Polymer Engineering Polymer Engineering (MM3POE) (MM3POE) - PowerPoint PPT Presentation

Polymer Engineering Polymer Engineering (MM3POE) (MM3POE) INJECTION MOULDING INJECTION MOULDING http://www.nottingham.ac.uk/~eazacl/MM3POE Injection Moulding 1 Contents Contents Principles of injection moulding Reciprocating


  1. Polymer Engineering Polymer Engineering (MM3POE) (MM3POE) INJECTION MOULDING INJECTION MOULDING http://www.nottingham.ac.uk/~eazacl/MM3POE Injection Moulding 1

  2. Contents Contents � Principles of injection moulding � Reciprocating screw machine Moulding sequence Machine features � Injection mould design � Mould filling calculations Filling pressures Clamping forces Filling times � Component design for injection moulding Injection Moulding 2

  3. 1. Introduction 1. Introduction Principles of Injection Moulding: Melting : Thermoplastic material (granules/pellets) heated to melt polymer Melt Transport & Shaping : Polymer melt is forced through a nozzle into a closed mould Stabilisation : Component cools in relatively “cold” mould prior to ejection Main Advantages: � Automation & high production rates � Manufacture of parts with close tolerances � Versatility in moulding wide range of products eg. appliance housings,washing up bowls, gearwheels, fascia panels, crash helmets, air intake manifolds Injection Moulding 3

  4. 1. Introduction 1. Introduction Plunger Type Machines Fig. 4.30 Plunger type injection moulding machine R J Crawford (1998) Plastics Engineering, Butterworth-Heinemann. Injection Moulding 4

  5. 1. Introduction 1. Introduction Plunger Type Machines Fig. 7.3 Injection moulding machine with screw preplasticator unit N G McCrum et al (1997) Principles of Polymer Engineering, Oxford Science Publications. Injection Moulding 5

  6. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine Machine Features: Feed hopper Heater bands CLAMPING UNIT DRIVE Screw/plunger Back flow Nozzle check valve Injection Moulding 6

  7. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine (a) Mould closes & screw (not rotating) injects melt into mould. Injection Moulding 7

  8. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine (b) Screw maintains pressure until material sets at the gate. Injection Moulding 8

  9. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine (c) Screw (rotating) draws material from hopper & plasticises it. Back pressure forces screw back until shot volume reached. Injection Moulding 9

  10. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine (d) When moulding has set, mould opens & part is ejected. Animation from: www.bpf.co.uk Injection Moulding 10

  11. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine Hopper Hopper Screw & ram Screw & ram Tool Tool Injection moulder with nanocomposite tensile specimens (inset) Injection moulder with nanocomposite tensile specimens (inset) Injection Moulding 11

  12. 2. Reciprocating Screw Machine 2. Reciprocating Screw Machine Screws : Similar to extruder screws Screws � Length/Diameter ratios 15 15- -25 25 � Compression ratios 2.5 2.5- -4.0 : 1 4.0 : 1 � Injection pressure up to 200 200 MPa MPa Injection Moulding 12

  13. 3. Injection Mould Design 3. Injection Mould Design backing plates backing plates locating locating ring ring sprue bush sprue bush guide pin guide pin Injection Moulding 13

  14. 3. Injection Mould Design 3. Injection Mould Design ejector ejector pin pin shoulder shoulder screw screw Injection Moulding 14

  15. 3. Injection Mould Design 3. Injection Mould Design vent vent channel channel sprue sprue cooling cooling channels channels runner runner cavity cavity Injection Moulding 15

  16. 3. Injection Mould Design 3. Injection Mould Design Fig. 7.31 Feed system of multi-impression mould N G McCrum et al (1997) Principles of Polymer Engineering, Oxford Science Publications. Injection Moulding 16

  17. 3. Injection Mould Design 3. Injection Mould Design Aalborg Universitet, Denmark Injection Moulding 17 http://www.aaue.dk/bm/mfg/

  18. 3. Injection Mould Design 3. Injection Mould Design Gate : Narrow constriction at entrance to cavity Gate cavity (impression). Incorrect gating can lead to problems during flow: Injection Moulding 18

  19. 3. Injection Mould Design 3. Injection Mould Design Gate : Narrow constriction at entrance to cavity Gate cavity (impression). Incorrect gating can lead to problems during flow: Injection Moulding 19

  20. 3. Injection Mould Design 3. Injection Mould Design Typical process conditions: Typical process conditions: � Process is non-isothermal as mould & barrel are at different temperatures: Table 1: Injection moulding conditions for thermoplastics (after Elias) T G / o C T M / o C T poly / o C T mould / o C Polymer Amorphous polymers PC 150 - 280 - 320 85 - 120 SAN 120 - 200 - 260 30 - 85 ABS 100 - 200 - 280 40 - 80 PS 100 - 170 - 280 5 - 70 PMMA 105 - 150 - 200 50 - 90 uPVC 82 - 180 - 210 20 - 60 Semi-crystalline polymers PET 70 265 270 - 280 120 - 140 PTFE 40 220 220 - 280 80 - 130 PA 6 50 215 230 - 290 40 - 60 POM -82 181 180 - 230 60 - 120 PP -15 176 200 - 300 20 - 60 HDPE -80 135 240 - 300 20 - 60 LDPE -80 115 180 - 260 20 - 60 Injection Moulding 20

  21. 5. Mould Filling Calculations 5. Mould Filling Calculations � Require expressions to calculate maximum injection pressure to fill a part injection pressure To design/select injection system To determine clamping force � In practice moulding operation can be complex:   Non-isothermal & non-Newtonian - hence η = f (T, ) Flow within sprue, runners, gate & mould cavity Injection sequence can be relatively complex � Can obtain reasonable approximation from: Isothermal analysis Mould cavity only Constant flow rate Injection Moulding 21

  22. 5.1 Filling Pressures 5.1 Filling Pressures Injection pressure ( P min ) for given flow rate ( Q ) can be determined from non-Newtonian flow expressions (see Melt Rheology & Processing Melt Rheology & Processing notes). Rectangular cavity (depth h): L T Gate 0 P min n   L (2n + 1).2Q   P = pressure drop P 2 C .   min   2 h nTh  12 LQ  (Newtonian, ie. n=1) a 3 Th Injection Moulding 22

  23. 5.1 Filling Pressures 5.1 Filling Pressures Injection pressure ( P min ) for given flow rate ( Q ) can be determined from non-Newtonian flow expressions (see Melt Rheology & Processing Melt Rheology & Processing notes). Rectangular cavity (depth h): L Min. pressure usually not sufficient T Gate Apply additional pressure to: 0 P min � Compact material n   L (2n + 1).2Q   P = pressure drop P 2 C .   � Counteract shrinkage min   2 h nTh  12 LQ Hold Hold- -on on pressure of up to 2 x P min  (Newtonian, ie. n=1) a 3 Th Injection Moulding 23

  24. 5.2 Clamping Forces 5.2 Clamping Forces Rectangular cavity: L T Gate dx x P X P G Force required to clamp element of mould dx: δ F = P x δ A = P x T dx Total clamping force: L x   F = T dx P = - P P P x x G L 0 Injection Moulding 24

  25. 5.2 Clamping Forces 5.2 Clamping Forces Rectangular cavity: L Assuming linear linear pressure T Gate distribution: x  = - P P P x G dx L x P X P G Therefore:      L x L P   F = T - P dx   = T L -  P  P G G     L 2 0    P   = TL - P G   2 Clamping force Clamping force = = Projected area Projected area x x Mean pressure Mean pressure Injection Moulding 25

  26. 5.3 Mould Filling Times 5.3 Mould Filling Times The time to fill a mould is simply: total volume = t f volume flow rate eg. for a rectangular mould cavity: L TLh = t f T Gate Q 0 P min Injection Moulding 26

  27. 5. Mould Filling Calculations 5. Mould Filling Calculations Worked Example - Injection Mould Filling Calculate the minumum gate pressure required to fill a rectangular plaque cavity, 150mm x 25mm x 3mm, with Acrylic resin in one second, assuming the following conditions: (a) Newtonian flow with apparent viscosity η a = 1000 Ns/m 2 or (b) Non-Newtonian flow using Acrylic flow data. If the gate pressure is 1.5 X this minimum, estimate the mould clamping force required for a double impression mould. Page 11 Injection Moulding 27

  28. 5. Mould Filling Calculations 5. Mould Filling Calculations n = 0.254 n = 0.254 1 s -1 1 s -1 C = 5.395 x 10 4 C = 5.395 x 10 4 10 s -1 10 s -1 40 s -1 40 s -1 50 s -1 50 s -1 10 2 s -1 10 2 s -1 10 3 s -1 10 3 s -1 n = 0.566 n = 0.566 C = 9.333 x 10 3 C = 9.333 x 10 3 Page 13 Injection Moulding 28

  29. 5. Mould Filling Calculations 5. Mould Filling Calculations Exercise sheet 4, Qu. 1 – Fig. Q1 Injection Moulding 29
