EuroLam GmbH

NSHEV, Louvre Windows & Special Constructions

Date of foundation: 01/24/1997 General Manager: Heidrun Hommer Managing Partner: Ernst Hommer Performance profile: Processing, producing and marketing of louvre windows, natural smoke and heat exhaust ventilation NSHEV’s and special designs. Home market: One of the leading providers for natural ventilation, climate control, smoke and heat extraction solutions. Employees: 2015 – 50 including 4 trainees/apprentices

Situated in the green heart of Germany

EuroLam Worldwide

Our advantages & benefits

• Long life due to weight-neutral suspension of the wing
• Easy to use with hand lever, folding handle, electric actuator or

pneumatic cylinder drive

• Accurate production according to the specifications of the customer
• Combination of high functionality and aesthetics
• Suitable for use as NSHEV (natural smoke and heat exhaust

ventilators), combined with automated ventilation, air conditioning and BMS control units

• High flexibility and diversity of systems: for almost every application

in the construction and modernization, even for ventilation in the hallway

• Up to 75% of the window area is usable for ventilation purposes

Large selection of glass types, glass construction or panels

Our Products

Construction: frame and blades made from thermally separated aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor constructions (subframes) for installation in post-beam constructions, wall masonry or window elements are available Louvre blades: made from thermally separated extruded aluminum profiles, overall thickness 38 mm and 48 mm respectively Opening fittings: hidden opening fittings, operation with manual crank handles, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230V or 24V Surface treatment: profiles anodised, powder or liquid coated to RAL, NCS, DB standards or special colour shades Seals: in APTK, EPDM, silicon quality Extras: Burglary protection is possible, limited ball impact protection is possible, mounting of the louvre blades in an off-centre position is possible Made in Germany: Suppliers mainly from Germany, many in the closest environment to our company

Installation in masonry Installation in post-beam constructions Installation in window construction

Insulated systems

TGL ISO 24 BT 50 / 32 BT 60

Construction: frame and blades made from thermally separated aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor constructions (subframes) for installation in post-beam constructions, wall masonry or window elements available Louvre blades: insulation glazing or panels as desired; total thickness 24 mm or 32 mm Opening fittings: hidden opening fittings, operation with manual levers, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230V or 24V Seals: in APTK, EPDM, silicon quality Finish: profiles anodised, powder or liquid coated to RAL, NCS, DB standards or special color shades

O2 World Arena - Berlin Airport Lech Walesa Gdansk Degussa Trostberg

Project Sheffield University

TGL ISO SLP BT 50 / 60

Construction: frame and blades made from thermally separated aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor constructions (subframes) for installation in post-beam constructions, wall masonry or window elements are available Louvre blades: made from thermally separated extruded aluminum profiles, overall thickness 38 mm and 48 mm respectively Opening fittings: hidden opening fittings, operation with manual levers, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230 V

• r 24 V

Seals: in APTK, EPDM (Ethylene-Propylene-Dien-Monomer rubber), silicon quality Finish: profiles anodised, powder or liquid coated to RAL, NCS, DB standards or special color shades

Sapphire Tower - Istanbul

STG ISO 36 BT 50

Construction: frame and blades made from thermally separated aluminum profiles; frame installation depths 50 mm Optional: various adapter constructions (subframes) for installation in post- beam constructions, wall masonry or window elements available Louvre blades: insulation glazing of your choice; total glass thickness 36 mm Opening fittings: hidden opening fittings, operation with manual levers, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230V or 24V Seals: in APTK, EPDM, silicon quality Finish: profiles anodised, powder or liquid coated to RAL, NCS, DB standards or special color shades

Vitzthum Gymnasium - Dresden Sparkasse - Euskirchen

GG ISO 24 BT 50 / 32 BT 60

Construction: frame and blades made from thermally separated aluminium profiles; frame installation depths 50 or 60 mm Optional: various adaptor subframes for installation in post-beam constructions, wall masonry or window elements available Insulating glass louvre: insulation glazing of your choice with lateral frame profile; total glass thickness 24mm or 32 mm Opening fittings: hidden opening fittings, operation with manual levers, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230V or 24V Seals: in APTK, EPDM, silicon quality Finish: profiles anodised, powder or liquid coated to RAL, NCS, DB, standards or special colour shades

Musikschule - Essen Augustinerkloster - Erfurt

EAL

Construction: frame and blades in thermally separated aluminum profiles; frame installation depths 80 mm 80° opening angle opens completely to the outside highly insulating no brush sealings three chamber profiles Triple glazing up to 46 mm Louvre blades: made from thermally separated extruded aluminum sections Opening fittings: hidden opening fittings, operation with electric servomotors with a choice of 230V or 24V Seals: in APTK, EPDM, silicon quality Surface treatment: profiles anodized, powder or liquid coated to RAL, NCS, DB standards or special color shades

Berufliches Schulzentrum - Stuttgart

Non-Insulated systems

GG / OL (Overlapping) BT 50 / 60

Construction: frame construction made from non- insulated or insulated extrusion moulding aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor subframes for installation in post-beam constructions, wall masonry or window elements Glass louvres: toughened safety glass or laminated glass panes, single glazing with 6, 8, 10

• r 12 mm thickness, all glass edges are completely polished. With the 12 mm

glass thickness, the frame profiles with 60 mm width must be used for structural reasons. The glass louvres are delivered with axle bearings as a standard. Optional: with lateral glass frame profile

MFH Johannis - Nürnberg Nyon Seniorenzentrum - Allermöhe

GG / ST (Step- cascaded glass) BT 50 / 60

Construction: frame construction in non- insulated or insulated extrusion moulding aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor sections for installation in post-beam constructions, wall masonry or window elements Glass louvres: laminated glass panes in 2x toughened safety glass, all the glass edges are completely polished. From glass thicknesses of 12 mm a structural depth of 60 mm must be implemented for technical reasons. The glass louvres are delivered with axle bearings as a standard. Optional: with lateral glass frame profiles

University of applied sience - Jena K+H Bank - Budapest

GG / BE 30 (Bevelled edge) BT 50 / 60

Construction: frame made from non-insulated or insulated extrusion moulding aluminum profiles; frame installation depths 50 or 60 mm Optional: various adaptor subframes for installation in post-beam constructions, wall masonry or window elements Glass Louvres: toughened safety glass panes, single glazing 6, 8, 10 or 12 mm thick, all glass edges are completely polished, the structural depth of 60 mm makes it possible to use glass thicknesses exceeding 12 mm. The glass louvres are delivered with axle bearing as a standard. Opening fittings: hidden opening fittings, operation with manual levers, kinked connecting rods, pneumatic cylinders or electric servomotors with a choice of 230V or 24V Seals: in APTK, EPDM, silicon quality Finish: profiles anodized, powder or liquid coated to RAL, NCS, DB standards or special colour shades; axes E6 / EV1 anodized

Deichtorcenter - Hamburg

GG / BH

Design: spot-held superimposed glass lamellas, fixed to on-site sub-construction by means of pivoting or fixed stainless steel brackets Glazing: patent glazing, LSG made of 2x heat soaked toughened safety glass or LSG

• f 2x TVG (heat-strengthened glass) according to structural calculations,

total glass thickness 24 mm Fittings: fittings of stainless steel, operation by electric motor optionally with 230 V or 24 V, e-drive protection category IP 65 Finish: electro-polished stainless steel

Biotürme Lauchhammer OFS - Neuenburg

S 200

Konstruktion: frame construction in non-insulated extrusion moulding aluminum profiles fixed / moveable louvres frame installation depth 50 mm Optional: various adaptor subframes for installation in post-beam constructions, wall masonry or window elements Lamellenprofil: The louvers that are mounted in a laterally turnable manner are >>s-shaped<< and arranged in an overlapping manner. Oberflächenbehandlung: profiles anodized, powder or liquid coated to RAL, NCS, DB standards or special colour shades

Bioethanol Anlage - Zeitz

CityLam

With cityLam System Greening the nature comes back to

• town. Individually planted modules will be installed as fixed or

movable modules on the façades of buildings or warehouses,

• r set up as a partition, for example, in stations and airports.

When placed in the vertical position, the mobile version appears to be a green-planted wall. When placed horizontally, the modules can be automatically watered. The green areas newfound lead not only to excellent cold, heat, or noise protection, but because of their carbon foot- print, they can be used as ecological compensation areas.

• Façade greening
• Façade beautification
• A room divider or window replacement
• Vertically movable
• Automatic irrigation
• Heat, cold, and noise insulation
• Particle binding
• Ecological compensation areas
• Planted with easy-care succulents
• Environmentally friendly

Study – facade

Your idea - our special solution sustainable implementation of the project fast delivery and competent performance Your complete package of construction services: qualitative Installation & Service

Our product in perfection The service package of EuroLam GmbH

Sustainable strong company Young dynamic team Leading edge technology Innovative

Any questions? Contact us! EuroLam GmbH info@eurolam.de www.eurolam.de +49 36462 33 88 0
