Official distributor

HD Golf™ has introduced more ‘next generation technology’ to the indoor virtual golf simulator industry than any other company: Computer Vision Technology: HD Golf™ pioneered advanced Computer Vision Technology with smart cameras for ball & club tracking. CVT provides the most precise and comprehensive measurements

• f any golf simulator, as verified by PGA Tour

players like Bubba Watson, top golf instructors like Jim McLean and equipment manufacturers like

• Nike. For example, clubface angle at contact is

accurate to within 1/10th of 1 degree. High Definition Golf™ also led the way by developing a completely integrated Professional Golf Instruction Studio featuring video swing analysis, swing dynamics and weight transfer

• analysis. Taking golf instruction to another level,

High Definition Golf™ was the first to develop automated video swing analysis based on Jim McLean’s 8-Step Swing System. But the firsts don’t stop there. COMPUTER VISION TECHNOLOGY

Realistic 3D modelling: We invented new, revolutionary image processing software to combine high-resolution digital images, satellite data and geophysical data into 3D models of golf

• courses. This allows us to deliver premium

championship courses using REAL COURSE

• DATA. Enjoy luxurious detail, experienced by few –

and loved by all who hold realism in the highest

• regard. This creates incredible realism that

transports you to some of the world’s most famous courses, like Pebble Beach or St. Andrews. REALLISTIC 3D MODELLING [background] Pebble Beach Hole 7 captured and reproduced in all it’s detail by HDG™

Automated Swing Capture – no operator required to hit a key on the keyboard to trigger the swing

• capture. Note: Some competitive systems rely on

acoustic triggers for swing capture but these tend to work poorly in noisy environments and can be very frustrating to operate. The Perfect Swing: Compare your swing to that of the pros! HD Golf™ Video Swing Analysis is the

• nly golf simulator that features The Perfect Swing

which incorporates the swings of Ernie Els, Ben Hogan and Tiger Woods (a composite swing model developed in conjunction with world-renowned golf instructor Jim McLean) Editing Tools: HD Golf™ Video Swing Analysis module is feature-rich and includes a complete set

• f drawing and editing tools that can be accessed

easily from the touch screen. Features include: Freeze Frame, Side by Side Comparison, Slow Motion Playback and the ability to save swings for later review. HD GOLF™ VIDEO SWING ANALYSIS High-Speed Cameras: Module uses high-speed cameras (120 frames per second) with special wide-angle lenses to capture data. HD Golf™ cameras also work well in low light and in situations where space is at a premium, such as an indoor hitting bay. Note: Competitors use standard DV camcorders (average of 30 frames per second) to capture data and they tend to produce blurry images. Most DV camcorders may

• perate poorly in low light conditions rendering

footage that may be useless for teaching purposes. Video Playback is always sharp and easy for players and coaches to review Module is easy to setup and even easier to use. Just connect the cameras (included) and you are ready to go. No need to purchase a costly second computer and software

High Definition Golf™ Weight Transfer/Balance Analysis provides instructors with a comprehensive series of balance measurements, collected at every point of the students swing including: Balance, Weight Transfer, Center of Gravity and Tempo. The HD Golf™ Pressure Mat, (with Sensor Technology from BodiTrak) provides a detailed analysis (based on 600 sensors) which indicates key pressure points allowing golfers to see micro- moves that cannot be seen on video. Integrated seamlessly into every HDG™ simulator, the HDG™ club fitting software uses advanced computer vision technology to make a comprehensive series of highly-accurate measurements in real-time. These measurements are then displayed on the system touch screen and large display screen for instant feedback. WEIGHT TRANSFER/BALANCE ANALYSIS

Professional club fitters take into consideration many factors when fitting clubs to a golfer. Whether it is a student just learning the game or a seasoned professional with years of experience the right fitting and most comfortable clubs will ultimately determine how well an individual will play the game. The big question is where do you start? Today, with so many choices in the marketplace, club fitters need a better tool that will help connect the golfer to the perfect clubs. For that reason, High Definition Golf™ introduces a revolutionary system that is so easy-to-use that professional club fitters and casual players alike can use it to achieve a perfect fit. Integrated seamlessly into every HDG™ simulator, the HDG™ club fitting software uses advanced computer vision technology to make a comprehensive series of highly-accurate measurements in real-time. These measurements are then displayed on the system touch screen and large display screen for instant feedback. CLUB FITTING

The High Definition Golf™ Swing Dynamics uses advanced Computer Vision Technology to make a comprehensive series of highly accurate Swing Dynamics and shaft measurements in “real-time.” As a result, club manufacturers and club fitters will be able to let their customers test and compare a variety of golf clubs and shafts with new

• confidence. The system, in turn, will generate a

detailed report that can be viewed on screen, printed or emailed to the customer for their personal records.

• Overall Shaft Flex
• Angle of Attack
• Club Head Acceleration
• Wrist Cock
• Load Factor
• Position of Maximum Club Head Speed
• Club Head Speed at Impact
• Swing Tempo

HD GOLF™ SWING DYNAMICS

Whether for entertainment, golf instruction, club fitting or golf retail, High Definition Golf™ systems can be configured to meet your specific needs. With six models to choose from, including our newest additions, which feature a wider field of view and curved screens, you can create a completely immersive playing environment. Installation is quick and simple, with no sub-floor or room construction required. And, your HD Golf™ simulator can be designed in either a “soft-wall” or “hard-wall”configuration for the most aesthetic

• appeal. The custom draperies extend during golf

play and retract when finished to create an integrated home theater or viewing area. HDG™ Home Theater - bring movies and events to life on the large High Brightness/Contrast screen by connecting satellite or cable, or by using the built-in DVD player. You can even connect a game console for the ultimate gaming experience. CUSTOMIZED FOR YOUR SPACE [background] One of three HDGolf™ simulators in CentrumGolf

Executive 9’ Tall x 14′ Wide x 20’ Long Standard 10’ Tall x 15.6″ Wide x 20’ Long Championship 11’ Tall x 17′ Wide x 21’ Long 16:10 CURVED WIDE SCREEN

Executive 9’ Tall x 14′ Wide x 18’ Long Standard 10’ Tall x 15.6″ Wide x 19’ Long Championship 11’ Tall x 17′ Wide x 20’ Long 16:10 FLAT WIDE SCREEN

Executive 9’ Tall x 12′ Wide x 18’ Long Standard 10’ Tall x 13″ Wide x 19’ Long Championship 11’ Tall x 14,6′ Wide x 21’ Long 4:3 FLAT SCREEN

Standard System Components

• HDTV Compatible High Brightness/Contrast

Digital LCD Projector

• 19” LCD Touch Screen
• Dell Precision Workstation
• Computer Vision Ball Tracking System with IST

High Speed Intelligent

• Spectrum Sensor Technology (4 “Smart”

cameras)

• HD Softstrike™ Hit Mat
• High strength & durability golf/projection

screen with multi-layer ‘low rebound/low noise design’

• Stereo Amplifier & Paradigm Speakers
• True Turf Artificial Turf
• Professional-quality golf mats (stance & hitting

mat) + tees

• Drapery Package

SYSTEM SPECIFICATIONS High Definition Golf™ Software Package Including

• Advanced Ball Tracking and Trajectory Analysis
• 20 Championship Golf Courses
• Complete Practice Facility - Driving Ranges,

Chipping/Putting Greens and Target Ranges

• Club Fitting
• Equipment Comparison
• Tournament Play
• Competitions – Closest-to-the-pin, longest

drive and putting Games

• Player Lockers
• Player statistics and printable score cards
• Internet/remote diagnostics

Options

• High Brightness/Contrast commercial grade

projector

• Rough + Sand Golf Mat Panels
• Computer/Touch-Screen Cabinet
• Professional Instruction Modules:
• Video Swing Analysis
• Weight Transfer/Balance Analysis
• Swing Dynamics • Motion Analysis
• Jim McLean 8-Step Swing Module
• Golf Center Management Software
• Internet Play with Live Video and Audio
• Paradigm Premium Surround Sound
• Golf Cage + Canopy + Awning
• Additional golf courses

Let’s keep in touch!

• ul. Burakowska 15

01-066 Warszawa warszawa@centrumgolf.pl (22) 428 88 84
