PCFGs: Viterbi CKY

CMSC 473/673 UMBC November 13th, 2017

Recap from last time…

Probabilistic Context Free Grammar

Set of weighted (probabilistic) rewrite rules, comprised of terminals and non-terminals Terminals: the words in the language (the lexicon), e.g., Baltimore Non-terminals: symbols that can trigger rewrite rules, e.g., S, NP, Noun (Sometimes) Pre-terminals: symbols that can only trigger lexical rewrites, e.g., Noun

1.0 S  NP VP .4 NP  Det Noun .3 NP  Noun .2 NP  Det AdjP .1 NP  NP PP 1.0 PP  P NP .34 AdjP  Adj Noun .26 VP  V NP .0003 Noun  Baltimore … Q: What are the distributions? What must sum to 1?

A: P(X  Y Z | X)

Probabilistic Context Free Grammar

p(

S NP VP

Noun

Baltimore

Verb

NP

is a great city

)=

p(

S NP VP ) *

p( ) * p( ) *

NP

Noun

p( ) *

Noun

Baltimore

VP

Verb

NP

p( ) *

Verb

is

p( )

NP

a great city

product of probabilities of individual rules used in the derivation

Probabilistic Context Free Grammar (PCFG) Tasks

Find the most likely parse (for an observed sequence) Calculate the (log) likelihood of an observed sequence w1, …, wN Learn the grammar parameters

any

CKY Precondition

Grammar must be in Chomsky Normal Form (CNF) non-terminal  non-terminal non-terminal non-terminal  terminal

X  Y Z X  a

binary rules can only involve non-terminals unary rules can only involve terminals no ternary (+) rules

“Papa ate the caviar with a spoon”

S  NP VP NP  Det N NP  NP PP VP  V NP VP  VP PP PP  P NP NP  Papa N  caviar N  spoon V  spoon V  ate P  with Det  the Det  a

1 2 3 4 5 6 7

Example from Jason Eisner

Entire grammar Assume uniform weights

Goal: (S, 0, 7)

“Papa ate the caviar with a spoon”

S  NP VP NP  Det N NP  NP PP VP  V NP VP  VP PP PP  P NP NP  Papa N  caviar N  spoon V  spoon V  ate P  with Det  the Det  a

1 2 3 4 5 6 7

Example from Jason Eisner

Entire grammar Assume uniform weights

First: Let’s find all NPs

(NP, 0, 1): Papa (NP, 2, 4): the caviar (NP, 5, 7): a spoon (NP, 2, 7): the caviar with a spoon

Second: Let’s find all VPs

(VP, 1, 7): ate the caviar with a spoon (VP, 1, 4): ate the caviar

Third: Let’s find all Ss

(S, 0, 7): Papa ate the caviar with a spoon (S, 0, 4): Papa ate the caviar

NP VP

6 1 2 3 4 5 1 2 3 4 5 6 7

(NP, 0, 1) (VP, 1, 7) (S, 0, 7)

start end

CKY Recognizer

Input: * string of N words * grammar in CNF Output: True (with parse)/False Data structure: N*N table T Rows indicate span start (0 to N-1) Columns indicate span end (1 to N) T[i][j] lists constituents spanning i  j

CKY Recognizer

T = Cell[N][N+1] for(j = 1; j ≤ N; ++j) { T[j-1][j].add(X for non-terminal X in G if X  wordj) } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(non-terminal Y : T[start][mid]) { for(non-terminal Z : T[mid][end]) { T[start][end].add(X for rule X  Y Z : G) } } } } }

X Y Z Y Z

CKY Recognizer

T = Cell[N][N+1] for(j = 1; j ≤ N; ++j) { T[j-1][j].add(X for non-terminal X in G if X  wordj) } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(non-terminal Y : T[start][mid]) { for(non-terminal Z : T[mid][end]) { T[start][end].add(X for rule X  Y Z : G) } } } } }

Q: What do we return? A: S in T[0][N] Q: How do we get the parse? A: Follow backpointers

“Papa ate the caviar with a spoon”

S  NP VP NP  Det N NP  NP PP VP  V NP VP  VP PP PP  P NP NP  Papa N  caviar N  spoon V  spoon V  ate P  with Det  the Det  a

1 2 3 4 5 6 7

Example from Jason Eisner

Entire grammar Assume uniform weights

Work through parse on board

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

NP S S

1

V VP VP

2

Det NP NP

3

N

4

P PP

5

Det NP

6

N V

CKY Recognizer

T = Cell[N][N+1] for(j = 1; j ≤ N; ++j) { T[j-1][j].add(X for non-terminal X in G if X  wordj) } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(non-terminal Y : T[start][mid]) { for(non-terminal Z : T[mid][end]) { T[start][end].add(X for rule X  Y Z : G) } } } } }

CKY Recognizer

T = Cell[N][N+1] for(j = 1; j ≤ N; ++j) { T[j-1][j].add(X for non-terminal X in G if X  wordj) } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(rule X  Y Z : G) { T[start][end].add(X if Y in T[start][mid] & Z in T[mid][end]) } } } }

CKY Recognizer

T = bool[K][N][N+1] for(j = 1; j ≤ N; ++j) { for(non-terminal X in G if X  wordj) { T[X][j-1][j] = True } } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(rule X  Y Z : G) { T[X][start][end] = T[Y][start][mid] & T[Z][mid][end] } } } }

Probabilistic Context Free Grammar (PCFG) Tasks

Find the most likely parse (for an observed sequence) Calculate the (log) likelihood of an observed sequence w1, …, wN Learn the grammar parameters

CKY Viterbi Parser

Input: * string of N words * probabilistic grammar in CNF Output: Parse with probability (or None) Data structure: K*N*N table T K non-terminal symbols in the grammar Rows indicate span start (0 to N-1) Columns indicate span end (1 to N) T[X][i][j] lists most likely constituents beginning with rule X spanning i  j

T = WeightedCell[K][N][N+1] for(j = 1; j ≤ N; ++j) { T[X][j-1][j] = argmax { p(X  wordj) for non-terminal X in G if X  wordj } } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] = argmax { p(X  Y Z) * T[Y][start][mid] * T[Z][mid][end] for rule X  Y Z : G} } } }

CKY Viterbi

“Papa ate the caviar with a spoon”

1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

1 2 3 4 5 6 7

Example from Jason Eisner

Entire grammar

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det NP NP

3

.6 N

4

1.0 P PP

5

.5 Det NP

6

.4 N .1 V

1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det .18 NP NP

3

.6 N

4

1.0 P .12 PP

5

.5 Det .12 NP

6

.4 N .1 V

.5 * .6 * .6 = .18

.6 NP  Det N

1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det .18 NP NP

3

.6 N

4

1.0 P .12 PP

5

.5 Det .12 NP

6

.4 N .1 V

.0972 .0065 1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det .18 NP NP

3

.6 N

4

1.0 P .12 PP

5

.5 Det .12 NP

6

.4 N .1 V

.0972 .0065 .00351 .00467 1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det .18 NP NP

3

.6 N

4

1.0 P .12 PP

5

.5 Det .12 NP

6

.4 N .1 V

.0972 .0065 .00351 .00467 .000467 1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

“Papa ate the caviar with a spoon”

1 2 3 4 5 6 7

Example from Jason Eisner

1 2 3 4 5 6 7

.1 NP S S

1

.9 V VP VP

2

.5 Det .18 NP NP

3

.6 N

4

1.0 P .12 PP

5

.5 Det .12 NP

6

.4 N .1 V

.0972 .0065 .00467 .000467 1.0 S  NP VP .6 NP  Det N .3 NP  NP PP .6 VP  V NP .4 VP  VP PP 1.0 PP  P NP .1 NP  Papa .6 N  caviar .4 N  spoon .1 V  spoon .9 V  ate 1.0 P  with .5 Det  the .5 Det  a

T = WeightedCell[K][N][N+1] T[*][*][*] = 0 for(j = 1; j ≤ N; ++j) { T[X][j-1][j] = argmax { p(X  wordj) for non-terminal X in G if X  wordj} } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] = argmax { p(X  Y Z) * T[Y][start][mid] * T[Z][mid][end] for rule X  Y Z : G} } } }

CKY Viterbi

Adapted from Jason Eisner

T = bool[K][N][N+1] T[*][*][*] = False for(j = 1; j ≤ N; ++j) { T[X][j-1][j] |= { True for non-terminal X in G if X  wordj} } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] |= { True & T[Y][start][mid] & T[Z][mid][end] for rule X  Y Z : G} } } }

CKY Recognizer

Adapted from Jason Eisner

CKY Comparison

Recognizer

T = bool[K][N][N+1] T[*][*][*] = False for(j = 1; j ≤ N; ++j) { T[X][j-1][j] |= { True for non-terminal X in G if X  wordj } } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] |= { True & T[Y][start][mid] & T[Z][mid][end] for rule X  Y Z : G} } } }

Viterbi

T = WeightedCell[K][N][N+1] T[*][*][*] = 0 for(j = 1; j ≤ N; ++j) {

T[X][j-1][j] = argmax { p(X  wordj) for non-terminal X in G if X  wordj}

} for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] = argmax { p(X  Y Z) * T[Y][start][mid] * T[Z][mid][end] for rule X  Y Z : G} } } }

T = SemiRingCell[K][N][N+1] T[*][*][*] = ⓪ for(j = 1; j ≤ N; ++j) { T[X][j-1][j] ⊕= { p(X  wordj) for non-terminal X in G if X  wordj} } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { T[X][start][end] ⊕= [ p(X  Y Z) ⊗ T[Y][start][mid] ⊗ T[Z][mid][end] for rule X  Y Z : G] } } }

General CKY

Adapted from Jason Eisner

CKY Algorithms

Weights ⊕ ⊗ ⓪ ①

Recognizer Boolean (True/False)

• r

and False True Viterbi [0,1] max * 1

Adapted from Jason Eisner
