SLIDE 1 Paxos week and the Temple of Doom
Doug Woos
SLIDE 2 Logistics notes
Next Monday: International Workers’ Day
- No in-class lecture
- Will record a video lecture
- Please watch by next Wednesday!
Lab 2b due tonight at 9pm Problem Set 2 due Friday
- Typeset, short answers, please!
SLIDE 3 Logistics notes
Friday: Paxos Made Moderately Complex
- Not an easy read
- Describes how to implement a practical version of
Paxos, in some detail
- Please spend an hour on it!
SLIDE 4
Review / Clarifications
SLIDE 5 State Machine Replication
Applying a series of client commands to some replicated state s.t. all nodes agree on the
Paxos: which command should we do next?
SLIDE 6 Proposers and acceptors
A B C D
A C D A = Put k1 v1 B = PutAppend k2 v2 C = Get k3 D = Delete k1
SLIDE 7
Proposal numbers
Attach numbers to proposals Used to ensure progress Must be unique—only used for one value! Unique if: Each node uses increasing proposal numbers And proposal numbers unique across nodes
SLIDE 8 Proposal numbers
A B C D
0, 4, 8, 12, 16, … 1, 5, 9, 13, 17, … 2, 6, 10, 14, 18, … 3, 7, 11, 15, 19, …
SLIDE 9
Majorities
Why does Paxos use majorities? Majorities intersect: for any two majorities S and S’, there is some node in both S and S’
SLIDE 10
Majorities
Why does Paxos use majorities? Majorities intersect: for any two majorities S and S’, there is some node in both S and S’
SLIDE 11
A few terms
A proposal is proposed when it is sent from a proposer to an acceptor A proposal is accepted when an acceptor accepts it A proposal is chosen when it is accepted by a majority of acceptors
SLIDE 12
Our approach
Started with a broad definition of consensus We should eventually choose a value We should only choose one value
SLIDE 13 Our approach
Refined further P1: An acceptor must accept the first proposal that it receives
- P2. If a proposal with value v is chosen,
then every higher-numbered proposal that is chosen has value v
SLIDE 14
Our approach
We’re refining our specification until we end up at an actual implementation At each step, we’re arguing that the refinement is valid—e.g., that P2a implies P2 All systems that have property P2a have property P2
SLIDE 15
We should only choose one value P2 P2a
SLIDE 16 The story so far
P1: An acceptor must accept the first proposal that it receives
- P2. If a proposal with value v is chosen,
then every higher-numbered proposal that is chosen has value v
- P2a. If a proposal with value v is chosen,
then every higher-numbered proposal accepted by any acceptor has value v
SLIDE 17
Another take on P2
Recall P2a: If a proposal with value v is chosen, then every higher-numbered proposal accepted by any acceptor has value v We strengthen it to: P2b: If a proposal with value v is chosen, then every higher-numbered proposal issued by any proposer has value v
SLIDE 18 Implementing P2 (I)
Suppose a proposer p wants to issue a proposal numbered n. What value should p propose? If (n’,v) with n’ < n is chosen, then in every majority set S of acceptors at least one acceptor has accepted (n’,v)... ...so, if there is a majority set S where no acceptor has accepted (or will accept) a proposal with number less than n, then p can propose any value
P2b: If a proposal with value v is chosen, then every higher- numbered proposal issued by any proposer has value v
SLIDE 19 Implementing P2 (II)
What if for all S some acceptor ends up accepting a pair (n’,v) with n’ < n? Claim: p should propose the value of the highest numbered proposal among all accepted proposals numbered less than n Proof: By induction on the number of proposals issued after a proposal is chosen
P2b: If a proposal with value v is chosen, then every higher- numbered proposal issued by any proposer has value v
SLIDE 20
Implementing P2 (II)
(1,A) (2,B) ? What do we know about the third acceptor? Could it have accepted (1,A)? Could it have accepted (2,B)?
SLIDE 21
Implementing P2 (II)
(1,A) (2,B) ? What do we know about the third acceptor? Could it have accepted (1,A)? No. Could it have accepted (2,B)? Yes. Proposal with highest number is the only proposal that could have been chosen!
SLIDE 22 Implementing P2 (III)
Achieved by enforcing the following invariant
P2c: For any v and n, if a proposal with value v and number n is issued, then there is a set S consisting of a majority of acceptors such that either: no acceptor in S has accepted any proposal numbered less than n, or v is the value of the highest-numbered proposal among all proposals numbered less than n accepted by the acceptors in S P2b: If a proposal with value v is chosen, then every higher-numbered proposal issued by any proposer has value v
SLIDE 23 P2c in action
No acceptor in S has accepted any proposal numbered less than n
(4,C) (1,C) (5,B)
S
(2,A)
SLIDE 24 P2c in action
v is the value of the highest-numbered proposal among all proposals numbered less than n and accepted by the acceptors in S
(4,G) (3,B) (5,B)
S
(18,B)
SLIDE 25 P2c in action
v is the value of the highest-numbered proposal among all proposals numbered less than n and accepted by the acceptors in S
(2,B) (3,B) (4,A)
S
(18,A) ( 5 , B ) (5,B)
The invariant is violated
SLIDE 26 Future telling?
To maintain P2c, a proposer that wishes to propose a proposal numbered n must learn the highest-numbered proposal with number less than n, if any, that has been or will be accepted by each acceptor in some majority
SLIDE 27 Future telling?
To maintain P2c, a proposer that wishes to propose a proposal numbered n must learn the highest-numbered proposal with number less than n, if any, that has been or will be accepted by each acceptor in some majority
Avoid predicting the future by extracting a promise from a majority of acceptors not to subsequently accept any proposals numbered less than n
SLIDE 28 The proposer’ s protocol (I)
A proposer chooses a new proposal number n and sends a request to each member of some (majority) set of acceptors, asking it to respond with: a. A promise never again to accept a proposal numbered less than n, and b. The accepted proposal with highest number less than n if any. ...call this a prepare request with number n
SLIDE 29 The proposer’ s protocol (II)
If the proposer receives a response from a majority
- f acceptors, then it can issue a proposal with
number n and value v, where v is a. the value of the highest-numbered proposal among the responses, or b. is any value selected by the proposer if responders returned no proposals A proposer issues a proposal by sending, to some set of acceptors, a request that the proposal be accepted. ...call this an accept request.
SLIDE 30
The acceptor’ s protocol
An acceptor receives prepare and accept requests from proposers. It can ignore these without affecting safety. It can always respond to a prepare request It can respond to an accept request, accepting the proposal, iff it has not promised not to, e.g. P1a: An acceptor can accept a proposal numbered
n iff it has not responded to a prepare request having number greater than n ...which subsumes P1.
SLIDE 31 Small optimizations
If an acceptor receives a prepare request r numbered n when it has already responded to a prepare request for n’ > n, then the acceptor can simply ignore r. An acceptor can also ignore prepare requests for proposals it has already accepted ...so an acceptor needs only remember the highest numbered proposal it has accepted and the number of the highest-numbered prepare request to which it has responded. This information needs to be stored on stable storage to allow restarts.
SLIDE 32 Choosing a value: Phase 1
A proposer chooses a new n and sends <prepare,n> to a majority of acceptors If an acceptor a receives <prepare,n’>, where n’ > n
- f any <prepare,n> to which it has responded, then it
responds to <prepare, n’ > with a promise not to accept any more proposals numbered less than n’ the highest numbered proposal (if any) that it has accepted
SLIDE 33 Choosing a value: Phase 2
If the proposer receives a response to <prepare,n> from a majority of acceptors, then it sends to each <accept,n,v>, where v is either the value of the highest numbered proposal among the responses any value if the responses reported no proposals If an acceptor receives <accept,n,v>, it accepts the proposal unless it has in the meantime responded to <prepare,n’> , where n’ > n
SLIDE 34 Learning chosen values (I)
Once a value is chosen, learners should find out about it. Many strategies are possible:
- i. Each acceptor informs each learner
whenever it accepts a proposal.
- ii. Acceptors inform a distinguished learner,
who informs the other learners
- iii. Something in between (a set of not-
quite-as-distinguished learners)
SLIDE 35 Learning chosen values (II)
Because of failures (message loss and acceptor crashes) a learner may not learn that a value has been chosen
☠
(4,G) (7,D)
Was D chosen?
Propose something!
SLIDE 36 Liveness
Progress is not guaranteed:
n1 < n2 < n3 < n4 < … p1 <propose,n1> <accept(n1,v1)> <propose,n3> p2 <propose,n2> <accept(n2,v2)> <propose,n4> Time
SLIDE 37
Implementing State Machine Replication
Implement a sequence of separate instances of consensus, where the value chosen by the ith instance is the ith message in the sequence. Each server assumes all three roles in each instance of the algorithm. Assume that the set of servers is fixed
SLIDE 38 The role of the leader
In normal operation, elect a single server to be a leader. The leader acts as the distinguished proposer in all instances of the consensus algorithm.
Clients send commands to the leader, which decides where in the sequence each command should appear. If the leader, for example, decides that a client command is the kth command, it tries to have the command chosen as the value in the kth instance of consensus.
SLIDE 39 A new leader is elected...
Since is a learner in all instances of consensus, it should know most of the commands that have already been chosen. For example, it might know commands 1-10, 13, and 15. It executes phase 1 of instances 11, 12, and 14 and
- f all instances 16 and larger.
This might leave, say, 14 and 16 constrained and 11, 12 and all commands after 16 unconstrained. then executes phase 2 of 14 and 16, thereby choosing the commands numbered 14 and 16 λ
λ
λ
SLIDE 40 Stop-gap measures
All replicas can execute commands 1-10, but not 13-16 because 11 and 12 haven't yet been chosen. can either take the next two commands requested by clients to be commands 11 and 12, or can propose immediately that 11 and 12 be no-op commands. runs phase 2 of consensus for instance numbers 11 and 12. Once consensus is achieved, all replicas can execute all commands through 16. λ λ
SLIDE 41 To infinity, and beyond
can efficiently execute phase 1 for infinitely many instances of consensus! (e.g. command 16 and higher)
just sends a message with a sufficiently high proposal number for all instances An acceptor replies non trivially only for instances for which it has already accepted a value
λ
λ
SLIDE 42
Paxos and FLP
Paxos is always safe–despite asynchrony Once a leader is elected, Paxos is live. “Ciao ciao” FLP? To be live, Paxos requires a single leader “Leader election” is impossible in an asynchronous system (gotcha!) Given FLP, Paxos is the next best thing: always safe, and live during periods of synchrony
SLIDE 43 Delegation
Paxos is expensive compared to primary/ backup; can we get the best of both worlds? Paxos group leases responsibility for order
- f operations to a primary, for a limited
period If primary fails, wait for lease to expire, then can resume operation (after checking backups) If no failures, can refresh lease as needed
SLIDE 44
Byzantine Paxos
What if a Paxos node goes rogue? (or two?) Solution sketch: instead of just one node in the overlap between majority sets, need more: 2f + 1, to handle f byzantine nodes
