Offline Language Translation Tool Capability Collaboration Event

11 June 2019

sofwerx.org/translator

Team Votes Black 15 Blue 2 Purple 4 Red 1 Green 18 Orange 9

Blue Sky Working Group Brief Outcomes

{Black} One-Year Product Development Plan

One-on-One, Two-Way Speech

1. Hardware

• Current generation Android phone
• Memory: 2 GB RAM, 16 GB internal mem (min)
• Microphone: Push-to-Talk directional microphone
• Audio: Speaker/AUX output

2. Software

• Identify candidate existing algorithm sources for…
• ASR, MT, TTS
• Build application, UI, integrate components
• Target MOPs: ILR = 1+; ASR Error < 50%; MT BLEU > 15;

Latency = 0.5s; CTR* = X 3. Language & Acoustics

• General Data collection (leverage existing data) >

Database population

• Use-specific Data Collection > Database population
• Build transcription and translation libraries
• Build language and acoustics models
• Target Languages: User’s single highest priority language

4. Other

• User interface research

Surreptitious/Background (Future)

1. Hardware

• Current generation Android phone w/ large display
• Memory: 2 GB RAM, 16 GB internal mem (min)
• Microphone: Far-field and/or array

2. Software

• Identify candidate existing algorithm sources for…
• ASR, MT
• Build application, UI, integrate components
• Target MOPs: ASR Error < 50%; MT BLEU > 15; Latency =

0.5s; CTR* = X

• Integrate keyword spotting algorithm

3. Language & Acoustics

• General Data collection (leverage existing data) > Database

population

• Use-specific Data Collection > Database population
• Build transcription and translation libraries
• Build language and acoustics models
• Target Languages: User’s single highest priority language

4. Other

• User interface research

{Black} Year 2/3 Product Improvement Plan

One-on-One, Two-Way Speech

1. Hardware

• Upgrade Android host phones as newer models

come out (refinements to software will only continue to increase computing load) 2. Software

• Refine ASR, MT, TTS algorithms
• Update UI based on testing/field data
• Target MOPs (increase): ILR = 1+; ASR Error < 25%;

MT BLEU > 25; Latency = 0.5s; CTR* = X 3. Language & Acoustics

• Update language and acoustics models based on

testing/field data

• Target Languages (user-driven): either (A) add

more languages, or (B) increase sophistication on priority languages, or (C) pay a ton of $ and do both 4. Other

• User interface research

Surreptitious/Background

1. Hardware

• Upgrade Android host phones as newer models

come out (refinements to software will only continue to increase computing load) 2. Software

• Refine ASR, MT, algorithms
• Update UI based on testing/field data
• Target MOPs (increase): ASR Error < 25%; MT

BLEU > 25; Latency = 0.5s; CTR* = X 3. Language & Acoustics

• Update language and acoustics models based on

testing/field data

• Target Languages (user-driven): either (A) add

more languages, or (B) increase sophistication on priority languages, or (C) pay a ton of $ and do both 4. Other

• User interface research

{Blue}

• One-Year product development plan

▪ Select/Define Use Case ▪ Real time transcription/translation via audio ▪ Must address concerns for: a) Hardware Architecture– Form Fit Factor, Processing Ability a) Wireless ear piece: Near Field Magnetic Solution b) Handheld/Body - S7 ATAK/Galaxy Note 8 c) Centralized Processing Unit – KLAS VOYAGER; AWS Snowball/Outpost, etc. a) Bandwidth = 80MB (Trellisware/MANET) b) Computing power = 50 Watts

{Blue}

• One-Year product development plan

▪ Select/Define Use Case ▪ Real time transcription/translation via audio ▪ Must address concerns for: a) Software Architecture – AI Software Selection/Configuration w/HW a) Engine Selection for Transcription/Translation w/ appropriate mix of AI engines a) Via, Sage Maker, Veritone aiWARE for orchestration and algorithm management b) Identify key acoustic engines – open source & proprietary c) Identify key transcription/translation engines – open source & proprietary b) Language – Identify Set # of Languages to process for first year. a) Arabic, Spanish, Russian, Chinese c) UI/UX Definition – SW/HW a) Data Processing & Analysis, Training. b) In Theater/On Scene Interactions

• How will you employ it?

▪ One on one, surreptitious/background/etc.? ▪ One on one – general collection/Ground Truth Classification/low noise ▪ Background Noise/Combination of Speakers – Preprocessing/ Adv Classification /De noise/Acoustic Eng

{Blue}

• Pre-Planned Product Improvements for year two to three:
• Add Use Cases
• Interactive Solution – More engines, recommender, Selective Speech ID
• Add languages
• Improve UI
• Audio/video – Ear Piece/Helmet Cam/Eye Glass
• Add additional cognitive categories
• Speaker separation, Speech ID, Language ID, Voice Recognition, Sentiment
• Object Detection, OCR, Clothing etc.
• Behavioral Engines
• Performance Improvements, Scale, Processing ability
• Adv Architecture deployment Core/Edge Solution via Cloud/Stand Alone
• On the fly Training Feedback Loop/Algorithm-Model Retraining Process
• Transition capability to additional problem sets
• Transition data to cloud-based system

{Purple}

• One-Year product development plan

▪ Must address concerns for: a) Hardware – microphones –far field experience. Beam forming tech on consumer smartphones. Mini cloud. Finite languages (2 or 3?). USB for terabyte extension b) Software –multiple OS (android/iOS). Transcription tech to share. Data at rest encryption. Gather existing solutions. c) Acoustics– capture enough noise environments. Phonetics. d) Language- decide on metrics/product viability. Recording data for languages without existing data sources. e) Other – assess cognitive load of the Warfighter when using machine translation

• How will you employ it?

▪ One on one at first

{Purple} –Year 1 Plan

• Stage 1:
• Test and evaluate using off the shelf commercial hardware

and software including Android/iOS using Google, Microsoft, iTranslate etc. Modern capable phone

• Using Warfighters, role players and interpreters, figure
• ut how a warfighter’s operational capability is

increased (eg detect when interpreter is changing the message or missed something important) with machine translation.

• Use best language translation pairs
• Evaluate key languages to begin field testing for the

languages with less data and begin improving them with acquisition of language data Stage 2: collect data from louder environments for key languages Stage 3: Measures of success – task completion %.

{Purple}- Year 2/3 Plan

• Pre-Planned Product Improvements for year two to three:
• Hardware development – microphones for multi-person

environments and background noise.

• Increase storage capacity on phones (USB?) for recordings

to improve the machine and assess accuracy of translations

• Increase language availability through acquisition of

language data

{Red} One Year

• Hardware
• Android based device
• Best of breed devices
• Focus on using earphones for translation
• Hands free as much as possible
• External microphones on user
• Bottom line: device is based upon program office procurements today and

future

{Red} One Year

• Software
• Application based
• Cloud Updates for new phrases and common terms
• Language Identification to distinguish unexpected languages
• Loose coupling: data can be processed and viewed the same way across

different systems

• Algorithms: Speech to text, text to text (translation), text to speech

{Red} One Year

• Acoustics
• Assessment of current technology, most effective
• Beamforming: multiple microphones to distinguish voices (alexa)
• Audio processing is noise cancelling for speaker’s separation from the

environment

{Red} One Year

• Language
• Upload and focus on gathering information for mission critical languages and

dialects (local translators, language database via government, social media, television closed captioning)

• Understand common phrases or indicators of harm (someone saying “bomb”)
• Languages will be selected on device before entering mission area (most

common languages/dialects in region)

• User discretion for switching language

{Red}

• Pre-Planned Product Improvements for year two to three:
• User feedback process improvement
• Upgrade size of devices
• Enhance range of microphones
• Continuously collect information for more languages and

dialects

• Bottom Line: stay consistent with program office and user

needs

End solution

• Different modules that could be used based on the situation and

available hardware.

• Mobile phone only
• Mobile phone + microphone
• Mobile phone + mic + Jetson

Jetson AGX Xavier + Battery + storage Standalone unit for situations where other hardware is not available Microphone

Hardware

• Discrete hardware the operator carries in their backpack (Jetson AGX

Xavier + battery ) connects to multiple mobile phones in the vicinity

• ver a local network.
• Phone is just an interface and can be any Android device if used with

discrete processing hardware

• In standalone mode (lower accuracy and capability) mobile phone will

be a Samsung Galaxy S7 / Note 8

• Wearable directional microphone (Optional)
• Data storage (SD card/Portable HDD) (Store 24 hours of audio that can

be offloaded and processed later)

Software

• Plug-in architecture to add different modules into the system on the

field

• Auto detect hardware
• Different ML models based on different situations
• HLT algorithms (Human language technologies)
• Ability to use different models based on operator feedback (select

language, dialect)

• Retrain on stored data with periodic upgrades
• Different noise cancellation algorithms based on environment

Acoustics

• Microphone
• Choice of having a unidirectional microphone vs omnidirectional mic.
• Limit to environments with few (2-5) speakers in the first year

Language

• Limit to few languages in first year (STT+MT)
• Spanish
• Portuguese
• Russian
• French
• Mandarin
• Farsi (stretch goal if data is available)
• See what data is available from other government entities.

Other

• Keyword alerts across devices

Phase 2 (2nd year)

• Increase model accuracy for standalone mode
• Multiple speaker diarization
• Add more languages
• Get more data (Transcribe the recorded audio)

Phase 3 (3rd year)

• Add code switching
• Add more languages
• Refine technology
• Add ability to focus on different conversations (eg: Focus on different

conversations based on important keywords)

• Train speaker ID based on collected and annotated data (if required as a

separate tool)

ORANGE Product development plan: Year 1

• Use case:
• One-on-one interaction: separate channel to verify interpreter performance
• Integrate speaker recognition/tracking to separately track interpreter and

foreign-language interlocutor

• Speaker ID for pre-enrolled speakers, to flag if the interlocutor is a known

speaker

• User chooses language
• Prioritize accuracy and performance over weight/compute power/battery life

Hardware

• Ruggedized laptop/tablet in backpack/vehicle
• Tethered by Bluetooth or wired (if in backpack) to phone
• Use built-in mic in phone
• Earbud and also scrolling on-screen display of translated output

Software

• User interface, multiple iterations with users
• Communications between phone and laptop, synchronization
• Format transcript so it’s usable
• Storage of audio recordings on laptop
• Storage of written transcripts on laptop and optionally on phone
• Integrate speaker recognition/tracking to separately track interpreter

and foreign-language interlocutor

• Means to download new language components, update models, upload

stored recordings & transcripts

Languages

• Year 1:
• Modern Standard Arabic, Farsi, Russian, (African) French
• Need to verify availability, quantity, quality, types of data
• Further improve existing speech recognition and machine translation engines
• Start data collection for out years
• Egyptian Arabic, Levantine Arabic, Korean, Indonesian
• Collect real or role-played interactions; make audio recordings, transcribe,

translate (in text)

• Gather data that’s already being created, e.g. US-funded/partnered

radio/TV/etc. (including call-ins), which is being translated back to English

• Collections of different dialect acoustics to support language ID

Program management

• Bimonthly meetings with government customer and with users to solicit

feedback

• Trial system with most developed language (e.g. MSA) starting from

month 8

• Trial again in month 10.5
• Delivery of systems at end of month 12

Year 2

• Use case
• Add language ID: user picks a set of most likely dialects (e.g. based on location),

system can make its own choice from among those or others

• Translate a conversation with no interpreter involved, just listening in
• Ability to give some feedback to the user about audio quality coming in
• Directional mic or array mic

Year 2

• Develop models for new languages for basic components
• Egyptian Arabic, Levantine Arabic, Korean, Indonesian
• Improvements, bug fixes, feature enhancements after year 1 delivery
• Add language ID
• Reduce component size with a view toward running on phone

standalone

• Plan for surreptitious/crowd-usage case
