SLIDE 1
REPLACEMENT OF EXCESS PAVEMENT AT SMO RUNWAY ENDS
Airport Commission Meeting September 25, 2017
PAVEMENT AT SMO RUNWAY ENDS Airport Commission Meeting September - - PowerPoint PPT Presentation
PAVEMENT AT SMO RUNWAY ENDS Airport Commission Meeting September - - PowerPoint PPT Presentation
REPLACEMENT OF EXCESS PAVEMENT AT SMO RUNWAY ENDS Airport Commission Meeting September 25, 2017 MAY 24 TH , 2017 COUNCIL MEETING Direct staff to return to Council as soon as possible with options for projects to remove the now unneeded
SLIDE 2
SLIDE 3
AIRPORT PAVEMENT
3,500’ Runway Taxiway Runway Safety Area (RSA) Pavement Removal
436.5 300
Runway Protection Zone (RPZ)
436.5 300
SLIDE 4
PAVEMENT REPLACEMENT OPTIONS OPTION 1: HYDROSEEDING $3.4M OPTION 2: ARTIFICIAL TURF $5.7M OPTION 3: PULVERIZE & STABILIZE $2.7M
SLIDE 5
OPTION 1: HYDROSEEDING
Outside RSA
Remove unused pavement and apply hydroseed (556,000 SF)
Within RSA
Pulverize existing pavement and stabilize (90,000 SF)
COST
Estimated $3.44M
Surface treatment used at San Bernardino International Airport
SLIDE 6
OPTION 1: HYDROSEEDING
SLIDE 7
3,500’ Runway Taxiway Runway Safety Area (RSA) Pavement Removal
OPTION 1: HYDROSEEDING
SLIDE 8
Outside RSA
Remove unused pavement and install artificial turf (556,000 SF)
Within RSA
Pulverize existing pavement and stabilize (90,000 SF)
COST
Estimated $5.69M
Surface treatment used at San Diego International Airport
OPTION 2: ARTIFICIAL TURF
SLIDE 9
OPTION 2: ARTIFICIAL TURF
SLIDE 10
3,500’ Runway Taxiway Runway Safety Area (RSA) Pavement Removal
OPTION 2: ARTIFICIAL TURF
SLIDE 11
OPTION 3: PULVERIZE & STABILIZE IN PLACE
Outside and Within RSA
Pulverize unused pavement and stabilize (646,000 SF)
COST
Estimated $2.73M
Surface treatment used at San Jose International Airport
SLIDE 12
OPTION 3: PULVERIZE & STABILIZE IN PLACE
SLIDE 13
3,500’ Runway Taxiway Runway Safety Area (RSA) Pavement Removal
OPTION 3: PULVERIZE
SLIDE 14
All three options are expected to have similar
implementation schedules
Design Procurement (2-4 months) Design (3-4 months) Construction Procurement (2-4 months) Construction (4-6 months)
ANTICIPATED SCHEDULE
SLIDE 15
NEXT STEPS
Council would provide staff with direction Staff would prepare a Request for Proposal for
design services
Staff would return to Council end 2017/early 2018 for
