Organic Oil Recovery (OOR)

Technical Overview

1

Organic Oil Recovery (OOR)

• 1. The Science.
• 2. The Benefits.
• 3. The Process.
• 4. The Results.
• 5. Re-Starting Idle Producers.
• 6. Value Creation
• 7. Reservoir Monitoring

2

Organic Oil Recovery (OOR)

• 1. The Science

3

Introduction - What Does it Do?

• Production Increase Through Applied Microbiology.
• OOR – The ‘Next Generation’ of The Science.
• Increase Reserves.
• Revives Shut-In Producers.
• Sweetens Fields and Reduces H2S.
• True Enhanced Production, Not Accelerated – Added!

4

Introduction – Reliable Science

• Mixed Track Record, Plugging
• Added Foreign Biology
• Sugar Based Nutrients / Aerobic
• Progressive Souring
• Corrosion Issues
• Emulsification (Hyper Nutrition)
• Short Lived Production Spikes
• Unsustainable Energy Requirement

MEOR (1st Generation)

• > 94% Treatment Success Rate
• Managed Down-Hole Ecology
• 100% Organic, Profiled to Well
• Progressive Sweetening
• Zero Corrosion (Anaerobic)
• Full Formation Ingress
• Stable 1-3 Year Production Step
• Over 300 Safe Treatments

OOR (2nd Generation)

5

Oil Water Interface

6

Oil Water Interface

7

Oil Water Interface

Flow 30 cm/day Pore Throat Oil Interactive Microbes 24 Hours Between Photomicrographs

Oil Micro-Droplet Formation is the Release Mechanism

8

Improved Recovery Factor

Pore Scale Displacement – is improved

• Interfacial Tension – between oil and water decrease as the oil interactive resident

microbes be come hydrophobic and they are pushed by the water to the oil/water interface.

• Improved Oil Mobility – Smaller micro droplets can more easily move through the pore

matrix and be recovered

• Wettability – Oil droplets are more easily released from the reservoir surfaces

Sweep Efficiency – is improved

• Micro Emulsion Formation - can lead to improved diversion of water which in turn can lead

to improve displacement of oil from previously upswept regions.

Improved Recovery and Water Cut Decrease

9

SPE Papers Published by Titan Customers

These papers verify 22 well tests. Average production increase above 250%.

10

Organic Oil Recovery (OOR)

• 2. The Benefits

11

OOR Benefits

• Substantial Increases in Oil Production.
• Recoverable Reserves Increase.
• Field Net Present Value Increases.
• Significant Increase in Cash Flow.
• Deferral of Well Abandonment.

OWS – ‘Organic Well Sweetening’ OWC – ‘Organic Wellbore Cleaning’ ORT – ‘Organic Reservoir Tracing’

Reservoir Economy Reservoir Ecology

12

OWS - Pushing out the SRB’s

Organic Well Sweetening

13

OWC – 4 X Increase - California

Organic Well Clean-Up

14

OWC – Single Producer Effect

1 10 100 1000 1993 1995 1997 1999 2001 2003 2005 2007 2009 2011 2013 2015

Barrels / Day Well 16-17-08W5 Alberta, Canada

Oil Water Treatment Forcast

Organic Well Clean-Up

15

ORT – Organic Reservoir Tracing

• Monitor Reservoir Fluid Movement
• Utilized Morphology and DNA
• Highly Measurable Population Increases
• Large Volumes OK
• No Chemicals or Radioactive Materials
• Unique In Situ Microbiology

Organic Reservoir Tracing

16

ORM – Managing Reservoir

• Understand Comingling Fluids
• Monitor Progressive Reservoir Souring
• Chemical Interaction Affects
• Fluid and OOR Sweep Improvements
• Information for Chemical Management

Organic Reservoir Management

17

Organic Oil Recovery (OOR)

• 3. The Process

18

OOR – Five Step Process

• 1. Field Screening of Reservoir Characteristics.
• 2. Laboratory Analysis – DNA Analysis.
• 3. In-Situ Microbial Response Analysis (ISMRA).
• 4. Targeted Water Flood Implementation.
• 5. Full Field Application.

19

Step 1 - Screening

• Oil gravity from 14-41 API.
• Water pH between 6-8.
• Current Reservoir Temperature Less than 95 C.
• Formation Water Salinity of Less than 140,000 ppm TDS.
• Field Pressure History, more than 25% of Original.
• Reservoir Porosity of more than 20% of formation volume.

(higher the better in general)

• Reservoir Permeability of greater than 7.5 millidarcies.

(higher the better in general)

The OOR ‘Sweet Spot’

20

Step 1 - Screening

• Well Understood Geology (mapping).
• Good Water Injection History, Indicated Response.
• Current Well Completion Diagrams.
• Oil and Water Production Records.
• Chemical Treatment History.
• Full H2S History.

Ideal Data Profile

21

Step 2 - Laboratory Analysis

• Titan Sampling Kit at Well Location.
• Samples Collected by Customer Personnel.
• Sample Kits Designed to Maintain & Log Transit Temperature.
• Samples Currently Shipped to Lab in California. (UK 2018)
• Processed in the Lab to Map Microbial Life Cycle & DNA.
• Lab Reports are Typically Issued within 4 Weeks.

Verifying Reservoir Biology

22

Step 3 – ISMRA

• The nutrient package is blended.
• Nutrients are delivered in a partially filled 1000 liter tote.
• Blended with 100 barrels of clean production water.
• Displaced with 150% of the tubing or casing volume.
• Production well is shut in for 7 days.
• Well Restarted Sampling:
• daily over the first week
• One per week for a month
• Once per month following
• An ISMRA lab and production report is provide with

recommendations for next steps.

Proving Microbial Response

23

Step 4 - Targeted Water Flood

• ISMRA Wells Selected with Offset Producer.
• Larger Volumes of Nutrients Tailored to the Field.
• Injector Shut in for 2 Days Gradually Retuned to Full Rate.
• Three Treatments, 4 to 6 Weeks Apart.
• Sampling at Offset producers to Establish Baseline.
• Samples are taken from Offset Producers Weekly, until

Production Increases Kick In – Thereafter every second Day for Two Weeks.

Initiating the Production Increase

24

Step 5 - Full Field Application

• Occurs when targeted water flood shows a clear positive
• il production response.
• Bi-weekly well samples are taken to monitor field

production.

• Further injection treatment will typically occur every 3 to 4

months based on microbial response.

Monitoring & Maintaining the Production Increase

25

Organic Oil Recovery (OOR)

• 4. The Results

26

Global Results

48 Commercial Oil Fields, Four continents. Over 300 OOR Well Applications

Treatment Summary Number of Number of Number of Success Oil Type Treatments Wells Increases Rate Increase

In- Situ Producer Test 49 47 36 73% 140% Producers 19 18 17 89% 133% Injectors 238 81 234 98% 54% Total 306 146 287 94% 92%

27

Organic Oil Recovery (OOR)

Venoco Gail

28

Offshore Large Volumes

29

Organic Oil Recovery (OOR)

California 2

30

Offshore Long Term Oil Cut California Offshore Well Response Over 3 Years

31

Organic Oil Recovery (OOR)

Related Case Studies

32

Canada Producer Impacts

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 1 10 100 Jul 2012 Jan 2013 Jul 2013 Jan 2014

WC BOPD

Field 42 - Saskatchewan, Canada

33

Canada Producer Impacts

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 1 10 100 Jul 2012 Jan 2013 Jul 2013 Jan 2014 Jul 2014

WC BOPD

Field 43, Well 2 - Saskatchewan, Canada

34

Canada Injector Impacts

35

Canada Injector Impacts

1.00E+05 1.00E+06 1.00E+07 1.00E+08 1.00E+09 1.00E+10 1.00E+11 1.00E+12 1 10 100 2009 2010 2011 2012 2013 2014

Oil Interactive Microbes(#/ml) Barrels/Day

Field 33, Well 1 - Saskatchewan, Canada

Oil Produced Injector Treatment Producer Treatment Microbial Count 36

Onshore Project $11 Million of Incremental Oil Revenue

• ver First 4

Years, Still Accruing!

37

Organic Oil Recovery (OOR)

• 5. Re-Starting Idle Wells

38

Idle Well Retuned to Production

39

In Pattern Well Brought to Life

5 10 15 20 25 30 35 40 45 50

Barrels of Oil / Day

0S 2 Well BOPD SPE PAPER 129742 Dead California Well (Shut-in since 2003) Returned to Production After the Titan Process Injector Treatment

• n 5/1/2008

40

Organic Oil Recovery (OOR)

• 6. Value Creation

41

Value Created for Customers

• Oil Fields Can Be Tested Easily and Inexpensively.
• Low Cost Field Trials, Zero CapEx
• Minimal Risk Profile. (HSE & Operational)
• Substantial Increase in Oil Production.
• Reserves Increase -
• Field Net Present Value Increases.
• Significant Increase in Cash Flow.
• Return Idle Wells to Production.
• Deferral of Well Abandonment.

42

OOR vs Polymer

• Large CAPEX
• 2-3 Year Implementation
• Issues Limited Platform Space
• Large Volume of Product
• Increased Viscosity of Fluid
• Well Bore Plugging Issues
• Unstable Above 70°C
• Potential Disposal & Aquatic Issues

Polymer

• No CAPEX
• 6 Months to Implement
• Only Totes and Pressure Pump
• Low Volume Supplemental
• Negligible Viscosity Changes
• Well Bore Cleaning Effect
• Stable up to 95°C
• No Disposal or Aquatic Issues

OOR (2nd Generation)

43

Organic Reservoir Monitoring (ORM)

• 7. Reservoir Monitoring

44

Valuable Information

Titan Oil Reservoir Monitoring Services

• Genetic analysis of your reservoirs microbial families and species
• DNA and RNA analysis
• Population densities and biosphere analysis
• Ecological Changes over time to understand future impacts

including:

• H2S
• Production issues
• Well completion issues
• Top side equipment issues
• Chemical treatment requirements
• Oil quality issues

45

Thank You

Colin Hill, Ph.D. Microbiologist and Chief Scientist

Chris Venske

Business Development Engineer, TEK-HUB christopher.venske@hunting-intl.com t +44 (0)1224 787123 m +44 (0)7587 035262
