Optimization

CS3220 - Summer 2008 Jonathan Kaldor

Problem Setup

• Suppose we have a function f(x) in one

variable (for the moment)

• We want to find x’ such that f(x’) is a

minimum of the function f(x)

• Can have local minimum and global

minimum - one is a lot easier to find than the other, though, without special knowledge about the problem

Problem Setup

• Can find global minimum for certain types of

problems

• Our focus: general (possibly nonlinear)

functions, and local minima

• Finding x’ such that f(x’) is minimal over

some local region around x’.

Constrained Versus Unconstrained

• Most general problem statement: find x’

such that f(x’) is minimized, subject to constraints g(x’) ≤ 0

• Function g(x) represents constraints on the

solution (can be equality or inequality constraints)

• Our focus: unconstrained optimization (so

no g() function)

Applications

• Many applications in sciences
• Energy Minimization
• Function representing the energy in a

system

• Find the minimum energy - stable state of

system

Applications

• Minimum Surface Area
• Given some shape, find the minimum

surface that matches at the boundaries

• Real life example: take some shape and dip

it into bubble solution. Bubble solution takes the shape of the minimum surface

Applications

• Planning and Scheduling
• Schedules for sports teams
• Finals schedules
• Typically solving constrained optimization

problems (we’ll look at unconstrained problems only)

Applications

• Protein Folding
• Image Recognition
• ... and many, many more

Bisection Method

• Suppose we have an interval [a,b] and we

would like to find a local minimum in that interval.

• Evaluate at c = (a+b)/2. Do we gain anything
• Answer: no (don’t have any idea which

interval the minimum is in

Bisection Method

a c b

Trisection Method

• If we divide up our interval into three

pieces, though, we can tell which interval has a minimum

• Suppose we have a < u < v < b. Then if f(u)

< f(v), we know that there is a local minimum in the interval [a,v]

• Similar case for f(v) < f(u), local minimum in

[u,b]

Trisection Method

• So we evaluate at u = a + (b-a)/3 and v = a +

2*(b-a)/3. Suppose f(u) < f(v), and our new interval is [a,v]

• The u we computed before is the midpoint

between a and v. We can’t reuse the function value on the next step, so we need to evaluate our function twice at every iteration

Trisection Method

• Note: we aren’t restricted to choosing u and

v evenly spaced between a and b

• Can we choose u and v such that we can

reuse the computation of whichever one doesn’t become an endpoint at the next step?

Trisection Method

• More accurately, suppose we are at [a0, b0],

and we compute u0, v0. Our next interval happens to be [a0, v0], and we now need to compute u1, v1. Can we arrange our u’s and v’s such that u0 = u1 or u0 = v1?

• Note: this will allow us to save a function

evaluation at each iteration

Golden Section Search

• Define h = ρ(b - a). This is the distance of
• ur u and v from the endpoints a and b.

Thus, u = a + h, v = b - h.

• We want to find ρ so that u0 is in the

correct position for the next step.

Golden Section Search

1 v0 u0 v1 u1 ρ 1-ρ 1-ρ

Golden Section Search

1 v0 u0 v1 u1 ρ 1-ρ 1-ρ ρ 1-ρ 1-ρ 1 =

Golden Section Search

• Given the relation between the ratios, we

can then compute the desired value of ρ: ρ = 1 - 2ρ + ρ2 ρ2 - 3ρ + 1 = 0 ρ = (3 - √5)/2 = 2 - ϕ ≈ 0.382 where ϕ is the golden ratio (again)

Convergence

• At every iteration, we compute a new

interval 61.8% the size of the old one

• Larger than the interval we compute

during bisection, but smaller than the interval we compute using trisection

• End up needing around 75 iterations to

reduce error in our bounds to epsilon

Existence / Uniqueness

• If our function is unimodular on the original

interval [a,b] (has only one minimum) then we will converge to it.

• If the function has multiple local minima in

the interval, we will converge to one of them (but it may not be the global minimum)

Sidestep: Calculus (again)

• Suppose we have some function f(x), and we

want to find the critical points of f

• Minima, maxima, and points of inflection
• Critical points are where f’(x) = 0
• Minima: f’(x) = 0, f’’(x) > 0

Maxima: f’(x) = 0, f’’(x) < 0 Point of inflection: f’(x) = f’’(x) = 0

Sidestep: Calculus (again)

• So, we want to find roots of f’(x)
• We can use the root finding strategies we

already talked about!

• In particular, we can use Newton’s Method

applied to f’(x). Our linear approximation is then f’(x+h) = f’(x0) + f’’(x0) h

• So h = -f’(x0) / f’’(x0)

Newton’s Method

• Another way of deriving it: suppose we are

at a point x0. When we wanted to find the root, we took a linear approximation to the function at that point, since it was easy to find the root

• What function is easy to find a minimum of?

A quadratic function! So take the quadratic approximation of f at x0

Newton’s Method

• f(x+h) = f(x0) + f’(x0) h + f’’(x0) h2 /2
• We can compute the minimum of this

function by taking the derivative with respect to h and solving.

• End up with h = - f’(x0) / f’’(x0)
• Note: same answer either derivation

Newton’s Method

• We gain all of the benefits (and drawbacks)
• f Newton’s Method
• In particular, we have no guarantee of

convergence if we don’t start reasonably close to the minimum

• We have the added wrinkle that we may

not even converge to a minimum (could converge to maximum or inflection pt)
