SLIDE 1
Rehabilitating the London 2012 Olympic Park site
Chinese media delegation briefing
Atkins Lectures
Olympic Park site Chinese media delegation briefing James Apted, - - PowerPoint PPT Presentation
Olympic Park site Chinese media delegation briefing James Apted, - - PowerPoint PPT Presentation
Atkins Lectures Rehabilitating the London 2012 Olympic Park site Chinese media delegation briefing James Apted, Ian Morrissey, Ian Mead 11 October 2013 The challenges Minimising Contamination Occupation Scale disruption to communities
SLIDE 2
SLIDE 3
SLIDE 4
SLIDE 5
The challenges
Delivered on time, on budget and to the standard required by follow on contractors.
Contamination Occupation Scale Minimising disruption to communities
SLIDE 6
Soil washing
Over 2.2M m3 of soil was excavated to create the site platform. In total over 900,000 m3 was treated of which 700,000 m3 was soil washed, which produces sand and gravel fractions for re-use.
SLIDE 7
Bioremediation
Alternative remediation techniques were also used such as bioremediation, which is good at treating organic contamination. However it takes 6-8 weeks per treatment batch. 30,000m3 of soil was treated by this process.
SLIDE 8
Groundwater treatment
Overview
Free product removal: 2,500 litres Pump and treat schemes: 235,000 cubic metres Diluted chemical reagents injected: 1,260 tonnes
CZ3a Hydraulic Containment CZ3 ISCO Round 1 CZ5a Perched water cut-off wall & GWTP CZ6d Perched water cut-off wall CZ6a/d Pump & Treat CZ1a DPVE ORS injection NAPL recovery CZ3a ISCO Round 2 CZ3a Thanet Sands DNAPL removal EVO Injection CZ8a EHCM injection
SLIDE 9
Cleaning the Olympic Park
SLIDE 10
SLIDE 11
SLIDE 12
Wetlands and river edges
Sustainable design
Wetland planting trials where undertaken during the enabling works to inform habitat design and future management requirements. This led to the selection of species and installation methods which would ensure biodiversity objectives were met for the Games and as a legacy.
SLIDE 13
SLIDE 14
SLIDE 15
Ecological heritage
Creating opportunities for wildlife through integrated habitat design within hard and soft landscaping elements.
SLIDE 16
Transformation
Landscaping extension
The landscaping has developed further in transformation via the removal of temporary venues and walkways. This has included the planting of 2,000 trees and the creation of 10 hectares of meadows and lawns.
SLIDE 17
Transformation
Protection of remediation
Atkins is currently on site on the Queen Elizabeth Olympic Park ensuring that the existing remediation works are appropriately protected.
SLIDE 18
North Park in legacy
SLIDE 19
For more information contact
James Apted james.apted@atkinsglobal.com
