OpenStack in the European Open Science Cloud

Enol Fernández

EGI Foundation

Jérôme Pansanel

IPHC

Boris Parák

CESNET

… … … …

→

• …
• …
• …
• …

EGI is a federation of National e-infrastructures

22 countries + 1 EIRO (CERN) EGI Foundation (Amsterdam, NL): coordination body https://www.egi.eu/about/egi-foundation

EGI: largest distributed e-infrastructure in the world

70,600 computing cores; 356 PB disk & 380 PB tape storage 666 open research publications from Jan 2018 (OpenAIRE stats)

EGI Service Catalogue

The list of services that EGI as a federation offers. Full details at https://www.egi.eu/services

EGI Cloud Federation (aka FedCloud)

• Multi-cloud IaaS with Single Sign-On based on Virtual Organisations (VO)

○ Allows research communities to bring computing near their data ○ Allows providers to easily support international collaborations

• Federation features:

○ VO-scoped Virtual Machine Image catalogue with replication across providers ○ Centralised usage accounting ○ Resource discovery ○ Availability/Reliability monitoring ○ Unified GUI dashboard ○ Supporting diverse IaaS technology: OpenStack, OpenNebula and Synnefo

Federated dashboard

EGI Cloud Federation infrastructure

20 providers supporting 11 SLAs:

• 15 OpenStack
• 4 OpenNebula (2 of them moving to OpenStack)
• 1 Synnefo (moving to OpenStack)

Growing this year with the EOSC-hub project and other related EOSC activities:

• 6 new OpenStack providers in the pipeline

Looking to expand beyond academic providers

EGI FedCloud at IPHC

The Hubert Curien Pluridisciplinary Institute

• A 400 person research institute based in Strasbourg - FRANCE
• Covering a large array of scientific domains (from particle physics to ecology)
• Hosting a scientific computing platform called SCIGNE
• For more information, visit our website: http://www.iphc.cnrs.fr

The SCIGNE platform

• A platform for on-demand scientific computing
• Managed by a team of 8 engineers
• Several collaborations (University of Strasbourg, CNRS, France Grilles,

French Bioinformatics Institute, CERN and EGI)

• Provides several services (grid and cloud computing, data management, disk

and tape storage, ...)

• Additional informations available on https://www.grand-est.fr

The OpenStack Cloud Infrastructure

• Started in 2013 with OpenStack Grizzly
• CentOS 7 & OpenStack Pike (RDO)
• 520 cores and 3.5 TB RAM (edge-scale)
• 300 TB storage for Cinder powered by CEPH
• Used for scientific computing (no CPU overallocation, NVIDIA GPU, ...)
• Available through the CLI and the Web dashboard (Horizon)
• Configured and maintained with Quattor - https://www.quattor.org
• Federated to the EGI, France Grilles and IFB Clouds
• Availability > 99 %

Integration into the EGI Federated Cloud - 1/2

• Certified in 2015
• Extensive documentation (previously hosted on the EGI wiki) -

https://egi-federated-cloud-integration.readthedocs.io/en/latest/

• Following EGI components in use:

○ EGI Checkin, Keystone-VOMS (single sign-on) ○ cASO / APEL (centralised usage accounting) ○ Cloudkeeper and Cloudkeeper-OS (image synchronization with the VO-scoped catalogue) ○ Cloud-info-provider (resource discovery)

Integration into the EGI Federated Cloud - 2/2

• The components are mostly easy to install and configure
• Cloudkeeper is also used by the French Cloud federation (FG-Cloud)
• Take care when upgrading OpenStack!
• Some hacks required with recent version of OpenStack (OOI/OCCI is not an

independant service)

• This issue will be solved in the short term (OCCI is not mandatory anymore)

FedCloud use cases and projects

• EGI use cases hosted at IPHC

○ ELIXIR, Biomed, NBIS, ... ○ Life and health sciences ○ Managed through SLA (also for opportunistic access) ○ Running on resources funded by France Grilles and IFB

• Several projects are ongoing

○ Deployment of EGI Notebook service ○ Development of a new version of Cloudkeeper-OS ○ Container-as-a-service at the European scale ○ Lease manager for VMs (os-vm-expire, openstack-lease-it) ○ Creation of an on-demand tensorflow service

Moving to OpenStack

Partners in Cloud

• National centre operating computing and data storage infrastructure
• Emphasis on experimental use of e-infrastructure resources for research
• Involved with ELIXIR, BBMRI, West-life, et al.
• e-Infrastructure established by public universities in Czech Republic
• Network, compute, and data services for research
• Involved with GÉANT, EGI, EOSC-hub, ELIXIR, et al.

Legacy Infrastructure

• Offering HPC cloud resources to communities from multiple disciplines
• Integrated in EGI Federated Cloud, ELIXIR Compute Platform
• Resources

○ 6k CPU cores ○ 65 TB of RAM ○ Local RAIDs and Ceph / IBM Spectrum Scale ○ 250 hypervisor nodes ○ GP GPU and SR-IOV InfiniBand ○ Both provider and overlay networks

• Running on OpenNebula, 7+ years

Motivation

• OpenStack APIs de facto standard
• Large existing ecosystem of tools
• Popular demand, mostly international communities
• Growing demands on service portfolio diversification

Rules

• Try to learn as much as possible
• Train a new team of flying cloud-monkeys
• Avoid vendor lock-in ‒ software or hardware
• Dead-ends are expected, within reason
• Experimental features are allowed
• Uptime and reliability are not everything
• Push for production in one year, Q1/2019
• Try not to get murdered by angry users

Technical Titbits

• Deployment in containers, from The Kolla Project
• Custom tooling mixing puppet and ansible, minimalistic
• Adventures with OVN (networking-ovn for Neutron)
• Fun and games with federated identity from multiple IdPs

Stay Tuned!

What are we missing in OpenStack?

• Overall quite happy :), but would appreciate:
• Better support for federation

○ Hierarchical projects auto-provisioning ○ Better OpenID Connect support

• Deprovisioning
• Better documentation on how OpenStack services interact
• Better tracing of user actions (e.g. for auditing)
• Nicer policy management

Become a provider

https://www.eosc-hub.eu/join-as-service-provider

Levels of Integration

Internal Catalogue

Supporting services. Federation Services

External Catalogue

Services from participating e-Infrastructures Thematic services Other services wishing to participate in EOSC-hub Level of Integration

HIGH MEDIUM LOW

EOSC-hub SMS

More information about the Service Catalogues: https://wiki.eosc-hub.eu/display/EOSC/EOSC-hub+service+catalogue HIGH

Support EOSC-hub processes (SPM, SLM, CRM, RDM, SACM, ISM, ISRM)

Provider responsiblitlies

Follow EOSC-hub processes

Run own SMS and integrate with EOSC (SPM, SLM, CRM, RDM, SACM, ISM, ISRM)

External SMS

EOSC-hub establishes key elements for European Open Science Cloud

• First set of services, including the EGI Cloud Federation
• Service request, provisioning and management processes

OpenStack is the main IaaS technology in the current EOSC landscape and will keep growing in the near future EOSC-hub is open to new providers, join us!

Conclusions

Thanks! Questions?

Backup

EOSC Objectives Actions Increase the ability to exploit research data across scientific disciplines and between the public & private sector > Publish, discover, access services and resources for all scientific disciplines > Open to national, regional, pan-European providers, and supports different exploitation models (e.g. free at point of use, commercial) Increase interoperability, interconnect the existing and the new research digital infrastructures across Europe > Provide thematic services integrated with European compute/data platforms for data exploitation > Single sign on, integrated access and order Support open science > Services to share and discover research artefacts (publications, datasets, software, workflows etc.), research artefacts data sources (publication repositories, publishers, data archives, software archives, etc.)

Some of the usage of EGI Cloud
