Noise-Induced Stop-and-Go Dynamics in Pedestrian Single-File Motion

joined work with Antoine Tordeux,Sylvain Lassarre, Jakob Cordes

Universität zu Köln

• observed in vehicular, bicycle and pedestrian motion
• succession of braking (shock) and acceleration

(rarefaction) sequences

• self-organized collective phenomenon
• have negative impact on safety, comfort, environment

Stop-and go waves

Universität zu Köln

• role of inertia in pedestrian models ?
• role of noise in pedestrian models ?

Stop-and go waves

• 1st order stochastic (toy) model for pedestrian dynamics
• new mechanism for stop-and-go waves

Stop-and-Go: Highway traffic

jam: v ≈ 0 free flow: v ≈ vmax separation into jams and free flow regions

Universität zu Köln

N=56 N=14 N=39 N=25

Stop-and-Go: Pedestrian dynamics

Wuppertal University FZ Jülich

separation into jams with v ≈ 0 and slowly moving regions with v = v(ρ) < vmax different mechanism compared to highway traffic ?

Universität zu Köln

Pedestrian models

Classification of models:

• description: microscopic ↔ macroscopic
• dynamics: stochastic ↔ deterministic
• variables: discrete ↔ continuous
• interactions: rule-based ↔ force-based
• fidelity: high ↔ low
• concept: heuristic ↔ first principles

Universität zu Köln

1st order vs. 2nd order models

typically deterministic 2nd order models force-based models

• ptimal-velocity

models 1st order models

Universität zu Köln

1st order vs. 2nd order models

role of inertia: damped harmonic oscillator

inertial mass damping (friction) driving force

Universität zu Köln

1st order vs. 2nd order models

role of inertia: damped harmonic oscillator inertia dominated damping dominated

4mk < b2

3 regimes

Universität zu Köln

1st order vs. 2nd order models

role of inertia: damped harmonic oscillator damping dominated: similar behavior to m = 0 dynamics described by 1st order equation

Universität zu Köln

1st order vs. 2nd order models

For pedestrian dynamics: almost instantaneous acceleration/stopping motion not inertia-dominated! 1st order model !!!

Universität zu Köln

1st order vs. 2nd order models

Overdamped social-force model:

(B. Maury, S. Faure 2019)

τ →0 :

dxi dt = Ui + Wij

j ≠ j

∑

for

Ui = desired velocity Wij = corrections to desired velocity

Problems with 2nd order models

• “tunneling” (penetration) of particles
• desired velocity can be exceeded
• oscillations when obstacles are approached

Universität zu Köln

all related to inertia effects! inertia “too strong” in most 2nd order pedestrian models (but: o.k. for vehicular traffic!) most cellular automata: no inertia, has to be implemented with transition rules

Problems with 2nd order models

Universität zu Köln

• ther issues with 2nd order models:
• superposition principle does not hold in general
• how to incorporate “decisions”?

(Seyfried, Sieben 2019) (talk by Bailo yesterday)

Problems with 2nd order models

Universität zu Köln

History never repeats?

Problems with 2nd order models

Universität zu Köln

Problems in 2nd order fluid models:

• Isotropy: no distinction between interactions with

following and preceding cars

• characteristic speed can be larger than the

average velocity (flow in front of a car is influenced by the traffic behind)

• Wrong-way travel: negative velocities possible
• Form of jam fronts unrealistic

Problems with 2nd order models

Universität zu Köln

introduction of a new pressure term and second conservation law avoids problems

Universität zu Köln

Stop-and-go waves in vehicular traffic

• stop-and-go in certain parameter

regimes

• homogeneous solution becomes

unstable

• phase transition from

homogeneous to heterogeneous configurations

• periodic solutions (limit-cycle)
• metastable or even chaotic

dynamics; hysteresis, capacity drop

single perturbation at time t0

Unstable models with inertia (2nd order):

Universität zu Köln

Stop-and-go waves for pedestrians

Guiding principles:

• 1st order model (no inertia effects)
• including stochasticity
• shows stop-and-go waves
• simple as possible

Role of stochasticity

• intrinsic stochasticity

– essential for dynamics – deterministic limit usually not realistic – persons act differently even in the same situation – reflects lack of knowledge about the true interactions

Universität zu Köln

• additive noise

– does not lead to a qualitative change of the underlying deterministic dynamics – „smears out“ trajectories – avoidance of unrealistic states

Nature of the noise

23

Data: ped.fz-juelich.de/database

(empirical) power spectrum of pedestrian speed ~ f-2 Brownian noise

Universität zu Köln

1st order Optimal-Velocity model (Pipes - Newell model) with additive Brownian noise (for 1d motion)

linear OV function V(d) = (d –l)/T (only congested flow) W(t) = Wiener process (Brownian motion)

1st order model

l = pedestrian size T = time gap α = noise amplitude β = noise relaxation

(Langevin equation for the noise) (OV model with noise)

Universität zu Köln

1st order model

alternative derivation: Optimal-velocity model with reaction time and anticipation expansion: full-velocity difference model + add white noise ξn(t) with : : Brownian noise

Universität zu Köln

1st order model

alternative derivation: Overdamped social-force model:

dxi dt = Ui + Wij

j ≠ j

∑

with corrections Wij to desired velocity Ui replace corrections by stochastic terms

Universität zu Köln

1st order model

homogeneous solution (for n pedestrians):

Real part Imaginary part

Unstable

λ2 λ1

θ −2/T −1/T −1/β −1/T 1/T θ = 0

stable for all n !!! xj+1(t) – xj(t) = L/n stability analysis:

Universität zu Köln

1st order model: Trajectories

n = 28

Time (s)

40 80 120

n = 45 n = 62

Real data 1 2 3 4

Space (m) Time (s)

40 80 120 1 2 3 4

Space (m)

1 2 3 4

Space (m)

Simulation

experiment: simulation:

Universität zu Köln

1st order model: Trajectories

wave speed: c = - l/T pedestrian speed: v = (L/n- l)/T

Universität zu Köln

1st order model: Correlations

Period = nT: Oscillations at longest wavelength for any α,β > 0

nT = L/(v-c)

autocorrelation of distance spacing

20 40 60 80 100 120

• 0.4

0.0 0.4 0.8

Time − tS (s) Autocorrelation 1/f = nT deterministic model

Universität zu Köln

1st order model: Correlations

autocorrelation of distance spacing for various noise parameters β

20 40 60 80 100 120 0.0 0.4 0.8

Time − tS (s) Autocorrelation β (s) 1.25 5 20

frequency only depends on T and n for pedestrians: β = 5s is most realistic

Universität zu Köln

Noise-induced stop-and-go

Noise-induced stop-and-go:

• homogeneous solution stable for

ALL parameter values

• Oscillation of the system at own

deterministic frequency (longest wavelength) due to stochasticity Linear stochastic system having unique stationary distribution No instability/metastability, non-linearity, inertia (or reaction time), neither as phase transition New mechanism for stop-and-go

Summary

Universität zu Köln

• 1st order pedestrian model
• unique homogeneous stationary state,

stable for all parameter values

• correlated noise “kicks” system out of

stable state

• stop-and-go not induced by instability
• no phase transition
• mechanism different from that in other

continuous models

• closer to the mechanism in stochastic

cellular automata models

• clarify role of noise and inertia in

pedestrian dynamics
