one coin, two sides: the microwave and gamma-ray haze Greg Dobler (KITP/UCSB) one coin, two sides: the microwave and gamma-ray haze Greg Dobler (KITP/UCSB) the Fermi haze from DM annihilation: halo shapes and anisotropic diffusion Greg Dobler

slide-1
SLIDE 1

Greg Dobler (KITP/UCSB)

  • ne coin, two sides:

the microwave and gamma-ray haze

slide-2
SLIDE 2

Greg Dobler (KITP/UCSB)

  • ne coin, two sides:

the microwave and gamma-ray haze

slide-3
SLIDE 3

Greg Dobler (KITP/UCSB)

the Fermi haze from DM annihilation:

halo shapes and anisotropic diffusion

slide-4
SLIDE 4

Greg Dobler (KITP/UCSB)

Ilias Cholis (NYU) Neal Weiner (NYU)

the Fermi haze from DM annihilation:

halo shapes and anisotropic diffusion

slide-5
SLIDE 5

Greg Dobler (KITP/UCSB)

Ilias Cholis (NYU) Neal Weiner (NYU) Doug Finkbeiner (Harvard/CfA) Tracy Slatyer (Harvard/CfA) Tongyan Lin (Harvard/CfA)

the Fermi haze from DM annihilation:

halo shapes and anisotropic diffusion

slide-6
SLIDE 6

the Fermi haze

Fermi 2-5 GeV

slide-7
SLIDE 7

the Fermi haze

Fermi 2-5 GeV

slide-8
SLIDE 8

the Fermi haze

Fermi 2-5 GeV

two robust features:

. elongated in b with an axis ratio ~1.7 . spectrum is harder than elsewhere

slide-9
SLIDE 9

the Fermi haze (spectrum)

Fermi 2-5 GeV

spectrum is consistent with IC emission from a hard population of electrons

. amplitude/shape can be fit model-independently . consistent with leptonic DM annihilations

slide-10
SLIDE 10

the Fermi haze (spectrum)

Lin, Finkbeiner, & Dobler (2010)

slide-11
SLIDE 11

the Fermi haze (morphology)

Fermi 2-5 GeV

morphology... much more difficult:

. north/south “edge”? . what happens towards the center?

slide-12
SLIDE 12

haze residuals

slide-13
SLIDE 13

haze residuals

SFD Uniform Haslam Bubbles 0.5<E<1.0 GeV Uniform GALPROP (modified)

slide-14
SLIDE 14

haze residuals

SFD Uniform Haslam Bubbles 0.5<E<1.0 GeV Uniform GALPROP (modified)

slide-15
SLIDE 15

hourglass or oval?

line of sight gas density issues?

slide-16
SLIDE 16

hourglass or oval?

line of sight gas density issues?

slide-17
SLIDE 17

hourglass or oval?

line of sight gas density issues?

slide-18
SLIDE 18

hourglass or oval?

line of sight gas density issues?

slide-19
SLIDE 19

hourglass or oval?

line of sight gas density issues?

slide-20
SLIDE 20

Fermi haze morphology

  • w x
slide-21
SLIDE 21

Fermi haze morphology

  • w x
slide-22
SLIDE 22

Fermi haze morphology

very little “pinching”, but… slightly under- subtracted disk, noisier significant “pinching”, but… over-subtracted disk, less noisy

slide-23
SLIDE 23

Fermi haze morphology

let’s run with this one for now...

does an IC signal from DM annihilation electrons produce this shape???

slide-24
SLIDE 24

dark matter IC morphology

not for “typical” diffusion parameters, but...

slide-25
SLIDE 25

dark matter IC morphology

not for “typical” diffusion parameters, but...

slide-26
SLIDE 26

dark matter IC morphology

not for “typical” diffusion parameters, but...

slide-27
SLIDE 27

dark matter IC morphology

not for “typical” diffusion parameters, but... for anisotropic diffusion yes!!!

slide-28
SLIDE 28

anisotropic diffusion via ordered fields

electrons travel along ordered magnetic fields, we motivate anisotropic diffusion by including both turbulent and ordered components: diffusion coefficients along r and z are related to the ratio of ordered vs turbulent field

slide-29
SLIDE 29

three IC components

slide-30
SLIDE 30

three IC components

starlight IC infrared IC CMB IC + +

slide-31
SLIDE 31

three IC components

starlight IC infrared IC CMB IC + +

template fitting may “soak up” star and IR components leaving a more hourglass-like shape...

slide-32
SLIDE 32

Fermi haze residuals

Cholis, Dobler, & Weiner, in prep

slide-33
SLIDE 33

Fermi haze residuals

Cholis, Dobler, & Weiner, in prep

slide-34
SLIDE 34

Fermi haze residuals

Cholis, Dobler, & Weiner, in prep

slide-35
SLIDE 35

Fermi haze residuals

Cholis, Dobler, & Weiner, in prep

slide-36
SLIDE 36

Fermi haze spectrum

Cholis, Dobler, & Weiner, in prep

  • anisotropic diffusion
  • prolate Einasto, q=2/3
  • Mχ=1.2 TeV, XDM, χχ->e+e-
  • Sommerfeld boost = 70
slide-37
SLIDE 37

conclusions

  • the Fermi haze has two unique features:

. morphology (elongated in b with respect to l) . spectrum (harder than elsewhere in the Galaxy)

  • particle DM models can reproduce the spectrum of IC

emission and amplitude with cross-section enhancement

  • morphology is more subtle but doable

. a spherical DM halo with isotropic diffusion provides a poor fit . a prolate DM halo with anisotropic diffusion provides a reasonable fit

  • outstanding issues:

. upper/lower “edge” (the most tricky part!!!) . morphology (bubbles? oval? templates to use?) . synchrotron polarization
