SLIDE 1
Open-Source Web Server Identification In The IPv4 Address Space: Side-Channeling HTTP
Ruben van der Ham • 04.07.2019
Overview
- Background
- Pipeline
- Identification
- Evaluation
- Conclusion
Open-Source Web Server Identification In The IPv4 Address Space: - - PowerPoint PPT Presentation
Open-Source Web Server Identification In The IPv4 Address Space: - - PowerPoint PPT Presentation
Open-Source Web Server Identification In The IPv4 Address Space: Side-Channeling HTTP Ruben van der Ham 04.07.2019 Background Pipeline Overview Identification Evaluation Conclusion Background RFC2616 Server:
SLIDE 2
SLIDE 3
Background
RFC2616
- Server: CERN/3.0 libwww/2.17
- Purpose not in the spec
- Present on ~81.6% of observed HTTPS servers
- > Can we identify the other ~18.4%?
SLIDE 4
Motivation
Why?
- Discloses vulnerabilities
- Patch cycle estimation
- Determine effectiveness of
hidden banners
- Determine if servers are
‘lying’
Why not?
- Script kiddies don’t care
about the Server header, they bruteforce
SLIDE 5
Pipeline
1. The dumping run 2. The identification run
SLIDE 6
Pipeline - Dumping
Old approach
- Zmap -> scanTool -> CSV/SQLite
New approach
- Zmap -> Zgrab -> Zgrab2db -> SQLite DB
SLIDE 7
Pipeline - Dumping
SLIDE 8
Pipeline - Identification
identificationTool
- Golang
- CPU bound
- Basic identification
- geoIP
- CVE+CVSS
SLIDE 9
SLIDE 10
Identification
- Baseline determination
- Request
SLIDE 11
Identification: baseline
- Docker containers, debian based compiled from source
- Concurrent Golang tool fires requests and generates overview
HTTP(S) servers
- Nginx
- 1.16.0, 1.14.0, 1.9.0, 1.6.0
- Apache 2.4.39
- Lighttpd 1.4.53
SLIDE 12
Identification: Requests
Request Identification Properties Index Date header pos, Default index, Etag Delete Date header pos, Status code, status text, Default error page Malformed HTTP Status code, HTTP version, Etag Random request type Date header pos, HTTP version, Status code, Default error page
SLIDE 13
Evaluation
- Planning
- Results
SLIDE 14
Evaluation - Planning
Pipeline
Wasted time with scanTool. Could have invested resources in an all-in-one tool.
Identification
Very limited -> needs to cover more versions and types
General
More thinking less programming
SLIDE 15
Evaluation - Numbers
HTTP
Amount of servers in Zmap: 43M Total amount of servers: 36M
HTTPS
Amount of servers in Zmap: 45M Total amount of servers: 29M?
delete 34M index 36M malformed http 34M random request type 33M delete 24M index 25M malformed http 21M random request type 24M
SLIDE 16
Conclusion
- It seems to be effective to hide
the banner
- This needs much more research
- More (statistics) will follow...
SLIDE 17
Questions, feedback, remarks?
Thank you for your time!
