Particle Identification Algorithms for the Medium Energy ( 1.5-8 GeV) MINERA Test Beam Experiment Tesista: Antonio Federico Zegarra Borrero Asesor: Dr. Carlos Javier Solano Salinas UNI, March 04, 2016 1 Contents (1)The

slide-1
SLIDE 1

1

Tesista: Antonio Federico Zegarra Borrero Asesor: Dr. Carlos Javier Solano Salinas

“Particle Identification Algorithms for the Medium Energy ( 1.5-8 GeV) ∼ MINERνA Test Beam Experiment”

UNI, March 04, 2016

slide-2
SLIDE 2

2

Contents

  • (1)The MINERνA Experiment at Fermilab
  • (2)Medium Energy MINERvA Test Beam experiment.
  • (3)Tools for Data Analysis & Particle ID
  • (4)Results on the composition (% p ± , π ± , μ ± , e

±) of the secondary beam for different energies & polarities

  • (5)Efficiency-Purity analysis to find the optimum cuts

to separate different species for the 2GeV sample

  • (6)Conclusions
slide-3
SLIDE 3

3

(1)The MINERνA Experiment at Fermilab

  • Neutrino-Nucleon interactions &

Neutrino Oscillation Experiments.

  • Many Interaction-channels with different

Cross-Sections at different Energies.

  • Particles in the final state have a Specific-Pattern of

depositing Energy inside the MINERνA main detector.

  • Their Identification is important for the Reconstruction of the

specific Event.

  • Calculation of Cross-Sections.
slide-4
SLIDE 4

4

The NuMI Beam & the MINERvA Main Detector

slide-5
SLIDE 5

5

Data Acquisition (DAQ)

slide-6
SLIDE 6

6

Energy Dependence of Neutrino Interactions

slide-7
SLIDE 7

7

  • CCQE:

Some examples of Neutrino Interactions

slide-8
SLIDE 8

8

Looking them in Arachne ...

slide-9
SLIDE 9

9

  • RES production of a single π:
slide-10
SLIDE 10

10

(2) Medium Energy MINERvA Test Beam experiment.

  • Main Goal of the Medium Energy Test Beam experiment.
  • Why ? ---> Test MC simulations
  • How ? ---> Constructing up and analyzing a Beam
  • Beamline elements:
slide-11
SLIDE 11

11

slide-12
SLIDE 12

12

Test Beam Detector Configurations

  • Pion & Electron Data Samples (Folders)
  • Advantage of the ECAL/HCAL configuration
  • Different species –---> different behavior inside different

Regions of the Detector (Energy deposition pattern, Number

  • f Hits, etc...)
slide-13
SLIDE 13

13

Time of Flight Device

  • Elements making up the 2 Stations (Upstream & DOWNstream)
  • How this device separates different species (different masses)
  • Interpretation of the ToF measured-time histogram
  • Limitations (Resolution: at E > 8GeV & particles inside the Pion-peak)
slide-14
SLIDE 14

14

  • Early Result (ToF histogram) from its usage (Data from February 2015):
slide-15
SLIDE 15

15

Limitations in the resolution of the ToF

  • Resolution (ToF): 100-200 ps
  • Considering a momentum as low as 1 GeV/c:
  • At E>= 8GeV other process (DIS) dominates

neutrino-Int.

slide-16
SLIDE 16

16

(3) Tools for Data Analysis & Particle ID

  • ROOT via C++ or python (concepts of DST, Chain, Tree,

Branch)

  • Ways to perform analysis: Monte Carlo simulations,

Scatterplots, physical criteria

  • Energy Deposition Patterns: Ionization (dE/dx),

Electromagnetic Showers & Hadronic Showers

  • Visualization of Events (for eye-scanning) via Arachne (a

software developed by MINERvA)

slide-17
SLIDE 17

17

Interaction of particles with matter

slide-18
SLIDE 18

18

Ionization

slide-19
SLIDE 19

19

Electromagnetic Showers

slide-20
SLIDE 20

20

Hadronic Showers

slide-21
SLIDE 21

21

Radiation & Interaction lengths in our Detector.

slide-22
SLIDE 22

22

Tracks in the TB Detector seen in Arachne for a given view (XZ)

slide-23
SLIDE 23

23

slide-24
SLIDE 24

24

Mandatory Conditions to retain meaningful Events (==Particles)

  • The Beam has to be ON:
  • There is Activity in the Detector:
  • All 6 PMTs of ToF Stations fire:
  • The Veto does not fire:
  • The Event occurs in the Triggered Slice:
  • Relevant to know what Veto Branch to use (Veto Sanity

Check) & an Analysis of Correlations between the ToF & the Veto

  • ----> 1 Event == 1 Particle ------> Start Isolating Species !
slide-25
SLIDE 25

25

What is a Slice ?

slide-26
SLIDE 26

26

Methodology for Particle Isolation

  • In the ToF_measured_time histograms:

– 1)Isolate the protons – 2) Eye-Scanning Events in Contamination-Intervals – 3)Isolate Events in the ToF Pion-peak (containing pions,

muons & some electrons).

– 4)To Isolate Species inside the ToF Pion-peak (definition

  • f Detector-Variables)

– For E >= 4GeV a cut in the histogram of Total-Energy

deposited

– For the 2GeV sample we need to cut on more than 1

Variable !

slide-27
SLIDE 27

27

  • To separate Species (e, µ, π) inside the ToF π-peak:

– MC simulations of pure µ to find what Variable separates

them better (µ are easier to locate).

– Definition of many Detector Variables to see which one

works better (via python dictionaries of dE/dx, PE & Hits per module).

– How to look at any electron.

slide-28
SLIDE 28

28

slide-29
SLIDE 29

29

slide-30
SLIDE 30

30

(4)Results on the composition (% p ± , π ± , μ ± , e ±) of the secondary beam for different energies & polarities

  • Methodology used for the 8 GeV π + sample (the same for the 4

& 6 GeV for both + & - polarities )

slide-31
SLIDE 31

31

  • Separating species in the ToF Pion-peak
slide-32
SLIDE 32

32

  • Patterns of Isolated species (from Data) & Pure species

(Monte Carlo)

slide-33
SLIDE 33

33

  • The Relevant-Intervals in all histograms used for the

isolation (in the ToF & Total-E) & how e+ are located (and counted) are detailed. The same criteria was used for the 6 & 4 GeV samples. Here Results for the 8GeV π+:

slide-34
SLIDE 34

34

  • Methodology used for the 2 GeV π + sample
  • More than 1 Var to separate species in the Pion-peak
slide-35
SLIDE 35

35

  • For separating µ from π in the ToF Pion-peak

– Not possible to rely on 1 single variable to separate µ from π – 5 different kinds of cuts combining different variables – The initial Logic was to look at π by knowing where µ are

located

– These are the cuts that look at π (UNIONS) :

slide-36
SLIDE 36

36

  • Let's see how was made CUT-1 (for example) with the aid of

MC simulations of µ (union of different cuts were used to look at π):

slide-37
SLIDE 37

37

slide-38
SLIDE 38

38

slide-39
SLIDE 39

39

slide-40
SLIDE 40

40

  • So the particular cut called CUT-1 is a UNION of cuts
  • f the Energy deposited in different regions of the

detector & looks at π.

slide-41
SLIDE 41

41

Results for All Energies & Polarities

  • These results are estimations because there will never be perfect PID

algorithms.

  • For the 2GeV samples the specific CUT-i used are shown.
slide-42
SLIDE 42

42

(5)Efficiency-Purity analysis to find the

  • ptimum cuts to separate different species

for the 2GeV sample

  • The Cuts used for the 2GeV samples: composed of a

UNION of cuts over different variables (5 per kind of Var).

  • For Data Analysis: Reduce Number of Cuts –-> Reduce

Systematic Uncertainties.

  • The IDEA: construct an OPTIMUM-CUT composed of only 2

cuts (among the 20 Variables)

  • For this reason an Efficiency-Purity Analysis was reliable
  • To analyze each of the cuts & the effect of one after another

–--> CHANGE IN THE LOGIC needed. This will look at µ instead of π

slide-43
SLIDE 43

43

Change in the Logic to look at µ

slide-44
SLIDE 44

44

For the MC an extra condition for the PE for the Hits for any Event was needed...

slide-45
SLIDE 45

45

The Analysis began while looking for the Best Variable to separate µ from π …

slide-46
SLIDE 46

46

Concepts of Efficiency & Purity

slide-47
SLIDE 47

47

slide-48
SLIDE 48

48

slide-49
SLIDE 49

49

slide-50
SLIDE 50

50

  • Best cuts to separate µ from π. Plot histograms of other Vars for

events in the µ-interval (for the best cut) –---> To find the Best second cut.

slide-51
SLIDE 51

51

Methodology followed

  • Select the Best-Cut (let's call it in Variable ) to retain

Events in the µ-Interval ( ).

  • Fill histograms of the other variables with the previous

Events to see which variable (let's call it ) separates better the µ & π present there. Select remaining µ in the new µ-interval ( ) of this new histogram.

  • 8 candidates were selected as the second cut (to add to the
  • ne cited above) and the most efficient (in selecting µ)

among them was chosen.

slide-52
SLIDE 52

52

New-Logic of the “Cuts”:

  • Cut_µ =={ }
  • Cut_π ==

(*)=={ } == ~ Cut_µ

  • Applying these cuts to the MC samples of pure µ & π we can find the

efficiencies:

– Fraction of µ looking as µ(pass the Cut_µ): – Fraction of µ looking as π: – The same for the case of π:

  • The best cut was chosen as the one which maximizes
slide-53
SLIDE 53

53

Candidate to be the Var

slide-54
SLIDE 54

54

  • In next slides: histograms of the variable (8 candidates)

for events in which

  • For each case: new µ-interval is shown, together with

the four numbers:

  • The 8 candidates for are:

– Total_E – Total_E_HCAL – Total_PE – Total_PE_HCAL – <dE/dx>_Total – <dE/dx>_HCAL – Total_Hits_HCAL – Total_Hits_L8P

slide-55
SLIDE 55

55

  • Due to its highest efficiency, the 2nd variable was chosen to be

Total_PE_HCAL

slide-56
SLIDE 56

56

slide-57
SLIDE 57

57

Application (of this cut == composition of 2 cuts) to Data

  • Relations :
slide-58
SLIDE 58

58

A similar procedure for the Cut (only 1 cut in variables of type Var_i_ß is enough) that separate e from µ : (Here just results of the best cuts found)

slide-59
SLIDE 59

59

Type of cut refers to any of the 20 sub-cuts to separate e from µ

slide-60
SLIDE 60

60

slide-61
SLIDE 61

61

slide-62
SLIDE 62

62

Some notes about e-µ separation

  • Many good cuts to separate e from µ.
  • Many cuts in LP-Vars are almost perfect. We expect that

electrons will almost never arrive at the LP so this is physically expected.

  • I believe that the best-cut (Hits_L8P) is enough for a very good

separation.

  • The best cuts to separate any e that may be in a µ sample

would be the ones with highest values of Eff*Pur:

slide-63
SLIDE 63

63

& for the Cut (again an intersection of 2 cuts ) to separate e from π …

slide-64
SLIDE 64

64

The Procedure for the PID would be

  • Considering that:

*Cut_i_j= Cut to separate species “i” from “j” *Cut_j_i = ~ Cut_i_j

  • & that the cuts “Cut_i_j” are already known:
  • ===> the way to do PID for π & e Folders of DR1 is:
slide-65
SLIDE 65

65

The way to apply the Tool

slide-66
SLIDE 66

66

(6)Conclusions

  • Estimations on the Composition of the Secondary Beam as well as

Efficient Tools for the Identification of specific kinds of particle species.

  • Importance: For MINERvA (To PID particles in its ECAL/HCAL region

in order to reconstruct Events), the Test Beam (to test the efficiency

  • f its beamline elements), the Accelerator Division & for comparisons

with a MC simulation of the secondary beam (in progress).

  • The usage of the variables Var_i_ß have proven to be useful and

agreed with the physical expectations.

  • There will not be perfect PID algorithms
  • The Efficiency-Purity analysis permits to look at any kind of particle

species that we think may be present in the secondary beam

  • The importance of my work is to show estimations and a specific way

to proceed in order to make up the Tool for particle isolation, since Data is not full calibrated yet.
