NU FRONTIERS Northeastern University Rover Deployment Experiment Agenda Overview of Vehicle Properties Stability Analysis Launch Vehicle Sections and Systems Nose Cone Section Payload Section Lower Avionics Section

slide-1
SLIDE 1

NU FRONTIERS

Northeastern University

Rover Deployment Experiment

slide-2
SLIDE 2

Agenda

  • Overview of Vehicle Properties
  • Stability Analysis
  • Launch Vehicle Sections and Systems

○ Nose Cone Section ○ Payload Section ○ Lower Avionics Section ○ Booster Section

  • Payload
  • Recovery

○ Drogues ○ Mains

  • Electronics
  • Full scale flight
  • Updates

2

slide-3
SLIDE 3

Overview of Vehicle Properties

Length 124 inches Maximum Diameter 6.17 inches Weight 50.1 pounds Body Tube Material G12 Fiberglass Fins 4 Trapezoidal, G10 Fiberglass Motor Cesaroni L1115 Classic Reloadable Number of Avionics Bays 2 Number of Altimeters 6 Number of Main Parachutes 2 Number of Drogue Parachutes 1

3

slide-4
SLIDE 4

Stability and Ascent Analysis

  • Center of Gravity = 75 inches
  • Center of Pressure = 94 inches
  • Stability = 2.97 cal

4

  • Thrust to weight: 5.05
  • Rail exit velocity: 67.4 ft/s
slide-5
SLIDE 5

Launch Vehicle Sections and Systems

5

slide-6
SLIDE 6

Nose Cone Section

  • Composed of Fiberglass
  • Houses a 72 inch elliptical Main Parachute
  • Mass: 1.98 lbs (898g)

6

slide-7
SLIDE 7

Payload Section

  • Houses Upper Avionics Bay and Payload
  • Mass: 17.19 lbs (7815 g)

7

slide-8
SLIDE 8

Lower Avionics Section

  • Houses Lower Avionics Bay, 1 Main and Drogue Parachute
  • Mass: 10.32 lbs (4690 g)

8

slide-9
SLIDE 9

Booster Section

  • 4 Trapezoidal Fins
  • Centering Rings

○ ¼” Plywood

  • Motor Mount

○ 75mm Blue Tube

  • Aero Pack Motor Retainer
  • Mass: 22.46 lbs (10210 g)

9

slide-10
SLIDE 10

Fin Properties

  • 4 G10 Fiberglass fins
  • Trapezoidal
  • Mounted through wall
  • Key slots in centering rings

○ Tabs on fins

10

slide-11
SLIDE 11

Motor Properties

Cesaroni L1115 Classic

Loaded Mass 4404.00 g Burnout Mass 1928.00 g Total Impulse 5015.00 Ns Maximum Thrust 1713.25 N Average Thrust 1119.00 N ISP 213.60 s Burntime 4.48 s

11

slide-12
SLIDE 12

Lower Avionics Bay Parachutes Subsystem Electronics

  • Components

○ 4 x StratoLogger Altimeter ○ 2 x Digikey Keylock Switches ○ 4 x 9 Volt Batteries ■ Held in custom 9V battery holders ○ 1 x teleGPS Unit ○ 1 x 3.8 Volt LiPo Battery

  • Wooden Sled

○ 1 x ¼ birch plywood sled ○ 2 x ¼-20 threaded rods

12

slide-13
SLIDE 13

Upper Avionics Bay Parachutes Subsystem Electronics

  • Components

○ 2 x StratoLogger Altimeter ○ 1 x Digikey Keylock Switches ○ 2 x 9 Volt Batteries ■ Held in custom 9V battery holders

  • Wooden Sled

○ 1 x ¼ birch plywood sled ○ 2 x ¼-20 threaded rods

13

slide-14
SLIDE 14

Test Plan and Procedures

  • Internal Design/Safety Review Board

○ Successful ground ejection tests ○ Wiring Continuity Audits ○ Simulation Audits ○ Detailed design review including full disassembly

  • Launch Day Checklists
  • Range Safety Officer Launch Vehicle Checks
  • Internal Post Launch Forms
slide-15
SLIDE 15

Payload

15

slide-16
SLIDE 16

Rover

16

  • Vex motor locomotion
  • Custom designed wheels and body
  • “Fanning” solar panels
  • Solenoid latching system
  • Dynamic support strut
slide-17
SLIDE 17

Pneumatic Ejection System

  • CO2 ejection system connected to pneumatic components

○ Peregrine Ejection System ○ Regulator ○ Speed Controller

  • Polyester bellows clamped to bulkheads
  • Forward bulkhead slides freely along steel rods
  • Rear and pneumatic base bulkheads are set screwed in place
  • Electronics mounted below pneumatics
slide-18
SLIDE 18

Payload Electronics Bay

18

  • Arduino Nano
  • 2x 7.4V 1000mAh LiPo
  • GY-521 Accelerometer and Gyroscope
  • Adafruit Ultimate GPS Breakout
  • DS1307 Real Time Clock (RTC)
  • Custom designed PCB
slide-19
SLIDE 19

Recovery

19

Drogues and Mains

slide-20
SLIDE 20

Parachute Subsystem

  • 48 inch drogue parachute

○ Fruity Chutes

  • Upper 72-in main, Lower 60-in main

○ Classic Elliptical, Fruity Chutes

  • ⅜” -16 Eye Bolts with 1” Washers
  • Swivels
  • ½” tubular Kevlar Shock Cord
  • ½” plywood bulkheads

20

slide-21
SLIDE 21

Launch Procedure and Separations

  • Apogee of 5060 ft
  • 3 Flight Events

21

slide-22
SLIDE 22

1st Flight Event

  • Launch Vehicle reaches an apogee of 5060 feet
  • The Booster and the Lower Avionics Sections separate, and 48 inch

drogue parachute is deployed

  • Launch Vehicle falls at 65 ft/s

22

slide-23
SLIDE 23

2nd Flight Event

  • Occurs at 800 feet
  • The Nose Cone and the Payload Sections separate, and 72 inch main

parachute is deployed. Launch Vehicle still tethered

23

3rd Flight Event

  • Occurs at 750 or shortly after flight event 2
  • The Payload and the Lower Avionics Sections separate, and 60 inch main

parachute is deployed. Launch Vehicle separates into two independent sections.

  • Upper sections fall at 10 ft/s, Lower sections fall at 16 ft/s
slide-24
SLIDE 24

Shock Cord

  • ½” Kevlar Shock Cord
  • Strong yet also slightly elastic
  • Attached to ⅜” Eye Bolts
slide-25
SLIDE 25

Black Powder Charges

Primary Charge Amount (g) Secondary Charge Amount (g) Drogue 2.2 2.6 Upper Main 2.0 2.4 Lower Main 2.0 2.4

slide-26
SLIDE 26

Recovery System - Kinetic Energy

  • 75 ft-lb Landing Maximum Competition Requirement

○ All sections meet requirements

26

Section Mass (kg) Terminal Velocity (m/s) Kinetic Energy (J) Kinetic Energy (Ft*lb) Nose Cone 0.898 3.0 4.2 3.1 Payload 7.815 3.0 36 27 Lower Avionics 4.690 4.9 56 41 Booster 7.734 4.9 92 68

slide-27
SLIDE 27

Recovery System - Lateral Drift

27

  • 2,500 foot Lateral Drift Maximum Competition Requirement

○ All sections meet requirement

27

Wind Speed Maximum Lateral Drift of Two Independently Falling Sections No Wind 8 feet 5-mph 525 feet 10-mph 1,125 feet 15-mph 1,782 feet 20-mph 2,490 feet

slide-28
SLIDE 28

Electronics

Recovery, Motor, Nose Cone, and Accelerometer

28

slide-29
SLIDE 29

Recovery Electronics

Power 4 Volts to 16 Volts, nominal 9 Volt battery Current Consumption 1.5 milliamp Launch Detect 160 feet to 300 feet AGL, default 160 feet Main Deploy Altitude 100 feet AGL to 9,999 feet AGL Maximum Altitude 100,000 feet MS Altitude Resolution 1 feet up to 38,000 feet MSL < 2 feet to 52,000 feet MSL < 5 feet to 72,000 feet MSL Measurement Precision +/- (0.1% reading + 1 foot) typical Flight Data Logged Altitude, temperature, battery voltage Recording Time Per Flight Over 18 minutes Operational Temperature

  • 40°C to +85°C (-40°F to +185°F)

Sample Rate 20 samples per second Cost $54.95

29

slide-30
SLIDE 30

Payload Ejection System Electronics Bay

  • XBee Pro XSC (S3)
  • XBee Breakout Board
  • Antenna
  • 2x 1000mAh 7.4V LiPo
  • Arduino Nano V3
  • XBee Explorer Dongle (Ground Station)
  • MPU 6050
  • LIS 331

30

slide-31
SLIDE 31

31

Communication System

slide-32
SLIDE 32

Telemetry

32

slide-33
SLIDE 33
  • The Adafruit GPS Breakout Board gets position data → Arduino Nano V3
  • Arduino Nano V3 → XBee
  • XBee → XBee Explorer Dongle at Ground Station
  • Data stored and read out on Computer

33

Data Flow

slide-34
SLIDE 34

Fullscale Test

34

slide-35
SLIDE 35

Fullscale Design

  • Uses final motor and parachute configuration
  • Simulates the actual launch closely to test the launch vehicle in its entirety
  • Motor: L1115 Cesaroni Classic
slide-36
SLIDE 36

Fullscale Ground Ejection Tests

  • Coordinated with Northeastern University Campus Police
  • Secured pedestrian-free area prior to test
  • All successful, proof of ejection charge calculations
slide-37
SLIDE 37

Fullscale Launch

  • March 4th, 2018
  • Champlain Region Model Rocket Club

○

  • St. Albans, VT
  • Temperature: 30°F
  • Weather: 13 mph wind and snow flurries
  • Launch Angle: 5° into the wind

37

slide-38
SLIDE 38

Fullscale Launch Results

  • All recovery systems deployed properly when commanded
  • Launch Vehicle successfully recovered
  • Apogee: 5,596 feet (using lighter payload mass)

38

slide-39
SLIDE 39

Fullscale Launch Results

  • Anomaly in lower e-bay stratologger Secondary 2

lead to lower main parachute deploy at apogee

  • Upper section assembly descended partially in

free fall

  • Lower section assembly descended under lower

main parachute from apogee

39

slide-40
SLIDE 40

Thank you for listening!

QUESTIONS?

40
