Online Quality Control of Polymers and Extruded Films Oliver - - PowerPoint PPT Presentation
Online Quality Control of Polymers and Extruded Films Oliver - - PowerPoint PPT Presentation
TAPPI 11th European PLACE Conference, Athens 2007 Online Quality Control of Polymers and Extruded Films Oliver Hissmann 1 Contents Introduction Online Quality Control in Polymer Plants Technology, Benefits, Online Lab, Close Loop
SLIDE 2
SLIDE 3
3
Online „Closed Loop Control“-Concept
Sampling Feedback Raw material Additives
Process
Production On-line Quality Assurance Process computer Determination of the process parameters Data (opt. measuring technique)
SLIDE 4
4
Principal of Online Quality Control
Gloss Measurement Gel Counter Thickness Measurement Haze Measurement Polymer Analysis by FTIR Spectroscopy Measurements on Extruded Films Film Extrusion
Blown Film / Cast Film
Pellets Color Measurement Pellets and Powder Inspection Pellets Throughput Measurement Pellets Size and Shape Distribution Melt Index Measurements on Pellets Pellet Preprocessing
Dedusting / Drying
Pellet Transport System
Pellet Sampling and Transport
Production of Polymer Pellets
SLIDE 5
5
Benefits of Online Control
Process Control
(Optimisation, capacity, cleaning, waste)
Product
(better quality, customer satisfaction/relation, less claims, more competitive products)
SLIDE 6
6
Pellets Color Measurement
PCM Measurement of LAB Color Values and Yellowness Index
Pellets and Powder Inspection
PS 25C, PS 25, PS 2 PT 2 Detection and Evaluation of Impurities in Pellets and Powder
Pellets Throughput Measurement
PTM Weight Measurement of the inspected Pellets
- ver the time
Pellets Size and Shape Distribution
PSSD Measurement of Size and Shape of the Pellets Detection of Twin, Triple and Multiple Pellets
Measurements on Pellets
Online Measurement of Pellets
SLIDE 7
7
Pellet Scan System
CCD-Camera Lighting unit Hopper Pellet stream
SLIDE 8
8
Pellet Scan System
SLIDE 9
9
Pellet Size & Shape Distribution
Lighting unit Hopper Pellet stream CCD-Camera
SLIDE 10
10
Pellet Size & Shape Distribution
SLIDE 11
11
Pellet Size & Shape Distribution
SLIDE 12
12
Pellet Colour Measurement
visible light color measuring device visible light
SLIDE 13
13
Online Measurement on Extruded Films
Gel Counter
Detection and Evaluation of Gels, Fish Eyes, Black Specs
Polymer Analysis by MID-IR Spectroscopy
Measurement of Additive Contents and Physical Properties by IR-Light Transmission Through Extruded Films
Gloss Measurement
Measurement of Gloss of Extruded Films
Haze Measurement
OHM Measurement of Haze and Transmission
- f Extruded Films
Thickness Measurement
TMD Measurement of Films Thickness
Measurements on Extruded Films Film Extrusion
Blown Film Cast Film
SLIDE 14
14
Online Quality Control
SLIDE 15
15
Online Integrated Measurement Solution
SLIDE 16
16
Online Integrated Measurement Solution
SLIDE 17
17
Online Gel Count
SLIDE 18
18
Online Gel Count
SLIDE 19
19
Defect Types
Gels Black Specs Contaminations
SLIDE 20
20
Web Inspection in Film Extrusion
100 % Optical Control of the Web
Photo of every defect Position of every defect Database Interface Reports Alarms
SLIDE 21
21
Benefits of Web Inspection
Process Control
(Optimisation, capacity, cleaning, waste)
Raw Material
(Optimisation material + recipe, control material)
Product
(better quality, customer satisfaction/relation, less claims, more competitive products)
SLIDE 22
22
Origin of Defects in Extrusion
Extrusion Line (screw geometry / dead zones) Resin (contamination, recipe) Production Process (extruder temperatures, screen change)
SLIDE 23
23
Defect Types in Film Extrusion
Gels Black Specs Contaminations Die Lines Insects Lamination Defects Oil Stains Fish Eyes etc.
SLIDE 24
24
Web Inspection System
Embedded Multiple Camera Solution
SLIDE 25
25
Embedded Solution Technology
High Speed CCD Line Scan Cameras 80 – 160 MHz, 512 – 8192 Pixel Embedded PC with High Speed Framegrabber Windows XP Server (network) Exact information on defects within the web (mosaics, position, alarms, protocols, storage)
SLIDE 26
26
Quality Reports / Alarming
Single Defect Trend Defects (20 gels per m²) Slit Defects Repeating Defect Gel Shower / Cluster Roll Defects
SLIDE 27
27
Rolling Map / Die Defect
SLIDE 28
28
Time History (Gel Level)
SLIDE 29
29
Mosaic View
SLIDE 30
30
3-D Defect Analysis
SLIDE 31
31
Lane Distribution
SLIDE 32
32
Die Defect
SLIDE 33
33
Calander Defect
SLIDE 34
34
Alarms / Repeaters
SLIDE 35
35
Teach-In Function - Fly
SLIDE 36
36
Teach-In Function – Oil Stain
SLIDE 37
37
Teach-In Function - Gel
SLIDE 38
38
Teach-In Function – Black Spec
SLIDE 39
39
Inspection Systems
SLIDE 40
40
Inspection Systems
SLIDE 41
41
Closed Frame
SLIDE 42
42
Interrelationship and Correlation Example
Online Compound Control (Gel Analysis) Oracle Database Integration Decision for Film Extrusion Quality (Grading) 100 % Web Inspection in Cast Line (Diaper Breathable Film)
SLIDE 43
43
Online Container for Plant Control (Example)
SLIDE 44
44
SLIDE 45
45
SLIDE 46
46
Gel Shower
SLIDE 47
47
Online Anticipation of Plant Shut Down
Start injection cleaning agent Plant shut down
SLIDE 48
48
Online Transition Control
Start extruder cleaning
Stop injection cleaning agent Stop extruder rinsing
SLIDE 49
49
Online Control of Extruder Start Up
Extruder startup after plant restart, start extruder cleaning
Stop injection cleaning agent Stop extruder rinsing
SLIDE 50
50
Summary
Close Loop Online Control (Process + Grading) is today‘s Standard in Polymer Plants 100 % Web Inspection in Film Extrusion Different Defect Types, but close Interrelation Working Together avoids Problems and improves Film Quality
