Dependency Grammars and Parsing

CMSC 473/673 UMBC

Outline

Review: PCFGs and CKY Dependency Grammars Dependency Parsing (Shift-reduce) From syntax to semantics

Probabilistic Context Free Grammar

Set of weighted (probabilistic) rewrite rules, comprised of terminals and non-terminals Terminals: the words in the language (the lexicon), e.g., Baltimore Non-terminals: symbols that can trigger rewrite rules, e.g., S, NP, Noun (Sometimes) Pre-terminals: symbols that can only trigger lexical rewrites, e.g., Noun

1.0 S → NP VP .4 NP → Det Noun .3 NP → Noun .2 NP → Det AdjP .1 NP → NP PP 1.0 PP → P NP .34 AdjP → Adj Noun .26 VP → V NP .0003 Noun → Baltimore … Q: What are the distributions? What must sum to 1?

A: P(X → Y Z | X)

Probabilistic Context Free Grammar

p(

S NP VP

Noun

Baltimore

Verb

NP

is a great city

)=

p(

S NP VP ) *

p( ) * p( ) *

NP

Noun

p( ) *

Noun

Baltimore

VP

Verb

NP

p( ) *

Verb

is

p( )

NP

a great city

product of probabilities of individual rules used in the derivation

“Papa ate the caviar with a spoon”

S → NP VP NP → Det N NP → NP PP VP → V NP VP → VP PP PP → P NP NP → Papa N → caviar N → spoon V → spoon V → ate P → with Det → the Det → a

1 2 3 4 5 6 7

Example from Jason Eisner

Entire grammar Assume uniform weights

First: Let’s find all NPs

(NP, 0, 1): Papa (NP, 2, 4): the caviar (NP, 5, 7): a spoon (NP, 2, 7): the caviar with a spoon

Second: Let’s find all VPs

(VP, 1, 7): ate the caviar with a spoon (VP, 1, 4): ate the caviar

Third: Let’s find all Ss

(S, 0, 7): Papa ate the caviar with a spoon (S, 0, 4): Papa ate the caviar

NP VP

6 1 2 3 4 5 1 2 3 4 5 6 7

(NP, 0, 1) (VP, 1, 7) (S, 0, 7)

start end S

CKY Recognizer

Input: * string of N words * grammar in CNF Output: True (with parse)/False Data structure: N*N table T Rows indicate span start (0 to N-1) Columns indicate span end (1 to N) T[i][j] lists constituents spanning i → j For Viterbi in HMMs: build table left-to-right For CKY in trees:

• 1. build smallest-to-largest &
• 2. left-to-right

CKY Recognizer

T = Cell[N][N+1] for(j = 1; j ≤ N; ++j) { T[j-1][j].add(X for non-terminal X in G if X → wordj) } for(width = 2; width ≤ N; ++width) { for(start = 0; start < N - width; ++start) { end = start + width for(mid = start+1; mid < end; ++mid) { for(non-terminal Y : T[start][mid]) { for(non-terminal Z : T[mid][end]) { T[start][end].add(X for rule X → Y Z : G) } } } } }

X Y Z Y Z

CKY is Versatile: PCFG Tasks

Task PCFG algorithm name HMM analog Find any parse CKY recognizer none Find the most likely parse (for an

• bserved sequence)

CKY weighted Viterbi Viterbi Calculate the (log) likelihood of an

• bserved sequence w1, …, wN

Inside algorithm Forward algorithm Learn the grammar parameters Inside-outside algorithm (EM) Forward- backward/Baum- Welch (EM)

Outline

Review: PCFGs and CKY Dependency Grammars Dependency Parsing (Shift-reduce) From syntax to semantics

Structure vs. Word Relations

Constituency trees/analyses: based on structure Dependency analyses: based on word relations

Remember: (P)CFGs Help Clearly Show Ambiguity

I ate the meal with friends

NP VP VP NP PP S NP VP S VP NP PP NP

CFGs to Dependencies

I ate the meal with friends

NP VP VP NP PP S NP VP S VP NP PP NP

CFGs to Dependencies

I ate the meal with friends

NP VP VP NP PP S NP VP S VP NP PP NP

CFGs to Dependencies

I ate the meal with friends

NP VP VP NP PP S NP VP S VP NP PP NP

CFGs to Labeled Dependencies

I ate the meal with friends

NP VP VP NP PP S NP VP S VP NP PP NP

nsubj dobj nmod nsubj dobj nmod

Labeled Dependencies

Word-to-word labeled relations governor (head) dependent

Chris ate nsubj

Labeled Dependencies

Word-to-word labeled relations governor (head) dependent

Chris ate nsubj de Marneffe et al., 2014

http://universaldependencies.org/

(Labeled) Dependency Parse

Directed graphs Vertices: linguistic blobs in a sentence Edges: (labeled) arcs

(Labeled) Dependency Parse

Directed graphs Vertices: linguistic blobs in a sentence Edges: (labeled) arcs Often directed trees

• 1. A single root node with no incoming arcs
• 2. Each vertex except root has exactly one incoming arc
• 3. Unique path from the root node to each vertex

Projective Dependency Trees

No crossing arcs

SLP3: Figs 14.2, 14.3

✔ Projective

Projective Dependency Trees

No crossing arcs

SLP3: Figs 14.2, 14.3

✔ Projective ✖ Not projective

Projective Dependency Trees

No crossing arcs

SLP3: Figs 14.2, 14.3

✔ Projective ✖ Not projective non projective parses capture

• certain long-range dependencies
• free word order

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of each node in a phrase

structure, using “appropriate” head rules.

• 2. In the dependency structure, make the head of

each non-head child depend on the head of the head-child.

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of

each node in a phrase structure, using “appropriate” head rules.

• 2. In the dependency

structure, make the head

• f each non-head child

depend on the head of the head-child.

Papa ate the caviar with a spoon

NP V D N P D N NP NP PP VP VP S

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of

each node in a phrase structure, using “appropriate” head rules.

• 2. In the dependency

structure, make the head

• f each non-head child

depend on the head of the head-child.

Papa ate the caviar with a spoon

NP V D N P D N NP NP PP VP VP S

spoon caviar

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of

each node in a phrase structure, using “appropriate” head rules.

• 2. In the dependency

structure, make the head

• f each non-head child

depend on the head of the head-child.

Papa ate the caviar with a spoon

NP V D N P D N NP NP PP VP VP S

ate spoon spoon caviar

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of

each node in a phrase structure, using “appropriate” head rules.

• 2. In the dependency

structure, make the head

• f each non-head child

depend on the head of the head-child.

Papa ate the caviar with a spoon

NP V D N P D N NP NP PP VP VP S

ate spoon spoon caviar ate

Are CFGs for Naught?

Nope! Simple algorithm from Xia and Palmer (2011)

• 1. Mark the head child of

each node in a phrase structure, using “appropriate” head rules.

• 2. In the dependency

structure, make the head

• f each non-head child

depend on the head of the head-child.

Papa ate the caviar with a spoon

NP V D N P D N NP NP PP VP VP S

ate spoon spoon caviar ate ate

Dependency Post-Processing (Keep Tree Structure)

Dependency Post-Processing (Get Possible Graph Structure)

Amaranthus, collectively known as amaranth, is a cosmopolitan genus of annual or short-lived perennial plants.

Outline

Review: PCFGs and CKY Dependency Grammars Dependency Parsing (Shift-reduce) From syntax to semantics

(Some) Dependency Parsing Algorithms

Dynamic Programming Eisner Algorithm (Eisner 1996) Transition-based Shift-reduce, arc standard Graph-based Maximum spanning tree

(Some) Dependency Parsing Algorithms

Dynamic Programming Eisner Algorithm (Eisner 1996) Transition-based Shift-reduce, arc standard Graph-based Maximum spanning tree

Shift-Reduce Parsing

Recall from CMSC 331 Bottom-up Tools: input words, some special root symbol ($), and a stack to hold configurations

Shift-Reduce Parsing

Recall from CMSC 331 Bottom-up Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – match top two elements of the stack against the grammar (RHS)

Reduce:

– If match occurred, place LHS symbol on the stack

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

decide how? Search problem!

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

decide how? Search problem! what is valid? Learn it!

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

decide how? Search problem! what is valid? Learn it! what are the possible actions?

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

decide how? Search problem! what is valid? Learn it! what are the possible actions?

Shift-Reduce Actions

Possibility Assign the current word as the head of some previously seen word Assign some previously seen word as the head

• f the current word

Wait processing the current word; add it for later

Shift-Reduce Actions

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head

• f the current word

RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

Shift-Reduce Actions

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head

• f the current word

RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

“Arc standard”

Arc Standard Parsing

state  {[root], [words], [] }

Arc Standard Parsing

state  {[root], [words], [] } while state not final { }

Arc Standard Parsing

state  {[root], [words], [] } while state not final { t ← ORACLE(state) state ← APPLY(t, state) }

Arc Standard Parsing

state  {[root], [words], [] } while state not final { t ← ORACLE(state) state ← APPLY(t, state) } return state

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head of the current word RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head of the current word RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← PREDICT(state) state ← APPLY(t, state) } return state

what is valid? Learn it!

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head of the current word RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

Shift-Reduce Dependency Parsing

Tools: input words, some special root symbol ($), and a stack to hold configurations Shift:

– move tokens onto the stack – decide if top two elements of the stack form a valid (good) grammatical dependency

Reduce:

– If there’s a valid relation, place head on the stack

decide how? Search problem! what is valid? Learn it! what are the possible actions?

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

• Choose LEFTARC if it produces a correct head-dependent relation given the reference

parse and the current configuration

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

• Choose LEFTARC if it produces a correct head-dependent relation given the reference

parse and the current configuration

• Choose RIGHTARC if
• it produces a correct head-dependent relation given the reference parse and

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

• Choose LEFTARC if it produces a correct head-dependent relation given the reference

parse and the current configuration

• Choose RIGHTARC if
• it produces a correct head-dependent relation given the reference parse and
• all of the dependents of the word at the top of the stack have already been

assigned

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

• Choose LEFTARC if it produces a correct head-dependent relation given the reference

parse and the current configuration

• Choose RIGHTARC if
• it produces a correct head-dependent relation given the reference parse and
• all of the dependents of the word at the top of the stack have already been

assigned

Deps Stack Word Buffer Action

• $

Papa ate the caviar SHIFT

• Papa $

ate the caviar SHIFT

• ate Papa $

the caviar LEFTARC ate->Papa ate $ caviar SHIFT ate->Papa the ate $

• SHIFT

ate->Papa caviar the ate $

• LEFTARC

ate->Papa, caviar->the caviar ate $

• RIGHTARC

ate->Papa, caviar->the, ate->caviar ate $

• RIGHTARC

ate->Papa, caviar->the, ate->caviar, $->ate

Learning An Oracle (Predictor)

Training data: dependency treebank Input: configuration Output: {LEFTARC, RIGHTARC, SHIFT}

t ← ORACLE(state)

• Choose LEFTARC if it produces a correct head-dependent relation given the reference

parse and the current configuration

• Choose RIGHTARC if
• it produces a correct head-dependent relation given the reference parse and
• all of the dependents of the word at the top of the stack have already been

assigned

• Otherwise, choose SHIFT

Training the Predictor

Predict action t give configuration s t = φ(s)

Training the Predictor

Predict action t give configuration s t = φ(s) Extract features of the configuration Examples: word forms, lemmas, POS, morphological features

Training the Predictor

Predict action t give configuration s t = φ(s) Extract features of the configuration Examples: word forms, lemmas, POS, morphological features How? Perceptron, Maxent, Support Vector Machines, Multilayer Perceptrons, Neural Networks

Papa ate the caviar

If time permits, work through on board

state  {[root], [words], [] } while state≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Possibility Action Name Action Meaning Assign the current word as the head of some previously seen word LEFTARC Assert a head-dependent relation between the word at the top of stack and the word directly beneath it; remove the lower word from the stack Assign some previously seen word as the head of the current word RIGHTARC Assert a head-dependent relation between the second word on the stack and the word at the top; remove the word at the top of the stack Wait processing the current word; add it for later SHIFT Remove the word from the front of the input buffer and push it onto the stack

Parse steps for “Papa ate the caviar”

Deps Stack Word Buffer Action

• $

Papa ate the caviar SHIFT

• Papa $

ate the caviar SHIFT

• ate Papa $

the caviar LEFTARC ate->Papa ate $ caviar SHIFT ate->Papa the ate $

• SHIFT

ate->Papa caviar the ate $

• LEFTARC

ate->Papa, caviar-> the caviar ate $

• RIGHTARC

ate->Papa, caviar-> the, ate->caviar ate $

• RIGHTARC

ate->Papa, caviar-> the, ate->caviar, $->ate

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Q: What is the time complexity?

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Q: What is the time complexity? A: Linear

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Q: What is the time complexity? A: Linear Q: What’s potentially problematic?

Arc Standard Parsing

state  {[root], [words], [] } while state ≠ {[root], [], [(deps)]} { t ← ORACLE(state) state ← APPLY(t, state) } return state

Q: What is the time complexity? A: Linear Q: What’s potentially problematic? A: This is a greedy algorithm

Becoming Less Greedy

Beam search Breadth-first search strategy (CMSC 471/671) At each stage, keep K options open

Evaluation

Exact Match (per-sentence accuracy) Unlabeled Attachment Score (UAS) Labeled Attachment Score (LS, LAS) Recall/Precision/F1 for particular relation types

Outline

Review: PCFGs and CKY Dependency Grammars Dependency Parsing (Shift-reduce) From syntax to semantics

Parsing as a Core NLP Problem

sentence 1 sentence 2 sentence 3 sentence 4 Parser Grammar

Evaluation

score Other NLP task (entity coref., MT, Q&A, …)

independent

• perations

Gold (correct) reference trees

From Dependencies to Shallow Semantics

From Syntax to Shallow Semantics

Angeli et al. (2015)

“Open Information Extraction”

From Syntax to Shallow Semantics

http://corenlp.run/(constituency & dependency) https://github.com/hltcoe/predpatt http://openie.allenai.org/ http://www.cs.rochester.edu/research/knext/browse/ (constituency trees) http://rtw.ml.cmu.edu/rtw/

Angeli et al. (2015)

“Open Information Extraction” a sampling of efforts
