Table of Content
TCP and MTU Bandwidth Test Scenario NDT – Bandwidth Test Performance Monitoring service Demo
SLIDE 4
TCP and MTU
“Symptom Hiding” “Symptom Scaling “
SLIDE 5
TCP and MTU
Request Reply
Internet Gateway 0 - 60 ms > 60 ms
Good Speed
Request Request Reply Reply
Slow Speed
SLIDE 6
TCP and MTU
MTU = MSS + IPHL + TCPHL
MSS – Maximum segment size MTU – Maximum transmission unit IPHL – IP header length TCPHL – TCP header length
IPHL + TCPHL = 40 + OP (options) bytes
SLIDE 7
Table of Content
TCP and MTU Bandwidth Test Scenario NDT – Bandwidth Test Performance Monitoring service Demo
SLIDE 8
Bandwidth Vs MTU (No Latency)
Bandwidth (Mbits/s) Time (s) MTU (Bytes)
SLIDE 9
Bandwidth Vs MTU (Latency)
Bandwidth (Mbits/s) Time (s) MTU (Bytes)
SLIDE 10
Table of Content
TCP and MTU Bandwidth Test Scenario NDT – Bandwidth Test Performance Monitoring service Demo
SLIDE 11
NDT - Bandwidth Test
Measure performance directly to user desktop Identify both performance and configuration problems Memory to memory client server test
Ignoring disk I/O effects kernel data automatically collected by the web100 monitoring infrastructure
Source: https://code.google.com/p/ndt/
SLIDE 12
NDT - Tests performed
Middlebox Test
Check duplex mismatch condition Checks if any intermediate node is modifying the connection settings
Firewall Test
Bidirectional test Find out firewall between server and client
SLIDE 13
NDT - Tests performed
Client to Server Throughput Test Server to Client Throughput Test
10 seconds memory-to-memory data transfer libpcap routine to perform packet trace used by the Bottleneck Link Detection algorithm. tcpdump trace to save to a standard tcpdump file all packets sent during the test on the newly created connection. web100 snaplog trace to dump web100 kernel MIB variables' values written in a fixed time interval (default is 5 msec) during the test for the newly created connection.
SLIDE 14
NDT – Detection Algos
Bottleneck Link Detection
Uses the inter-packet delay and the size of the packet as a metric to gauge what the narrowest link in the path is Calculates the inter-packet throughput by dividing the packet's size, in bits, by the difference between the time that it arrived and the time the previous packet arrived
The bins are defined in mbits/second: 0 < inter-packet throughput (mbits/second) <= 0.01 - RTT 0.01 < inter-packet throughput (mbits/second) <= 0.064 - Dial-up Modem 0.064 < inter-packet throughput (mbits/second) <= 1.5 - Cable/DSL modem 1.5 < inter-packet throughput (mbits/second) <= 10 - 10 Mbps Ethernet or WiFi 11b subnet 10 < inter-packet throughput (mbits/second) <= 40 - 45 Mbps T3/DS3 or WiFi 11 a/g subnet 40 < inter-packet throughput (mbits/second) <= 100 - 100 Mbps Fast Ethernet subnet 100 < inter-packet throughput (mbits/second) <= 622 - a 622 Mbps OC-12 subnet 622 < inter-packet throughput (mbits/second) <= 1000 - 1.0 Gbps Gigabit Ethernet subnet 1000 < inter-packet throughput (mbits/second) <= 2400 - 2.4 Gbps OC-48 subnet 2400 < inter-packet throughput (mbits/second) <= 10000 - 10 Gbps 10 Gigabit Ethernet/OC-192 subnet bits cannot be determined - Retransmissions (this bin counts the duplicated or invalid packets and does not denote a real link type)
- therwise - ?
SLIDE 15
NDT - Detection Algos
Firewall Detection
A firewall is detected when the connection to the ephemeral port was unsuccessful in the specified time
NAT Detection
A Network Address Translation (NAT) box is detected by comparing the client/server IP addresses as seen from the server and the client boxes
MSS Modification Detection
Comparing the final value of the MSS variable in the Middlebox test.
Initial value is 1456
SLIDE 16
Table of Content
TCP and MTU Bandwidth Test Scenario NDT – Bandwidth Test Performance Monitoring service Demo
SLIDE 17
Performance Monitoring in NKN
NKN Core Service
Tests performance between servers located at different locations Tests performed on International links
Bandwidth Monitoring Service
Tests performance between NKN user client and server Java enabled Web browser
SLIDE 18
Performance Monitoring in NKN
Internet
Test Test Test Test Test Test Test Test
Delhi Hyderabad Mumbai Bangalore Chennai Kolkata Guwahati NKN User
Test Test
SLIDE 19
NKN Core Service
Core link Bandwidth testing Bandwidth testing to Overseas PoPs Traceroute service OWAMP
One way ping
SLIDE 20
Bandwidth Test : NKN Core Delhi to Bangalore
SLIDE 21
Bandwidth Test : NKN Delhi to San Deigo
SLIDE 22
Bandwidth Test : NKN Delhi to Washington, US
SLIDE 23
Bandwidth Test : NKN Delhi to Bangkok, Thailand
SLIDE 24
Bandwidth Monitoring Service
Servers located at NKN super core PoPs
Delhi - https://perfdel.nkn.in Bangalore – https://perfblr.nkn.in Hyderabad – https://perfhyd.nkn.in Chennai – https://perfchn.nkn.in Mumbai – https://perfmum.nkn.in Kolkata – https://perfkol.nkn.in Guwahati – https://perfght.nkn.in
SLIDE 25
Table of Content
TCP and MTU Bandwidth Test Scenario NDT – Bandwidth Test Performance Monitoring service Demo
SLIDE 26
Demo DEMO
SLIDE 27
GUI Snapshots
SLIDE 28
GUI Snapshots
