1

November 14, 2017

Pedestrian Safety Action Plan Local Call for Projects Webinar

2

Webinar Instructions

• Webinar is being recorded.
• Participants are in listen-only

mode.

• Submit questions in the chat pod.
• We will answer chat box

questions at the end.

• A recording, PowerPoint and Q

and A document will be posted to the PSAP Local Call Website following the webinar.

If you require assistance during the call, contact Robert Zitowsky at 518-265-3147.

3

Regina Doyle New York State Department of Transportation Regina.Doyle@dot.ny.gov 518-485-0164 PSAP Local Call Web Page

https://www.dot.ny.gov/divisions/operating/osss/highway/psap

My Contact Info

4

 Pedestrian Safety Action Plan Background  Local Call Projects 

Eligibility Requirements



Schedule and Application Process



Additional Information



Q and A

Today’s Agenda

Background

6

https://www.ny.gov/pedestrian-safety-action-plan/pedestrian-safety-action-plan

 Five-year initiative  $110 million for

pedestrian safety in:

 Engineering  Education  Enforcement

The NYS Pedestrian Safety Action Plan aka ‘PSAP’

7

• Approximately 300 pedestrians killed each year
• Over 15,000 pedestrians injured
• Over 25% of motor vehicle related fatalities are pedestrians

Economic cost over a 5 year period between 2009-2013 for pedestrian crashes outside NYC is estimated at $5.82 billion

New York Crash Statistics

8



88% occurred in Urban Areas



50% in 20 communities



All road types



Intersections and midblock



State and Local Jurisdictions



More severe, over represented

• n State Road



70% occur on local roads

Data Analysis (2009-2013)

9

 Engineering  Investigate and treat hot spots  Low-cost systemic improvements at ~ 2,400

signalized intersections and ~1,350 uncontrolled/midblock crosswalks on the State system in urban areas outside NYC

 Includes $40M in funding for local PSAP projects  Education  Enforcement

PSAP Program (3 E’s)

Local Call - Eligibility

11

 Counties, towns, villages OR  Cities with a population < 1 million

AND

 Located in a 2010 federal adjusted urban area

Who can apply?

12

 Based on 2010 Census then Adjusted for

Transportation Purposes

FHWA Urban Area Definitions by Population Range FHWA Area Type Population Range Urban Area 5,000+ Small Urban Area (from clusters) 5,000-49,999* Urbanized Areas 50,000+ * Note that the Census Bureau uses a lower limit of 2,500 for urban

• clusters. The PSAP uses the FHWA definition with a lower limit of

5,000.

2010 Federally Adjusted Urban Areas

13

Go to the NYSDOT Functional Class Viewer at

https://gis3.dot.ny.gov/fc

To identify eligible urban areas

14

Select Zoom to Place and enter a Place Name Select + Sign to Zoom in Further

Find Your Location

15

 $250k - $5 million HSIP project cost  Counties/municipalities may bundle to

meet minimum

 One sponsor responsible for delivery of

all locations

 Systemic implementation of PSAP

countermeasures

Project Criteria

16

 Public roads as per 23 CFR § 924.3  2010 federal urban areas  Local/County owned or maintained  Locally owned signalized locations on

state touring routes are also eligible.

Location Criteria

17

Uncontrolled Crosswalks

Eligible Location Types

Signalized Intersections

No signal, no stop sign

18

Systemic Definition

A systemic approach to safety involves widely implemented improvements based on high-risk roadway features correlated with specific severe crash types…Rather than managing risk at certain locations, a systemic approach takes a broader view and evaluates risk across an entire roadway system1…

1 FHWA - A Systemic Approach to Safety - Using Risk to Drive Action

19

 High Risk Roadway Features  Signalized Intersections  Uncontrolled Crosswalks  Urban Areas  Severe Crash Type  Pedestrian crashes while crossing the road (as

• pposed to walking along the road)

 Widely implemented/low cost improvements

New York PSAP Systemic Program

20

 State System Goals - Uncontrolled 

Basic package at 100% urban locations (~1,350)



Enhanced treatments at 20% urban locations

 State System Goals – Signalized Intersections 

PSAP improvements at 50% urban signalized intersections (~ 2,400)

State Systemic Program

21

#1 At crosswalk:  High visibility crosswalk markings  Double posted (back to back) fluorescent yellow-green ped crossing signs  Retroreflective sign posts on ped crossing signs #2 In advance of crosswalk:  Fluorescent yellow-green ped crossing signs  Fluorescent yellow-green ahead plaque  Yield line (sharks teeth) pavement markings w/ yield here to ped sign (multi lane midblock only)*  Restrict parking*

*Basic or enhanced depending on speed and # lanes

Uncontrolled Crosswalks – Basic Treatments

#1 #2 #2 #2

22

Enhanced Treatments:

 In-street pedestrian crossing signs  Rectangular Rapid Flashing

Beacons (RRFB)

 High-Intensity Activated crossWalK

Beacon (aka HAWK)

 Raised Refuge Islands  Enhanced Illumination

Uncontrolled Crosswalks – Enhanced Treatments

23

 Justification for Enhanced Treatments  Safety Evaluation  Engineering Judgement  Crash Experience/exposure  Identified Community Need  NYSDOT Guidance

Uncontrolled Crosswalks – Enhanced Treatments

24

 Retime traffic signals for proper pedestrian clearance time/intervals  Retime traffic signals for better coordination (and bandwidth use)  Back plates with retro-reflective borders  Countdown timers  High visibility crosswalk markings  Restricted parking  Evaluate left turn phasing  Accessible Pedestrian Signals (APS)  Leading Pedestrian Interval (LPI)/No Turn On Red LED & Accessible Pedestrian Signal

Signalized Intersections

25

 New pedestrian signal with countdown indications  Advance cross street name signs  Signal ahead signs  Turning Vehicle Yield to Pedestrian Sign (MUTCD sign designation: R10- 15)  No Turn On Red Signs (standard or LED/blank-out) with optional plaques (MUTCD sign designations: R10-11, R10-30, NYR7-4P & NYR7-5P)  Move regulatory signs overhead  Raised Pedestrian Refuge Islands  Enhanced illumination at crossings

Signalized Intersections

26

 Intersection widening and the installation of turn lanes at

• ne signalized location

 Rebuild of an outdated traffic signal

Ineligible Projects / Treatments

Funding

28

 $40 million in Highway Safety

Improvement Program (HSIP) Funds

 Design, Construction, Construction

Inspection are eligible

 Right of Way may be funded in isolated

cases

 Application development is not fundable

Funding

29

 Eligible projects may be eligible for up to

100% funding.

 Funds cannot be used to replace other

fund sources in an existing project.

 Partial funding is allowed.

Funding

30

 Sponsors are required to first instance project costs  Costs will be reimbursed by NYSDOT per the terms of a State Local Agreement  Sponsors are responsible for cost overruns

Funding

31

 The applicability of the ADA to the PSAP is explained in NYSDOT’s Traffic Safety & Mobility Instruction (TSMI) 17-02 available online here: https://www.dot.ny.gov/divis ions/operating/oom/transpo rtation-systems/official- issuances  Under the HSIP, ADA activities directly resulting from an eligible PSAP project are reimbursable

Americans with Disabilities Act (ADA)

Schedule and Application Process

33

 Applications due no later than March 09,

2018

 Contact List can be found at: https://www.dot.ny.gov/divisions/operating/osss/highway/psap  Projects located in an MPO, should be emailed to the MPO contact identified in Appendix A - PSAP Local Call Contact List  Projects outside an MPO, should be emailed to the NYSDOT Regional Planning contact identified in Appendix A - PSAP Local Call Contact List

 Funding decisions expected late spring

2018

Schedule

34

Review Guidelines and Supporting Materials at https://www.dot.ny.gov/divisions/operating/osss/highway/psap prior to beginning the application

Application Process

35

 The application is a fillable pdf form. A copy is available on

the PSAP Local Call Web Page

 Download and Save a Copy to Your Computer  Open Adobe Reader  Open the Application  Save As to create a copy for the project you are working

• n

 “File” > “Save as”> Save as Type should be a pdf

Completing the Application

36

 Naming Convention  PSAP_CountyName_MPOName_SponsorEntity_ShortP

rojectName

 PSAP_Albany_CDTC_TownColonie_UncontrolXwalks  Use the “Tab” function to navigate from field to field within

the form

Naming Convention

38

39

40

41

42

43

44

45

46

47

48

49

50

52

Software requirements

 Minimum software: Adobe Acrobat version 9 or higher  Recommended software:  Adobe Acrobat DC  Adobe Reader 11  Consider using a word processing program to type large

amounts of text, and then cut and paste the entry into the

• form. Save the documents for your reference.

 Zip large files prior to attaching them as the email limit on

• verall file size is approximately 20 MB.

Application Process – Some Hints

53

 Consultants can be used to prepare the application and

design plans

 Must be selected through a competitive, qualifications-

based selection (QBS) process within the last 3 years.

 Only eligible to work on the phases (application,

design, and/or construction) named in the solicitation.

 Application development is not an eligible project cost.

Use of Consultants

54

 Phases of work and conflict of interest  If later phases are not referenced in a solicitation, and

the Sponsor must go through another competitive, qualifications-based selection process, the original consultant cannot be considered due to a conflict of interest/unfair advantage

Use of Consultants

55

Appendix F. Countermeasure Cross Reference

Additional Information

56

PSAP Local Call Webpage https://www.dot.ny.gov/divisions/operating/osss/highway/psap Regina Doyle New York State Department of Transportation Regina.Doyle@dot.ny.gov 518-485-0164 Robert Zitowsky New York State Department of Transportation Robert.Zitowsky@dot.ny.gov 518-265-3147

Additional Information

57

Thank you!!!
