Orange County Public Schools Pershing / Pine Castle K8 100% Design and Land Use update Community Meeting August 28, 2017 Superintendent Dr. Barbara Jenkins Chief Facilities Officer John Morris Orange County Public Schools Pershing /

slide-1
SLIDE 1

Orange County Public Schools

Superintendent Dr. Barbara Jenkins Chief Facilities Officer John Morris

Pershing / Pine Castle K8 100% Design and Land Use update Community Meeting August 28, 2017

slide-2
SLIDE 2

Orange County Public Schools Pershing / Pine Castle K8 100% Design and Land Use Community Meeting Agenda

August 28, 2017, Pine Castle-Pershing Elementary School, 6:00 PM

  • Welcome – Linda Kobert – School Board Member
  • Introductions & Land Use Update – Tyrone Smith
  • Project Update –Architect: Zyscovich Architects
  • 208-K8-SE-3 Pershing K8
  • Questions and Answers
  • Adjournment

2

slide-3
SLIDE 3

Orange County Public Schools

Where we are today……

3

 Technical Review Group (TRG) Pre-Application Meeting  Application submitted and found sufficient for review  Community Meeting (Required per Public School Siting Regulations)  Comments on initial submittal due to OCPS  TRG meeting  Development Review Committee meeting – Sept. 6  Planning & Zoning Commission public hearing – Oct. 19  Board of County Commissioners public hearing – Nov. 14

slide-4
SLIDE 4

Orange County Public Schools

Land Use Plan

  • Request to change the use

from residential uses to K8 school

  • Buffers shall comply with

PSSR’s

  • Setbacks shall comply with

Orange County code

  • Access to site will be from

the existing ingress, with egress on Pershing Avenue

  • “Daytime Visitor Access”

entrance added on Pershing Avenue

4

  • Bus access will be from Pershing

Avenue

  • Pedestrian Access from Gatlin Oaks

Lane

slide-5
SLIDE 5

Orange County Public Schools

5

N

Proposed 208-K8-SE-3 Pershing K8 Site

Pershing Avenue Overlake Avenue March Ave.

Potential traffic calming devices along Overlake and March Avenues

slide-6
SLIDE 6

Orange County Public Schools

9

N

Conceptual 208-K8-SE-3 Pershing K8 Site

3-story admin/ media/ classroom 2-story classroom 1-story dining Arts wing Daytime Visitor Access Only

slide-7
SLIDE 7

Orange County Public Schools

10

208-K8-SE-3 Pershing K8

B U I L D I N G

slide-8
SLIDE 8

Orange County Public Schools

11

Sustainability

208-K8-SE-3 Pershing K8 is designed to meet Green Globes sustainable building standards Sustainable Features Include: Site

  • Native/low water plants – reduce water consumption
  • Low Impact Design (LID) stormwater design

Building

  • 10% more energy efficient than ASHRAE 90.1 standard
  • High Efficiency Chillers (8% energy reduction)
  • Light colored roof to reduce heat gain and improves energy

performance

  • Energy Star rated equipment
  • Water saving toilets, faucets, and fixtures
  • Most general classrooms have daylighting
  • Thermal efficient windows/glazing
  • Fully automated building controls system
slide-9
SLIDE 9

Orange County Public Schools

12

Site Perspective

slide-10
SLIDE 10

Orange County Public Schools

13

Perspective (looking east on Pershing Ave.)

slide-11
SLIDE 11

Orange County Public Schools

14

Perspective (looking southeast on Pershing Ave.)

slide-12
SLIDE 12

Orange County Public Schools

15

Perspective (looking southwest on Pershing Ave.)

slide-13
SLIDE 13

Orange County Public Schools

Example – Reception Area

16

slide-14
SLIDE 14

Orange County Public Schools

Example – Media Center

17

slide-15
SLIDE 15

Orange County Public Schools

Example – Collaborative Area

18

slide-16
SLIDE 16

Orange County Public Schools

Example – Multi-Purpose Room

19

slide-17
SLIDE 17

Orange County Public Schools

Example – Gymnasium

20

slide-18
SLIDE 18

Orange County Public Schools

Example – Classrooms

21

slide-19
SLIDE 19

Orange County Public Schools

Example – Music

22

slide-20
SLIDE 20

Orange County Public Schools

Example – Art

23

slide-21
SLIDE 21

Orange County Public Schools

Example – Skills Lab

24

slide-22
SLIDE 22

Orange County Public Schools

Example – Hardcourt

25

slide-23
SLIDE 23

Orange County Public Schools

208-K8-SE-3 Pershing K8 Schedule

2017 2019

Today Apr Jul Oct 2018 Apr Jul Oct 2019 Apr Jul

School Opens

April 2017 - Sept 2017

Design & Construction Documents

Sept 2017 – Dec 2017

Permit & GMP

  • Jan. 2018 – Jun. 2019

Construction

School Opens 2019

Early Package: DEMO

  • Nov. – Dec. 2017

June 2017 - Nov 2017

Land Use Entitlements

slide-24
SLIDE 24

Orange County Public Schools

27

THANK YOU!

Thank you to Orange County taxpayers for the ½ penny sales tax, which makes this construction possible.

slide-25
SLIDE 25

Orange County Public Schools

QUESTIONS?

28
