Oil Injected Rotary Screw – New CPC-G Range Gear Driven, Fixed Speed, 40- 60HP

Agenda:

 Reliability  Machine Layout  Dimensions  Noise Levels  Energy Saving Technology  Numbers and Comparisons  Documentation  Range Availability  Summary

RELIABILITY

 Gearbox transmission

– No belt tensioning – No coupling maintenance – No transmission losses – No trouble

 Siemens drive motor

 C90 air end

– 15,000 air ends in the field w/o problem

Reliable Components

Simple & Sleek

Simple

ES 4000 Advanced Controller

• energy saving algorithm
• data logging
• Intelligent unload cycle
• Auto Restart
• ES6i and ES4i capability
• Realtime clock
• Programmable start-stop
• Remote start-stop
• Remote visualization (ethernet)

Easy Removeable Filtration Mats

• Protection against

contamination

• Extended oil lifetime
• Lower operating temp

Removable trap doors for Easy Cooler Maintenance Standard Integrated Float Drain

• protect downstream network from

condensate

• extended lifetime

Oil Type:

• Rotair Xtra
• Quantity: 5.3 Gallons

Sleek

Neatly arranged, easy-to-service components

Workplace Friendly

52’’ 35’’ 70.5’’ 57’’ 42’’ 64’’ OLD NEW

25% FOOTPRINT REDUCTION!

Compact

52’’ 35’’ 70.5’’ No Dryer

Dimension Comparison – New Models

71.3’’ 35’’ With Dryer 70.5’’

11

Radial Cooling Fan Controlled Airflow Perfect Insulation

SILENT OPERATION AT MAX 68 DB(60HP) AS LOW AS 66 DB ON 40HP!

68 Db(A) 67 dB 45 dB 70 dB 85 dB 100 dB 125 dB

Energy Saving

 Low pressure drop  Elimination of valves downstream of the air end  Repositioned outlet grating  Lower power consumption of cooling fan  Siemens IE3 motors  2% better efficiency

ENERGY SAVING TECHNOLOGY

The Result?

• Even less pressure drop
• A quieter, more energy efficient unit

Numbers

New Design vs. Old Design – 100psi

CFM

189 233 271 214 247 297 50 100 150 200 250 300 350 40 HP 50 HP 60 HP

CPC-G Flow Comparison - Old vs. New - 100psi

Old Design New Design

New Design vs. Old Design – 125psi

174 218 256 193 230 273 50 100 150 200 250 300 40 HP 50 HP 60 HP

CPC-G Flow Comparison - Old vs. New 125PSI

Old Design New Design

CFM

159 195 235 175 214 249 50 100 150 200 250 300 40 HP 50 HP 60 HP

CPC-G Flow Comparison - Old vs. New - 150psi

Old Design New Design

New Design vs. Old Design – 150psi

CFM

150 180 218 153 190 223 50 100 150 200 250 40 HP 50 HP 60 HP

CPC-G Flow Comparison - Old vs. New - 175psi

Old Design New Design

New Design vs. Old Design – 175psi

CFM

How does it stack up? – Flow Rate

181 160 193 184 50 100 150 200 250 GD - L30 Sullair - ST3008 CPC-G 40 IR -RS30i

Competitor Comparison - CFM of 40HP Gear Drive @ 125psi

CFM

218.6 219 230 220 222 210 215 220 225 230 235 240 GD - L37 Sullair - ST3708 CPC-G 50 IR -RS37i FS Curtis RS50D

Competitor Comparison - CFM of 50HP Gear Drive @ 125psi

How does it stack up? – Flow Rate

CFM

How does it stack up? – Flow Rate

CFM

252 269 273 265 275 240 245 250 255 260 265 270 275 280 GD - L45 Sullair - 4509B CPC-G 60 IR -RS45i FS Curtis RS60D

Competitor Comparison - CFM of 60HP Gear Drive @ 125psi

How does it stack up? – Energy Savings

20.8 22.7 19.0 19.9 17.0 18.0 19.0 20.0 21.0 22.0 23.0 GD - L30 Sullair - ST3008 CPC-G 40 IR -RS30i

Specific Energy Ratio - 40HP Gear Drive @ 125psi

Kw/100cfm

How does it stack up? – Energy Savings

Kw/100cfm

21.0 20.7 18.9 19.0 21.7 17.5 18.0 18.5 19.0 19.5 20.0 20.5 21.0 21.5 22.0 GD - L37 Sullair - ST3708 CPC-G 50 IR -RS37i FS Curtis RS50D

Specific Energy Ratio - 50HP Gear Drive @ 125psi

How does it stack up? – Energy Savings

Kw/100cfm

22.0 20.1 18.6 20.3 21.5 16.0 17.0 18.0 19.0 20.0 21.0 22.0 23.0 GD - L45 Sullair - 4509B CPC-G 60 IR -RS45i FS Curtis RS60D

Specific Energy Ratio - 60HP Gear Drive @ 125psi

CONCLUSIONS

New CPC-G compressors are delivering more flow than most competitors without compromising energy efficiency. Specific energy of CPC-G 40-60 @125psig (most popular pressure in USA) is extremely low which will bring energy savings to our

• customers. Same goes with unload power.

Documentation

New OIS 40-60 HP Flyer New Tech Data Sheets New CAGI Data Sheets

Dimensional Drawings, Instruction Manuals, and more! All available at www.revupcp.com

Range availability 40-50-60 HP

Gear drive C90

• 4 pressure variants
• 3 voltage variants
• Fixed Speed
• Air Cooled – (Water-cooled units available through specials)
• All models available in integrated dryer version

Pressure variants

 60Hz

– 230V – 460V – 575V(Canada)

Factory Options Available:

 ICONS Connectivity(standard on stock units)  Foodgrade Oil  Tropical Thermostat  Energy recovery...and more!(see next slide)

Voltages

 100psi  125psi  150psi  175psi

Approvals

 USA/Mexico: UL/cUL  Canada: CSA

 ICONS Connectivity(standard on stock units)  Foodgrade Oil  Tropical Thermostat  Energy recovery  ES4000 Advanced Controller(standard on stocked units)  Auto drain for WSD  High efficiency pre panel filtration  Oil preheater  4000 and 8000 hour oil(8000H standard on stocked units)  Silencing Baffle  ECOntrol6i  Wooden package

Factory Options Available:

SUMMARY

Big Changes/Difference Makers:

 Higher CFM output on all models and versions

and lower energy consumption

 New Radial Fan standard on all models, much quieter!  Noise levels down from 74 dB(A) to as low as 66 dB(A)

(40HP)

 Smaller dimensions, smaller footprint  Now available with integrated dryers  ICONS Connectivity standard on stocked

units(activation required)

Price Positioning

 There will be no price change on 60HP units  40-50HP units will see slight increase versus previous

models

 For quotes in this HP range that require a lower price to

be competitive we offer the CPBg and CPBg D 40-50 gear driven units(integrated dryer versions available) and the CPC 40-60 belt driven units(no integrated dryer

• ption available)

 There has not been any redesign or price change on

VSD units within this range

Contact Information:

 Technical Support: 877-861-2722 option 1  Sales Support: Regional Sales Manager or 877-

861-2722 option 4 or cp.sales@cp.com

 Order inquiries: equipment@cp.com  Documentation and more: www.revupcp.com
