Almost... several DAGs can encode the same conditional

independence relationships. They form an equivalence class, described by a CPDAG.

• One can estimate this CPDAG, for example using the PC-algorithm
• f Peter Spirtes and Clark Glymour (Spirtes et al, 2000)
• Fast implementation in the R-package pcalg
• Consistent in sparse high-dimensional settings

(Kalisch and B¨ uhlmann, JMLR 2007)

IDA (oracle version)

Marloes Maathuis, ETH Z¨ urich 12 / 29

• racle

CPDAG PC-algorithm DAG 1 DAG 2 . . . . . . DAG m do-calculus effect 1 effect 2 . . . . . . effect m multi-set Θ

The multi-set Θ

Marloes Maathuis, ETH Z¨ urich 13 / 29

• Why multi-set instead of a unique value?

The multi-set Θ

Marloes Maathuis, ETH Z¨ urich 13 / 29

• Why multi-set instead of a unique value?
• Recall quote of Pearl. We make “weak” causal assumptions:
• The data are generated from unknown DAG
• There are no hidden confounders

The multi-set Θ

Marloes Maathuis, ETH Z¨ urich 13 / 29

• Why multi-set instead of a unique value?
• Recall quote of Pearl. We make “weak” causal assumptions:
• The data are generated from unknown DAG
• There are no hidden confounders
• What information does Θ provide? Examples:
• Θ = {1.5} ⇒ causal effect is 1.5
• Θ = {1.5, 0.5, 3.1} ⇒ causal effect is positive
• Θ = {1.5, 1.5, −1} ⇒ absolute value of causal effect ≥ 1

The multi-set Θ

Marloes Maathuis, ETH Z¨ urich 13 / 29

• Why multi-set instead of a unique value?
• Recall quote of Pearl. We make “weak” causal assumptions:
• The data are generated from unknown DAG
• There are no hidden confounders
• What information does Θ provide? Examples:
• Θ = {1.5} ⇒ causal effect is 1.5
• Θ = {1.5, 0.5, 3.1} ⇒ causal effect is positive
• Θ = {1.5, 1.5, −1} ⇒ absolute value of causal effect ≥ 1
• Hence:
• The true causal effect is always contained in Θ
• The minimum absolute value of Θ is a lower bound on the size
• f the true causal effect

Scalability

Marloes Maathuis, ETH Z¨ urich 14 / 29

• Finding all DAGs in an equivalence class is very computationally

intensive

• Hence, method only works for small graphs (< 15 nodes)
• Solution: local method

IDA (oracle version)

Marloes Maathuis, ETH Z¨ urich 15 / 29

• racle

CPDAG PC-algorithm DAG 1 DAG 2 . . . . . . DAG m do-calculus effect 1 effect 2 . . . . . . effect m multi-set Θ

IDA (local oracle version)

Marloes Maathuis, ETH Z¨ urich 16 / 29

• racle

CPDAG PC-algorithm do-calculus effect 1 effect 2 . . . . . . effect q multi-set ΘL

Comparison of Θ and ΘL

Marloes Maathuis, ETH Z¨ urich 17 / 29

• Multiplicities of elements in Θ and ΘL may differ
• Distinct elements of Θ and ΘL are identical
• Example: Θ = {1.5, 1.5, −1}, ΘL = {1.5, −1}

Comparison of Θ and ΘL

Marloes Maathuis, ETH Z¨ urich 17 / 29

• Multiplicities of elements in Θ and ΘL may differ
• Distinct elements of Θ and ΘL are identical
• Example: Θ = {1.5, 1.5, −1}, ΘL = {1.5, −1}
• Minimum absolute values of ΘL and Θ are identical

Sample version

Marloes Maathuis, ETH Z¨ urich 18 / 29

• In practice there is no oracle...
• Use sample version of PC algorithm to obtain an estimated

CPDAG G(α), where α is a tuning parameter

• Replace all causal effects by their estimated versions (least

squares regression)

• Denote results by

Θ(α) and ΘL(α)

IDA (local oracle version)

Marloes Maathuis, ETH Z¨ urich 19 / 29

• racle

CPDAG PC-algorithm do-calculus effect 1 effect 2 . . . . . . effect q multi-set ΘL

IDA (local sample version)

Marloes Maathuis, ETH Z¨ urich 20 / 29

data CPDAG PC-algorithm do-calculus effect 1 effect 2 . . . . . . effect q multi-set ΘL

IDA (local sample version)

Marloes Maathuis, ETH Z¨ urich 21 / 29

data

• CPDAG

PC-algorithm do-calculus

• effect 1
• effect 2

. . . . . .

• effect q

multi-set ΘL requires tuning parameter α

High dimensional setting

Marloes Maathuis, ETH Z¨ urich 22 / 29

• We allow the underlying graph to grow as n grows:
• DAG G = Gn
• Number of variables p = pn
• Distribution P = Pn
• Causal sets Θnij and ΘL

nij containing the effect of Xni on Xnj

High dimensional setting

Marloes Maathuis, ETH Z¨ urich 22 / 29

• We allow the underlying graph to grow as n grows:
• DAG G = Gn
• Number of variables p = pn
• Distribution P = Pn
• Causal sets Θnij and ΘL

nij containing the effect of Xni on Xnj

• Assume:
• Pn is multivariate Gaussian and faithful to true unknown causal

DAG Gn

• High-dimensionality and sparseness:
• pn = O(na), for some 0 ≤ a < ∞
• Maximum number of neighbors in Gn is of order O(n1−b),

for some 0 < b ≤ 1

• Some regularity conditions on partial correlations and

conditional variances

Consistency in high dimensional setting

Marloes Maathuis, ETH Z¨ urich 23 / 29

• Uniform consistency of

Θnij and ΘL

nij: There exists a sequence αn

such that sup

i=j∈{1,...,pn}

d( Θnij(αn), Θnij) →p 0 as n → ∞, sup

i=j∈{1,...,pn}

d( ΘL

nij(αn), ΘL nij) →p 0 as n → ∞.

Consistency in high dimensional setting

Marloes Maathuis, ETH Z¨ urich 23 / 29

• Uniform consistency of

Θnij and ΘL

nij: There exists a sequence αn

such that sup

i=j∈{1,...,pn}

d( Θnij(αn), Θnij) →p 0 as n → ∞, sup

i=j∈{1,...,pn}

d( ΘL

nij(αn), ΘL nij) →p 0 as n → ∞.

• Corollary: the minimum absolute value of Θnij can be consistently

estimated by the local algorithm, i.e., there exists a sequence αn such that sup

i=j∈{1,...,pn}

• min{|

θ| : θ ∈ ΘL

nij(αn)} − min{|θ| : θ ∈ Θnij}

• →p 0.

Validation: overview

Marloes Maathuis, ETH Z¨ urich 24 / 29

complex system experimental data

• bservational

data compute and rank causal effects apply IDA and rank the effects compare rankings

Validation: data and methods

Marloes Maathuis, ETH Z¨ urich 25 / 29

• Yeast gene expression data (Hughes et al., Cell 2000):
• Experimental data: expression levels of 5361 genes for 234

single gene deletion strains

• Observational data: expression levels of 5361 genes for 63

wild-type cultures

Validation: data and methods

Marloes Maathuis, ETH Z¨ urich 25 / 29

• Yeast gene expression data (Hughes et al., Cell 2000):
• Experimental data: expression levels of 5361 genes for 234

single gene deletion strains

• Observational data: expression levels of 5361 genes for 63

wild-type cultures

• Experimental data:
• Compute causal effects of the knock-out genes on all remaining

genes (234 × 5360 ≈ 1 million effects)

Validation: data and methods

Marloes Maathuis, ETH Z¨ urich 25 / 29

• Yeast gene expression data (Hughes et al., Cell 2000):
• Experimental data: expression levels of 5361 genes for 234

single gene deletion strains

• Observational data: expression levels of 5361 genes for 63

wild-type cultures

• Experimental data:
• Compute causal effects of the knock-out genes on all remaining

genes (234 × 5360 ≈ 1 million effects)

• Observational data:
• Apply IDA
• Apply other methods: random guessing, Lasso and Elastic-net

Evaluation: comparing the rankings

Marloes Maathuis, ETH Z¨ urich 26 / 29

• For the effects based on experimental data:
• Define the largest 10% as target set

Evaluation: comparing the rankings

Marloes Maathuis, ETH Z¨ urich 26 / 29

• For the effects based on experimental data:
• Define the largest 10% as target set
• For the effects based on the observational data (for 4 methods):
• Rank them and take the top q effects
• Compute nr of true positives: effects in the target set
• Compute nr of false positives: effects not in the target set

Evaluation: comparing the rankings

Marloes Maathuis, ETH Z¨ urich 26 / 29

• For the effects based on experimental data:
• Define the largest 10% as target set
• For the effects based on the observational data (for 4 methods):
• Rank them and take the top q effects
• Compute nr of true positives: effects in the target set
• Compute nr of false positives: effects not in the target set
• Create ROC curve

ROC curve

Marloes Maathuis, ETH Z¨ urich 27 / 29

1000 2000 3000 4000 false positives 200 400 600 800 1000 true positives

ROC curve

Marloes Maathuis, ETH Z¨ urich 27 / 29

1000 2000 3000 4000 false positives 200 400 600 800 1000 true positives

Consider top q = 1000 effects TP FP Random guessing 100 900

ROC curve

Marloes Maathuis, ETH Z¨ urich 27 / 29

1000 2000 3000 4000 false positives 200 400 600 800 1000 true positives

Consider top q = 1000 effects TP FP Random guessing 100 900 Lasso / E-net 130 870

ROC curve

Marloes Maathuis, ETH Z¨ urich 27 / 29

1000 2000 3000 4000 false positives 200 400 600 800 1000 true positives

Consider top q = 1000 effects TP FP Random guessing 100 900 Lasso / E-net 130 870 IDA 425 575

Summary

Marloes Maathuis, ETH Z¨ urich 28 / 29

• Problem:
• Learning perturbation effects without doing perturbation

experiments

Summary

Marloes Maathuis, ETH Z¨ urich 28 / 29

• Problem:
• Learning perturbation effects without doing perturbation

experiments

• Existing work:
• Estimating causal effects when DAG is known (do-calculus)
• Estimating equivalence class of DAGs (PC-algorithm)

Summary

Marloes Maathuis, ETH Z¨ urich 28 / 29

• Problem:
• Learning perturbation effects without doing perturbation

experiments

• Existing work:
• Estimating causal effects when DAG is known (do-calculus)
• Estimating equivalence class of DAGs (PC-algorithm)
• New contributions:
• Put these two pieces together to estimate sets of possible

perturbation effects (Θ)

• Fast local method that correctly finds the distinct values of Θ
• Consistency in sparse high-dimensional settings
• Validation of the method on yeast data
• New computational tool for the design of experiments

Summary

Marloes Maathuis, ETH Z¨ urich 28 / 29

• Problem:
• Learning perturbation effects without doing perturbation

experiments

• Existing work:
• Estimating causal effects when DAG is known (do-calculus)
• Estimating equivalence class of DAGs (PC-algorithm)
• New contributions:
• Put these two pieces together to estimate sets of possible

perturbation effects (Θ)

• Fast local method that correctly finds the distinct values of Θ
• Consistency in sparse high-dimensional settings
• Validation of the method on yeast data
• New computational tool for the design of experiments
• Current work: allow for hidden variables

References

Marloes Maathuis, ETH Z¨ urich 29 / 29

• Main references:
• MAATHUIS, KALISCH AND B ¨

UHLMANN (2009).

“Estimating high-dimensional intervention effects from

• bservational data”. Annals of Statistics 37 3133-3164.
• MAATHUIS, COLOMBO, KALISCH AND B ¨

UHLMANN (2010).

”Predicting causal effects in large-scale systems from

• bservational data”. Nature Methods 7 247-248.
• R-package pcalg (available on CRAN)
• Contact info:
• http://www.stat.math.ethz.ch/∼maathuis
• maathuis@stat.math.ethz.ch

References

Marloes Maathuis, ETH Z¨ urich 29 / 29

• Main references:
• MAATHUIS, KALISCH AND B ¨

UHLMANN (2009).

“Estimating high-dimensional intervention effects from

• bservational data”. Annals of Statistics 37 3133-3164.
• MAATHUIS, COLOMBO, KALISCH AND B ¨

UHLMANN (2010).

”Predicting causal effects in large-scale systems from

• bservational data”. Nature Methods 7 247-248.
• R-package pcalg (available on CRAN)
• Contact info:
• http://www.stat.math.ethz.ch/∼maathuis
• maathuis@stat.math.ethz.ch

Thanks!
