Our mission We provide Metal and Plastic parts and combine them in Mechatronic Manufacturing Solutions (MMS) for various application areas We are a reliable partner during the product life cycle for customers with a focus on technology and

slide-1

SLIDE 1

slide-2

SLIDE 2

Our mission

Corporate presentation

We provide Metal and Plastic parts and combine them in Mechatronic Manufacturing Solutions (MMS) for various application areas We are a reliable partner during the product life cycle for customers with a focus

n technology and innovation

“We Industrialize Your Idea”

slide-3

SLIDE 3

Our company strategy

Corporate presentation

➢Engineering & Manufacturing ➢Metal & Plastic & Decoration technologies ➢Creating integrated modules/ products ➢Worldwide production facilities ➢One roof concept ➢Joint focus on worldwide customer support ➢Reliability and Trust “Powerful in Metal-Plastic Combinations”

slide-4

SLIDE 4

Worldwide production

Corporate presentation

slide-5

SLIDE 5

KeyTec Netherlands presentation

slide-6

SLIDE 6

Our company

KeyTec Netherlands presentation

➢ Established in 1999

➢ Small series & Mass production ➢ Floorspace 9000m2 ➢ 90 colleagues ➢ Metal & Plastic & Assembly ➢ IATF16949 and ISO13485 since 2008 ➢ Sales 14 M€ (2017)

KeyTec Netherlands B.V. in Sittard

slide-7

SLIDE 7

Our capabilities in High Volume Metal

KeyTec Netherlands presentation

High volume precision components: ➢ Flat stamping, deep drawing, bending ➢ Presses 25T to 250T ➢ All special alloys, ➢ Thickness 0.1-5.0 mm ➢ Progressive dies, Bihler, Butting ➢ Tolerances +/- 0,01 mm ➢ < 10 PPM level ➢ 100 % Vision inspection.

slide-8

SLIDE 8

Our capabilities in Small Series Metal

KeyTec Netherlands presentation

.

Low volume metal forming: ➢ Flat stamping, deep drawing, extrusion, bending, turning and milling ➢ Laser cutting ➢ Presses from 5T up to 250T ➢ Material Thickness 0.05 - 4.0 mm ➢ Tolerances up to +/- 0.01mm ➢ Special materials like Invar, 100% Ni, 100% Sn, Mo, O2 free copper, FeNiCo Ti, and others

slide-9

SLIDE 9

Our capabilities in Insert Molding

KeyTec Netherlands presentation

➢Insert and Over Moulding ➢Precision Parts ➢Product weight of < 0.1 gram possible ➢Presses from 15T up to 250T ➢Engineering plastics (incl. LCP, PEI) ➢PPM level < 10

slide-10

SLIDE 10

Our capabilities in Assembly

KeyTec Netherlands presentation

➢Laser and Ultrasonic welding ➢Glueing ➢Automated & Manual Assembly ➢Testing

slide-11

SLIDE 11

Our Project phase

KeyTec Netherlands presentation

➢ Options for pre-tooling samples ➢ DFM & Feasibility check ➢ Focus on short tooling leadtime ➢ 100% vision inspection ➢ Testing

slide-12

SLIDE 12

Our Tooling

KeyTec Netherlands presentation

➢Partners in both Europe and Asia Pacific ➢Leadtime for T1 samples ➢PPAP & Run at Rate ➢R & M in House

slide-13

SLIDE 13

Our organisation

KeyTec Netherlands presentation

➢IATF 16949 automotive certification ➢ISO 13485 medical certification ➢ISO 14000 environmental certification ➢100% customer specific products ➢Sister companies in Czech Republic and China

slide-14

SLIDE 14

Our equipment

KeyTec Netherlands presentation

➢ Molding machines with mechanisation (5 to 250T) ➢ Metal presses for progressive dies (25 to 250T) ➢ Modular Metal presses (5 to 250T) ➢ Bihler machines ➢ Butting machines (Jouhsen) ➢ CNC and manual Turning ➢ Degreasing, Deburring and Washing ➢ Laser welding equipment (Trumph) ➢ US welding, Hot insertion, Soldering ➢ Bolt insertion ➢ Glueing (include UV) ➢ In house Repair & Maintenance ➢ 3D Measuring (Zeiss, Keyence)

slide-15

SLIDE 15

Our customers

KeyTec Netherlands presentation

slide-16

SLIDE 16

Metal-Glass connection

KeyTec Netherlands presentation

➢ Specific metal alloys ➢ Dedicated process ➢ Heat treatment and cleaning ➢ Low and high volume applications ➢ Isotropy in thermal expansion. Application = Solar, X-ray, Medical, Radar, Night Vision

slide-17

SLIDE 17

Connector pins

KeyTec Netherlands presentation

➢ Pre- and post plated pins ➢ Simultaneous thread tapping ➢ 100% Vision control possible ➢ High speed Bruderer and Kaiser presses

slide-18

SLIDE 18

Busbars & Terminals

KeyTec Netherlands presentation

➢ Different alloys, pre- and post plated ➢ On reel or in bulk.

slide-19

SLIDE 19

Springs

KeyTec Netherlands presentation

➢Progressive dies ➢Manufacturing from coils. ➢Precision/Complex geometries

slide-20

SLIDE 20

Brackets

KeyTec Netherlands presentation

➢ Incl. KTL treatment ➢ Incl. Nutwelding ➢ 250 T Press ➢Short leadtime for tooling

slide-21

SLIDE 21

Insert Moulded parts

KeyTec Netherlands presentation

➢ From reel or by robot ➢ In house stamping & moulding ➢ In line testing & vision inspection

slide-22

SLIDE 22

Assembly for Medical Devices

KeyTec Netherlands presentation

➢ ISO 13485 certified ➢ In house moulding & metal stamping/deepdrawing ➢ Assembly, Testing, Packaging with traceability ➢ US Welding, Glueing, Soldering

slide-23

SLIDE 23

Moulding for Hybrid/Electrical applications

KeyTec Netherlands presentation

➢ Different Materials ➢ Insertion.

slide-24

SLIDE 24

Butting

KeyTec Netherlands presentation

Brass and NiFe alloys; ➢ Pre- and postplated; ➢ With or without in-line milling; ➢ High volumes, high output (1 Billion pcs/yr); ➢ Demanding quality performance; ➢ Dedicated production environment. ➢ Dedicated cleaning Application = Battery Pin

slide-25

SLIDE 25

Scan engine module

KeyTec Netherlands presentation

➢ Laserwelding ➢ UV cured glueing ➢ Semi clean room ➢ Automated assembly ➢ Functional testing

Application = Optical module for bar code scanner

slide-26

SLIDE 26

Responsibilities

KeyTec Netherlands presentation

➢ 40% energy consumption reduction in 5 years ➢ 90% water consumption reduction in 10 years ➢ 90% waste reduction in 10 years. ➢ Returnable or cardboard packaging. ➢ Focus on minimal raw material usage + recycling. ➢ Participate in renewable energy industry (solar). ➢ Maximize usage of evaporating oil in metal stamping. ➢ Challenging, safe and pleasant working environment. ➢ Participation in social employment.

slide-27

SLIDE 27

The end

THANK YOU

KeyTec Netherlands presentation
