On the integrality gap of hypergraphic Steiner tree relaxations

Neil Olver

Department of Mathematics, MIT

Aussois, January 2012 Joint work with Michel Goemans, Thomas Rothvoß and Rico Zenklusen.

Steiner tree

T erminals Steiner nodes

2 / 29

Approximation results

• Perf. guarantee

Folklore 2 Zelikovsky [1991] 11/6 ≤ 1.83 Berman & Ramaiyer [1991] 16/9 ≤ 1.78 Zelikovsky [1993] 1 + ln(2) + ε ≤ 1.70 Karpinski & Zelikovsky [1997] ≤ 1.65 Prömel & Steger [2000] 5/3 ≤ 1.67 Hougardy & Prömel [1999] ≤ 1.59 Robins & Zelikovsky [2005] 1 + ln(3)/2 ≤ 1.55 Byrka, Grandoni, Rothvoß, Sanità [2010] ln(4) + ε ≤ 1.39

3 / 29

Hypergraphic relaxations

◮ Different (but equivalent) relaxations:

◮ Warme [1998] (we’ll use this one). ◮ Polzin and Vahdati-Deneshmand [2003]. ◮ Könemann, Pritchard and T

an [2009].

◮ All have a variable for each component.

4 / 29

Hypergraphic relaxations

◮ Different (but equivalent) relaxations:

◮ Warme [1998] (we’ll use this one). ◮ Polzin and Vahdati-Deneshmand [2003]. ◮ Könemann, Pritchard and T

an [2009].

◮ All have a variable for each component.

4 / 29

Undirected component-based relaxation

min

• C∈K

xC cost(C)

• C∈K

xC(|S ∩ R(C)| − 1)+ ≤ |S| − 1 ∀ ∅ S ⊆ R

• C∈K

xC(|R(C)| − 1) = |R| − 1 xC ≥ 0 ∀ C ∈ K. (LP)

Warme [1998] ◮ K = set of components. ◮ Exponential # of variables—but can get a PTAS by only

considering components up to a certain size.

Borchers & Du [1997]

5 / 29

Integrality gaps

◮ Directed variant used by BGRS for their algorithm—but

their analysis does not bound the integrality gap!

◮ They do prove a bound of 1.55 on the integrality gap by other

methods.

◮ Chakrabarty, Könemann and Pritchard [2010] give a simpler

proof of this bound.

6 / 29

Our results (I)

◮ Deeper understanding of the component-based LP

.

◮ Leads to simpler algorithm, performance directly

comparable to LP solution:

◮ Deterministic (derandomization much simpler than for BGRS

algorithm).

◮ Gives matching bound on the integrality gap. ◮ Don’t need to re-solve LP in each iteration. 7 / 29

Overview of algorithm

◮ Solve component LP to get near-optimal solution x. ◮ Until all terminals are connected:

◮ Select component Q to contract; add Q to solution. ◮ Modify LP solution x to be feasible in the new contracted in-

stance.

8 / 29

Overview of algorithm

◮ Solve component LP to get near-optimal solution x. ◮ Until all terminals are connected:

◮ Select component Q to contract; add Q to solution. ◮ Modify LP solution x to be feasible in the new contracted in-

stance.

◮ No re-solving of LP!

8 / 29

Blowup graph

1 1/2 1/2 1/2 N = 2  X

◮ Choose N s.t. xC · N ∈ N for all C ∈ K. ◮ Make xC · N “copies” of C ∈ K. ◮ Notation: Γ(X) := set of components in X.

9 / 29

Blowup graph

1 1/2 1/2 1/2 N = 2  X

◮ X contains all information about x; in particular, can

determine feasibility.

◮ cost(X) :=

• e∈E(X) c(e) = N · cost(x).

◮ For any F ⊆ E(X), X − F is another blowup graph.

10 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

11 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

◮ Important to look at minimal edge removals:

11 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

◮ Important to look at minimal edge removals:

11 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

◮ Important to look at minimal edge removals:

11 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

◮ Important to look at minimal edge removals:

11 / 29

Edge removals

Crucial question What are the possible edge removals after contracting a set of terminals Q?

◮ Important to look at minimal edge removals:

11 / 29

Matroid structure

Given a set Q of terminals to contract, let BQ = {B ⊆ E(X) | (X /Q) − B is feasible, and B is minimal with this property}. Theorem

◮ BQ form the bases of a matroid MQ of rank N(|R(Q)| − 1).

12 / 29

Matroid structure

Given a set Q of terminals to contract, let BQ = {B ⊆ E(X) | (X /Q) − B is feasible, and B is minimal with this property}. Theorem

◮ BQ form the bases of a matroid MQ of rank N(|R(Q)| − 1). ◮ Can precisely describe the rank function rQ. ◮ MQ is a gammoid.

12 / 29

Thought experiment

◮ We want to show that there exists a component Q and

removal set B ∈ BQ s.t. cost(B)/N is “large” compared to cost(Q).

◮ Try an averaging argument: pick (Q, B) randomly from some

distribution D s.t. B ∈ BQ, and E{cost(B)/N} large compared to E{cost(Q)}.

13 / 29

Thought experiment

◮ We want to show that there exists a component Q and

removal set B ∈ BQ s.t. cost(B)/N is “large” compared to cost(Q).

◮ Try an averaging argument: pick (Q, B) randomly from some

distribution D s.t. B ∈ BQ, and E{cost(B)/N} large compared to E{cost(Q)}.

◮ Choose D s.t. P{Q = C} = 1/|Γ(X)|

∀C ∈ Γ(X).

◮ So E{cost(Q)} = cost(X)/|Γ(X)|. 13 / 29

Thought experiment

◮ We want to show that there exists a component Q and

removal set B ∈ BQ s.t. cost(B)/N is “large” compared to cost(Q).

◮ Try an averaging argument: pick (Q, B) randomly from some

distribution D s.t. B ∈ BQ, and E{cost(B)/N} large compared to E{cost(Q)}.

◮ Choose D s.t. P{Q = C} = 1/|Γ(X)|

∀C ∈ Γ(X).

◮ So E{cost(Q)} = cost(X)/|Γ(X)|.

◮ So if we can also ensure that P{e ∈ B} ≥ α · N/|Γ(X)|, we get

E{cost(B)/N} = 1

N

• e

c(e)P{e ∈ B} = α · cost(X)/|Γ(X)|, implying an integrality gap ≤ α.

13 / 29

Thought experiment

◮ We want to show that there exists a component Q and

removal set B ∈ BQ s.t. cost(B)/N is “large” compared to cost(Q).

◮ Try an averaging argument: pick (Q, B) randomly from some

distribution D s.t. B ∈ BQ, and E{cost(B)/N} large compared to E{cost(Q)}.

◮ Choose D s.t. P{Q = C} = 1/|Γ(X)|

∀C ∈ Γ(X).

◮ So E{cost(Q)} = cost(X)/|Γ(X)|.

◮ So if we can also ensure that P{e ∈ B} ≥ α · N/|Γ(X)|, we get

E{cost(B)/N} = 1

N

• e

c(e)P{e ∈ B} = α · cost(X)/|Γ(X)|, implying an integrality gap ≤ α.

◮ Unfortunately we can’t get better than α = 2.

13 / 29

Removal probabilities

◮ Let B(MQ) be the base polytope associated with MQ. ◮ p ∈ B(MQ) iff there exists a distribution DQ on BQ s.t.

PDQ{e ∈ BQ} = pe.

◮ Consider the scaled Minkowski sum

Brem = 1 |Γ(X)|

• Q∈Γ(X)

B(MQ).

◮ p ∈ Brem iff there exists D s.t. for random (Q, B), B ∈ BQ,

P{Q = C} = 1/|Γ(X)| ∀C and PD{e ∈ B} = pe.

14 / 29

Polymatroids for random contraction

◮ Brem is a polymatroid, with rank function

r = 1 |Γ(X)|

• Q∈Γ(X)

rQ.

◮ But rQ has an implicit description:

rQ(F) = min

S⊇Q hX −F(S).

15 / 29

Polymatroids for random contraction

◮ Brem is a polymatroid, with rank function

r = 1 |Γ(X)|

• Q∈Γ(X)

rQ.

◮ But rQ has an implicit description:

rQ(F) = min

S⊇Q hX −F(S).

Theorem Brem ⊇

N |Γ(X)|B(MR).

Equivalently:

• Q∈Γ(X)

B(MQ) ⊇ N · B(MR).

15 / 29

Core edges

◮ The set of extreme points of B(MR) is precisely BR. ◮ So for any K ∈ BR, the vector p of marginals given by

pe =

• N/|Γ(X)|

e ∈ K e / ∈ K . is in Brem.

16 / 29

Core edges

◮ The set of extreme points of B(MR) is precisely BR. ◮ So for any K ∈ BR, the vector p of marginals given by

pe =

• N/|Γ(X)|

e ∈ K e / ∈ K . is in Brem.

◮ What must remain after removing some B ∈ BR? Precisely a

spanning tree on X /R.

16 / 29

Core edges

◮ The set of extreme points of B(MR) is precisely BR. ◮ So for any K ∈ BR, the vector p of marginals given by

pe =

• N/|Γ(X)|

e ∈ K e / ∈ K . is in Brem.

◮ What must remain after removing some B ∈ BR? Precisely a

spanning tree on X /R.

16 / 29

Witness sets

e

17 / 29

Witness sets

e W(e)

17 / 29

Witness sets

e

17 / 29

Witness sets

e

17 / 29

Weights

◮ Charge cost of cleanup edges to edges in K:

w(f) = c(f) +

• e /

∈K:f∈W(e)

c(e) |W(e)| .

Theorem

There exists a component Q and B ∈ BQ so that w(B)/N ≥ cost(Q).

◮ (Q, B) can be found algorithmically (for each Q, find a

maximum weight basis in BQ; the gammoid structure of MQ is helpful here).

18 / 29

Algorithm

◮ Start with blowup graph X and K ∈ BR. ◮ N = 2 in this example.

19 / 29

Algorithm

◮ Find Q and max weight basis B ∈ BQ s.t. cost(Q) ≤ w(B)/N.

20 / 29

Algorithm

◮ Remove B

21 / 29

Algorithm

◮ Remove B and cleanup edges: F = {e /

∈ K | W(e) ⊆ B}.

21 / 29

Algorithm

◮ Remove B and cleanup edges: F = {e /

∈ K | W(e) ⊆ B}.

◮ Contract Q.

21 / 29

Algorithm

◮ Find Q and B ∈ BQ s.t. cost(Q) ≤ w(B)/N.

22 / 29

Algorithm

◮ Find Q and B ∈ BQ s.t. cost(Q) ≤ w(B)/N. ◮ Remove B

22 / 29

Algorithm

◮ Find Q and B ∈ BQ s.t. cost(Q) ≤ w(B)/N. ◮ Remove B and cleanup edges.

22 / 29

Algorithm

◮ Contract.

23 / 29

Algorithm

◮ Contract. ◮ Final tree.

23 / 29

Full algorithm

For a given blowup graph X and K ∈ BR: Algorithm

◮ T ← ∅ ◮ While T is not a Steiner tree:

◮ Find Q and B ∈ BQ s.t. cost(Q) ≤ w(B)/N. ◮ Cleanup: Let F = {e /

∈ K | W(e) ⊆ B}.

◮ Update: T ← T ∪ Q, X ← (X − B − F)/Q, K ← K \ B.

Theorem

Algorithm returns solution of cost at most ΦK(X)/N, where ΦK(X) =

• e∈K

H(|W(e)|).

24 / 29

Potential analysis

◮ Can find K minimizing ΦK(X) by a dynamic program. ◮ For best K, can show that

◮ ΦK(X) ≤ ln(4)cost(X). ◮ If G is quasi-bipartite, ΦK(X) ≤ 73

60 cost(X).

25 / 29

Our results (II)

◮ Quasi-bipartite:

◮ 73/60 bound on integrality gap (previous best of 1.28 by

Chakrabarty, Könemann and Pritchard [2010]).

◮ Can show how to obtain optimal solution to hypergraphic LP by

solving bidirected relaxation.

◮ Separation of undirected component-based LP by |R|

max-flow computations.

◮ Rank computations with one max-flow.

◮ Easy proof of sparsity of basic solutions (first proven by

Chakrabarty et al. [2010]).

26 / 29

Open problems

◮ Improve the bound! ◮ Practical (non-galactic) approximation algorithms? ◮ Better than 2 bound on integrality gap of bidirected cut

relaxation?

27 / 29
