Pentium 4

• Deeply pipelined processor supporting multiple

issue with speculation and multi-threading

– 2004 version: 31 clock cycles from fetch to retire, 3.2 GHZ clock rate (deep pipeline allows higher clock rate)

• Front end decoder translates each IA-32

instruction into a series of RISC like micro-

• perations called uops
• Uops executed by dynamically scheduled

speculative pipeline

Section 2.10 2

Pentium 4, continued

• Uops are stored in an execution trace

cache

– Stores sequences of instructions to be executed, including nonadjacent instructions – Accessed using branch prediction bits and address of first instruction in trace – Has its own branch target buffer for predicting the outcome of uop branches – Very high hit rate – IA-32 instruction fetch rarely needed

Section 2.10 3

Pentium 4, continued

• Uops executed by an out-of-order speculative

pipeline that uses register renaming rather than a reorder buffer

• Up to three uops per clock cycle can be

renamed and dispatched to the functional unit queue

• Up to three uops can commit each clock cycle
• Up to six uops can be dispatched to functional

units each clock cycle

Section 2.10 4

Figure 2.26

Section 2.10 5

About figure 2.26

• Front-end BTB – predicts next IA-32 instruction

to fetch; only accessed if miss in execution trace cache

• Execution trace cache – holds uops
• Trace cache BTB – predicts the next uop
• Registers for renaming – 128; supports 128

uops executing simultaneously

• Functional units – 7 (simple ones run at twice

the clock rate and accept up to two every clock cycle)

Section 2.10 6

About figure 2.26

• L1 data cache – supports up to 8
• utstanding misses; integer load latency is

4 cycles; FP load latency is 12 cycles

• L2 cache – 18 cycle access time

Section 2.10 7

Pentium 4

• Deep pipeline makes speculation and

branch prediction very important for high performance

• Cost of cache miss is also very high as

queues will fill waiting for the miss to be handled

Section 2.10 8

Pentium 4: Branch misprediction

• Figure 2.28 (next slide) show branch-

misprediction rate per 1000 instructions

– Top five are integer benchmarks (average 186 branches per 1000 instructions) – Bottom five are fp benchmarks (48 branches per 1000 instructions) – Misprediction rate for integer benchmarks is 8 times higher than for fp benchmarks

Section 2.10 9

Figure 2.28

Section 2.10 10

Pentium 4: Misspeculation

• Misprediction causes wrong instructions to

be executed (misspeculated instructions), requires recovery time and wastes energy

• Figure 2.29 (next slide) shows the

percentage of uop instructions issued that are misspeculated

• Note Figure 2.29 closely matches Figure

2.28

Section 2.10 11

Figure 2.29

Section 2.10 12

Pentium 4: cache misses

• Trace cache miss rates are almost

negligible for SPEC benchmarks

• L1 and L2 miss rates are more significant
• Figure 2.30 (next slide) shows misses per

1000 instructions for the L1 and L2 caches

• Misses for L1 is higher, however miss

penalty for L2 is higher so both will impact performance

Section 2.10 13

Figure 2.30

Section 2.10 14

Pentium 4: CPI

• Figure 2.31 (next slide) shows cycles per

instruction for these same 10 SPEC benchmarks

• Note mcf has worst misspeculation rate

and worst L1 and L2 miss rate and also has highest CPI

• Note swim has high L1 and L2 miss rate

and is lowest performing FP benchmark

Section 2.10 15

Figure 2.31

Section 2.10 16

Comparing Pentium 4 to AMD Opteron

• Both use dynamically scheduled, speculative

pipeline capable of issuing three IA-32 instructions per clock cycle

• Both have two levels of on-chip cache, but

Opteron L1 instruction cache is not a trace cache

• Biggest difference is that the Pentium 4 is more

deeply pipelined

• Pentium 4 has higher CPI (figure 2.32) but this

makes sense given deeper pipeline

Section 2.10 17

Figure 2.32

Section 2.10 18

Comparing Pentium 4 to AMD Opteron

• Deeper pipelining allows increase in clock

rate – Will this increase make up for increase in CPI?

• Figure 2.33 (next slide) compares 2.8 GHz

AMD Opteron versus 3.8 GHz Intel Pentium 4

• Note the AMD has higher performance,

thus the higher clock rate is insufficient to

• vercome the higher CPI

Section 2.10 19

Figure 2.33

Section 2.10 20

Comparing Pentium 4 to IBM Power5

• Sophisticated multiple-issue pipelines usually

have slower clock rates than simple pipelines

• Faster clock rate will win in the presence of

limited ILP

• IBM Power5 designed for high-performance

integer and FP (two processor cores each capable of sustaining four instructions per clock cycle); 1.9GHz clock rate

Section 2.10 21

Comparing Pentium 4 to IBM Power5

• Pentium 4 – single processor with

multithreading; very deep pipeline; can sustain three instructions per clock cycle; higher clock rate (3.8GHz)

• Figure 2.34 (next slide) compares the

performance of these machines

– Note that the Power5 often does better on the FP benchmarks (less branches, more parallelism) – Pentium 4 does better on Integer (higher clock rate)

Section 2.10 22
