FACULTY OF SCIENCE Bart Jacobs Structuring Computations Structuring Computations Contents Jacobs Types06, 18/4/06 p.1/52 Structuring Computations Contents I. Sneak preview VII. Hoare logic for JML II. Comonads VIII. Conclusions

slide-1
SLIDE 1

FACULTY OF SCIENCE

Bart Jacobs

Structuring Computations

slide-2
SLIDE 2

Contents

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.1/52

slide-3
SLIDE 3

Contents

Structuring Computations

  • I. Sneak preview
  • II. Comonads
  • III. Arrows
  • IV. Monads, also for

Java

  • V. Java verification
  • VI. Static checking
  • VII. Hoare logic for JML
  • VIII. Conclusions

Jacobs – Types’06, 18/4/’06 – p.1/52

slide-4
SLIDE 4

Contents

Structuring Computations

  • I. Sneak preview
  • II. Comonads
  • III. Arrows
  • IV. Monads, also for

Java

  • V. Java verification
  • VI. Static checking
  • VII. Hoare logic for JML
  • VIII. Conclusions

No explicit message; some type/object-related topics that I like; and you too, hopefully!

Jacobs – Types’06, 18/4/’06 – p.1/52

slide-5
SLIDE 5
  • I. Sneak preview

Jacobs – Types’06, 18/4/’06 – p.2/52

slide-6
SLIDE 6

Purely functional programs

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.3/52

slide-7
SLIDE 7

Purely functional programs

Structuring Computations

Writing X for the type of inputs, Y for outputs . . .

Jacobs – Types’06, 18/4/’06 – p.3/52

slide-8
SLIDE 8

Purely functional programs

Structuring Computations

Writing X for the type of inputs, Y for outputs . . . . . . a functional program from X to Y is simply a function X

Y

Jacobs – Types’06, 18/4/’06 – p.3/52

slide-9
SLIDE 9

Imperative, state-based programs

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.4/52

slide-10
SLIDE 10

Imperative, state-based programs

Structuring Computations

Writing S for the type of states . . .

Jacobs – Types’06, 18/4/’06 – p.4/52

slide-11
SLIDE 11

Imperative, state-based programs

Structuring Computations

Writing S for the type of states . . . . . . an imperative program is: X × S

Y × S

Jacobs – Types’06, 18/4/’06 – p.4/52

slide-12
SLIDE 12

Imperative, state-based programs

Structuring Computations

Writing S for the type of states . . . . . . an imperative program is: X × S

Y × S

Or, equivalently, X

(Y × S)S

Jacobs – Types’06, 18/4/’06 – p.4/52

slide-13
SLIDE 13

Imperative, state-based programs

Structuring Computations

Writing S for the type of states . . . . . . an imperative program is: X × S

Y × S

Or, equivalently, X

(Y × S)S

Involving the State Monad Y − → (Y × S)S

Jacobs – Types’06, 18/4/’06 – p.4/52

slide-14
SLIDE 14

Reactive, stream-based programs

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.5/52

slide-15
SLIDE 15

Reactive, stream-based programs

Structuring Computations

A reactive program is: XN

Y N

Jacobs – Types’06, 18/4/’06 – p.5/52

slide-16
SLIDE 16

Reactive, stream-based programs

Structuring Computations

A reactive program is: XN

Y N

Or, equivalently, XN × N

Y

Jacobs – Types’06, 18/4/’06 – p.5/52

slide-17
SLIDE 17

Reactive, stream-based programs

Structuring Computations

A reactive program is: XN

Y N

Or, equivalently, XN × N

Y

Involving the Stream Comonad X − → XN × N

Jacobs – Types’06, 18/4/’06 – p.5/52

slide-18
SLIDE 18

Quantum program

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.6/52

slide-19
SLIDE 19

Quantum program

Structuring Computations

A possible quantum program is: X × X

[0, 1](Y ×Y )

Jacobs – Types’06, 18/4/’06 – p.6/52

slide-20
SLIDE 20

Quantum program

Structuring Computations

A possible quantum program is: X × X

[0, 1](Y ×Y )

It is a “superoperator” on “density matrices” (or quantum states)—after Vizotto, Altenkirch, Sabry

Jacobs – Types’06, 18/4/’06 – p.6/52

slide-21
SLIDE 21

Quantum program

Structuring Computations

A possible quantum program is: X × X

[0, 1](Y ×Y )

It is a “superoperator” on “density matrices” (or quantum states)—after Vizotto, Altenkirch, Sabry It forms an example of an Arrow: computations with unit and composition.

Jacobs – Types’06, 18/4/’06 – p.6/52

slide-22
SLIDE 22

Overview

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.7/52

slide-23
SLIDE 23

Overview

Structuring Computations

  • Functional: X −

→ Y

Jacobs – Types’06, 18/4/’06 – p.7/52

slide-24
SLIDE 24

Overview

Structuring Computations

  • Functional: X −

→ Y

  • Imperative: X −

→ T(Y ), with T monad (including Java programs)

Jacobs – Types’06, 18/4/’06 – p.7/52

slide-25
SLIDE 25

Overview

Structuring Computations

  • Functional: X −

→ Y

  • Imperative: X −

→ T(Y ), with T monad (including Java programs)

  • Reactive: G(X) −

→ Y , with G comonad

Jacobs – Types’06, 18/4/’06 – p.7/52

slide-26
SLIDE 26

Overview

Structuring Computations

  • Functional: X −

→ Y

  • Imperative: X −

→ T(Y ), with T monad (including Java programs)

  • Reactive: G(X) −

→ Y , with G comonad

  • Quantum: A(X, Y ), with A “arrow”

Jacobs – Types’06, 18/4/’06 – p.7/52

slide-27
SLIDE 27
  • II. Comonads

Jacobs – Types’06, 18/4/’06 – p.8/52

slide-28
SLIDE 28

Comonads for computations

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.9/52

slide-29
SLIDE 29

Comonads for computations

Structuring Computations

  • Monads are well-established in functional

programming & language semantics

Jacobs – Types’06, 18/4/’06 – p.9/52

slide-30
SLIDE 30

Comonads for computations

Structuring Computations

  • Monads are well-established in functional

programming & language semantics

  • But little attention for the dual notion of

comonad . . .

Jacobs – Types’06, 18/4/’06 – p.9/52

slide-31
SLIDE 31

Comonads for computations

Structuring Computations

  • Monads are well-established in functional

programming & language semantics

  • But little attention for the dual notion of

comonad . . .

  • . . . until Uustalu & Vene recently used them

for structuring reactive/dataflow programming—building on Brookes & Geva

Jacobs – Types’06, 18/4/’06 – p.9/52

slide-32
SLIDE 32

Comonads for computations

Structuring Computations

  • Monads are well-established in functional

programming & language semantics

  • But little attention for the dual notion of

comonad . . .

  • . . . until Uustalu & Vene recently used them

for structuring reactive/dataflow programming—building on Brookes & Geva

  • Slogan: monads structure output,

comonads structure input

Jacobs – Types’06, 18/4/’06 – p.9/52

slide-33
SLIDE 33

Comonad structure

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.10/52

slide-34
SLIDE 34

Comonad structure

Structuring Computations

  • Categorically: endofunctor G: C → C with

two natural transformations ε: G ⇒ Id and δ: G ⇒ G2 satisfying standard equations

Jacobs – Types’06, 18/4/’06 – p.10/52

slide-35
SLIDE 35

Comonad structure

Structuring Computations

  • Categorically: endofunctor G: C → C with

two natural transformations ε: G ⇒ Id and δ: G ⇒ G2 satisfying standard equations

  • Computationally: Type operator G with
  • coreturn : GX −

→ X

  • cobind : (GX → Y ) −

→ (GX → GY ) satisfying suitable equations

Jacobs – Types’06, 18/4/’06 – p.10/52

slide-36
SLIDE 36

Comonad structure

Structuring Computations

  • Categorically: endofunctor G: C → C with

two natural transformations ε: G ⇒ Id and δ: G ⇒ G2 satisfying standard equations

  • Computationally: Type operator G with
  • coreturn : GX −

→ X

  • cobind : (GX → Y ) −

→ (GX → GY ) satisfying suitable equations

  • Logically: structure for weakening and

contraction (like bang ! in linear logic)

Jacobs – Types’06, 18/4/’06 – p.10/52

slide-37
SLIDE 37

Comonad example

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.11/52

slide-38
SLIDE 38

Comonad example

Structuring Computations

  • Mapping X −

→ XN × N

Jacobs – Types’06, 18/4/’06 – p.11/52

slide-39
SLIDE 39

Comonad example

Structuring Computations

  • Mapping X −

→ XN × N

  • Input streams with past / current / future:

x0, x1, . . . , xn−1, xn , xn+1, xn+2, . . .

Jacobs – Types’06, 18/4/’06 – p.11/52

slide-40
SLIDE 40

Comonad example

Structuring Computations

  • Mapping X −

→ XN × N

  • Input streams with past / current / future:

x0, x1, . . . , xn−1, xn , xn+1, xn+2, . . .

  • Counit / coreturn: XN × N −

→ X (α, n) − → α(n)

Jacobs – Types’06, 18/4/’06 – p.11/52

slide-41
SLIDE 41

Comonad example

Structuring Computations

  • Mapping X −

→ XN × N

  • Input streams with past / current / future:

x0, x1, . . . , xn−1, xn , xn+1, xn+2, . . .

  • Counit / coreturn: XN × N −

→ X (α, n) − → α(n)

  • Delta: XN × N −

→ (XN × N)N × N (α, n) − → (λm: N. (α, m), n)

Jacobs – Types’06, 18/4/’06 – p.11/52

slide-42
SLIDE 42

coKleisli category of computations

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.12/52

slide-43
SLIDE 43

coKleisli category of computations

Structuring Computations

  • coKleisli maps XN × N −

→ Y form a category

Jacobs – Types’06, 18/4/’06 – p.12/52

slide-44
SLIDE 44

coKleisli category of computations

Structuring Computations

  • coKleisli maps XN × N −

→ Y form a category

  • Identity via coreturn; composition via

delta/cobind

Jacobs – Types’06, 18/4/’06 – p.12/52

slide-45
SLIDE 45

coKleisli category of computations

Structuring Computations

  • coKleisli maps XN × N −

→ Y form a category

  • Identity via coreturn; composition via

delta/cobind

  • Gives output in Y for completely given input

stream of X’s

Jacobs – Types’06, 18/4/’06 – p.12/52

slide-46
SLIDE 46

coKleisli category of computations

Structuring Computations

  • coKleisli maps XN × N −

→ Y form a category

  • Identity via coreturn; composition via

delta/cobind

  • Gives output in Y for completely given input

stream of X’s

  • Basis for dataflow calculus by Uustalu &

Vene (like in Lustre, Lucid)

Jacobs – Types’06, 18/4/’06 – p.12/52

slide-47
SLIDE 47

Discrete time signals

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.13/52

slide-48
SLIDE 48

Discrete time signals

Structuring Computations

Three basic comonads:

Jacobs – Types’06, 18/4/’06 – p.13/52

slide-49
SLIDE 49

Discrete time signals

Structuring Computations

Three basic comonads: X⋆ × X XN × N

causality no future

  • anti-causality

no past

XN (α(0),...,α(n−1),α(n)) (α,n)

  • λm. α(n+m)

Jacobs – Types’06, 18/4/’06 – p.13/52

slide-50
SLIDE 50

Discrete time signals

Structuring Computations

Three basic comonads: X⋆ × X XN × N

causality no future

  • anti-causality

no past

XN (α(0),...,α(n−1),α(n)) (α,n)

  • λm. α(n+m)

with “comonad homomorphisms” between them

Jacobs – Types’06, 18/4/’06 – p.13/52

slide-51
SLIDE 51

Continuous time signals

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.14/52

slide-52
SLIDE 52

Continuous time signals

Structuring Computations

Analogues fundamental diagram of comonads:

Jacobs – Types’06, 18/4/’06 – p.14/52

slide-53
SLIDE 53

Continuous time signals

Structuring Computations

Analogues fundamental diagram of comonads:

  • t∈[0,∞)

X[0,t) × X X[0,∞) × [0, ∞)

  • X[0,∞)

Jacobs – Types’06, 18/4/’06 – p.14/52

slide-54
SLIDE 54

Continuous time signals

Structuring Computations

Analogues fundamental diagram of comonads:

  • t∈[0,∞)

X[0,t) × X X[0,∞) × [0, ∞)

  • X[0,∞)

where:

  • t∈[0,∞)

X[0,t) × X ∼ =

  • t∈[0,∞)

X[0,t] ∼ = X[0,1] × [0, ∞)

Jacobs – Types’06, 18/4/’06 – p.14/52

slide-55
SLIDE 55
  • III. Arrows

Jacobs – Types’06, 18/4/’06 – p.15/52

slide-56
SLIDE 56

Arrow overview

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.16/52

slide-57
SLIDE 57

Arrow overview

Structuring Computations

  • Introduced in Haskell by Hughes in 2000, as

common interface extending monads (parser as main example)

Jacobs – Types’06, 18/4/’06 – p.16/52

slide-58
SLIDE 58

Arrow overview

Structuring Computations

  • Introduced in Haskell by Hughes in 2000, as

common interface extending monads (parser as main example)

  • Binary type operation A(−, +) with three
  • perations: arr, >

> >, first.

Jacobs – Types’06, 18/4/’06 – p.16/52

slide-59
SLIDE 59

Arrow overview

Structuring Computations

  • Introduced in Haskell by Hughes in 2000, as

common interface extending monads (parser as main example)

  • Binary type operation A(−, +) with three
  • perations: arr, >

> >, first.

  • Folklore claim: Arrows are Freyd categories

(Power & Robinson’99)

Jacobs – Types’06, 18/4/’06 – p.16/52

slide-60
SLIDE 60

Arrow overview

Structuring Computations

  • Introduced in Haskell by Hughes in 2000, as

common interface extending monads (parser as main example)

  • Binary type operation A(−, +) with three
  • perations: arr, >

> >, first.

  • Folklore claim: Arrows are Freyd categories

(Power & Robinson’99)

  • Recently substantiated by first describing

arrows as monoids in a category of bifunctors Cop × C → Sets

Jacobs – Types’06, 18/4/’06 – p.16/52

slide-61
SLIDE 61

Arrow in Haskell

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.17/52

slide-62
SLIDE 62

Arrow in Haskell

Structuring Computations

Introduced as type class:

Jacobs – Types’06, 18/4/’06 – p.17/52

slide-63
SLIDE 63

Arrow in Haskell

Structuring Computations

Introduced as type class:

class Arrow A where arr :: (X → Y ) → A X Y (> > >) :: A X Y → A Y Z → A X Z first :: A X Y → A (X, Z) (Y, Z)

Jacobs – Types’06, 18/4/’06 – p.17/52

slide-64
SLIDE 64

Arrow in Haskell

Structuring Computations

Introduced as type class:

class Arrow A where arr :: (X → Y ) → A X Y (> > >) :: A X Y → A Y Z → A X Z first :: A X Y → A (X, Z) (Y, Z)

Which should satisfy 8 equations, such as: (a > > > b) > > > c = a > > > (b > > > c) a > > > arr(1) = a first(arr(f)) = arr(f × 1), etc

Jacobs – Types’06, 18/4/’06 – p.17/52

slide-65
SLIDE 65

Arrow examples

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.18/52

slide-66
SLIDE 66

Arrow examples

Structuring Computations

  • (X, Y ) −

→ (X → T(Y )), for T monad (X, Y ) − → (G(X) → Y ), for G comonad

Jacobs – Types’06, 18/4/’06 – p.18/52

slide-67
SLIDE 67

Arrow examples

Structuring Computations

  • (X, Y ) −

→ (X → T(Y )), for T monad (X, Y ) − → (G(X) → Y ), for G comonad

  • (X, Y ) −

→ (X × X → [0, 1](Y ×Y )) for quantum computation

Jacobs – Types’06, 18/4/’06 – p.18/52

slide-68
SLIDE 68

Arrow examples

Structuring Computations

  • (X, Y ) −

→ (X → T(Y )), for T monad (X, Y ) − → (G(X) → Y ), for G comonad

  • (X, Y ) −

→ (X × X → [0, 1](Y ×Y )) for quantum computation

  • (X, Y ) −

→ (XN → P(Y N)) for “non-deterministic dataflow”

Jacobs – Types’06, 18/4/’06 – p.18/52

slide-69
SLIDE 69

Arrow examples

Structuring Computations

  • (X, Y ) −

→ (X → T(Y )), for T monad (X, Y ) − → (G(X) → Y ), for G comonad

  • (X, Y ) −

→ (X × X → [0, 1](Y ×Y )) for quantum computation

  • (X, Y ) −

→ (XN → P(Y N)) for “non-deterministic dataflow”

  • (X, Y ) −

→ (2 × S⋆)× ((S⋆ × X) → (1 + (S⋆ × Y ))) for Swierstra-Duponcheel parser that motivated Hughes

Jacobs – Types’06, 18/4/’06 – p.18/52

slide-70
SLIDE 70

Arrows, categorically

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.19/52

slide-71
SLIDE 71

Arrows, categorically

Structuring Computations

  • A is functorial: for f: X′ → X and g: Y → Y ′,

A(X, Y ) A(f, g)

A(X′, Y ′)

a

arr(f) >

> > a > > > arr(g)

Jacobs – Types’06, 18/4/’06 – p.19/52

slide-72
SLIDE 72

Arrows, categorically

Structuring Computations

  • A is functorial: for f: X′ → X and g: Y → Y ′,

A(X, Y ) A(f, g)

A(X′, Y ′)

a

arr(f) >

> > a > > > arr(g)

  • arr: (+)(−) → A(−, +) is natural

transformation (natro, for short)

Jacobs – Types’06, 18/4/’06 – p.19/52

slide-73
SLIDE 73

Arrows, categorically

Structuring Computations

  • A is functorial: for f: X′ → X and g: Y → Y ′,

A(X, Y ) A(f, g)

A(X′, Y ′)

a

arr(f) >

> > a > > > arr(g)

  • arr: (+)(−) → A(−, +) is natural

transformation (natro, for short)

  • >

> > is natro A ⊗ A → A, for tensor product of distributors / profunctors

Jacobs – Types’06, 18/4/’06 – p.19/52

slide-74
SLIDE 74

Arrows, categorically

Structuring Computations

  • A is functorial: for f: X′ → X and g: Y → Y ′,

A(X, Y ) A(f, g)

A(X′, Y ′)

a

arr(f) >

> > a > > > arr(g)

  • arr: (+)(−) → A(−, +) is natural

transformation (natro, for short)

  • >

> > is natro A ⊗ A → A, for tensor product of distributors / profunctors

  • first corresponds to “internal strength”

Jacobs – Types’06, 18/4/’06 – p.19/52

slide-75
SLIDE 75

Excurs: monoid in a category

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.20/52

slide-76
SLIDE 76

Excurs: monoid in a category

Structuring Computations

  • Standardly, a monoid is a set M with

associative m: M × M → M and two-sided unit e: 1 → M

Jacobs – Types’06, 18/4/’06 – p.20/52

slide-77
SLIDE 77

Excurs: monoid in a category

Structuring Computations

  • Standardly, a monoid is a set M with

associative m: M × M → M and two-sided unit e: 1 → M

  • Can be formulated in category with finite

products (1, ×): equations become diagrams

Jacobs – Types’06, 18/4/’06 – p.20/52

slide-78
SLIDE 78

Excurs: monoid in a category

Structuring Computations

  • Standardly, a monoid is a set M with

associative m: M × M → M and two-sided unit e: 1 → M

  • Can be formulated in category with finite

products (1, ×): equations become diagrams

  • No projections/diagonals needed: also in

monoidal category with (I, ⊗). Eg. M ⊗ M m M ⊗ I 1 ⊗ e

  • M
  • ∼

=

  • ∼

= I ⊗ Me ⊗ 1

M ⊗ M

m

  • M

M

Jacobs – Types’06, 18/4/’06 – p.20/52

slide-79
SLIDE 79

Excurs: monads are monoids

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.21/52

slide-80
SLIDE 80

Excurs: monads are monoids

Structuring Computations

  • The functor category CC is monoidal:

F ⊗ G = F ◦ G I = Id

Jacobs – Types’06, 18/4/’06 – p.21/52

slide-81
SLIDE 81

Excurs: monads are monoids

Structuring Computations

  • The functor category CC is monoidal:

F ⊗ G = F ◦ G I = Id

  • A monoid in CC is a functor M: C → C with

natros: M ⊗ M µ

M

Id η

  • M ◦ M

satisfying the monoid equations

Jacobs – Types’06, 18/4/’06 – p.21/52

slide-82
SLIDE 82

Excurs: monads are monoids

Structuring Computations

  • The functor category CC is monoidal:

F ⊗ G = F ◦ G I = Id

  • A monoid in CC is a functor M: C → C with

natros: M ⊗ M µ

M

Id η

  • M ◦ M

satisfying the monoid equations

  • A monoid in CC is precisely a monad!

Jacobs – Types’06, 18/4/’06 – p.21/52

slide-83
SLIDE 83

Arrows are also monoids

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.22/52

slide-84
SLIDE 84

Arrows are also monoids

Structuring Computations

  • Arrows are monoids in category of bifunctors

Cop × C → Sets

Jacobs – Types’06, 18/4/’06 – p.22/52

slide-85
SLIDE 85

Arrows are also monoids

Structuring Computations

  • Arrows are monoids in category of bifunctors

Cop × C → Sets

  • Tensor ⊗ more complicated, with

exponentiation/hom as unit

Jacobs – Types’06, 18/4/’06 – p.22/52

slide-86
SLIDE 86

Arrows are also monoids

Structuring Computations

  • Arrows are monoids in category of bifunctors

Cop × C → Sets

  • Tensor ⊗ more complicated, with

exponentiation/hom as unit

  • Allows for precise comparison with Freyd

categories (bijective correspondence)

Jacobs – Types’06, 18/4/’06 – p.22/52

slide-87
SLIDE 87

Arrows are also monoids

Structuring Computations

  • Arrows are monoids in category of bifunctors

Cop × C → Sets

  • Tensor ⊗ more complicated, with

exponentiation/hom as unit

  • Allows for precise comparison with Freyd

categories (bijective correspondence)

  • Details in Heunen & Jacobs, MFPS’06.

Jacobs – Types’06, 18/4/’06 – p.22/52

slide-88
SLIDE 88

Arrows, intuitively

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-89
SLIDE 89

Arrows, intuitively

Structuring Computations

  • Most fundamental mathematical structure in

computing?

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-90
SLIDE 90

Arrows, intuitively

Structuring Computations

  • Most fundamental mathematical structure in

computing?

  • Monoid (A, ; , skip) of programs/actions

A ∈ Sets with sequential composition

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-91
SLIDE 91

Arrows, intuitively

Structuring Computations

  • Most fundamental mathematical structure in

computing?

  • Monoid (A, ; , skip) of programs/actions

A ∈ Sets with sequential composition

  • Adding input and output makes A(−, +)

binary operator

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-92
SLIDE 92

Arrows, intuitively

Structuring Computations

  • Most fundamental mathematical structure in

computing?

  • Monoid (A, ; , skip) of programs/actions

A ∈ Sets with sequential composition

  • Adding input and output makes A(−, +)

binary operator

  • Hence carrier A becomes bifunctor

Cop × C → Sets

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-93
SLIDE 93

Arrows, intuitively

Structuring Computations

  • Most fundamental mathematical structure in

computing?

  • Monoid (A, ; , skip) of programs/actions

A ∈ Sets with sequential composition

  • Adding input and output makes A(−, +)

binary operator

  • Hence carrier A becomes bifunctor

Cop × C → Sets

  • Keeping the monoid structure leads to

Hughes’ Arrow

Jacobs – Types’06, 18/4/’06 – p.23/52

slide-94
SLIDE 94
  • IV. Monads

Jacobs – Types’06, 18/4/’06 – p.24/52

slide-95
SLIDE 95

Monad overview

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.25/52

slide-96
SLIDE 96

Monad overview

Structuring Computations

  • Introduced by Moggi (1991), popularised in

functional programming by Wadler

Jacobs – Types’06, 18/4/’06 – p.25/52

slide-97
SLIDE 97

Monad overview

Structuring Computations

  • Introduced by Moggi (1991), popularised in

functional programming by Wadler

  • for structuring outputs / computational effects

Jacobs – Types’06, 18/4/’06 – p.25/52

slide-98
SLIDE 98

Monad overview

Structuring Computations

  • Introduced by Moggi (1991), popularised in

functional programming by Wadler

  • for structuring outputs / computational effects
  • Standard examples:
  • lift / maybe 1 + (−)
  • exception E + (−)
  • list (−)⋆
  • state (− × S)S
  • non-determinism P (powerset)
  • probability D (distribution)

Jacobs – Types’06, 18/4/’06 – p.25/52

slide-99
SLIDE 99

Java monad

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.26/52

slide-100
SLIDE 100

Java monad

Structuring Computations

  • Definition [Jacobs & Poll’03]:

J(X) = (1 + S × X + S × E)S

Jacobs – Types’06, 18/4/’06 – p.26/52

slide-101
SLIDE 101

Java monad

Structuring Computations

  • Definition [Jacobs & Poll’03]:

J(X) = (1 + S × X + S × E)S

  • Combination of state, lift, exception monad

Jacobs – Types’06, 18/4/’06 – p.26/52

slide-102
SLIDE 102

Java monad

Structuring Computations

  • Definition [Jacobs & Poll’03]:

J(X) = (1 + S × X + S × E)S

  • Combination of state, lift, exception monad
  • Actual “abnormal” termination in Java more

complicated: exceptions, return, break, continue

Jacobs – Types’06, 18/4/’06 – p.26/52

slide-103
SLIDE 103

Java monad

Structuring Computations

  • Definition [Jacobs & Poll’03]:

J(X) = (1 + S × X + S × E)S

  • Combination of state, lift, exception monad
  • Actual “abnormal” termination in Java more

complicated: exceptions, return, break, continue

  • Exception mechanism (plus logic)

axiomatised as equaliser by [Schröder & Mossakowski]

Jacobs – Types’06, 18/4/’06 – p.26/52

slide-104
SLIDE 104

Kleisli composition for Java monad

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.27/52

slide-105
SLIDE 105

Kleisli composition for Java monad

Structuring Computations

  • Kleisli composition for J is “argument

evaluation, before use” (and not sequential composition ; )

Jacobs – Types’06, 18/4/’06 – p.27/52

slide-106
SLIDE 106

Kleisli composition for Java monad

Structuring Computations

  • Kleisli composition for J is “argument

evaluation, before use” (and not sequential composition ; )

  • For a: X → J(Y ), and p: Y → J(Z),

p • a = λx: X. λs: S. CASES a x s OF ∗ − → ∗ // non-termination (s′, y) − → p y s′ // normal termination (s′, e) − → (s′, e) // except. termination

Jacobs – Types’06, 18/4/’06 – p.27/52

slide-107
SLIDE 107
  • V. Java program verification

(at Nijmegen)

Jacobs – Types’06, 18/4/’06 – p.28/52

slide-108
SLIDE 108

Developments

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.29/52

slide-109
SLIDE 109

Developments

Structuring Computations

  • Original focus: theorem proving for small

Java programs (for smart cards)

Jacobs – Types’06, 18/4/’06 – p.29/52

slide-110
SLIDE 110

Developments

Structuring Computations

  • Original focus: theorem proving for small

Java programs (for smart cards)

  • Outcome:
  • No scaling beyond couple of pages
  • Practical experience, formalisations &

deeper theory

Jacobs – Types’06, 18/4/’06 – p.29/52

slide-111
SLIDE 111

Developments

Structuring Computations

  • Original focus: theorem proving for small

Java programs (for smart cards)

  • Outcome:
  • No scaling beyond couple of pages
  • Practical experience, formalisations &

deeper theory

  • Shift of focus:
  • Extension to security properties (esp.

confidentiality)

  • Static checking primary, theorem proving

secondary

Jacobs – Types’06, 18/4/’06 – p.29/52

slide-112
SLIDE 112

JML: Java Modeling Language

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.30/52

slide-113
SLIDE 113

JML: Java Modeling Language

Structuring Computations

JML [Leavens et al.] adds specifications as special comments in Java code, mainly for:

Jacobs – Types’06, 18/4/’06 – p.30/52

slide-114
SLIDE 114

JML: Java Modeling Language

Structuring Computations

JML [Leavens et al.] adds specifications as special comments in Java code, mainly for:

  • Class invariants and constraints

Jacobs – Types’06, 18/4/’06 – p.30/52

slide-115
SLIDE 115

JML: Java Modeling Language

Structuring Computations

JML [Leavens et al.] adds specifications as special comments in Java code, mainly for:

  • Class invariants and constraints
  • Method specifications:

/*@ behavior @ requires <precondition> @ assignable <items that may be modified> @ diverges <precondition for non-termination> @ ensures <postcond for normal termination> @ signals <postcond for exceptional @ termination> @*/ void method() { ... }

Jacobs – Types’06, 18/4/’06 – p.30/52

slide-116
SLIDE 116

JML: example

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.31/52

slide-117
SLIDE 117

JML: example

Structuring Computations

JML method specifications may clarify the behaviour of Java methods:

Jacobs – Types’06, 18/4/’06 – p.31/52

slide-118
SLIDE 118

JML: example

Structuring Computations

JML method specifications may clarify the behaviour of Java methods:

int f(int x) { int count = 0, sum = 1; while (sum <= x) { count++; sum += 2 * count + 1; } return count;

}

Jacobs – Types’06, 18/4/’06 – p.31/52

slide-119
SLIDE 119

JML: example

Structuring Computations

JML method specifications may clarify the behaviour of Java methods:

/*@ normal_behavior @ requires x >= 0; @ assignable \nothing; @ ensures \result * \result <= x && @ x < (\result+1) * (\result+1); @*/ int f(int x) { int count = 0, sum = 1; while (sum <= x) { count++; sum += 2 * count + 1; } return count;

}

Jacobs – Types’06, 18/4/’06 – p.31/52

slide-120
SLIDE 120

LOOP project

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-121
SLIDE 121

LOOP project

Structuring Computations

  • LOOP tool: compiles Java+JML to PVS

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-122
SLIDE 122

LOOP project

Structuring Computations

  • LOOP tool: compiles Java+JML to PVS
  • Based on formalised semantics of Java+JML

in PVS

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-123
SLIDE 123

LOOP project

Structuring Computations

  • LOOP tool: compiles Java+JML to PVS
  • Based on formalised semantics of Java+JML

in PVS

  • Including Hoare logic (see later) &

WP-reasoner (all with provably sound rules)

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-124
SLIDE 124

LOOP project

Structuring Computations

  • LOOP tool: compiles Java+JML to PVS
  • Based on formalised semantics of Java+JML

in PVS

  • Including Hoare logic (see later) &

WP-reasoner (all with provably sound rules)

  • Used for several non-trivial case studies, but

now in “sleep mode”

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-125
SLIDE 125

LOOP project

Structuring Computations

  • LOOP tool: compiles Java+JML to PVS
  • Based on formalised semantics of Java+JML

in PVS

  • Including Hoare logic (see later) &

WP-reasoner (all with provably sound rules)

  • Used for several non-trivial case studies, but

now in “sleep mode”

  • Static checking is simply more effective;

theorem proving best for difficult left-overs.

Jacobs – Types’06, 18/4/’06 – p.32/52

slide-126
SLIDE 126
  • VI. Static Checking for Java

Jacobs – Types’06, 18/4/’06 – p.33/52

slide-127
SLIDE 127

ESC/Java and ESC/Java2

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-128
SLIDE 128

ESC/Java and ESC/Java2

Structuring Computations

Extended static checker: original ESC/Java by Leino et. al at Compaq, but no longer supported.

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-129
SLIDE 129

ESC/Java and ESC/Java2

Structuring Computations

Extended static checker: original ESC/Java by Leino et. al at Compaq, but no longer supported.

  • tries to prove correctness of specifications,

at compile-time, fully automatically

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-130
SLIDE 130

ESC/Java and ESC/Java2

Structuring Computations

Extended static checker: original ESC/Java by Leino et. al at Compaq, but no longer supported.

  • tries to prove correctness of specifications,

at compile-time, fully automatically

  • not sound, not complete, but finds lots of

potential bugs quickly

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-131
SLIDE 131

ESC/Java and ESC/Java2

Structuring Computations

Extended static checker: original ESC/Java by Leino et. al at Compaq, but no longer supported.

  • tries to prove correctness of specifications,

at compile-time, fully automatically

  • not sound, not complete, but finds lots of

potential bugs quickly

  • Original ESC/Java only supports a (not fully

compatible) subset of full JML

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-132
SLIDE 132

ESC/Java and ESC/Java2

Structuring Computations

Extended static checker: original ESC/Java by Leino et. al at Compaq, but no longer supported.

  • tries to prove correctness of specifications,

at compile-time, fully automatically

  • not sound, not complete, but finds lots of

potential bugs quickly

  • Original ESC/Java only supports a (not fully

compatible) subset of full JML

  • New ESC/Java2 is open source, compatible

and handles more (eg. assignable clauses).

Jacobs – Types’06, 18/4/’06 – p.34/52

slide-133
SLIDE 133

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; int n; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Jacobs – Types’06, 18/4/’06 – p.35/52

slide-134
SLIDE 134

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; int n; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Warning: possible null deference. Plus other warnings

Jacobs – Types’06, 18/4/’06 – p.36/52

slide-135
SLIDE 135

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Jacobs – Types’06, 18/4/’06 – p.37/52

slide-136
SLIDE 136

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Warning: Array index possibly too large

Jacobs – Types’06, 18/4/’06 – p.38/52

slide-137
SLIDE 137

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Jacobs – Types’06, 18/4/’06 – p.39/52

slide-138
SLIDE 138

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 1; i <= n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Warning: Array index possibly too large

Jacobs – Types’06, 18/4/’06 – p.40/52

slide-139
SLIDE 139

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 0; i < n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Jacobs – Types’06, 18/4/’06 – p.41/52

slide-140
SLIDE 140

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 0; i < n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Warning: Possible negative array index

Jacobs – Types’06, 18/4/’06 – p.42/52

slide-141
SLIDE 141

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; //@ requires n > 0; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 0; i < n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

Jacobs – Types’06, 18/4/’06 – p.43/52

slide-142
SLIDE 142

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; //@ requires n > 0; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 0; i < n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

No more warnings about this code

Jacobs – Types’06, 18/4/’06 – p.44/52

slide-143
SLIDE 143

ESC/Java “demo”

Structuring Computations

class Bag { int[] a; //@ invariant a != null; int n; //@ invariant 0 <= n && n <= a.length; //@ requires n > 0; int extractMin() { int m = Integer.MAX_VALUE; int mindex = 0; for (int i = 0; i < n; i++) { if (a[i] < m) { mindex = i; m = a[i]; } } n--; a[mindex] = a[n]; return m; }

. . . but warnings about calls to extractMin() that do not ensure precondition : design by contract

Jacobs – Types’06, 18/4/’06 – p.45/52

slide-144
SLIDE 144
  • VII. Hoare logic for JML

Jacobs – Types’06, 18/4/’06 – p.46/52

slide-145
SLIDE 145

Hoare logic issues for Java & JML

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.47/52

slide-146
SLIDE 146

Hoare logic issues for Java & JML

Structuring Computations

  • Complications in Hoare logic for Java:
  • exceptions and other abrupt control flow
  • expressions may have side effects

Jacobs – Types’06, 18/4/’06 – p.47/52

slide-147
SLIDE 147

Hoare logic issues for Java & JML

Structuring Computations

  • Complications in Hoare logic for Java:
  • exceptions and other abrupt control flow
  • expressions may have side effects
  • Thus:
  • not Hoare triples but Hoare n-tuples,
  • both for statements & expressions

Jacobs – Types’06, 18/4/’06 – p.47/52

slide-148
SLIDE 148

Hoare Logic assertions

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.48/52

slide-149
SLIDE 149

Hoare Logic assertions

Structuring Computations

For { Pre } m { Post } write

  • requires = Pre

statement = m ensures = Post

  • Jacobs – Types’06, 18/4/’06 – p.48/52
slide-150
SLIDE 150

Hoare Logic assertions

Structuring Computations

For { Pre } m { Post } write

  • requires = Pre

statement = m ensures = Post

  • For JML one needs:

     diverges = D requires = Pre statement = m ensures = Post signals = S     

Jacobs – Types’06, 18/4/’06 – p.48/52

slide-151
SLIDE 151

Hoare composition Rule

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.49/52

slide-152
SLIDE 152

Hoare composition Rule

Structuring Computations

     diverges = λx. b requires = Pre statement = s1 ensures = Q signals = S           diverges = λx. b requires = Q statement = s2 ensures = Post signals = S           diverges = λx. b requires = Pre statement = s1 ; s2 ensures = Post signals = S     

Jacobs – Types’06, 18/4/’06 – p.49/52

slide-153
SLIDE 153

Hoare composition Rule

Structuring Computations

     diverges = λx. b requires = Pre statement = s1 ensures = Q signals = S           diverges = λx. b requires = Q statement = s2 ensures = Post signals = S           diverges = λx. b requires = Pre statement = s1 ; s2 ensures = Post signals = S      Intermediate predicate provided by the user in JML

Jacobs – Types’06, 18/4/’06 – p.49/52

slide-154
SLIDE 154

Use of the Hoare logic

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.50/52

slide-155
SLIDE 155

Use of the Hoare logic

Structuring Computations

  • Actual use seems clumsy, but PVS takes

care of the bookkeeping

Jacobs – Types’06, 18/4/’06 – p.50/52

slide-156
SLIDE 156

Use of the Hoare logic

Structuring Computations

  • Actual use seems clumsy, but PVS takes

care of the bookkeeping

  • This logic forms basis for semantics of JML

Jacobs – Types’06, 18/4/’06 – p.50/52

slide-157
SLIDE 157
  • VIII. Conclusions

Jacobs – Types’06, 18/4/’06 – p.51/52

slide-158
SLIDE 158

Main points

Structuring Computations

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-159
SLIDE 159

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-160
SLIDE 160

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

  • Main notions: monad / comonad / arrow

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-161
SLIDE 161

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

  • Main notions: monad / comonad / arrow
  • This elegance is not completely lost in

concrete languages / systems

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-162
SLIDE 162

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

  • Main notions: monad / comonad / arrow
  • This elegance is not completely lost in

concrete languages / systems

  • For our Java work: practice preceded theory

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-163
SLIDE 163

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

  • Main notions: monad / comonad / arrow
  • This elegance is not completely lost in

concrete languages / systems

  • For our Java work: practice preceded theory
  • Theorem proving cannot beat static checking

in program verification

Jacobs – Types’06, 18/4/’06 – p.52/52

slide-164
SLIDE 164

Main points

Structuring Computations

  • There is mathematical uniformity & elegance

in the structure of computation

  • Main notions: monad / comonad / arrow
  • This elegance is not completely lost in

concrete languages / systems

  • For our Java work: practice preceded theory
  • Theorem proving cannot beat static checking

in program verification Thanks for your attention!

Jacobs – Types’06, 18/4/’06 – p.52/52
