PATKOL serves the world with friendly engineering in Refrigeration, Ice and Food Processing

พัฒน์กลน ำเสนอวิศวกรรมฉันท์มิตรในกระบวนกำรผลิต อำหำร ระบบท ำควำมเย็น และเครื่องท ำน ้ำแข็งของโลก

Milestones

1965 Founded as refrigeration contractor company 1974 Started sale of Dairy projects 1976 Started Tube Ice Machine business 1985 Started production

• f food Grade

stainless steel tank 1991 New Factory 1 in Samutrprakan 1993 Listed on SET & rename to “PATKOL” 2000 ASME U-Stamp certified 2005 Opened 2nd factory in Petchburi 2006 Started Turnkey project 2007 ISO9001 Certified 2012 Registered capital raised to THB 600 MB 1992 New Head office 1995 Started PKB Co.,Ltd. Panel Production

PATKOL

PATKOL

“Quality with Service” Revenue : 120 Million USD in 2014

Over 1,600 employees

• ver 35

0 fulltime engineers

Serves 50 Countries 5 continents 3 Factories

World standards

Continuous R&D

Own patents

Awards

PM’s Export Awards 1993, 2001 Outstanding Technologist 2004

Business Fields

Refrigeration System Ice Machine Liquid Food Processing Solid Food Processing Tank & Pressure Vessel

PATKOL

“Quality with Service”

• serving more than 40 countries in 5 continents

since 1976

• Reliable & Low Power Consumption
• Hygienic clear ice

Ice Machine Business

“World Leader in Ice Machines” Product Groups

Tube Ice Block Ice Ice Handling Process Plate Ice Scale Ice

Tube Ice Machine

Ice Machine Business

• Long life

37 years* old machine still in

• peration
• serving more than 40

countries in 5 continents since 1976

• Hygienic clear ice
• tropical areas design
• Low power consumption
• global manufacturing

standard

Block Ice Plant

Ice Machine Business

• Long life

44 years* old plant still in operation

• Low Power Consumption
• Easy to operate
• High Reliability
• 10 to 500 tons per day

Plate Ice Machine

Ice Machine Business

• 5 to 200 tons per day
• Produced hygienic ice
• Ice thickness between 3 to 9 mm.
• All parts in stainless steel
• High efficiency due to vertical flow
• f evaporator plates
• Self contained complete ice

making unit for 20 ton or smaller

• Simple and reliable operation
• Harvest conveyor available

Scale Ice Machine

Ice Machine Business

• 2.5 to 80 tons per day
• Produced hygienic ice
• Ice thickness between 0.5 to

1.5 mm.

• Evaporator Drum and Frame

construction in stainless steel

• Dry- Frozen ice, approximate
• temp. -3๐c
• Easy to operate and

maintenance

• Compact type and easy to

installation

Ice Handling Process

Ice Machine Business

• Automatic ice storage and

packing system

• Customized design for

individual needs

• GMP Compliance to ensure

food safety

• Optional PLC monitoring

and control

Customers

Ice Machine Business

Refrigeration System Business

“Think Cool…think PATKOL”

• Turnkey Refrigeration system
• Friendly Professional service since 1982
• International experiences since 1990
• High efficiency & Durable

Product Groups

Refrigeration Projects Refrigeration Products

• Average more than 200 Jobs

per yearly

• Reference project in U.S.A.,

China Asians and many

• Biggest machine room in

Thailand with 11,000 Hp compressor motors

• Professional team works with

more than 150 peoples

• Overseas sale representative
• ffice & Agents
• Environmental & Safety

concerns Refrigeration System Business

Refrigeration Projects

+18๐c To +10๐c

• 25๐c To -40๐c

Refrigeration System Business

Refrigeration Products

1/3 Shell & Tube Ice Bank Ripple Plate

0.5๐c

• Free refrigerant leakage
• Customized design
• Stainless steel material for

hygienic application

• Fully insulated for energy

saving

• Low Water temperature

supply 0.5C

Refrigeration System Business

Refrigeration Products

2/3

Package Compressor Heat Recovery Evaporative Condenser Package Vessel Automatic Air Purger

• “ PATKOL” Pressure Vessels

Design, assembly & welding following ASME Standard

• Approved of producing

pressure vessel with “U-stamp”

• Certified manufacturing quality

standard ISO 9001:2008 .

Refrigeration System Business

Refrigeration Products

3/3

• Best Utilization of Space
• Effective Store
• Good Sanitation
• Easy Installation
• Flexibility for Expansion
• Energy Conservation
• Lower Civil Works Cost
• Meet The Economic Criteria
• High efficiency compressor

and Unit cooler

Freeze& Cool unit Cold Storage Warehouse Cold room Building

Customers

Refrigeration System Business

Food and Dairy Business

“All solutions for liquid processing projects”

Machine Unit Automation Sanitary Tank Dairy Processing Processing Plant

Product Groups

• Highly experience for liquid food processing
• Hygienic plant and equipments design
• Design base on engineering
• Manually and automatically control

Sanitary Tank

• 28 Years experience*
• Stainless steel grade 304, 316L,

316Ti and Duplex

• Surfaces roughness Ra ≤ 0.8 µm or

up to Ra ≤ 0.4 µm

• Various types of jacket; half pipe,

dimple, spiral, etc.

• Meet FDA, GMP, HACCP standards
• Design according to ASME code
• Chemical passivation and cleaning

Food and Dairy Business

Dairy Processing

• 39 years experience*
• Base on hygienic plant design
• Turnkey processing
• Pasteurization milk process
• UHT milk process
• Flexible productivity capacity

(1 – 600 tons/day)

*since 1974

Food and Dairy Business

Processing Plant

• Turnkey process
• Flexible capacities
• Carbonated beverage
• Non carbonated beverage
• Cosmetic & pharmaceutical
• Hygienic equipments and

processing design

*Example process; Sweated condensed milk & Evaporated milk (SCM & EVM), Fruit juice with pulp, Functional drink (Beauty drink), Cola, Beer, Tea, Wine, Ice cream, Body Lotion

Food and Dairy Business

Machine Unit

Food and Dairy Business

To emphasize your productivity, quality and safety we also serve

• CIP system
• UHT system
• Tubular heat exchanger
• Pigging system
• Retort sterilizer
• Reverse engineering
• Valuable engineering
• Design base on engineering
• Test run and commissioning by

engineer

Commissioning CIP unit Tubular heat exchanger Vacuum cooler

Automation

Food and Dairy Business

To enhance system standard and reduce productivity cost could be possible by

• PLC, SCADA
• HMI
• Machine interface

Advantages of automation system

• Save operating cost
• Preventing human error
• Improve productivity

Customers

Food and Dairy Business

FOOD NON-FOOD

Solid Food Process Business

“World leader of food processing” Product Groups

• energy conservation
• eco-friendliness and saving of production and

labor costs.

• Hygienic design the machine to processing line

1 2 4 6

Packing Machine Shrimp Processing Washer and Material handing IQF Tuna Processing

Tuna Processing

• Export many machines and

Tuna process to many countries in the world.

• Design all of processing plant
• Friendly environment
• Highest benefits such as
• energy saving
• Reducing labour

Solid Food Process Business

Shrimp Processing

Solid Food Process Business

• Reducing of labours
• Machines are durable over 10

years

• Energy saving
• Easy cleaning machines

Material handing

Solid Food Process Business

• Low Operation washing cost
• Reducing of labours
• Continues operation more

than 12 hour.

Continues Freezers

Solid Food Process Business

• Fully welded floor
• Cleaning systems use short

time and design for hygiene

• Top down airflow for food

product have less weigh

Cabinet freezer

Solid Food Process Business

• Freezing capacity up to 150kg
• Low Freezing cost
• Easy to cleaning and

maintenance

• Compact area for installation

Packing system Process

Solid Food Process Business

• Heavy duty can operate

continues more than 24 hr.

• Low cost packing operation
• Automatic weighing system
• High accuracy
• Packaging and products loss

controls

Customers

Solid Food Process Business

Tank & Pressure Vessel Business

“We are specialized in manufacturing all kinds of tanks”

Sanitary Tank

• 28 Years experience*
• Stainless steel grade 304, 316L,

316Ti and Duplex

• Surfaces roughness Ra ≤ 0.8 µm or

up to Ra ≤ 0.4 µm

• Various types of jacket; half pipe,

dimple, spiral, etc.

• Meet FDA, GMP, HACCP standards
• Design according to ASME code
• Chemical passivation and cleaning

Food and Dairy Business

Customers

Food and Dairy Business

FOOD NON-FOOD

PATKOL Group
