Planning a Software Project

Jalote - Project Planning 2

Agenda

❚ Background ❚ Process planning ❚ Effort estimation ❚ Schedule and resource estimation ❚ Quality Planning ❚ Risk management ❚ Configuration Management ❚ Project monitoring plans

Jalote - Project Planning 3

Software Project

❚ Goal: Build a software system to meet commitments on cost, schedule, quality ❚ Worldwide - many projects fail

❙ one-third are runaways with cost or schedule

• verrun of more than 125%

Jalote - Project Planning 4

Project Failures

❚ Major reasons for project runaways

❙ unclear objectives ❙ bad planning ❙ no project management methodology ❙ new technology ❙ insufficient staff

❚ All of these relate to project management ❚ Effective project management is key to successfully executing a project

Jalote - Project Planning 5

Why improve PM?

❚ Better predictability leading to commitments that can be met ❚ Lower cost through reduced rework, better resource mgmt, better planning,.. ❚ Improved quality through proper quality planning and control ❚ Better control through change control, CM, monitoring etc.

Jalote - Project Planning 6

Why improve PM ….

❚ Better visibility into project health and state leading to timely intervention ❚ Better handling of risks reducing the chances of failure ❚ All this leads to higher customer satisfaction ❚ And self and organization improvement

Jalote - Project Planning 7

Two Dimensions in project execution

Jalote - Project Planning 8

Process-based Project Execution

❚ Small project both engg and PM can be done informally ❚ Large projects require formality ❚ Formality: well defined processes used for each task; measurements used to control ❚ Here we focus on processes for PM only

Jalote - Project Planning 9

The Project Mgmt Process

❚ Has three phases - planning, monitoring and control, and closure ❚ Planning is done before the main engineering LC and closure after the LC ❚ Monitoring phase is in parallel with LC

Jalote - Project Planning 10

Project Planning

❚ Basic objective: To create a plan to meet the commitments of the project, I.e. create a path that, if followed, will lead to a successful project ❚ Planning involves defining the LC process to be followed, estimates, detailed schedule, plan for quality, etc. ❚ Main output - a project management plan and the project schedule

Jalote - Project Planning 11

Key Planning Tasks

❚ Define suitable processes for executing the project ❚ Estimate effort ❚ Define project milestones and create a schedule ❚ Define quality objectives and a quality plan ❚ Identify risks and make plans to mitigate them ❚ Define measurement plan, project-tracking procedures, training plan, team organization, etc.

Jalote - Project Planning 12

Process Planning

❚ Plan how the project will be executed, I.e. the process to be followed ❚ Process will decide the tasks, their

• rdering, milestones

❚ Hence process planning is an important project planning task ❚ Should plan for LC and PM processes as well as supporting processes

Jalote - Project Planning 13

Life Cycle Process

❚ Various LC models - waterfall, iterative, prototyping; diff models suit different projects ❚ During planning can select the model that is best for the project ❚ This gives the overall process which has to be fine-tuned to suit the project needs ❚ Usually done by process tailoring - changing the process to suit the project ❚ Tailoring finally results in adding, deleting, modifying some process steps

Effort Estimation

Jalote - Project Planning 15

Effort Estimation

❚ For a project total cost and duration has to be committed in start ❚ Requires effort estimation, often in terms

• f person-months

❚ Effort estimate is key to planning - schedule, cost, resources depend on it ❚ Many problems in project execution stem from improper estimation

Jalote - Project Planning 16

Estimation..

❚ No easy way, no silver bullet ❚ Estimation accuracy can improve with more information about the project ❚ Early estimates are more likely to be inaccurate than later

❙ More uncertainties in the start ❙ With more info, estimation becomes easier

Jalote - Project Planning 17

Estimation accuracy

Jalote - Project Planning 18

Effort Estimation Models..

❚ A model tries to determine the effort estimate from some parameter values ❚ A model also requires input about the project, and cannot work in vacuum ❚ So to apply a model, we should be able to extract properties about the system ❚ Two types of models - top-down and bottom-up

Jalote - Project Planning 19

Effort Estimation Models

Extract Estimation Model Values of some characteristics Effort Estimate Knowledge about SW project

Jalote - Project Planning 20

Top-down Estimation

❚ First determines the total effort, then effort for components ❚ Usually works with overall size ❚ One method is to see estimate as a function of effort; the common function used is Effort = a * size b ❚ E is in person-months, size in KLOC ❚ Constants a and b determined through regression analysis of past project data

Jalote - Project Planning 21

Top down estimation

❚ Can also estimate from size and productivity

❙ Get the estimate of the total size of the software ❙ Estimate project productivity using past data and project characteristics ❙ Obtain the overall effort estimate from productivity and size estimates

❚ Effort distribution data from similar project are used to estimate effort for different phases

Jalote - Project Planning 22

Bottom-up Estimation

❚ Effort for components and phases first estimated, then the total ❚ Can use activity based costing - all activities enumerated and then each activity estimated separately ❚ Can group activities into classes - their effort estimate from past data

Jalote - Project Planning 23

An Estimation Procedure

❚ Identify programs in the system and classify them as simple, medium, or complex (S/M/C) ❚ Define the average coding effort for S/M/C ❚ Get the total coding effort. ❚ Use the effort distribution in similar projects to estimate effort for other tasks and total ❚ Refine the estimates based on project specific factors

Jalote - Project Planning 24

COCOMO Model for Estimation

❚ Is a top-down approach ❚ Uses size, but adjusts using some factors ❚ Basic procedure

❙ Obtain initial estimate using size ❙ Determine a set of 15 multiplying factors from different project attributes ❙ Adjust the effort estimate by scaling it with the final multiplying factor

Jalote - Project Planning 25

COCOMO..

❚ Initial estimate: a * size b ; some standard values for a, b given for diff project types ❚ There are 15 cost driver attributes line reliability, complexity, application experience, capability, … ❚ Each factor is rated, and for the rating a multiplication factor is given ❚ Final effort adjustment factor is the product of the factors for all 15 attributes

Jalote - Project Planning 26

COCOMO – Some cost drivers

Cost Driver Very low Low Nominal High Very High Required reliability Database size Product complexity Execution time constraint Memory constraint Analyst capability Application experience Programmer capability Use of software tools Development schedule .75 .7 1.46 1.29 1.42 1.24 1.23 .88 .94 .85 1.19 1.13 1.17 1.10 1.08 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.15 1.08 1.15 1.11 1.06 .86 .91 .86 .91 1.04 1.4 1.16 1.3 1.3 1.21 .71 .82 .70 .83 1.1

Jalote - Project Planning 27

COCOMO – effort distribution

❚ Effort distribution among different phases is given as a percent of effort ❚ Eg. For medium size product it is

❙ Product design – 16% ❙ Detailed design – 24% ❙ Coding and UT – 38% ❙ Integration and test – 22%

Scheduling and Staffing

Jalote - Project Planning 29

Project Schedule

❚ A project Schedule is at two levels -

• verall schedule and detailed schedule

❚ Overall schedule comprises of major milestones and final date ❚ Detailed schedule is the assignment of lowest level tasks to resources

Jalote - Project Planning 30

Overall Schedule

❚ Depends heavily on the effort estimate ❚ For an effort estimate, some flexibility exists depending on resources assigned ❚ Eg a 56 PM project can be done in 8 months (7 people) or 7 months (8 people) ❚ Stretching a schedule is easy; compressing is hard and expensive

Jalote - Project Planning 31

Overall Scheduling...

❚ One method is to estimate schedule S (in months) as a function of effort in PMs ❚ Can determine the fn through analysis of past data; the function is non linear ❚ COCOMO: S = 2.5 E 3.8 ❚ Often this schedule is checked and corrected for the specific project ❚ One checking method – square root check

Jalote - Project Planning 32

Determining Overall Schedule from past data

Effort in person-days 50 100 150 200 250 300 350 400 200 400 600 800 1000 1200 1400 1600 1800

Schedule (Days)

Jalote - Project Planning 33

Determining Milestones

❚ With effort and overall schedule decided, avg project resources are fixed ❚ Manpower ramp-up in a project decides the milestones ❚ Manpower ramp-up in a project follows a Rayleigh curve - like a normal curve ❚ In reality manpower build-up is a step function

Jalote - Project Planning 34

Manpower Ramp-up

Design Build Test PTS

Jalote - Project Planning 35

Milestones ...

❚ With manpower ramp-up and effort distribution, milestones can be decided ❚ Effort distribution and schedule distribution in phases are different ❚ Generally, the build has larger effort but not correspondingly large schedule ❚ COCOMO specifies distr of overall sched. Design – 19%, programming – 62%, integration – 18%

Jalote - Project Planning 36

An Example Schedule

# Task Dur.

(days)

Work (p-

days)

Start Date End Date 2 Project Init tasks 33 24 5/4 6/23 74 Training 95 49 5/8 9/29 104 Knowledge sharing 78 20 6/2 9/30 114 Elaboration iteration I 55 55 5/15 6/23 198 Construction iteration I 9 35 7/10 7/21

Jalote - Project Planning 37

Detailed Scheduling

❚ To reach a milestone, many tasks have to be performed ❚ Lowest level tasks - those that can be done by a person (in less than 2-3 days) ❚ Scheduling - decide the tasks, assign them while preserving high-level schedule ❚ Is an iterative task - if cannot “fit” all tasks, must revisit high level schedule

Jalote - Project Planning 38

Detailed Scheduling

❚ Detailed schedule not done completely in the start - it evolves ❚ Can use MS Project for keeping it ❚ Detailed Schedule is the most live document for managing the project ❚ Any activity to be done must get reflected in the detailed schedule

Jalote - Project Planning 39

An example task in detail schedule

Module Act Code Task Duration Effort History PUT Unit test # 17 1 day 7 hrs

• St. date

End date %comp Depend. Resource 7/18 7/18 0% Nil SB

Jalote - Project Planning 40

Detail schedule

❚ Each task has name, date, duration, resource etc assigned ❚ % done is for tracking (tools use it) ❚ The detailed schedule has to be consistent with milestones

❙ Tasks are sub-activities of milestone level activities, so effort should add up, total schedule should be preserved

Jalote - Project Planning 41

Team Structure

❚ To assign tasks in detailed schedule, need to have a clear team structure ❚ Hierarchic team org is most common

❙ Project manager has overall responsibility; also does design etc. ❙ Has programmers and testers for executing detailed tasks ❙ May have config controller, db manager, etc

Jalote - Project Planning 42

Team structure..

❚ An alternative – democratic teams

❙ Can work for small teams; leadership rotates

❚ Another one used for products

❙ A dev team led by a dev mgr, a test team led by test mgr, and a prog. Mgmt team ❙ All three report to a product mgr ❙ Allows specialization of tasks and separate career ladders for devs, tests, PMs

Jalote - Project Planning 43

SCM process and planning

❚ Have discussed SCM process earlier ❚ During planning, the SCM activities are planned along with who will perform them ❚ Have discussed planning also earlier

❙ Includes defining CM items, naming scheme, directory structure, access restrictions, change control, versioning, release procedure etc

Quality Planning

Jalote - Project Planning 45

Quality Planning

❚ Delivering high quality is a basic goal ❚ Quality can be defined in many ways ❚ Current industry standard - delivered defect density (e.g. #defects/KLOC) ❚ Defect - something that causes software to behave in an inconsistent manner ❚ Aim of a project - deliver software with low delivered defect density

Jalote - Project Planning 46

Defect Injection and Removal

❚ Software development is labor intensive ❚ Defects are injected at any stage ❚ As quality goal is low delivered defect density, these defects have to be removed ❚ Done primarily by quality control (QC) activities of reviews and testing

Jalote - Project Planning 47

Defect Injection and Removal

Req. Analysis Design R Coding R UT IT/ST AT Development Process Defect Injection R Defect Removal

Jalote - Project Planning 48

Approaches to Quality Management

❚ Ad hoc - some testing, some reviews done as and when needed ❚ Procedural - defined procedures are followed in a project ❚ Quantitative - defect data analysis done to manage the quality process

Jalote - Project Planning 49

Procedural Approach

❚ A quality plan defines what QC tasks will be undertaken and when ❚ Main QC tasks - reviews and testing ❚ Guidelines and procedures for reviews and testing are provided ❚ During project execution, adherence to the plan and procedures ensured

Jalote - Project Planning 50

Quantitative Approach

❚ Goes beyond asking “has the procedure been executed” ❚ Analyzes defect data to make judgements about quality ❚ Past data is very important ❚ Key parameters - defect injection and removal rates, defect removal efficiency (DRE)

Jalote - Project Planning 51

Quality Plan

❚ The quality plan drives the quality activities in the project ❚ Level of plan depends on models available ❚ Must define QC tasks that have to be performed in the project ❚ Can specify defect levels for each QC tasks (if models and data available)

Risk Management

Jalote - Project Planning 53

Risk Management

❚ Any project can fail - reasons can be technical, managerial, etc. ❚ Project management aims to tackle the project management aspect ❚ Engineering life cycles aim to tackle the engineering issues ❚ A project may fail due to unforeseen events - risk management aims to tackle this

Jalote - Project Planning 54

Risk Management

❚ Risk: any condition or event whose

• ccurrence is not certain but which can

cause the project to fail ❚ Aim of risk management: minimize the effect of risks on a project

Jalote - Project Planning 55

Risk Management Tasks

RISK MANAGEMENT RISK ASSESSMENT RISK IDENTIFICATION RISK ANALYSIS RISK PRIORITIZATION RISK MANAGEMENT PLANNING RISK RESOLUTION RISK MONITORING RISK CONTROL

Jalote - Project Planning 56

Risk Identification

❚ To identify possible risks to a project, i.e. to those events that might occur and which might cause the project to fail ❚ No “algorithm” possible, done by “what ifs”, checklists, past experience ❚ Can have a list of “top 10” risks that projects have seen in past

Jalote - Project Planning 57

Top Risk Examples

❚ Shortage of technically trained manpower ❚ Too many requirement changes ❚ Unclear requirements ❚ Not meeting performance requirements ❚ Unrealistic schedules ❚ Insufficient business knowledge ❚ Working on new technology

Jalote - Project Planning 58

Risk Prioritization

❚ The number of risks might be large ❚ Must prioritize them to focus attention on the “high risk” areas ❚ For prioritization, impact of each risk must be understood ❚ In addition, probability of the risk occurring should also be understood

Jalote - Project Planning 59

Risk Prioritization ...

❚ Risk exposure (RE) = probability of risk

• ccurring * risk impact

❚ RE is the expected value of loss for a risk ❚ Prioritization can be done based on risk exposure value ❚ Plans can be made to handle high RE risks

Jalote - Project Planning 60

A Simple approach to Risk Prioritization

❚ Classify risk occurrence probabilities as: Low, Medium, High ❚ Classify risk impact as: Low, Medium, High ❚ Identify those that are HH, or HM/MH ❚ Focus on these for risk mitigation ❚ Will work for most small and medium sized projects

Jalote - Project Planning 61

Risk Control

❚ Can the risk be avoided?

❙ E.g. if new hardware is a risk, it can be avoided by working with proven hardware

❚ For others, risk mitigation steps need to be planned and executed

❙ Actions taken in the project such that if the risk materializes, its impact is minimal ❙ Involves extra cost

Jalote - Project Planning 62

Risk Mitigation Examples

❚ Too many requirement changes

❙ Convince client that changes in requirements will have an impact on the schedule ❙ Define a procedure for requirement changes ❙ Maintain cumulative impact of changes and make it visible to client ❙ Negotiate payment on actual effort.

Jalote - Project Planning 63

Examples ...

❚ Manpower attrition

❙ Ensure that multiple resources are assigned

• n key project areas

❙ Have team building sessions ❙ Rotate jobs among team members ❙ Keep backup resources in the project ❙ Maintain documentation of individual’s work ❙ Follow the CM process and guidelines strictly

Jalote - Project Planning 64

Examples ...

❚ Unrealistic schedules

❙ Negotiate for better schedule ❙ Identify parallel tasks ❙ Have resources ready early ❙ Identify areas that can be automated ❙ If the critical path is not within the schedule, negotiate with the client ❙ Negotiate payment on actual effort

Jalote - Project Planning 65

Risk Mitigation Plan

❚ Risk mitigation involves steps that are to be performed (hence has extra cost) ❚ It is not a paper plan - these steps should be scheduled and executed ❚ These are different from the steps one would take if the risk materializes - they are performed only if needed ❚ Risks must be revisited periodically

Project Monitoring Plans

Jalote - Project Planning 67

Background

❚ A plan is a mere document that can guide ❚ It must be executed ❚ To ensure execution goes as per plan, it must be monitored and controlled ❚ Monitoring requires measurements ❚ And methods for interpreting them ❚ Monitoring plan has to plan for all the tasks related to monitoring

Jalote - Project Planning 68

Measurements

❚ Must plan for measurements in a project ❚ Without planning, measurements will not be done ❚ Main measurements – effort, size, schedule, and defects

❙ Effort – as this is the main resource; often tracked through effort reporting tools ❙ Defects – as they determine quality; often defect logging and tracking systems used

❚ During planning – what will be measured, how, tool support, and data management

Jalote - Project Planning 69

Project Tracking

❚ Goal: To get visibility in project execution so corrective actions can be taken when needed to ensure project succeeds ❚ Diff types of monitoring done at projects; measurements provide data for it

Jalote - Project Planning 70

Tracking…

❚ Activity-level monitoring

❙ Each activity in detailed schd is getting done ❙ Often done daily by managers ❙ A task done marked 100%; tools can determine status of higher level tasks

❚ Status reports

❙ Generally done weekly to take stock ❙ Summary of activities completed, pending ❙ Issues to be resolved

Jalote - Project Planning 71

Tracking…

❚ Milestone analysis

❙ A bigger review at milestones ❙ Actual vs estimated for effort and sched is done ❙ Risks are revisited ❙ Changes to product and their impact may be analyzed

❚ Cost-schedule milestone graph is another way of doing this

Jalote - Project Planning 72

Cost-schedule milestone graph

Jalote - Project Planning 73

Project Management Plan

❚ The project management plan (PMP) contains outcome of all planning activities - focuses on overall project management ❚ Besides PMP, a project schedule is needed

❙ Reflects what activities get done in the project ❙ Microsoft project (MSP) can be used for this ❙ Based on project planning; is essential for day-to- day management ❙ Does not replace PMP !

Jalote - Project Planning 74

PMP Structure - Example

❚ Project overview - customer, start and end date, overall effort, overall value, main contact persons, project milestones, development environment.. ❚ Project planning - process and tailoring, requirements change mgmt, effort estimation, quality goals and plan, risk management plan, ..

Jalote - Project Planning 75

PMP Example ...

❚ Project tracking - data collection, analysis frequency, escalation procedures, status reporting, customer complaints, … ❚ Project team, its organization, roles and responsibility, …

Jalote - Project Planning 76

Project Planning - Summary

❚ Project planning forms the foundation of project management ❚ Key aspects: effort and schedule estimation, quality planning, risk mgmt., … ❚ Outputs of all can be documented in a PMP, which carries all relevant info about project ❚ Besides PMP, a detailed project schedule maintains tasks to be done in the project
