NKN Enabler for NII National Information Infrastructure A K Balani Sr. Director / HOD NKN, DeitY 1 Segregated Infrastructures NKN Connect Research & Educational Institutions SWAN and SDC - Access to Internet and Interstate

slide-1
SLIDE 1

NKN Enabler for NII

National Information Infrastructure A K Balani

  • Sr. Director / HOD NKN, DeitY

1

slide-2
SLIDE 2

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts
  • Multi- 10G Core Connecting all state capitals
  • Multi- 1G Links Connecting states to All Districts

Segregated Infrastructures

slide-3
SLIDE 3

SWAN

  • Connects Govt Offices till Blocks
  • Provide eGov services
  • 7500+ PoPs upto Block Level
  • Limited Bandwidth

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts

Segregated Infrastructures

slide-4
SLIDE 4

NOFN

  • Block to GP Connectivity (2.5 Lakh GPs)
  • Serve citizens at GP level
  • Laying 6 Lakh Km of OFC
  • 100 Mbps bandwidth at each GP
  • Implementation by BBNL
  • Funding from USOF - Rs. 27,800 Cr
  • State Governments to provide Free ROW
  • Revised PDC – Dec 2016

SWAN

  • Connects Govt Offices till Blocks
  • Limited Bandwidth

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts

Segregated Infrastructures

slide-5
SLIDE 5

GUN

  • District to Block Connectivity
  • Last mile connectivity from GPs
  • 10 Mbps bandwidth to each user

NOFN

  • Block to GP Connectivity (100 Mbps)
  • Serve citizens at GP level

SWAN

  • Connects Govt Offices till Blocks
  • Limited Bandwidth

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts

Segregated Infrastructures

slide-6
SLIDE 6

Segregated Infrastructures

MeghRaj

  • Cloud Enable SDCs
  • Hosting eGov applications

NOFN

  • Block to GP Connectivity (100 Mbps)
  • Serve citizens at GP level

SWAN

  • Connects Govt Offices till Blocks
  • Limited Bandwidth

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts

GUN

  • District to Block Connectivity
  • Last mile connectivity from GPs
  • 10 Mbps bandwidth to each user
slide-7
SLIDE 7

Enabling MeghRaj

  • NKN Enabler for Services
slide-8
SLIDE 8

Segregated Infrastructures

MeghRaj

  • Cloud Enable SDCs
  • Hosting eGov applications

NOFN

  • Block to GP Connectivity (100 Mbps)
  • Serve citizens at GP level

SWAN

  • Connects Govt Offices till Blocks
  • Limited Bandwidth

NKN

  • Connect Research & Educational Institutions
  • SWAN and SDC - Access to Internet and Interstate
  • Access from State to Districts

GUN

  • District to Block Connectivity
  • Last mile connectivity from GPs
  • 10 Mbps bandwidth to each user
slide-9
SLIDE 9
  • Enhancing

storage, computing through National GI Cloud (MeghRaj)

  • Enhancing bandwidth through integration of

different networks

  • Creating suitable institutional mechanism

Modality/ Strategy

0-9 months - Planning, Capacity building 6-18 months - Integration of infrastructure and Services 18-24 months Onwards - Operations and maintenance

Implementation Plan

  • Unified e-Governance infrastructure
  • Leverage NKN, NOFN, SWAN, SDC,

GI Cloud, NICNET, SSDG, MSDG, etc

Need

  • Optimize resources, cost effectiveness

due to economies of scale

  • Challenges - Fragmented Infrastructure,

Duplicate Efforts, Skilled manpower, Cyber security threats, Strategic control

Rationale/Utility

National Information Infrastructure

slide-10
SLIDE 10
  • Robust infrastructure through integration of networks and cloud
  • Public Information Infrastructure for G2G, G2B and G2C services
  • Social services such as e-education, telemedicine, Financial Inclusion
  • NII key components:

– Infrastructure: Cloud and connectivity up to village level – Services: Platform for application service providers and users

  • Integrate existing infrastructure like NOFN, NKN, SWAN, SDC, etc.
  • Enhance storage & computing through GI Cloud (MeghRaj)

Scope and Components - NII

slide-11
SLIDE 11

SWAN NKN GUN/ NOFN

Create Network Infrastructure for E-Gov in the states. To connect all the offices in the state.

Key Stakeholder: States Key Features: Creation of Network up to the block level. Funded by Centre and Bandwidth from the states

To connect 250000 Gram Panchayats (GP) in country

Key Stakeholders: BBNL, TSPs Key Features: Bridge connectivity b/w GP and blocks Not a service provider. Provide Connectivity from District to GP.

To connect 1500+ institutes in country using high bandwidth & low latency network

Key Stakeholders: Office of PSA to GoI, DeitY, NIC Key Features: Virtual Classrooms, Collaborative research, Data centric services, Grid Computing, Remote Labs, etc, 100% GoI funded , Multi 10G in the Core, Multi 1G at the District .

Network Integration in NII

slide-12
SLIDE 12

NKN Infrastructure connecting State Capitals, Districts and SWANs at Capitals

NII Implementation

slide-13
SLIDE 13

NOFN Infrastructure connecting Blocks with GPs

NII Implementation

slide-14
SLIDE 14

GUN infrastructure connecting Districts with Blocks and reaching GP over NOFN, also provisioning connectivity at GPs Integrate NKN PoP at Districts

NII Implementation

slide-15
SLIDE 15

NII Implementation

slide-16
SLIDE 16

NII Implementation

slide-17
SLIDE 17

REN SWAN NII

REN Education Research Knowledge Sharing International Collaborations SWAN Voice Data Internet Intrastate NII All Govt Offices All Govt Services

Collaboration

State India STEP 1 STEP 2 STEP 3

Expanding Role of NKN in Contribution for Citizen Enablement

NKN Contribution and Growth

slide-18
SLIDE 18

All Applications

  • n Cloud

Storage And Computing Capacity Building Integration

  • f

Networks

Rising Utility of NKN

Reach Timespan Effect Impact

2013-14 1,226 Institute 66 VC 280 Districts 2 Lakh+ Users 28 SWAN 25 SDC

1.5 Million Locations 7 Years Duration Touch Millions

  • f Users

Exponential Growth

2011-12 462 Institute 50 VC Districts 1 Lakh+ Users 4 SWAN 3 SDC

slide-19
SLIDE 19

NKN – Growing Organically

slide-20
SLIDE 20

NKN– Growing Inorganically with NII

slide-21
SLIDE 21

/SPV/ NII MO

  • Headed by Apex/Empowered Committee
  • DeitY
  • Strategic Guidance
  • Guidelines and Standards
  • Audit Conformance
  • Funding
  • NII Agency/PMU/SPV
  • Policy Enforcement
  • Standard Enforcement
  • Interstate Coordination
  • Infra Capacity Planning
  • Financial Planning
  • Coordination
  • Facilitation – Integration and Operation

NII Institutional Structure

slide-22
SLIDE 22

Enrich

Each one of us in its own novel way

Enable

Better Infrastructure and Services Platform

Encourage

Penetration of ‘Digital India’ Vision

NII and NKN

Empower

States in terms of better Compute, Storage and Connectivity

slide-23
SLIDE 23

Thank You

slide-24
SLIDE 24

NII Coverage

slide-25
SLIDE 25

NII and NKN

Encourage Penetration of ‘Digital India’ Vision Empower All States in terms of better Compute, Storage and Bandwidth Enable Better Infrastructure and Services Platform Enrich Each one of us in its own novel way
