Nueva Sere Genesis LED Presentando nueva Serie Genesis LED - - PowerPoint PPT Presentation
Nueva Sere Genesis LED Presentando nueva Serie Genesis LED Dispositivos de ultra bajo consume de Compact Wall corriente. Multiples opciones de marcacin " FIRE y color. Wall Diseo bajo perfl. Compatible con las
Company Proprietary & Confidential
Company Proprietary & Confidential
Horn/Strobe products - Compact Wall, Wall & Ceiling – 75 candela
110-177 candela – Wall & Ceiling Strobe, Horn/Strobe Low Freq. Horns & Horn/Strobes – Wall & Ceiling Outdoor appliances Speaker & Speaker/Strobe – Wall & Ceiling – 75 candela
Compact Wall Wall Ceiling Outdoor LED light design implemented on compact wall, wall, ceiling packages Speaker v ersions added Speaker used to generate 520Hz horn tones Outdoor rated enclosure NEMA 4x
Enclosure Types
110-177 candela – Wall & Ceiling Speaker/Strobe
High candela LED light design implemented
1 2 3 4 5 6
Company Proprietary & Confidential
Genesis – Strobe – 75cd @ typical 50’ device spacing
NAC Loop
255ma / device
Limited Devices, Larger Wire Size, Shorter Wire Runs Max. NAC Loop
Devices: 11* 550’ 12 AWG wire 11* 550’ 14 AWG wire 9 450’ 16 AWG wire 7 350’ 18 AWG wire * Limited by available Power Supply current (3.0A).
Limited by High Current
NAC Loop
Genesis LED – Strobe – 75cd @ typical 50’ device spacing
24 ma / device 24 ma / device
More Devices, Reduced Wire Size, Longer Wire Runs Max. NAC Loop
Devices: 51 2,550’ 12 AWG wire 40 2,000’ 14 AWG wire 31 1,500’ 16 AWG wire 25 1,250’ 18 AWG wire
~4X improvement
Company Proprietary & Confidential
Compact Wall
Selectable horn setting, no jumpers to cut Voltage Test Port Room Side Wiring Plate Diagnostics check bar
Wall and Ceiling
Core Product
