Oracle ESB Header Support

Slide 3

ES B Header S upport

• Use Cases

– Files, JMS , AQ, MQ, B2B, Apps

• Header Transformation

– Uses XS L Transformations – XS L variables – New XPATH Get/ S et Header functions – Minimal GUI S upport

• Header Based Routing

– Uses Filter Expressions

Slide 4

One Way Invocation

• Request Header
• Outbound Header

Routing Service F X Request Header Outbound Header Propagate

Slide 5

Two Way Request/ Reply Invocation

• Inbound Response Header
• Response Header

Routing Service Response Header Inbound Response Header Pass-through X

Slide 6

Header Transformation

• S

upported using XS LT extension functions

• User can read/ get Request headers and Inbound

Response Headers

• User can write/ set Outbound headers and Response

Headers

• Namespace for all the extension functions is :

http://www.oracle.com/XSL/Transform/java/oracle.tip .esb.server.headers.ESBHeaderFunctions

Slide 7

Header Transformation Extension Functions

• 1. String getRequestHeader(String xpathExpression,String namespaceDecl)
• 2. void setOutboundHeader(String xpathExpression,String value, String namespaceDecl)
• 3. String getInboundResponseHeader(String xpathExpression,String namespaceDecl)
• 4. void setResponseHeader(String xpathExpression,String value, String namespaceDecl)

Where, xpathExpression : XPath expression to get/set value : value to be set for the xpathExpression namespaceDecl : namespace declarations in the form ‘prefix=namespace;’

Slide 8

Header Transformation Example

Example: To read ‘ fileName’ header from an inbound file adapter message

// Declare extension function’s namespace in the XSL file as <xsl:stylesheet version="1.0“ …. xmlns:ehdr=http://www.oracle.com/XSL/Transform/java/oracle.tip.es b.server.headers.ESBHeaderFunctions exclude-result-prefixes=“…”> // Read ‘fileName’ from the header <xsl:variable name="GET_INFILENAME" select="ehdr:getRequestHeader( '/fhdr:InboundFileHeaderType/fhdr:fileName', 'fhdr=http://xmlns.oracle.com/pcbpel/adapter/file/;’)” />

Slide 9

Header Transformation Example

Example: To write ‘ fileName’ header to an outbound file adapter message

// Declare extension function’s namespace in the XSL file as <xsl:stylesheet version="1.0“ …. xmlns:ehdr=http://www.oracle.com/XSL/Transform/java/oracle.tip.es b.server.headers.ESBHeaderFunctions exclude-result-prefixes=“…”> // Write ‘fileName’ from the header <xsl:variable name="SET_OUTFILENAME" select="ehdr:setOutboundHeader('/fhdr:OutboundFileHeaderType/fhdr :fileName', $GET_INFILENAME, 'fhdr=http://xmlns.oracle.com/pcbpel/adapter/file/;')"/>

Slide 10

Header Based Routing

• S

upported using XPath extension functions

• User can add filters using Request headers and Inbound Response Headers
• S

yntax is same as that for the current filter expressions. { filterExprssion };{ namespaceDeclaration }

• Namespace for all the extension functions is :

http://www.oracle.com/XSL/Transform/java/oracle.tip.esb.server.headers.E SBHeaderFunctions

• Following XPath extension functions are added
• 1. String getRequestHeader(String xpathExpression)
• 2. String getInboundResponseHeader(String xpathExpression)

Where, xpathExpression : XPath expression to read the header

Slide 11

Header Based Routing Example

Example: To check if ‘ fileName’ read by inbound file adapter message is Payload.xml

// Check if ‘fileName’ from the header is ‘Payload.xml’ // Filter Expression will look like

{ehdr:getRequestHeader('/fhdr:InboundFileHeaderType/fhdr:fileName‘) == ‘Payload.xml’};{ namespace ehdr= http://www.oracle.com/XSL/Transform/java/oracle.tip.esb.server.headers.E SBHeaderFunctions namespace fhdr=http://xmlns.oracle.com/pcbpel/adapter/file/}

Slide 12

Dynamic S OAP Endpoint Example

Example: To dynamically override the outbound S OAP endpoint, set the Location header to http:/ / localhost:7777/ esb in your XS L as shown below.

ESB XSL CODE <xsl:variable name="LocationIn" select="'http://localhost:7777/esb'" /> <xsl:variable name="LocationOut" select="ehdr:setOutboundHeader('/shdr:ESBHeader/shdr:location', $LocationIn, 'shdr=http://xmlns.oracle.com/esb;')"/>

This functionality requires SOA/ESB 10.1.3.3 or a 10.1.3.1 patch

Slide 13

Known Limitations

• S

et Header() functions support only following types of Xpath expr

– Absolute Path - / Customer/ Address/ Zip – Indexing - / Customer/ Address[2]/ Zip – if Address[1] is not already present in the target document, it will be created. – JMS Custom properties supported with the following syntax

• Get “ Property[position()=1]/@name”
• S

et “ Property[@name=&quot;Country&quot;]/@value”

– Get and S etHeader functions used inside XS L must not have opaque inputs/ outputs

• Limited S

OAP support

– ‘ Header’ element will be set as header – User has to use XPath expressions starting with header element –

• eg. ‘ / Header/ Message/ Priority’
• Limited Tooling support

Slide 14

File Header Demo JDeveloper

• File to File
• Filter routes only if input Filename = ‘Mobile.xml’
• Transform propagates filename to output adapter

Slide 15

File Header Demo XPATH Filter

Filter Expression

ehdr:getRequestHeader('/fhdr:InboundFileHeaderType/fhdr:fileName') = 'Mobile.xml'

Slide 16

File Header Demo XS LT

XSL Variables Design View

INFILENAME, OUTFILENAME

Slide 17

File Header Demo XS LT

XSL Variables Source View

INFILENAME, OUTFILENAME

… <xsl:variable name="INFILENAME" select="ehdr:getRequestHeader('/fhdr:InboundFileHeaderType/fhdr:fileName','fhdr=http://xmlns.oracle.com/pcbpel/adapter/file/;')"/> <xsl:variable name="OUTFILENAME" select="ehdr:setOutboundHeader('/fhdr:OutboundFileHeaderType/fhdr:fileName', $INFILENAME, 'fhdr=http://xmlns.oracle.com/pcbpel/adapter/file/;')"/> …

Slide 18

File Header Demo Runtime

Slide 19

File Header Demo Instructions

1 – Unzip ESBHeader.zip from “training\sampledata” folder to c:\temp 2 – Start JDeveloper 3 – Select existing ESBSamples project 4 - Open “C:\temp\ESBheader\HeaderSupportDemo\HeaderSupportDemo.jpr” 5 – Register with ESB Server 6 – Observe new service metadata in ESB Console under System “TVox” 6 – Copy C:\temp\ESBheader\*.xml files to C:\temp\ESBheader\in 7 – Observe both files deleted but only Mobile.xml in Out dir 8 – View in ESB console Instance data Note: The C:\temp location is hard coded in both adapters. You can unzip to another location and then run the file adapter wizards to change the location.

Slide 20

Additional Header Info

Adapter Namespace In Properties Out Properties XPATH Example

JMS

http:/ / xmlns.oracle.com/ pcbpel/ adapter/ j ms/ j msAdapterInboundHeader.wsdl

JMS CorrelationID JMS DeliveryMode JMS Expiration JMS MessageID JMS Priority JMS Redelivered JMS Type JMS Timestamp JMS ReplyTo

j msAdapterOutboundHeader.wsd

JMS DestinationName JMS DestinationProperties JMS CorrelationID JMS Type JMS ReplyTo

('/ j hdr:JMSInboundHeadersAndProper ties/ j hdr:JMSInboundHeaders/ j hdr:J MS CorrelationID') = 'HIGH'

File

http:/ / xmlns.oracle.com/ pcbpel/ adapter/ file/ fileAdapterInboundHeader.wsdl

filename directory

fileAdapterOutboundHeader.wsdl

Filename

('/ fhdr:InboundFileHeaderType/ fhdr: fileName') = 'Mobile.xml'

AQ

http:/ / xmlns.oracle.com/ pcbpel/ adapter/ aq/ in bound/ aqAdapterInboundHeader.wsdl aqAdapterInboundHeader.xsd

MessageId Priorit y Correlation Attempts EnqueueTime OrigMessageId

aqAdapterOutboundHeader.wsdl aqAdapterOutboundHeader.xsd

Priorit y Delay Expiration Correlation RecipientList ExceptionQueue

S OAP

http:/ / schemas.xmlsoap.org/ soap/ envelope/ Custom Custom Location ('/ soap:Header/ ns1:country') = ‘ US‘ (‘ / shdr:ES BHeader/ shdr:location’ )

Other adapter examples: S

ee BPEL S amples and Adapter OTN Pages
