• Background

– Introduction – Protocols – ECU/Components

• OMA DM

– Parser problems – Self-defined – Inconsistency

• Summary

– Recap – Suggestion – Resource

> > No NotSurprised Surprised

Intro

• UCCU Hacker
• AIS3 2016 trainee
• HITCON Defend 2018 3rd (etc.)
• SITCON 2019 speaker
• MOPCON 2019 speaker
• Becks.io#5 speaker
• ITRI Engineer (serve my country)
• 5-years Bachelor & Master of NSYSU

Email : notsurprisedtw@gmail.com Skill

• Windows Kernel Driver (Minifilter)
• Penetration Test (Web)
• Malware Analysis (Ransomware)
• Ethereum Smart Contract (Solidity)
• Car Security (OMA DM)

>

Drone, IoT, AI Manufacture, AI Car(VANET) sounds great, but…

Are They Secure?

>

>

• Charlie Miller Jeep Cherokee

– Charlie Miller share series attack vectors

• Tencent KeenLab Tesla Model S
• ADCD Key Signal repeat

– Proof that signals can be simply trigger and enhance to repeat received signals

• PWN2OWN 2019 Tesla Model 3
• Car2go Auto Review Application in Chicago

– This connect to server problem, review mechanism can be fraud and unlock the car with fake person id

>

• RFID
• CAN Bus
• Bluetooth
• Cellular Network (Internet)
• VANET
• OMA DM

>

Car Internal Communication Car external communication Key Manufacture server

>

>

>

• RFID(Radio Frequency Identification), radio also
• In vehicle, long distance, usually in high frequencies, UHF

root@kali:~# nfc-list nfc-list uses libnfc 1.7.1 NFC device: pn532_uart:/dev/ttyUSB0 opened 1 ISO14443A passive target(s) found: ISO/IEC 14443A (106 kbps) target: ATQA (SENS_RES): 00 04 UID (NFCID1): 3c 3d f1 0d SAK (SEL_RES): 08 root@kali:~# nfc-mfsetuid 3c3df10d NFC reader: pn532_uart:/dev/ttyUSB0 opened Sent bits: 26 (7 bits) Received bits: 04 00 Sent bits: 93 20 Received bits: 0c 5c ee 0d b3 Sent bits: 93 70 0c 5c ee 0d b3 5c c2 Generate fake RFID key RFID Reader with Arduino

>

• Signal Amplification Relay Attack
• Original designed to copy for

backup and become all in one RFID key in personal used

• Can copy 125 kHz (“low frequency”)

RFID

• Can not copy 13.56MHz (“high

frequency”) NFC

>

>

>

>

• Best way to get into CAN bus

– Compromise the car’s mini computer ( OS: QNX, Win CE, Linux, Android, Green Hills) – As a component in car, mini computer connect to CAN bus and dash board

• Message on CAN bus system

– CAN message format

• ISO 11519-2 / ISO 11898:1993 / ISO 11898:1995
• Make largest privilege code in your broadcast packet

– Diagnostic trouble code format

• Sometime trigger automatic reaction
• Aircraft also use CAN bus

– Same problem that microcontroller is the last defend line in simple aircraft

>

>

• CAN

– ISO-TP (ISO 15765-4) – CANopen – GMLAN bus

• SEA J1850

– PWN – VPW

• KWP

– KWP2000 (ISO 9141-2) – ISO 14230-4

• LIN Bus
• MOST

– Independent from bus line, for IVI, connect to speaker and cellular network.

• FlexRay
• Ethernet

>

credit :

>

credit :

>

credit :

>

• FlexRay bus

– Fastest – Expensive – Top class car – Sensitive

• CAN bus

– Good CP value – Widely used

credit :

>

• OBDII (On-Board Diagnostic System II) ft. EcomCat

credit :

>

ECOM2 OBDII Cable

US $203.37

ValueCan3 OBDII Cable

US $395.00

>

ELM327 OBDII Cable

US $8.40~$2.50

>

Expensive OBD2 Cable Cheap OBD2 Cable

Normal Limited Usually not Sometimes GUI / Auto Link Open Source / Self-defined High Low (china copycat) Yes No Lots None Yes None

>

Some interesting tool:

• ICSim: Instrument Cluster Simulator

– For Can

>

• MyCar, CarDoctor, Car Scanner

– Type of product connect to OBDII and APP – Control your car’s status to prevent frauded by repair shop – Usually Bluetooth(shorter distance, more secure), WIFI/3G/4G – As IoT, default AC/PW remain problem – Bluetooth default paring key: 0000/1234 (sometime even not give a request)

>

• Using uuid and handle (company identifier) primary and

characteristic command.

• Sometime you can brutal force it or OSINT for hint.
• MiBand2 no auth key, MiBand3 has breakable auth key.

>

• Torque
• Car scanner
• OBD Auto Doctor

>

• ELM327 OBD2 BLE
• Cannot change PIN
• Support several

client APP

credit :

>

• ELM327 OBD2 WiFi
• Default IP & Port
• Support several

client APP

>

>

credit : Semantic

>

• HTTP sniffer than you will get the AC/PW
• Door seq. being shown on URL query as plaintext
• Even you have no AC/PW, you can unlock most door remote by SQLi
• There's a password to switch to setting mode on product’s user manual,

you can find it on internet. e.g. #123456#

>

• A human-readable JSON protocol “encrypted” with an easily reversible autokey (-85) XOR cipher

and a binary DES-encrypted configuration (AC/PW : admin/admin)

>

• Not just Bluetooth, also using GPS and a cellular connection to

extend their range to anywhere with an internet connection.

credit :

>

• Acoount & Password is default in factoryBootstrap and popular
• User Guide which contain AC/PW public on internet

– https://fccid.io/2AEB4AG21/User-Manual/User-manual-3104674

credit :

>

• Such Vulhub website provide by MyCar Vendors

credit :

>

• SQLi to other account and launch other’s car engine by web API

credit :

credit :

BUG BUG BUG BUG CVE CVE CVE CVE

MyCar Vendor MyCar Vendor MyCar Vendor MyCar Vendor

>

credit : Automotive Electronics

>

credit :

>

credit : LGACL Simulator

Vehicular Ad Hoc Network

On-Board Unit, OBU Road Side Unit, RSU

• On board device to receive/send message system
• Combined with sensors
• microcontroller, speed sensor, brake sensor, radar, GPS, etc…
• Road side sensor to receive/send message system
• Has computing abilities
• Co-work with OBU to make V2V communication happened
• RSU can connect to central control center to make road state under control

>

credit : yenchih.kuo@NSYSU

• Communication between car：Vehicle to Vehicle, V2V
• Communication between car and road：Vehicle to infrastructure, V2I
• Dedicated Short Range Communications (DSRC)
• 5.85GHz~5.925GHz
• Infrared、RFID、IEEE802.11p、IEEE1609
• in IEEE1609.x Wireless Access in the Vehicular Environment (WAVE)
• Transmission Rate：3~27Mbps
• Most Range：1km

>

credit : yenchih.kuo@NSYSU

>

• Every sec, car will delivered its own basic info. Including highway ID, delivered time,

position, speed.

• Attacker can overwrite Beacon info to make MDS make mistake.
• Therefore, vehicle need to confirm pkg from valid node, and check checksum.

VANET Attack can conclude into 5 phases:

• Abnormal Data Check
• Alert Check
• Node Oriental Detecting Method
• Data Oriental Detecting Method
• Privacy

>

In next section →

>

In next section →

>

• JTAG

– A kind of debugging protocol, can download and upload the firmware, find the PIN on manual

• JTAGulator

– A tool to help researcher find the JTAG PIN on chip

credit : attify

>

• SWD (serial wire debug)

– A kind of debugging protocol, support by STM32F4 series (STM32F4 is the most widely used car chip)

• STM32F4 Discovery Kit

– A debug tool provide by ST themself

credit : st

>

• IVI (In-Vehicle Information System)
• MCU (Microcontroller Unit)

credit : iotm2mcouncil

>

MobilePhone / Server HMI MicroController HTTP Modbus Canbus Device PLC ECU No No / TLS1.2 No No Strong Normal Wea eak Lots Few Fe Few *Public Private *Pu *Public lic *Few *Few Lo Lots Remote / Extranet Remote / Extranet Phy Physical / / Sh Shor

• rt-dist /

/ Remote

>

• Most are targeted attack
• Vehicle security base on close-source and inconsistency, just

like OT

• Revenue is totally different class in IoT device, worth targeted

attack

• As AI raise, automatous vehicle definitely need standards to

connect to the road system and collect info for AI, therefore, it bring problems in security

>

>

>

>

>

>

• OEM (Original Equipment Manufacturer) / ODM (Original Design

Manufactures) try to add remote updating ability to the vehicle ECU

• There need a Update Solution standard to support several ECU vendors'

remote updating requirements

>

• Open Mobile Alliance (OMA) designed a protocol for Device

Management (DM), to remote implement UPDATE, MANAGE, CONTROL and

• BACKUP. Car Vendors can use this protocol to remote control

version update and retrieve data.

• Automotive Grade Linux (AGL) is sub-org under The Linux

Foundation which engage in cross industry requirements for internet of car. Recently, AGL try to defined OMA DM 2.0 to become car communication standard.

• Tesla convince that their protocol is too rough and their last

line in security protection is Black Box, open source will make their products in risk.

>

• OMA DM is a device management protocol for server to control the client

device.

• OMA DM include following major phases:

– Generic device information maintain (DevInfoMO, DmAccMO, DCMO) – Firmware maintain (FUMO) – Software maintain (SCOMO)

• OMA DM now has two version release:

– OMA DM I (complete)

• base on SyncML (Synchronization Markup Language) data format, OMA also

give a project as syncml rtk which plays as communication protocol of SyncML – OMA DM II (uncomplete)

• base on JSON data format, it simply use HTTP as communicate protocol
• only main protocol update to version II, not FUMO, SCOMO, or any else

>

• OMA DM 1.3 Communication Flow

Syn yncM cML

>

• OMA DM 2.0 Communication Flow

JS JSON

>

• How to Registration? How to identify response with Async Report?

>

• First Time Package1 session establish:
• Else:

Factory Bootstrap Device Serial Number Match Server’s Unregister Device Auth

> > >

Some else RFC2617 Headers (e.g. Authorization)

>

• That means registration key is store on

microcontroller DB as un-encrypted state and can be inferred

• You can register a fake client just like which we

infer door number that mentioned in Section 1 IoT part

>

• TLS/SSL is recommended in OMADM 2.0
• RFC2617 Basic Authentication Schema MUST be supported (newest: RFC 7617 (2015))
• RFC 2617 security options are optional. If Server doesn’t set QOP, Client will work

as RFC 2069.

• Basic Authentication Schema is easy attack by MITM. Attacker can easily set OFF on

QOP to let Client use RFC 2069.

• Moreover, there’s no mechanism to let Client check Server identification.
• RFC 2617 block user to use STRONG hash algorithm to store sensitive data like PSW,

they defined as recoverable value. HTTP PlainText HTTP Basic and Digest Access Authentication HTTPS/SSL HTTPS/TLS

< <

We all know where recommends are going ¯\_(ツ)_/¯

>

• HTTP

Publ Public ic

>

• OMA DM Modules and Functions

– Command Dealer – Parser & Database maintainer – Package Handeler

• OMA DM Data structures

>

• Table Name?

>

• Table Name?

>

• Database type storage in OMA DM

– Pros

• Insert / Update / Parse can easily use database schema mechanism to check DDF

invalid

– Cons

• Need more designing on table name also reach the consensus between Server &

Client

• XML type storage in OMA DM

– Pros

• easily fit the document designing

– Cons

• Insert a new MO tree will be hard to check if is valid DDF

>

• Actually Usage of Value?

>

• Cross Protocol Version:

– DataBuffer stream boundary different in SML & HTTP (1st command result following with 1st data /1st command result code with 2nd command result code) – Command method not backward compatible (Ver2 not support REPLACE command)

• OMA DM NodeName & SQL Syntax conflict:

– urn:oma:mo:fumo:1.0/<x>/update

• A lot of Extension in OMA DM tree: (there can not be multiple tables in same name)

– urn:oma:mo:oma-dm-devinfo:1.2/<x>/Ext – urn:oma:mo:oma-dm-dmacc:1.2/<x>/Push/GCM/Ext – urn:oma:mo:fumo:1.0/<x>/Ext

• Result Code inconsistency:

– Sometime diff MO module use same result code, sometime not.

• Same MO module, different DDF

>

• Request Launching in different way

– Server use method commands – Client use Generic Alerts (the one they usually used is to respond the

results of async commands like EXEC)

• Alert Type

– urn:oma:at:dm:2.0:BootstrapComplete – urn:oma:at:dm:2.0:ClientInitiatedMgmt – urn:oma:at:dm:2.0:ServerInitiatedMgmt – urn:oma:at:scomo:1.1:UpdateUserRequest – org.openmobilealliance.dm.firmwareupdate:update – org.openmobilealliance.dm.firmwareupdate:downloadandupdate

>

• urn:oma:mo:moid:1.0//

– Cannot resolve, there’s two MO instances.

• urn:oma:mo:moid:1.0/left/Data/1/Value

– identifies one nodes; the moroot1/Data/1/Value

• Ellipsis:

Usually use on MIID, this regards as only one node/value come up as result.

• Real Name:

The actually node name.

>

• urn:oma:mo:moid:1.0/(x)/Data/*/Value?nv=(x)/ID:GPS

– identifies two nodes; the moroot1/Data/1/Value and moroot1/Data/2/Value node

• x-name:

the DM Client MUST resolve

• nly one node that satisfies all

corresponding nv fields for this x-name component; if multiple nodes are resolved, an error code MUST be returned

• Wildcard:

the DM Client MUST address all nodes at the specified location

>

• In fact, Client and Server should share same MO trees (even though

Server will manage lots of Clients, but server should sync every Client)

• This over-freedom parser should only implement on Server backend

control panel, or better not exist

• Server and Client should send what they exactly needed rather than

making parser more complicated

• It is strongly suggest that not to allow # ; = > < this kind of SQL symbol as

valid characters in every node in URI

>

• Too complicate for Developer to implement property

– With dynamic-changing table schema in SCOMO – Apply to self-defined table schema with different Vendors’ clients

• SQLinjection with PlainText HTTP body (especially URI)
• Sometime Vendors’ clients simply send sub-tree in it’s own style.

(e.g. strings in integers, arrays in different JSON objects)

> &

• There’s no token designed(relative key in OMADM1.0, but not in OMADM2.0)

and authenticate mechanism(registration) in this protocol.

• MITM still problem here. (RFC2617 doesn’t work to prevent this link attack.)
• There’s no checksum confirmed mechanism for FUMO,(firmware update

module) client cannot even check if it is runnable or not before

it exec the binary.

• There’s checksum confirmed mechanism for SCOMO (software update

module), however, download source URL still can be a trap. (Server not even going to auth or check Remote Repository Server status and give a valid token let client to confirm source)

> > &

Server Client Hacker Un-encrypted DB Fake Request Hacking Payload Response e.g. DevID (API key)

> > &

Benign Server Benign Client Hacker Request Update Fake Command Fake Request Response

>

Hacker Request Update Malicious Server Benign Server Benign Client Compromised Switch Hack Request Update Malicious Payload DownloadURL Malicious Payload DownloadURL

>

Hacker Compromised Remote Repository Benign Server Benign Client Hack

Auth Sync????

Update Request TargetURL Response Download Request Malware / File Name Command injection e.g. Ruby,Net::FTP command injection e.g. Unsnenitize file name donwload

>

Hacker Request Update Compromised Server Client Fake Command Server Control Panel Hack ECU

• 1. Return shell with malicious update
• 2. finding ECU ID from Brutal Force

OMA DM component db information with GET cmd

• 3. Sending Canbus modified

malicious component application e.g. Node.js ft. misconfigure debugger handshake Allow command injection

>

RDS Bluetooth WiFi SD USB GPS Infotainment 3G/4G OBD2 Physical Remote Android Apps Remote Repository MyCar server Update server

>

• In IoT, OT, and Vehicle communication, plaintext and default AC/PW still

make serious problems

• Latest Cross-Industry features (AI manufacture, AI medication, AI car) still

not take Information Security as a serious problem, then come out with lots of vulnerabilities application

• In past, low revenues device (PC, IoT) can be find out exploit value by

black industry. Apparently, vehicle with its high value deserve to own its targeting attack, and it’s worthy

• Vehicle security can be a research draft of aircraft, it’s really

sensitive to country security

• OMA DM 2.0 is a protocol that need to harden. Should take serious

concern on security issues on its document

>

• Supply chain attack make vendors pay attention on every third-party

libraries (& Remote Repository Server)

• Make sure to use BL/WL mechanism and Hash check
• Cipher and CA always enhance your communication, use them
• Physical attack cannot avoid, but take care every addon on your car and

make sure to change your AC/PW

• Every remote access to CAN bus components (OBDII, MyCar, ECU update) should

apply auth confirm & encrypted communication. Vendors’ Web should apply vulnerabilities scanning to fix bugs, avoid brutal force and information leak.

• Mini computer is the major component in all attack vectors, Application

Whitelist can ease the lost after compromised by hacking

>

• http://www.openmobilealliance.org/
• http://illmatics.com/Remote%20Car%20Hacking.pdf
• https://ioactive.com/pdfs/IOActive_Adventures_in_Automotive_Networks_and_Control_Units.pdf
• https://www.sans.org/reading-room/whitepapers/threats/hacking-bus-basic-manipulation-modern-

automobile-through-bus-reverse-engineering-37825

• http://www.aut.upt.ro/~pal-stefan.murvay/papers/dos-attacks-controller-area-networks-fault-

injections-from-software-layer.pdf

• https://media.defcon.org/DEF%20CON%2027/DEF%20CON%2027%20presentations/DEFCON-27-Jmaxxz-

Your-Car-is-My-Car-Code-6e0e599/

• https://www.shs.edu.tw/works/essay/2012/11/2012111421572430.pdf
• https://hackaday.com/2019/06/10/takatas-deadly-airbags-an-engineering-omnishambles
• https://blog.avast.com/hacker-breaches-gps-service-of-27000-cars
• https://www.zdnet.com/article/dhs-warns-about-can-bus-vulnerabilities-in-small-aircraft
• https://www.outilsobdfacile.com/vehicle-list-compatible-obd2
• https://github.com/gmacario/easy-build
• https://www.st.com/resource/en/user_manual/dm00039084-discovery-kit-with-stm32f407vg-mcu-

stmicroelectronics.pdf

• https://www.elmelectronics.com/wp-content/uploads/2017/01/ELM327DS.pdf

>

>
