On-line water quality analysis with real time data transfer

• Ing. Luca Sanfilippo

Project Manager Marketing Manager

Indian Central Pollution Control Board direction

• Requirement to on-line measure COD, BOD, pH

and TSS in all water outlets of Indian industries, CETPs, hazardous and biomedical waste incinerators

• On-line calibration required
• Collected on-line data have to be sent to CPCB

remote server

• On-line water quality monitoring systems have to

be in operation by 31 March 2015.

Central Pollution Control Board direction (2)

• 17 categories of industries were identified
• Other chemical parameters to be added on the

basic set of COD, BOD, pH and TSS for the following categories:

• Dye and dye intermediate: chromium 6+
• Fertilizers: ammonia
• Pesticides: chromium 6+ and arsenic
• Pharmaceuticals: chromium 6+ and arsenic
• Pulp and paper: Adsorbable Organic Halides (AOX).

Micromac ECO

• n-line analyzer:
• Batch sequential multiparametric

analysis of COD, BOD, pH and TSS

• To be combined with other

Micromac C on-line analyzers tomeasure chemical compounds

• ZetaLOG data acquisition unit to

acquire data from Micromac ECO and another Micromac C

• analog acquisition of water flow

data can be included.

• COD, BOD and TSS are indirectly measured
• Local calibration of COD, BOD, and TSS

according to analytical methods are required to provide accurate data for the specific water matrix to be monitored

• COD: .by standard dichromate + sulphuric acid

colorimetric method

• BOD: by 5 days digestion and O2 consumption

measurement using DO electrode

• TSS: by gravimetric method.

Micromac ECO: local calibrations required

Optional on-line self-cleaning filtration unit

• Suggested for any waste

water outlet application

• Self-cleaning by compressed

air, to be available on-site as standard

• Internal compressed air

generator available on request

• Suggested filtration cut-off

100 microns is compatible with TSS measurements.

BOD5 direct correlation with tryptophan

• Tryptophan is an essential amino

acid in human diet and is the main component of protein fluorescence.

• It is associated with microbial

activity, i.e. from sewage & faecal contamination of wastewaters.

• Published data over the past

decade has clearly demonstrated a strong correlation between Tryptophan-like fluorescence and BOD.

BOD indirect measurement by fluorimetric method

• Measurement done by the excitation at 280 nm of

Tryptophan-like UV fluorescence, measured at 340-360 nm, which correlates with both bacterial loading and BOD

• Internal calibration factor is used to convert the

Tryptophan-like fluorescence measured to the reported BOD equivalent value in units of mg/L

• The use of fluorescence provides signal detection

sensitivity far superior to optical absorption methods, while the real-time reporting of BOD equivalence enables the measurement to be used for process control

• Featuring autocleaning and programmable calibration

check by tryptophan reference solution.

BOD

trypthophan like fluorescence method shows better correlation with BOD5 than UV (SAC 254 nm) direct reading(*)

(*) Using Synchronous Fluorescence Technique as a Water Quality Monitoring Tool for an Urban River, Jin Hur & Soon-Jin Hwang & Jae-Ki Shin Water Air Soil Pollut (2008) 191:231–243

TSS

example of data correlation with turbidity for DRY and WET weather

• Local calibration of COD, BOD, and TSS

according to analytical methods are required to provide accurate data

• Built-in autocalibration checks ensure long term

measurement stability

• 0-5 V or 4-20 mA + digital I/O as standard outputs

provide measurement data to the local SCADA

• ZetaLOG integration can provide data to CPCB

server and to ZetaCED remote data visualization and validation system, accessible on the Web.

Micromac ECO:

• perativity and data output

Micromac C MP2 Arsenic and Chromium6+ analyzer:

• Power supply: 12 Vdc, 20 W
• Multiparanetric sequential batch

analysis

• Low reagents consumption
• Around one hour measurement

time (two As sequential strippings)

• Full integration compatibility with

Zetalog+ZetaCED

Micromac C Arsenic measurement method

• Based on standard Mo-

blue spectrophotometric method with preliminary repeated Arsine gas stripping.

• LFA technology ensures

reliability and high circuit cleaning Available ranges from 0-20 ppb

Micromac C Arsenic (low level) test:

Micromac C on-line analyzers:

• ther measurement methods

required by CPCB

The automated procedure for the determination of hexavalent chromium in water depends upon the reaction of diphenylcarbazide with hexavalent chromium in an acid medium, to produce a reddish purple colour which can be measured at 520/550 nm.

Chromium6+ Ammonia

In this automated method, the ammonia ions present in the sample react with salicilate in an alkaline medium pH 12, while nitroprusside acts as a catalyst. The blue color is measured at 660-630 nm.

Micromac COD

Micromac COD automates the standard bichromate + sulphuric acid method, applied in any laboratory worldwide as COD reference method.

In 2011 the analyzer was successfully tested by Chinese EPA as equivalent method

Micromac short users list of CPCB requested parameters

Micromac short users list of CPCB requested parameters (2)

ZetaLOG: a powerful remote data communication device

• Combined GSM / SMS and

GPRS technology

• data delivery by SMS to plant
• perators to notify threshol

alarms

• ftp data delivery to CPCB server
• direct GPRS data

communication to ZetaCED Web server

• direct control of the on-line

analyzer by GPRS remote connection allows easy diagnostic.

Micromac ECO running demo in India: WWTP outlet monitoring at Lupin Ltd, Tarapur, Maharastra

Management advance using a Web based data centre

• Station accessibility from any type of Internet

connecting tool, including palm devices and last generation mobile phones

• Remote data validation by operators located in

different places

• Data stored in relational data-base installed in a

remote server located in a Service Provider facility

• r directly in CPCB’s head quarter
• No specific application needed to be run in any

computer's Client

• Remote maintenance and update facility.

Advanced automated solutions for field analysis of chemical parameters in water

WIZ in-situ probe µMAC-Smart

Easychem TOX OL Overview

A RANDOM ACCESS - DIRECT READING ON-LINE ANALYZER FOR ACUTE TOXICITY TESTING AND ADDITIONAL OPTIONAL CHEMICAL MEASUREMENTS EASYCHEM TOX OL INCLUDES: LUMINESCENT BACTERIA COOLED STORAGE AREA LUMINOMETER OPTIONAL COLORIMETER DEDICATED SOFTWARE.

Easychem TOX OL A full integrated multiparametric platform

Easychem TOX OL Applications

TOXICITY WITH BACTERIA Luminescence detection Blank Control 3 Positive Controls CHEMICAL DETERMINATIONS (optional) Spectrophotometric detection Up to 10 parameters

Our indian subsidiary, providing technical and after sales support to our network of channel partners: SYSTEA Analytical Technologies Pvt Ltd

418, Chokhani Square, Sector 18, Noida, 201301 New Delhi NCR, Uttar Pradesh

Stock of spare parts and consumables are locally available to ensure continuous operation for 5 years. Country Manager: Sanjay Sinha e-mail: sanjay.sinha@systea.it

SYSTEA SpA

• ur subsidiary in India
