Particle dynamics
• Particle overview • Particle system • Forces • Constraints • Second order motion analysis
Particle system • Particles are objects that have mass, position, and velocity, but without spatial extent • Particles are the easiest objects to simulate but they can be made to exhibit a wide range of objects
Particle animation • Each particle has a position, mass, and velocity • maybe color, age, temperature • Seeded randomly at start • maybe some created each frame • Move each frame according to physics • Eventually die when some condition met
Sparks from a campfire • Add 2-3 particles at each frame • initialize position and temperature randomly • Move in specified turbulent smoke flow and decrease temperature as evolving • Render as a glowing dot • Kill when too cold to glow visibly
Rendering • Simplest rendering: color dots • Animated sprites • Deformable blobs • Transparent spheres • Shadows
A Newtonian particle • First order motion is sufficient, if • a particle state only contains position • no inertia • particles are extremely light • Most likely particles have inertia and are affected by gravity and other forces • This puts us in the realm of second order motion
Second-order ODE What is the differential equation that describes the behavior of a mass point? f = m a What does f depend on? x ( t ) = f ( x ( t ) , ˙ x ( t )) ¨ m
Second-order ODE x ( t ) = f ( x ( t ) , ˙ x ( t )) ¨ = f ( x , ˙ x ) m This is not a first oder ODE because it has second derivatives Add a new variable, v ( t ), to get a pair of coupled first order equations { ˙ x = v v = f /m ˙
Phase space x 1 x 2 Concatenate position and � x � x 3 velocity to form a 6-vector: = v v 1 position in phase space v 2 v 3 � ˙ � v � � First order differential equation: x = f ˙ velocity in the phase space v m
• Particle overview • Particle system • Forces • Constraints • Second order motion analysis
Particle structure Particle x position a point in the phase space v velocity f force accumulator mass m
Solver interface solver interface system solver 6 GetDim particle x x v Get/Set State v f v m Deriv Eval f m
Particle system structure system x 1 x 2 x n v n v 1 v 2 particles ... f n f 1 f 2 m n m 1 m 2 n time
Particle system structure solver system solver interface 6n GetDim particles x 1 x 2 x n n time Get/Set State . . . v 1 v 2 v n v 1 v 2 v n Deriv Eval f 1 f 2 f n . . . m 1 m 2 m n
Deriv Eval Clear forces: loop over particles, zero force accumulator Calculate forces: sum all forces into accumulator Gather: loop over particles, copy v and f /m into destination array
• Particle overview • Particle system • Forces • Constraints • Second order motion analysis
Forces • Constant • gravity • Position/time dependent • force fields, springs • Velocity dependent • drag
Particle systems with forces system x 1 x 2 x n v n v 1 v 2 particles ... f n f 1 f 2 m n m 1 m 2 n time ... forces F 1 F 2 F m
Force structure • Unlike particles, forces are heterogeneous (type-dependent) • Each force object “knows” • which particles it influences • how much contribution it adds to the force accumulator
Particle systems with forces system x 1 x 2 x n v n v 1 v 2 particles ... f n f 1 f 2 m n m 1 m 2 n time ... forces F 1 F 2 F m
Gravity x 1 x 2 x n Unary force: f = m G v 1 v 2 v n f 1 f 2 f n m 1 m 2 m n F Exerting a constant p force on each particle . . . sys apply_fun particle system G p->f += p->m*F->G
Viscous drag At very low speeds for small x 1 x 2 x n v 1 v 2 v n particles, air resistance is f 1 f 2 f n m 1 m 2 m n approximately: F p f drag = − k drag v . . . sys apply_fun particle system k p->f += p->v*F->k
Attraction Act on any or all pairs of particles, depending on their positions l f p = − k m p m q l x p | l | 2 | l | x q f q = − f p l = x p − x q
Attraction x p x q v p v q l f p = − k m p m q f p f q m p m q | l | 2 | l | F p sys apply_fun particle system k
Damped spring x p � � ˙ l · l l f p = − k s ( | l | − r ) + k d | l | | l | r f q = − f p | l | l = x p − x q x q
Damped spring x p x q v p v q � � ˙ l · l l f p f q f p = − k s ( | l | − r ) + k d | l | | l | m p m q F r p k d sys apply_fun particle system k s
Deriv Eval 1. Clear force accumulators x 1 x 2 x n v n v 1 v 2 2. Invoke apply_force ... f n f 1 f 2 functions m n m 1 m 2 ... F 1 F 2 F m 3. Return derivatives to solver � ˙ � v � � x = f ˙ v m
ODE solver Euler’s method: x ( t 0 + h ) = x ( t 0 ) + hf ( x , t ) x t +1 = x t + h ˙ x t v t +1 = v t + h ˙ v t
Euler step solver interface system solver x t +1 = x t + h ˙ x t GetDim 3. particles v t +1 = v t + h ˙ v t 4. 2. x 1 x 2 x n 5. Advance time Get/Set State . . . v 1 v 2 v n time 1. v 1 v 2 v n Deriv Eval Deriv Eval f 1 f 2 f n . . . m 1 m 2 m n
• Particle overview • Particle system • Forces • Constraints • Second order motion analysis
Particle Interaction • We will revisit collision when we talk about rigid body simulation • For now, just simple point-plane collisions
Collision detection Normal and tangential components x v T v N = ( N · v ) N N v N v T = v − v N v
Collision detection Particle is on the legal side if ( x − p ) · N ≥ 0 Particle is within of the wall if � x v T N ( x − p ) · N < � v N v Particle is heading in if p v · N < 0
Collision response Before After collision collision v � − k r v N v T v T v N v v � = v T − k r v N coefficient of restitution: 0 ≤ k r < 1
Contact Conditions for resting contact: 1. particle is on the collision surface 2. zero normal velocity If a particle is pushed into the contact plane a contact force f c is exerted to cancel the normal component of f N x v p f f N f T
• Particle overview • Particle system • Forces • Constraints • Second order motion analysis
Linear analysis • Linearly approximate acceleration a ( x , v ) ≈ a 0 − Kx − Dv • Split up analysis into different cases • constant acceleration • linear acceleration
Constant acceleration • Solution is v ( t ) = v 0 + a 0 t x ( t ) = x 0 + v 0 t + 1 2 a 0 t 2 • v ( t ) only needs 1st order accuracy, but x ( t ) demands 2nd order accuracy
Linear acceleration • When K (or D) dominates ODE, what type of motion does it correspond to? a ( x , v ) = − Kx − Dv � � � � � � � � d x 0 I x x = A = v − K − D v v dt • Need to compute the eigenvalues of A
Linear acceleration � � u 1 Assume is an eigenvalue of A , is the α u 2 corresponding eigenvector � � � � � � 0 I u 1 u 1 = α − K − D u 2 u 2 � � u The eigenvector of A has the form α u Often, D is linear combination of K and I (Rayleigh damping) That means K and D have the same eigenvectors
Linear acceleration � � u For any u , if is an eigenvector of A, following α u must be true � � � � � � 0 I u u = α − K − D α u α u Now assume u is an eigenvector for both K and D − λ k u − αλ d u = α 2 u � α = − 1 (1 2 λ d ) 2 − λ k 2 λ d ±
Eigenvalue approximation • If D dominates α ≈ − λ d , 0 • exponential decay • If K dominates √ � α ≈ ± λ k − 1 • oscillation
Analysis • Constant acceleration (e.g. gravity) • demands 2nd order accuracy for position • Position dependence (e.g. spring force) • demands stability but low or zero damping • looks at imaginary axis • Velocity dependence (e.g. damping) • demands stability, exponential decay • looks at negative real axis
Explicit methods • First-order explicit Euler method • constant acceleration: bad (1st order) • position dependence: very bad (unstable) • velocity dependence: ok (conditionally stable) • RK3 and RK4 • constant acceleration: great (high order) • position dependence: ok (conditionally stable) • velocity dependence: ok (conditionally stable)
Implicit methods • Implicit Euler method • constant acceleration: bad (1st order) • position dependence: ok (stable but damped) • velocity dependence: great (monotone) • Trapezoidal rule • constant acceleration: great (2nd order) • position dependence: great (stable and no damp) • velocity dependence: good (stable, not monotone)
What’s next?
• How do we enforce constraints on the particles? • Read (optional): Particle animation and rendering using data parallel computation, SIG90, Karl Sims
