Bachelor Project RIOT in the Internet of Things Cenk Gndogan, Peter Kietzmann, Thomas C. Schmidt iNET AG, Dept. Informatik HAW Hamburg TODAY (1) RIOT Introduction (2) Setup Work Environment (3) Project Introduction (4) Recent and
SLIDE 2
SLIDE 3
www.riot-os.org 3
AGENDA
- Internet of Things: Which OS?
- RIOT in a nutshell
- RIOT user and developer evolution
- Roadmap
SLIDE 4
www.riot-os.org 4
The Internet of Things (IoT)
1-2 GB > 4GB ~ 2 GB 16 KB 96 KB 8 KB > 4GB 512 MB IoT = programmable world
SLIDE 5
5
IoT: The operating system question
IoT = programmable world
www.riot-os.org
SLIDE 6
www.riot-os.org 6
RIOT: The friendly IoT operating system
IoT = programmable world
SLIDE 7
www.riot-os.org 7
AGENDA
- Internet of Things: Which OS?
- RIOT in a nutshell
- RIOT user and developer evolution
- Roadmap
SLIDE 8
8
"If your IoT device cannot run Linux, then run RIOT!"
- RIOT requires only a few kB of RAM/ROM, and small CPU
- With RIOT, code once & run heterogeneous IoT hardware
– 8bit hardware (e.g. AVR) – 16bit hardware (e.g. MSP430) – 32bit hardware (e.g. ARM Cortex-M)
RIOT: Positioning
SLIDE 9
www.riot-os.org 9
RIOT: Fact sheet
- µ-kernel-like architecture(for robustness)
- Modular design (for adaptivity)
- Tickless scheduler (for energy efficiency)
- Deterministic O(1) scheduling (for real-time)
- Low latency interrupt handling (for reactivity)
- Preemptive multi-threading & powerful IPC
- Efficient hardware abstraction
- Full featured, extendable network-stacks
SLIDE 10
www.riot-os.org 10
RIOT: IoT development made easy
- Open source, community-driven
- Write your code in ANSI-C or C++
- Compliant to the most widely used POSIX
features such as pthreads and sockets
- No IoT hardware needed for debugging
– Run & debug RIOT as native process in Linux
SLIDE 11
www.riot-os.org 11
RIOT: Built to connect
- RIOT supports several network stacks
- Open-access protocol specs by the IETF/IRTF
- e.g. 6LoWPAN, IPv6, CoAP
SLIDE 12
12
RIOT already runs on a wide range of IoT hardware
www.riot-os.org
Support for > 70 boards, various CPUs, different architectures, radios, sensors, …
SLIDE 13
Minimized Hardware-Dependent Code
Zoom on Board & CPU
Red: must have Green: must have but shared by all ports with same architecture Grey: optional for initial porting
SLIDE 14
www.riot-os.org 16
AGENDA
- Internet of Things : Which OS?
- RIOT in a nutshell
- RIOT user and developer evolution
- Roadmap
SLIDE 15
www.riot-os.org 17
RIOT Origins
History
- 2008 – Project roots:
The kernel was started as part of a research project
- 2010 – Towards the IoT:
Implementation of 6LoWPAN and RPL was initiated
- 2013 – RIOT goes public:
Branding of RIOT started, source code moved to Github Founding institutions
SLIDE 16
RIOT stats
194 contributors, 90 active in last 12 months from industry, academia and makers scene- Estimated cost: $8.5M, 154 person-years [1]
[1] source: www.openhub.net/p/RIOT-OS estimate using the basic COCOMO Model
SLIDE 17
20
Join the RIOT
- World-wide, open source community
- ~ 730 forks on GitHub
https://github.com/RIOT-OS/RIOT
- Hundreds on the developer mailing list: devel@riot-os.org
- Developers from Asia, Europe, North America, South America
- Support & discussions on IRC:
irc.freenode.org #riot-os
www.riot-os.org
SLIDE 18
Some Active Supporters
21
SLIDE 19
Embedded World 2015, 2016, 2017
22
SLIDE 20
www.riot-os.org 24
AGENDA
- Internet of Things: Which OS?
- RIOT in a nutshell
- RIOT user and developer evolution
- Roadmap
SLIDE 21
26
Roadmap 2017
- Network stack developments
– Optimization, BLE support, new ICN features ... – Application layer protocols (MQTT, Rest, …)
- Deployment tools
– Over-the-air application updates, over-the-air OS update...
- More development tools
– Advanced test-framework, including distributed testing – Distributed application framework
- Cloud interface and integration
www.riot-os.org
