Offshore CO2 EOR as Part of a National CCS Programme: Opportunities - - PowerPoint PPT Presentation

Offshore CO2 EOR as Part of a National CCS Programme: Opportunities and Challenges David S Hughes Principal Reservoir Engineer/CCS and EOR Specialist Senergy 18th February 2014 Introduction Substantially material prepared for a new SPE


slide-1
SLIDE 1

Offshore CO2 EOR as Part of a National CCS Programme: Opportunities and Challenges

David S Hughes Principal Reservoir Engineer/CCS and EOR Specialist Senergy 18th February 2014

slide-2
SLIDE 2

Introduction

  • Substantially material prepared for a new SPE

Distinguished Lecture (from September 2014)

  • Include more detail of recent UK CO2 EOR screening

exercise undertaken for DECC (report available)

  • DECC/ PILOT/ Oil & Gas UK initiative
  • Presented to industry 1 October 2013
  • For copy of ‘DECC Miscible Flooding’

report (8 MB) email david.hughes@senergyworld.com

slide-3
SLIDE 3

Opening remarks: Geological Storage of CO2

  • New business stream for oil industry
  • Store liquid/supercritical CO2 in depleted oil and gas fields

and also in saline aquifers

  • Synergies with existing operations through reuse of

infrastructure etc. and opportunity to increase hydrocarbon recovery

  • Contributes to the fight on climate change
  • Has value through Cap and Trade arrangements or

through avoiding carbon taxes

  • But comes with regulations and liabilities
  • Uses all our skills
slide-4
SLIDE 4
  • Worldwide requirement for CO2 emissions reductions

and role of carbon capture and storage (CCS)

  • Specific UK targets
  • Expected amounts and locations of captured CO2

from national CCS programme

  • Types and locations of storage sites including estimate
  • f UK CO2 enhanced oil recovery (EOR) potential
  • Challenges of implementing CO2 EOR offshore
  • Discussion

Outline of Talk

slide-5
SLIDE 5

Worldwide CO2 Equivalent Emissions and Reduction Requirement

  • Emissions reductions pathway consistent with limiting

temperature rise to 2°C (1990 baseline)

  • 85% reduction in developed countries
  • 50% reduction overall

Source: Adapted from UNDP, 2007

slide-6
SLIDE 6

Inter-governmental Panel on Climate Change (IPCC) Fifth Assessment Report

  • From second order draft of the IPCC Working Group III

contribution to the IPCC's Fifth Assessment Report (published in Economist 20th July 2013)

  • Compares with 445-490 ppm giving likely rise of 2.0-2.4°C

in Fourth Assessment Report

slide-7
SLIDE 7

From IPCC Special Report on Carbon Dioxide Capture and Storage 2005 and BP Statistical Review, 2012

IPCC 2005 Prediction of Requirement for Carbon Capture and Storage (CCS)

  • From ~2030 amount of CO2

that requires to be stored is ~4 billion tonnes/year, rising to ~18 billion tonnes/year in 2095

  • c.f. 4.0 billion tonnes/year oil

production and 3.0 billion tonnes oil equivalent/year gas production in 2011

  • 2030
slide-8
SLIDE 8

European Union (EU) 2007 Prediction of Requirement for CCS

  • EU prediction suggests requirement for ~3 billion tonnes

per year of CO2 storage

slide-9
SLIDE 9

CO2 Flooding is a Major Enhanced Oil Recovery (EOR) Process in USA

slide-10
SLIDE 10

USA CO2 EOR and CO2 Supply

  • 10
  • ~120 projects
  • ~300,000 stb/d
  • ~75 million tonnes

per year

(CO2 capture)

slide-11
SLIDE 11

UK Commitment to Reduction in CO2 Emissions

  • Under Kyoto Protocol, UK committed to reducing

greenhouse gas emissions by 12.5% from their 1990 levels by 2012 – actually achieved 25.7% (provisional figure)

  • UK implemented legal requirement for 80% reduction in

1990 emissions by 2050, with interim target of ~34% by 2020

  • Capture of CO2 emitted from fossil fuelled power plants

seen as one means of reducing emissions, with geological CO2 storage in depleted oil and gas fields, and saline aquifers

slide-12
SLIDE 12

Contribution to UK CO2 Emissions From Power Sector

  • UK CO2 emissions 2012

479 million tonnes

  • About 1/3 from fossil

fuelled power stations

  • Many coal-fired power

stations due to close

  • 12
slide-13
SLIDE 13

50 100 150 200 250 300 350 400 TWh/year Coal Coal and Gas CCS Oil Gas Nuclear Renewables Storage

UK Power Generation Prediction by Fuel (DECC, September 2013)

From DECC – Updated Energy and Emissions Projections 2013, September 2013 (Reference Scenario)

slide-14
SLIDE 14

2 4 6 8 10 12 14 16 18 Captured CO2 (million tonnes/year)

CO2 Captured from CCS in UK Power Generation Prediction

Derived from DECC – Updated Energy and Emissions Projections 2013, September 2013 (Reference Scenario)

Late 2020s Average ~12 mill te/y

slide-15
SLIDE 15

More Bullish Outlook for CCS in UK from Energy Technology Institute (ETI)

  • ETI predicts 35 million tonnes/year 2025-30
  • Rising to 110 million tonnes/year 2035-50

Source: A Picture of CO2 Storage in the UK – learnings from ETI’s UKSAP and derived Projects, ETI, June 2013

slide-16
SLIDE 16

ETI Appraisal of Sources and Potential Sinks of CO2 Around North Sea (Amounts in late 2020s)

Source: www.co2stored.co.uk :

10 mill te/y 15 mill te/y 10 mill te/y

slide-17
SLIDE 17

Southern North Sea (SNS) Gas Fields CO2 Storage Potential

  • 53 fields most Permian

Leman Sandstone

  • Proven geological trap for

hydrocarbon gas

  • Near to CO2 sources
  • Existing infrastructure
  • Well and pressure depletion

may have compromised trap

  • Aquifer influx may reduce

capacity

  • CO2 capacity ~2.8 billion

tonnes

slide-18
SLIDE 18

SNS Bunter Sandstone CO2 Storage Potential

  • 29 closed structures (2 under

appraisal)

  • Good porosity (average

18.7%) and permeability

  • 650-9800 ft deep
  • Near to CO2 sources
  • Good seal (mudstones and

evaporites) - gas bearing in places proves trap (or not!)

  • Some existing infrastructure
  • Cut by faults which may leak
  • CO2 capacity ~14.3 billion

tonnes

Material on SNS gas field and aquifer storage from: An assessment of carbon sequestration potential in the UK – SNS case study, Michele Bentham, January 2006, Tyndall Centre

slide-19
SLIDE 19

ETI Appraisal of Sources and Potential Sinks of CO2 Around North Sea (Amounts in late 2020s)

Source: www.co2stored.co.uk :

10 mill te/y 15 mill te/y 10 mill te/y

slide-20
SLIDE 20

10 20 30 40 50 60 70 25 50 75 100 125 150 175 200 225 Cumulative oil (billion stock tank barrels) Oil field (largest to smallest STOIIP) Cum STOIIP (billion stb) Cum oil produced (billion stb) Cum ultimate oil recovery (billion stb)

Some fraction of remaining oil Say 5 billion barrels 43% 37% UK Oil Production and the EOR Prize

slide-21
SLIDE 21

How does CO2 EOR work?

  • CO2 acts as a solvent flushing oil from rock
  • Most efficient above the so called minimum miscibility

pressure (MMP)

  • CO2 may be more or less dense than the oil, but always

less dense than water

  • Efficiency of displacement is limited by heterogeneity and

gravity override

  • Expected incremental recovery 5-15% of oil initially in

place

  • Between 2 and 5 incremental barrels per net tonne of CO2

injected, but significant recycling of CO2 required

slide-22
SLIDE 22

Screening for CO2 EOR Potential

  • All 119 UK fields with oil initially in place >100 MMstb

screened (database made available by DECC)

  • Screening parameters considered include:
  • Ratio operating pressure/CO2 MMP
  • Ratio oil density/CO2 density
  • Ratio oil viscosity/CO2 viscosity
  • CO2 efficiency (stb/tonne)
  • Results are aggregated into overall score
  • Best candidates, 2nd rank candidates and 3rd rank

candidates identified

  • Potential incremental recovery calculated
slide-23
SLIDE 23

Estimated Incremental Recovery Potential and CO2 Stored by Category

  • Leading Operators (best and second rank candidates)
  • BP
  • Apache
  • Nexen
  • Talisman
  • Taqa

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-24
SLIDE 24

Incremental Recovery Factor Distribution

2 4 6 8 10 12 14 1% 2% 3% 4% 5% 6% 7% 8% 9% 10% 11% 12% 13% 14% 15% 16% Number of Fields Incremental Recovery Factor

77 fields 47 leading candidates 9 2nd rank candidates 21 3rd rank candidates

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-25
SLIDE 25

2 3 9 10 11 12 13 14 15 16 20 21 22 23 28 29 30 42 43 44 47 48 49 110 113 204 205 206 210 211 53 54 55 56 57 58 59 60 61 62

  • 5
  • 4
  • 3
  • 2
  • 1

1 2 3 Latitude Longitude 3rd rank technical candidates 2nd rank technical candidates Best technical candidates Blocks coastline

UK Potential for CO2 EOR (potential proportional to area of circles)

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-26
SLIDE 26

5 10 15 20 25 30 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 9.5 10 10.5 11 11.5 12 Number of Fields Initial CO2 Rate at 3% HCPV per year (million tonnes)

Initial CO2 Import Rate at 3% HCPV per year (No Hub Constraint, All Candidates)

77 fields 47 leading candidates 9 2nd rank candidates 21 3rd rank candidates

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-27
SLIDE 27

Decline in Potential in Operating Fields as Fields Reach their COP Dates

  • ~2/3rds of potential is in fields that will have ceased

production by late 2020s

500 1000 1500 2000 2500 3000 3500 total <2013 2013 2014 2015 2016 2017 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036 2037 2038 2039 2040 2041 2042 Incremental Recovery (MMstb) Best candidates Best and 2nd rank Best, 2nd and 3rd rank candidates

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-28
SLIDE 28

Map Showing Agreements for Lease for CO2 Storage Granted by Crown Estate

Goldeneye (Shell) Aspen (Petrofac) Mid NS High (Progressive) MacCulloch (Progressive) Bunter 3/44 (NGC) Bunter 5/42 (NGC) Maureen (Progressive) Balmoral area (Premier)

Grangemouth St Fergus Teesside Humberside 11 12 13 14 15 16 20 21 22 23 28 29 30 42 43 44 47 48 49 110 113 53 54 55 56 57 58 59

  • 4
  • 3
  • 2
  • 1

1 2 3

Latitude Longitude Offshore hubs Onshore hubs Blocks coastline

Brae/Miller

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-29
SLIDE 29

2 3 9 10 11 12 13 14 15 16 20 21 22 23 28 29 30 205 206 210 211 55 56 57 58 59 60 61 62

  • 4
  • 3
  • 2
  • 1

1 2 3 Latitude Longitude 3rd rank technical candidates 2nd rank technical candidates Best technical candidates Hubs Blocks coastline

UK Potential for CO2 EOR (Hub Constrained)

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

slide-30
SLIDE 30

Estimated Incremental Recovery Potential and CO2 Stored by Category (Hub Constrained)

  • Leading Operators (best and second rank candidates)
  • Nexen
  • Talisman

Source: PILOT Miscible Gas EOR Workshop, October 2013 (DECC)

45 fields 15 leading candidates 13 2nd rank candidates 17 3rd rank candidates

slide-31
SLIDE 31

CO2 EOR Onshore - Advantages

  • Mature CO2 supply network
  • High well density, pattern flood, relatively cheap to

redrill/refurbish

  • Relatively low secondary recovery (35-45%)
  • Phased implementation
  • Large surface area available for facilities
slide-32
SLIDE 32

CO2 EOR Offshore - Challenges

  • Limited CO2 supply at present but significant quantities

likely to become available on 5-10 year timescale (i.e. early to mid 2020s)

  • Fewer wells, peripheral floods, expensive new wells and

workovers

  • High secondary recovery (up to 70%) therefore smaller

target

  • Single implementation (i.e. no chance to introduce the

project in phases or to undertake pilot)

  • Existing facilities mainly incompatible with high CO2

content in fluids

  • Limited weight and space for new facilities
slide-33
SLIDE 33

Well Density – Onshore vs. Offshore

  • Onshore high well density
  • ~2 million barrels per well
  • Offshore fewer wells
  • ~30 million barrels per well
slide-34
SLIDE 34

20000 40000 60000 80000 100000 120000 140000 Year 1 Year 3 Year 5 Year 7 Year 9 Year 11 Year 13 Year 15 Year 17 Year 19 Year 21 Year 23 Year 25 Year 27 Year 29 Year 31 Year 33 Year 35 Year 37 Year 39 Year 41 Year 43 Year 45 Oil Production Rate (stb/d) 0% 10% 20% 30% 40% 50% 60% 70% Recovey Factor (%) Oil Production Rate - Waterflood (stb/d) Oil Production Rate - CO2 Injection (stb/d) Recovery Factor (%)

Delay?

Typical CO2 EOR Response in North Sea Oil Field

slide-35
SLIDE 35

Offshore CO2 EOR Implementation (Capital Expenditure)

  • Additional ~20 years from existing facilities
  • CO2 reception facilities and controls
  • Flow lines to injectors (CO2 and water) and

control valves

  • Gas/liquid separation facilities capable of

handling high content CO2 in produced fluids

  • Separation of CO2 and hydrocarbon gas (or

just separate enough for fuel gas)

  • Dehydration and compression of produced

gas for reinjection (increasing CO2 content in produced gas)

  • Start-up CO2 pumps
  • Production well tubing needs replacing with

stainless steel (to deal with produced CO2)

  • Baseline measurements for subsequent

monitoring

slide-36
SLIDE 36
  • Produced gas

Assure Storage of Injected CO2 in EOR Project (to meet regulations)

  • Measure amounts injected and

produced to maintain inventory

  • Keep average reservoir pressure below

initial pressure

  • Assess CO2 seal capacity and seismic

risk over storage period

  • Model long-term migrations and

reactions, if any

  • Monitor for potential leakage via wells or

geological pathways during injection period

  • Abandon wells in a manner consistent

with long-term secure CO2 storage

slide-37
SLIDE 37

To conclude: So what does the future hold for CO2 EOR in the North Sea?

  • Supply of CO2 will (in all probability) develop from CCS
  • Initial CCS projects will plan for storage only, but proximity and

availability of CO2 likely to provide opportunities for EOR initially possibly in the smaller/medium sized fields

  • If successful, redevelopment of larger mature fields may occur
  • New specialist CO2 operators may emerge
  • Once EOR phase complete some extra opportunity to store

additional CO2

  • Adjustment of tax regime may be needed to make offshore

EOR economic

  • Regulation around CO2 storage (over and above O&G

regulations) may be a significant burden

slide-38
SLIDE 38

Big Decision

  • Bulk of CO2 captured in

south (2035-50 numbers from ETI)

  • Saline aquifer storage

nearby

  • but EOR opportunity in
  • il fields in north
  • Trunk pipeline required
  • Who should pay?
  • Up to £1 billion?

95 mill te/y 15 mill te/y

Source: www.co2stored.co.uk

slide-39
SLIDE 39
  • That concludes my talk
  • Thank you to Senergy (www.senergyworld.com) for

allowing me to make this presentation

  • Discussion

Discussion

slide-40
SLIDE 40

UK Competition Projects

  • Shell/SSE – Peterhead, existing 340 MW CCGT, post-

combustion capture, 1 million tonnes per year, stored in Goldeneye (Blocks 14/29a, 20/4b and 20/3b)

  • Alstom/Drax/BOC/National Grid – White Rose, Selby, 450

MW (gross), Oxyfuel, 2 million tonnes per year, stored in Bunter Block 5/42

  • Other projects
  • 2Co Energy/National Grid – Don Valley, Hatfield
  • Summit Power/Petrofac/National Grid/Siemens – Captain

Clean Energy Project, Grangemouth

  • Progressive Energy/GDF SUEZ/Premier Oil/BOC –

Teesside Low Carbon Project
