SLIDE 1
Nottingham/Kirkwood Area Reconstruction Meeting
Carol Haddock, P.E., Senior Asst. & Interim Deputy Director
1
OVERVIEW OF THE PROJECT
2
NEXT STEPS
3
CONTACT INFORMATION
AGENDA
2
Nottingham/Kirkwood Area Reconstruction Meeting Carol Haddock, P.E., - - PowerPoint PPT Presentation
Nottingham/Kirkwood Area Reconstruction Meeting Carol Haddock, P.E., - - PowerPoint PPT Presentation
Nottingham/Kirkwood Area Reconstruction Meeting Carol Haddock, P.E., Senior Asst. & Interim Deputy Director AGENDA 1 OVERVIEW OF THE PROJECT 2 NEXT STEPS 3 CONTACT INFORMATION 2 Nottingham/Kirkwood Area Reconstruction Examples of
SLIDE 2
SLIDE 3
Pavement /Mobility
Nottingham/Kirkwood Area Reconstruction
Examples of Current Conditions
3
Drainage & Mobility Pavement /Drainage
SLIDE 4
Improve water and wastewater as needed
Nottingham/Kirkwood Area Reconstruction
Identified Improvement Needs
Pedestrian safety and accessibility Improve storm drainage
4
Improve pavement conditions and mobility Improve existing bike lanes
SLIDE 5
Nottingham/Kirkwood Area Reconstruction
M-000247 Project Area : Memorial to Britoak (just south of Katy Fwy)
5
LEGEND
TREE TO REMAIN EXISTING RIGHT-OF-WAY (ROW) 5’ SIDEWALK TREE TO BE REMOVED NEW MEDIAN EXISTING MEDIAN PAVEMENT
KIRKWOOD Memorial Britoak Kimberley
(Intersection)
SLIDE 6
Nottingham/Kirkwood Area Reconstruction
Intersection: Kimberley at Kirkwood
6
LEGEND
TREE TO REMAIN EXISTING RIGHT-OF-WAY (ROW) 5’ SIDEWALK TREE TO BE REMOVED NEW MEDIAN REPLACED SIGNAL EXISTING MEDIAN PAVEMENT
SLIDE 7
Nottingham/Kirkwood Area Reconstruction
Proposed Cross Section: Kirkwood North of Memorial
7
SLIDE 8
Nottingham/Kirkwood Area Reconstruction
Proposed Cross Section: Woodthorpe from Carlingford to West Forest
8
SLIDE 9
CURRENT CIP PART I / IN DESIGN PANEL REPLACEMENT PROJECT
Nottingham/Kirkwood Area Reconstruction
Improvements to Existing Bike Lanes
9 MEMORIAL DRIVE BUFFALO BAYOU BRIAR FOREST DRIVE WESTHEIMER ROAD
NOTTINGHAM/KIRKWOOD CIP PROJECT CURRENT CIP PART II
- Existing bike lane is 2’ in width
and considered substandard
- Increase comfort level by
introducing a 5’ bike lane and a 3’ buffer
- Striped/painted bike lane and
buffer allows for street sweeping and maintenance
- Striped/painted bike lane and
buffer allows for street sweeping and maintenance
- Substandard facilities are
not considered safe, and will not be restriped along portions of the corridor not programmed with the CIP project we are discussing
- today. To learn more, please
visit the Houston Bike Plan.
- When funding is received,
PWE will need to move the curb in this area to update the bike facility KIRKWOOD ROAD
- 6’ bike lane
- r 5’bike lane
with a 2’ painted buffer
- 6’ bike lane or 5’ bike lane
with a 2’ painted buffer
SLIDE 10
Nottingham/Kirkwood Area Summary
Improve pavement conditions and mobility Improve storm drainage
10
Sidewalks and ramps to meet ADA Standards Improve existing bike lanes Improve water and wastewater as needed
SLIDE 11
2013 Planning (Complete) 2016 Design (Ongoing) 2018 Scheduled Construction 2020 Anticipated Completion
11
Timeline subject to change
Next Steps: Nottingham/Kirkwood Area – Phase I
SLIDE 12
ReBuild Houston Goals
Reduce impact of flooding Improve mobility Quality of life
12
SLIDE 13
Future Construction Completed Construction Current Construction
www.RebuildHouston.org
13
SLIDE 14
We Want Your Input
14
Or email us your comments at: pweplanning@houstontx.gov www.RebuildHouston.org Fill out a comment card tonight
We Want Your
Or email us your comments at: Fill out a comment card tonight
YOUR INPUT BY
July 19, 2016
WILL HELP US STAY ON SCHEDULE
SLIDE 15
