FSC status Pavel Semenov IHEP, Protvino on behalf of the IHEP PANDA group PANDA Collboration Meeting, Goa 11-15 March 2012 Overview FSC prototype FSC digital filter (pile-up recovery) studies FSC slow control development

slide-1
SLIDE 1

FSC status

Pavel Semenov IHEP, Protvino

  • n behalf of the IHEP PANDA group

PANDA Collboration Meeting, Goa 11-15 March 2012

slide-2
SLIDE 2

Pavel Semenov, PANDA collaboration meeting, Goa

Overview

  • FSC prototype
  • FSC digital filter (pile-up recovery) studies
  • FSC slow control development
  • Possible preassembly in Julich
slide-3
SLIDE 3

Pavel Semenov, PANDA collaboration meeting, Goa

New shashlyk prototype status

  • The first version of the mold was ready by the end of

January, but after some tests the manufacturer decided to rebuild one part

  • New mold should be assembled and checked in 2 weeks
  • New die to produce lead plates – also in 2 weeks
  • Modified HV base (type B) is developed and tested – non-

linearity of a few percent with 100 mA output

  • All the materials to produce 4-5 modules of FSC (lead,

polystyrene and dopants, Y11 optical fiber) are available

  • The plan to produce prototype modules in April-May.
slide-4
SLIDE 4

Pavel Semenov, PANDA collaboration meeting, Goa

Mold engineering drawings

slide-5
SLIDE 5

Pavel Semenov, PANDA collaboration meeting, Goa

Fiber bending station

slide-6
SLIDE 6

Pavel Semenov, PANDA collaboration meeting, Goa

Pile-up recovery studies for FSC

  • FSC signal is shorter in comparison with target EMC EC
  • Deconvolution algorithm is different
  • First simulation showed the possibility of pile-up

recovery within a range of up to 30 ns Simulated overlaped signals from FSC and simulation results of digital pile-up recovery

slide-7
SLIDE 7

Pavel Semenov, PANDA collaboration meeting, Goa

Slow control node for FSC

  • First version based on uC STM32F2xx is ready
  • Functionality includes HV control (Cocroft-Walton type

bases) and 1-wire protocol to read temperature sensors

  • Iterface: Modbus on RS485, CAN bus available, but

currently not implemented

  • Compatibility with slow control system developed in

Bohum should be discussed

slide-8
SLIDE 8

Pavel Semenov, PANDA collaboration meeting, Goa

Possible preassembly at Julich

  • Prototype after tests at Mainz (may be used in 2014, first

half of 2015)

  • Full readout chain including PMT and HV base, cable and

ADC
