Overview and Highlights FZJ Andreas Lehrach, FZJ and RWTH Aachen Subtopic coordinator ARD ST2 March 6 th , 2019 5 th Annual MT Meeting Helmholtz Institute Jena 1 5 th Annual MT Meeting, March 5-7, 2018, Jena HZB A. Lehrach Outline I

slide-1
SLIDE 1
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

1

Andreas Lehrach, FZJ and RWTH Aachen

Subtopic coordinator ARD ST2

Overview and Highlights FZJ

March 6th, 2019 5th Annual MT Meeting Helmholtz Institute Jena

slide-2
SLIDE 2
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

2

Outline Introduction Progress

First deuteron EDM measurement at COSY Technical developments for proton EDM ring Developments at COSY for HESR and EDM Novel polarized proton source

Conclusion & Plans

slide-3
SLIDE 3
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

3

Measurements of charged particle EDMs from COSY to a prototype and final EDM storage ring

  • Ideal starting point for R&D work
  • Deliver first direct EDM

measurement for deuterons

  • Prototype EDM ring
  • Energy 35 - 45 MeV, CW-CCW beams
  • Pure electric and combined E/B
  • Length roughly 100m

Stepwise Approach for EDM

Cooler Synchrotron COSY Prototype EDM Ring  Design of a final EDM storage ring

slide-4
SLIDE 4
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

4

HIGHLIGHT: FIRST DEUTERON EDM MEASUREMENT PRECURSOR EXPERIMENT AT COSY

Copper electrodes Ferrite cage Belt drive for 90° rotation Vacuum vessel Beam position monitor

Waveguide RF Wien filter Glance into its inside Installation in COSY Commissioning: Spin rotation First ever deuteron EDM measurement

EDM Limits for COSY: Statistical sensitivity:

10-(23-24) e∙cm

Systematics due to Imperfections & alignment:

~ 10-19 e∙cm

EDM Precursor Experiment at COSY

slide-5
SLIDE 5
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

5

Design Study for Prototype EDM Ring

Beam Parameter for PT EDM Ring

  • A. Lehrach, S. Martin, R.M. Talman,

Design of a Prototype EDM Storage Ring, PoS(SPIN2018) 144.

slide-6
SLIDE 6
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

6

Challenge: Investigate/demonstrate the feasibility of ExB deflector for deuteron EDM storage ring with 10 MV/m and 0.3 T. Study breakdown behavior in presence of magnetic fields

Static ExB deflector

Commissioning in April this year

Different shapes of electrodes will be tested

Electrodes Feed- Throughs Actuators Shield-Tighteners

Setup of electrodes using existing ANKE Magnet Simulation of electron trajectories

with E field with ExB field

By

+

  • +
  • B-field: 0 T

Deflector Development

B-field: 0.15 T

slide-7
SLIDE 7
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

7

Stochastic Cooling

HESR slot-ring couplers

  • 1,5
  • 1
  • 0,5

0,5 1 5 10 15 17:16:48 17:19:41 17:22:34 17:25:26 17:28:19 17:31:12

beam current horizontal / vertical beam-size in mm time

PANDA Cluster-Target with Stochastic Cooling

without cooling with cooling

Successfully tested with PANDA cluster target at COSY

Plans:

  • Further development of the

slot ring couplers in terms

  • f aperture limitation,

frequency range and resonant design

  • Development of algorithms

to adjust stochastic cooling while cooling is in operation

  • Study of cooling structures

for colliding beams

  • Stochastic cooling with

weak focusing EDM lattice

Courtesy: Rolf STASSEN (FZJ) Poster by Nikolay SHURKHNO (FZJ)

slide-8
SLIDE 8
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

8

Plans:

Modeling

  • Cooler hardware
  • Cooling process
  • Compensation schemes

Improve transverse cooling Move 2 MeV cooler to HESR

– Benefits heavy ion operation

2438200 2438260 2438340 f / MHz

PANDA cluster target (reduced thickness, 3∙1014) e-cooling with 0.6 A

2438175 2438250 2438350 f / MHz

Successful electron cooling down to dP/P = 3.85∙10-5 Ie = 0.6 A, with barrier bucket P = 2425 MeV/c

Best e-cooling performance observed with fast stochastic transverse pre-cooling

10 min

Electron Cooling

Courtesy: Seva KAMERDZIEV (FZJ) Poster by Arthur HALAMA (FZJ)

slide-9
SLIDE 9
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

9

10 min

Precision Beam Control

Plans:

  • Beam instrumentation for HESR
  • Beam instrumentation developments for EDM

Enhanced orbit control

– Novel BPMs for EDM

Development @

– New BPM electronics – Orbit correction software

Automatic correction & feedback Developed together with industry partners

Tune measurement during ramping

Detailed and time-correlated archiving of beam parameters

Tune feedback in flat top and during acceleration Courtesy: Bernd LORENTZ (FZJ)

slide-10
SLIDE 10
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

10

Prototyping and Beam Physics

EDM accelerator component tests and experiments with spin at COSY

Deflector Development Beam and Spin Dynamics Siberian Snake COSY Polarized Ion Source

MT MT MT

2 MV Electron Cooler

MT

Prototype RF Wien Filter

MT

Beam Position Monitor Waveguide RF Wien Filter

MT & MU MU MU

Ion Source for ELENA at CERN

slide-11
SLIDE 11
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

11

Build in cooperation: IKP 2 and 4, PGI-6, and University of Crete

Method described in:

  • T. P. Rakitzis,

Chem.Phys.Chem. 5, 1489 (2004)

Lamb-Shift polarimeter

For measurement of nuclear polarization

  • R. Engels et al., Rev.Sci.Instrum. 74, 4607 (2003)

Nozzle

For HCl gas jet

IR/UV Laser

For photo-dissociation & polarization of H atoms, 100 mJ @ 1064 nm, 20 mJ @ 213 nm, 5 Hz, 170 ps

Development of a Novel Polarized Source

Nuclear polarized H atoms from HCl gas jet

Principle Assembly at IKP

Start of measurements: May 2018

slide-12
SLIDE 12
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

12

  • Participation in ATHENAh:

Polarized targets for proton and ion acceleration (and maybe, electrons)

Simulation results: Development of polarized targets:

  • Participation in ATHENAe:

kHz Betatron radiation source

Injection of as electron bunches from nm-sized solid targets into a wake field

Simulation results: Development of cluster targets:

Two new laser systems (JuSPARC I):

  • (40 mJ / 30 fs / 1 kHz)

for SOFT X-RAY MAGNETO OPTICS

  • (50 µJ / 100 fs / 10 MHz) for PHOTOELECTRON SPECTROSCOPY

Cooperation partners: FZJ, HHUD, WWU, Univ. of Crete, SIOM

Nuclear polarized H atoms from HCl jet Proton spin rotation during TNSA acceleration

Laser-Plasma Acceleration

Talk by Anna HÜTZEN (FZJ)

slide-13
SLIDE 13
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

13

Conclusion:

  • First deuteron EDM measurement at COSY
  • Conceptional design of Prototype EDM Ring
  • Technical developments (Deflector, BPMs, …)
  • Successful beam test at COSY for HESR and EDM

Plans:

  • Push limit for Deuteron EDM measurement at COSY
  • R&D work and technical design for prototype and final EDM storage ring
  • Advanced phase-space cooling and beam control for FAIR (and EDM)
  • Development of a novel polarized source

Conclusion & Plans

Deliverables for EDM Storage Rings:

  • Scientific Input for The European Strategy for Particle Physics (ESPP)
  • Executive Summary to CERN Physics Beyond Colliders (PBC)
  • Design Report for Proton EDM Ring
slide-14
SLIDE 14
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

14

Approach: EDM search in time development of spin in a storage ring: A magic storage ring for protons (electrostatic), deuterons, and helium-3 “Freeze“ horizontal spin precession; watch for development of a vertical component !

Search for Electric Dipole Moments

particle p (GeV/c) E (MV/m) B (T) proton 0.701 16.789 0.000 deuteron 1.000

  • 3.983

0.160

3He

1.285 17.158

  • 0.051

One machine with r ~ 30 m B

slide-15
SLIDE 15
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

15

  • All Dipoles produced, tested in Jülich and 65% are delivered to FAIR
  • Quadrupoles are all produced in Jülich
  • Two assembly lines for the quadrupole groups in the arcs are in

preparation

  • Sextupoles, steerers and their power converters are in

production(Romania), magnets arriving continuously in Jülich

  • Nearly all other power converters are produced, in Jülich.
  • RF equipment is in mechanical design
  • Stochastic cooling equipment, Beam diagnostics and Injection

kickers are in production

Status of HESR at FAIR

High-Energy Storage Ring (HESR) in time and budget

slide-16
SLIDE 16
  • A. Lehrach

5th Annual MT Meeting, March 5-7, 2018, Jena HZB

16

20 mJ @ 213 nm 100 mJ @ 1064 nm Alignment of HCl bonds Photo-dissociation and polarization of the H nucleus Acceleration of the protons in gas jet 300 J @ 800 nm ~ c

lide 16

Production of Polarizted Proton Beams
