Numerical computations – with a view towards R

Søren Højsgaard Department of Mathematical Sciences Aalborg University, Denmark October 8, 2012

Printed: October 8, 2012 File: numComp-slides.tex

2

Contents

1 Computer arithmetic is not exact 3 2 Floating point arithmetic 4 2.1 Addition and subtraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.2 The Relative Machine Precision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2.3 Floating-Point Precision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.4 Error in Floating-Point Computations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3 Example: A polynomial 10 4 Example: Numerical derivatives 14 5 Example: The Sample Variance 16 6 Example: Solving a quadratic equation 18 7 Example: Computing the exponential 19 8 Ressources 24

3

1 Computer arithmetic is not exact

The following R statement appears to give the correct answer.

R> 0.3 - 0.2 [1] 0.1

But all is not as it seems.

R> 0.3 - 0.2 == 0.1 [1] FALSE

The difference between the values being compared is small, but important.

R> (0.3 - 0.2) - 0.1 [1] -2.775558e-17

4

2 Floating point arithmetic

Real numbers“do not exist”in computers. Numbers in computers are represented in floating point form s × be where s is the significand, b is the base and e is the exponent. R has“numeric”(floating points) and“integer”numbers

R> class(1) [1] "numeric" R> class(1L) [1] "integer"

5

2.1 Addition and subtraction

Let s be a 7–digit number A simple method to add floating-point numbers is to first represent them with the same exponent. 123456.7 = 1.234567 * 10^5 101.7654 = 1.017654 * 10^2 = 0.001017654 * 10^5 So the true result is (1.234567 + 0.001017654) * 10^5 = 1.235584654 * 10^5 But the approximate result the computer would give is (the last digits (654) are lost) 1.235585 * 10^5 (final sum: 123558.5) In extreme cases, the sum of two non-zero numbers may be equal to one of them Quiz: how to sum a sequence of numbers x1, . . . , xn to obtain large accuracy?

6

2.2 The Relative Machine Precision

The accuracy of a floating-point system is measured by the relative machine precision or machine epsilon. This is the smallest positive value which can be added to 1 to produce a value different from 1. A machine epsilon of 10−7 indicates that there are roughly 7 decimal digits of precision in the numeric values stored and manipulated by the computer. It is easy to write a program to determine the relative machine precision

R> .Machine$double.eps [1] 2.220446e-16

7 R> macheps <- function(){ eps <- 1 while(1+eps/2 != 1) eps <- eps / 2 eps } R> macheps() [1] 2.220446e-16

8

2.3 Floating-Point Precision

The preceding program shows that there are roughly 16 decimal digits of precision to R arithmetic. It is possible to see the effects of this limited precision directly.

R> a = 12345678901234567890 R> print(a, digits=20) [1] 12345678901234567168

The effects of finite precision show up in the results of calculations.

9

2.4 Error in Floating-Point Computations

Numbers are accurate to about 15 significant digits. Subtraction of positive values is one place where the finite precision of floating-point arithmetic is a potential problem.

R> x = 1+1.234567890e-10 R> print(x, digits = 20) [1] 1.0000000001234568003 R> y = x - 1 R> print(y, digits = 20) [1] 1.234568003383174073e-10

There are 16 correct digits in x, but only 6 correct digits in y. Subtraction of nearly equal quantities (known as near cancellation) is a major source of inaccuracy in numerical calculations and requires special care.

10

3 Example: A polynomial

The function f(x) = x7 − 7x6 + 21x5 − 35x4 + 35x3 − 21x2 + 7x − 1 is a 7th degree polynomial, and its graph should appear very smooth. To check this we can compute and graph the function over a range of values

R> x = seq(.988, 1.012, by = 0.0001) R> y = x^7 - 7*x^6 + 21*x^5 - 35*x^4 + 35*x^3 - 21*x^2 + 7*x - 1 R> plot(x, y, type = "l")

11

0.990 0.995 1.000 1.005 1.010 −4e−14 0e+00 4e−14 x y

Not very smooth!

12

To see where the cancellation error comes split the polynomial into individual terms and see what happens when we sum them.

R> x = .99 R> y = c(x^7, - 7*x^6, + 21*x^5, - 35*x^4, 35*x^3, - 21*x^2, + 7*x, - 1) R> y [1] 0.9320653

• 6.5903610

19.9707910 -33.6208604 33.9604650 -20.5821000 [7] 6.9300000

• 1.0000000

R> cumsum(y) [1] 9.320653e-01 -5.658296e+00 1.431250e+01 -1.930837e+01 1.465210e+01 [6] -5.930000e+00 1.000000e+00 -1.521006e-14

It is the last subtraction (of 1) which causes the catastrophic cancellation and loss

• f accuracy.

We can reformulate the problem by noticing that f(x) = x7 − 7x6 + 21x5 − 35x4 + 35x3 − 21x2 + 7x − 1 = (x − 1)7 Notice that although we are still getting cancellation, when 1 is subtracted from values close to 1, we are only losing a few digits of accuracy.

13

The difference is apparent in the plot.

R> x = seq(.988, 1.012, by = 0.0001) R> y = (x - 1)^7 R> plot(x, y, type = "l")

0.990 0.995 1.000 1.005 1.010 −3e−14 0e+00 3e−14 x y

14

4 Example: Numerical derivatives

The derivative f ′(x) may be approximated by f ′(x) ≈ f(x + h/2) − f(x − h/2) h , h small For small h we get near cancellation errors. A generic R function is

R> numDeriv <- function(f, x, h=1e-8){ (f(x+h/2)-f(x-h/2))/h }

Find derivative of exponential at x = 1:

R> g <- function(x){exp(x)} R> print(numDeriv(g, 1), digits=20) [1] 2.7182818218562943002 R> print(exp(1), digits=20) [1] 2.7182818284590450908

15

Try range of h values:

R> hvec <- seq(5e-9, 1e-6, 1e-8) R> dvec <- numDeriv(g, 1, hvec) R> plot(hvec, (dvec-exp(1))/exp(1), type='l') R> abline(h=0, col='red')

0e+00 2e−07 4e−07 6e−07 8e−07 1e−06 −5e−09 5e−09 hvec (dvec − exp(1))/exp(1)

16

5 Example: The Sample Variance

Consider the formula for the sample variance 1 n − 1

n

• i=1

(xi − ¯ x)2 = 1 n − 1

• n
• i=1

x2

i − n¯

x2

• The left-hand side of this equation provides a much better computational

procedure for finding the sample variance than the right-hand side. If the mean of xi is far from 0, then

i x2 i and n¯

x2 will be large and nearly equal to each other. The relative error which results from applying the right-hand side formula can be very large. There can, of course, be loss of accuracy using the formula on the left, but it is not nearly as severe.

17 R> sdval <- 5 R> x <- rnorm(10, mean=1000000, sd=sdval) R> x.bar <- mean(x) R> n <- length(x) R> lhs <- sum((x-x.bar)^2)/(n-1) R> rhs <- (sum(x^2)-n*x.bar^2)/(n-1) R> print(lhs, digits=10) [1] 29.51578653 R> print(rhs, digits=10) [1] 29.51584201 R> print(rhs-lhs, digits=10) [1] 5.548186877e-05

18

6 Example: Solving a quadratic equation

Consider solving ax2 + bx + c = 0 Letting D = b2 − 4ac, the roots are r1 = −b + √ D 2a , r2 = −b − √ D 2a If b2 ≫ ac then √ D = √ b2 − 4ac ≈ |b|. If b > 0 then −b + √ D involves a near cancellation (same for −b − √ D if b < 0). Rewrite the problem: Multiply numerator and dominator of r1 by −b + √ D (and

• f r2 by −b +

√ D) by to obtain r1 = 2c −b − √ D , r2 = 2c −b + √ D

19

7 Example: Computing the exponential

The exponential function is defined by the power series exp(x) =

n

• n=0

xn n! Letting tn = xn

n! we have tn+1 = tn x n+1 so these terms must eventually become

small. One strategy for summing the series is to accumulate terms of the series until the terms become so small that they do not change the sum.

20 R> expf <- function(x){ n <- 0 term <- 1 ans <- 1 while(abs(term)> .Machine$double.eps) { n = n + 1 term = term * x / n ans <- ans + term } ans }

21

Compare expf() with R’s built in function. For positive values, the results are good:

R> (expf(1) - exp(1))/exp(1) [1] 1.633713e-16 R> (expf(20) - exp(20))/exp(20) [1] -1.228543e-16

For negative values less so:

R> (expf(-1) - exp(-1))/exp(-1) [1] 3.017899e-16 R> (expf(-20) - exp(-20))/exp(-20) [1] 1.727543

Why?

22

When x < 0 the terms in exp(x) =

n

• n=0

xn n! alternate in sign. For large negative x values, the value returned by the function is small while at least some of the terms are large. Hence, at some point, there has to be near-cancellation of the accumulated sum and the next term of the series. This is the source of the large relative error. Notice: When the argument to expf() is positive, all the terms of the series are positive and there is no cancellation.

23

There is an easy remedy: Since exp(−x) = 1/ exp(x) it is for negative x better to compute the result as exp(x) = 1/ exp(−x)

R> expf <- function(x){ if (x<0) { 1/expf(-x) } else { n <- 0; term <- 1; ans <- 1 while(abs(term)> .Machine$double.eps) { n = n + 1 term = term * x / n ans <- ans + term } ans } } R> (expf(-1) - exp(-1))/exp(-1) [1] -1.50895e-16 R> (expf(-20) - exp(-20))/exp(-20) [1] 2.006596e-16

24

8 Ressources

What Every Computer Scientist Should Know About Floating-Point Arithmetic: http://docs.oracle.com/cd/E19957-01/806-3568/ncg_goldberg.html
