Partial squeeze-film levitation modulates fingertip friction Controlling macroscopic friction in vivo Michal Wiertlewski, Rebecca Fenton Friesen, J. Edward Colgate why does touch matter? low friction Courtesy of R. Johansson, Umea University

slide-1
SLIDE 1

Michaël Wiertlewski, Rebecca Fenton Friesen, J. Edward Colgate

Partial squeeze-film levitation modulates fingertip friction

Controlling macroscopic friction in vivo

slide-2
SLIDE 2

low friction

why does touch matter?

2

Courtesy of R. Johansson, Umea University

slide-3
SLIDE 3

low friction

the role of shear force

3

slide-4
SLIDE 4

low friction

haptic interfaces

4

Controlling forces on the user via manipulandum

slide-5
SLIDE 5

5

flickr/ChaochaoX

slide-6
SLIDE 6

low friction

ultrasonic friction modulation

6 Watanabe and Fukui, 1995

slide-7
SLIDE 7

low friction

amplitude dependency

7

vibration amplitude

(µm)

friction coefficient 2 1

typical participant

1 2 3

artificial finger

α

slide-8
SLIDE 8

low friction

vibration modulation

8

slide-9
SLIDE 9

low friction

previous hypotheses : squeeze film

9

Watanabe and Fukui, 1995 Winfield et al. 2007 Biet et al. 2007

∂ ∂x ✓ ¯ u3p 12µ ∂p ∂x ◆ = ∂(p¯ u) ∂t

p

vibration lift air ow

α sin ωt u

slide-10
SLIDE 10

low friction

previous hypotheses : squeeze film

9

Watanabe and Fukui, 1995 Winfield et al. 2007 Biet et al. 2007

µ0 µ = 1 − fsq fn ∂ ∂x ✓ ¯ u3p 12µ ∂p ∂x ◆ = ∂(p¯ u) ∂t fsq = Z

S

p0 @ s u2 + 3

2α2

u2 − α2 − 1 1 A

p

vibration lift air ow

α sin ωt u

slide-11
SLIDE 11

low friction

near-field acoustic levitation

10

Chu and Apfel 1982 Hashimoto et al 1996

u ∝ s β fp α

slide-12
SLIDE 12

low friction

structure of the fingertip

11

skin collagen fjbers network bone

Persson et al. 2013 Pasumarty et al. 2011

slide-13
SLIDE 13

low friction

surface topography

12

3 4 5 6 7

  • 30
  • 28
  • 26
  • 24
  • 22
  • 20
  • 18
  • 16

log q (1/m)

red: dry 1 green: dry 2 blue: wet 1 H=0.75

log C (m

4)

Persson et al. 2013

slide-14
SLIDE 14

low friction

measurement real area of contact

13

Wiertlewski, M., Fenton Friesen R., Colgate, E., PNAS 2016

evanescent wave scattering ~300 nm

brightness friction force (N) 0.5 1 0.5 1

Wiertlewski, M., Fenton Friesen R., Colgate, E., PNAS 2016

slide-15
SLIDE 15

low friction

setup

14

Wiertlewski, M., Fenton Friesen R., Colgate, E., PNAS 2016

t stroboscopic illumination

camera

  • 30 kHz resonance frequency
  • pixel size of 10 µm
  • green light to limit diffusion
slide-16
SLIDE 16

low friction

variable friction

15

slide-17
SLIDE 17

low friction

contact mechanics

16

asperities height distribution

u0

urms

ps pr

Greenwood & Williamson 1966 Persson 2007

pr = pc e−u/urms

pc = 0.375 q0 urms E 1 − ν2

with

E = 20 MPa urms = 2.5µm q0 = 104m−1

slide-18
SLIDE 18

low friction

squeeze-film levitation

17

∂ ∂x ✓ ¯ u3p 12µ ∂p ∂x ◆ = ∂(p¯ u) ∂t

Reynold’s lubrication equation for laminar flow:

α small α large u u0

pa = p0 @ s u2 + 3

2α2

u2 − α2 − 1 1 A ≈ 5 4 p0 α2 u2

leads to : Salbu 1964 Minikes et al. 2004

if σ = 12ωµL2 p0u2 > 36

slide-19
SLIDE 19

low friction

equilibrium

18

p(r) p(r) α sin(ωt)

fjngertip applied pressure reaction from support squeeze fjlm pressure pa

pr

ps − pr = pa ps ⇣ 1 − e

−u+u0 urms

⌘ = 5 4 p0 α2 u2

2 4 6 8 10 initial gap

u0/urms u/urms

normalized film thickness

5

10 15

fixed pressure pr normalized amplitude α/urms

slide-20
SLIDE 20

low friction

relation to friction

19

Bowden and Tabor 1939 Persson 2007

apparent area

  • f contact

true area of contact

A = A0 e

−u+u0 urms

≈ A0 e

−α2 2Γ

ft = τ0 A

A/A0

0.2 0.4 0.6 0.8 1

relative area

0.2 0.4 0.6 0.8

1

normalized amplitude α/urms

slide-21
SLIDE 21

low friction

real area of contact

20

Wiertlewski, M., Fenton Friesen R., Colgate, E., PNAS 2016 Wiertlewski, M., Fenton Friesen R., Colgate, E., PNAS 2016

radial coordinate (mm) estimated pressure (kPa) 2 4 6 applied pressure 0.5 µm 1 µm 1.5 µm 2 µm squeeze film 5 10

  • 5

5 interfacial separation (µm)

A B

slide-22
SLIDE 22

low friction

model vs data

21

vibration amplitude

(µm)

friction coefficient 2 1

typical participant

1 2 3

artificial finger

α

slide-23
SLIDE 23

low friction

effect of moisture

22

slide-24
SLIDE 24

low friction

strobing

23

light strobe plate motion

slide-25
SLIDE 25

low friction

micro-second stroboscopy

24

slide-26
SLIDE 26

low friction

dynamic of the contact area

25

  • 2
  • 1

1 2 4 8

ωt

brightness plate displacement (µm)

π

0.6 0.7 0.8 0.9 1 2π RMS brightness variation (%)

m

fingertip dynamic vibrating plate x1 = α sin(ωt) squeeze film & asperities bt kt x2 = u + x1

brightness

∝ exp − u urms

2π/ω

slide-27
SLIDE 27

low friction

artificial fingers

26

Fenton Friesen R. Wiertlewski, M., Peshkin M.A, Colgate, E., Worldhaptics 2015

rigid skin backing alumium core

Rebecca Fenton Friesen

slide-28
SLIDE 28

low friction

artificial fingers

26

50 100 relative friction reduction (%) 0.3 0.7 1.1 linearized stifgness (N/mm) 0.4 0.2 0.1 coeffjcient of restitution 0.3 TangoPlus human fjnger BioTac DragonSkin

Fenton Friesen R. Wiertlewski, M., Peshkin M.A, Colgate, E., Worldhaptics 2015

Rebecca Fenton Friesen

slide-29
SLIDE 29

low friction

influence of damping in the tissues

27

nonlinear squeeze film asperity tips creating gap

α sin(ωt) ps

displacement (µm) −1 1 2 1 ms high damping factor

ζ = 0.1 ζ = 2.5

low damping factor

g >0 g

Fenton Friesen R. Wiertlewski, M., Colgate, E., Haptic Symposium 2016.

1 0.6 1.2 Average gap (µm)

ζ

0.1 10 damping ratio under-damped regime

slide-30
SLIDE 30

low friction

friction modulation under vacuum

28

amplitude (um) 0.5 1 1.5 2 2.5 3 relative friction 0.2 0.4 0.6 0.8 1 1 atm 0.5 atm 0.1 atm 0.02 atm experimental conditions

0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 44 45 46 47 48 49 50 51 52 amplitude (um) aligned motor current (mA) atmospheric vacuum stalled motor 1 0.5 estimated relative friction

Fenton Friesen R. Wiertlewski, M., Peshkin M.A, Colgate, E., Worldhaptics 2017

force sensor motor vacuum gauge vacuum pump actuating piezos sensing piezo nodal lines camera vacuum chamber finger

slide-31
SLIDE 31

low friction

lastest hypothesis : partial levitation

29

5µm throw cushioned impact max separation descent

30 µs time

slide-32
SLIDE 32

30

what can we do with it?

slide-33
SLIDE 33

31

slide-34
SLIDE 34

31

ultrasonic actuators glass plate

  • ptical sensor

led controller

slide-35
SLIDE 35

low friction

high-fidelity rendering

32

  • fast non-contact position sensor (8 µm - 5 kHz)
  • 6.25 points per cycle with vc = 250mm/s
  • 12 bit dac and linear amplifier
  • compensation filters

Daniele Leonardis

David Meyer

Wiertlewski, M., Leonardis D., Meyer, D., Peshkin, M., Colgate, E., Eurohaptics 2014.

modulation signal carrier friction force ultrasonic fjnger friction

a(t) ft(t) sin 2πf0t

driving signal

slide-36
SLIDE 36

low friction

vibration of texture

33

5 10 15 20 25 30 fjnger position (mm) −100 100 0.1 10 1 4 8 interaction force (mN)

  • spat. freq. (1/mm)
  • ampl. (mN)

Wiertlewski, M., Lozada,J., Hayward, V. IEEE Transactions on Robotics, 2011

slide-37
SLIDE 37

low friction

normal force modulation

34

  • J. Monnoyer, E. Diaz, C. Bourdin, M. Wiertlewski. Eurohaptics 2016

low friction high friction

Johansson & Flanagan 2009

slide-38
SLIDE 38

low friction

normal force modulation

35

  • J. Monnoyer, E. Diaz, C. Bourdin, M. Wiertlewski. Eurohaptics 2016.


falling friction normal force

5 10 0.5 1

n=14

normal force rising friction

0.5 1 5 10

n=9 no correlation

5 10 0.5 1

n=5 correlation p<5% friction variation (a.u)

Jocelyn Monnoyer

slide-39
SLIDE 39

low friction

conclusion

  • Friction carries rich tactile

information

  • Multi-scale model is useful to

capture the behavior of ultrasonic levitation

  • ongoing work to understand

sliding friction force fluctuations

  • in vivo friction is messy
  • large variability
  • multi-physics

36

conclusion

slide-40
SLIDE 40

low friction

acknowledgments

37

  • Stéphane Viollet
  • Jocelyn Monnoyer, Xi Lin
  • Viviane Gleizes, Nicolas Huloux, Di Chen

michael.wiertlewski@univ-amu.fr

  • Ed Colgate
  • Michael Peshkin
  • Rebecca Fenton Friesen
  • David Meyer,
