Open IPTV Forum (OIPF) http://www.oipf.org Jan Lindquist (Ericsson) OIPF Members Network CE/Mobile/Home Public Network Service / Content Technology Operators Device Vendors Infrastructure Providers Providers Ericsson Internal |

SLIDE 1

Open IPTV Forum (OIPF)

http://www.oipf.org

Jan Lindquist (Ericsson)

SLIDE 2

Ericsson Internal | 2010-08-24 | Page 2

OIPF Members

Public Network Infrastructure Technology Providers Network Operators CE/Mobile/Home Device Vendors Service / Content Providers

SLIDE 3

Ericsson Internal | 2010-08-24 | Page 3

Standardization

a success factor for IPTV mass market

› Standardization landscape fragmentation › Market dominated by proprietary solutions › Interoperable specifications needed to establish IPTV market growth

Open IPTV Forum works towards an interoperable IPTV solution

IPTV CPE - Home Devices IMS - Control Layer

e2e

Service Layer Transport

SLIDE 4

Ericsson Internal | 2010-08-24 | Page 4

OIPF Strengths

› Flexible organization to facilitate go-to-market activities complementing the specification development

– Interoperability Centers – Certification programs – Pilot deployments – Regional specific features

› Global organization containing representatives from all key stake-holders in the IPTV area

– Network providers, CE/Home/Mobile device manufactures, Network Infrastructure providers, Content & Service providers and Technology providers

SLIDE 5

Ericsson Internal | 2010-08-24 | Page 5

OIPF References

(http://www.oipf.org/specifications.html)

› Release 2:

– Functional Architecture V2.0 ( PDF 3.26 MB) - 2009/09/08 – Service and Platform Requirements V2.0 (PDF, 269KB) - 2008/12/12 – Services and Functions for Release 2 V1.0 (PDF, 56KB) - 2008/10/20

› Release 1:

– Volume 1 - Overview V1.1 (PDF, 400 KB) - 2009/10/08 – Volume 2 - Media Formats V1.1 (PDF, 101 KB) - 2009/10/08 – Volume 3 - Content Meta Data V1.1 (PDF, 371 KB) - 2009/10/08 – Volume 4 - Protocols V1.1 (PDF, 1.2 MB) - 2009/10/08 – Volume 5 - Declarative Application Environment V1.1 (PDF, 1.6 MB) - 2009/10/08 – Volume 6 - Procedural Application Environment V1.1 (PDF, 535 kb) - 2009/10/08 – Volume 7 - Authentication, Content Protection and Service Protection V1.1 (PDF, 919 kb) - 2009/10/08 – Profiles specification V1.0 (PDF, 233 kb) - 2009/10/08 – V1.1 Errata 1 (PDF, 203 KB) - 2010-07-27 – V1.1 XML Schemas (ZIP. 113KB) - 2010-07-27 – Release 1 DAE Reference Guide (PDF, 409KB) - 2010/03/11

SLIDE 6

Ericsson Internal | 2010-08-24 | Page 6

Technical Working Groups : Requirements WG Architecture WG Solution WG IOT WG

OIPF Structure

Platform & Service Requirements Functional Architecture Work In Progress: Reference Implementation & Interoperability Testing Solution Workgroup Task Forces : Procedural Application Environment TF Declarative Application Environment TF Protocols TF Metadata TF Content & Service Protection TF Media Formats TF Specification Volume # 2 3 4 5 6 7

SLIDE 7

Ericsson Internal | 2010-08-24 | Page 7

Terminal Reference Architecture

Capabilities Media Playback Content Service Protection Configuration Content Download IMS Messaging Presence Chat Application Manager (Widgets) CoD Metadata Notification Gateway Discovery/Control Parent Rating and Control Scheduled Recording Remote Management Scheduled Content and hybrid tuner Playback FavouriteL ChannelScan Native Applications HTML Applications OS Graphics User Interface Platform Components SVG Applications HTML engine SVG engine DAE Functional Components

OITF

SLIDE 8

Sample Use Cases

›Personalization ›Seamless experience across Devices ›Red button

SLIDE 9

Ericsson Internal | 2010-08-24 | Page 9

Personalized Services

Incoming call: +46702674156

Incoming call pop up Remote parent control Personalization

SLIDE 10

Ericsson Internal | 2010-08-24 | Page 10

Seamless experience across devices

SLIDE 11

Ericsson Internal | 2010-08-24 | Page 11

Red Button
