SLIDE 1
November 18, 2015
Joint Base Fort Myer- Henderson Hall to the Pentagon Reservation
2
November 18, 2015 Joint Base Fort Myer- Henderson Hall to the - - PowerPoint PPT Presentation
November 18, 2015 Joint Base Fort Myer- Henderson Hall to the - - PowerPoint PPT Presentation
November 18, 2015 Joint Base Fort Myer- Henderson Hall to the Pentagon Reservation 2 Joint Base Fort Myer- Henderson Hall to the Pentagon Reservation What the County will be getting : Two (2) 4-inch conduits each containing three 1.25 inch
SLIDE 2
SLIDE 3
Joint Base Fort Myer- Henderson Hall to the Pentagon Reservation What the County will be getting : Two (2) 4-inch conduits each containing three 1.25 inch innerduct totaling 19,070 feet. Two (2) 144 count loose tube fiber optic cables for the entire length. Conduit and cable run from Clarendon’s Fire Station 4 to the Pentagon Reservation
3
SLIDE 4
Conduit with Innerduct
4
Conduit One Conduit Two 144 Strands Of Fiber Cable 144 Strands Of Fiber Cable
SLIDE 5
Joint Base Fort Myer- Henderson Hall to the Pentagon Reservation
Benefits the County and Base could receive from these facilities:
- Enhanced communication capabilities
- Redundancy
- Computer aided dispatch
- Interoperability
5
SLIDE 6
Current Status, ConnectArlington 2.0
- Hand hole replacement completed (204 total)
- All conduit proofed and repaired
- 864 count fiber cable being installed now
– Rosslyn to CHP complete, CHP to FS4 in progress
- Cold weather moratorium approx. Dec ‘15 - April ’16
- Planned completion Summer 2016
6
SLIDE 7
Benefits of CA 2.0 for Dark Fiber Licensees
- Security - highly secure, dedicated fiber that enables collaboration with the
nation's top defense and research agencies
- Cost savings - access to varied, competitive pricing options to improve your
bottom line
- Speed - enables transmission far greater than those currently offered with
the right equipment
- Scalability - dedicated bandwidth allows you to grow along with your
business needs
- Redundancy- allows for distinct fiber routes to increase reliability
- Compliance - secure continuity of operations for those operating in regulated
industries
7
SLIDE 8
Recent Accomplishments & Work In-Progress
- JBFM-HH DVP Easement and Conduit/Fiber
- Virginia Tech Agreement/Interconnection
- UMD/MAX Proposed Agreement
- GMU Interest for Arlington Campus
- Virginia Tech/Vornado Interest
- Service Provider Interest
- Fiber Management System Review & Analysis
8
SLIDE 9
Fiber Optic Cable Pull – 864 fibers/cable
9
SLIDE 10
Fiber Optic Cable Pull – Figure 8 Layout
10
SLIDE 11
Fiber Optic Cable Pull – Handhole Pull Point
11
