Making Light Work NOAA GMAC 2018 Open-Path Laser Dispersion Spectrometer for Methane Emissions Mapping and Quantification Dr Graham Leggett VP, Business Development OUTLINE 1. 1. Abo bout ut M MIRICO 2. 2. Tec echno hnology


slide-1
SLIDE 1

Making Light Work

NOAA GMAC 2018 Open-Path Laser Dispersion Spectrometer for Methane Emissions Mapping and Quantification

Dr Graham Leggett VP, Business Development

slide-2
SLIDE 2

OUTLINE

2

1.

  • 1. Abo

bout ut M MIRICO 2.

  • 2. Tec

echno hnology

  • Laser Dispersion Spectroscopy (LDS)

3.

  • 3. Em

Emissions M Mappi pping a and nd Qua uantification

  • CH4 release trials in collaboration with Shell Global

Solutions International B.V.

  • Mapping derived using Shell LightSource software
  • Collaboration with NPL

4.

  • 4. Conclus

usions ns

slide-3
SLIDE 3

ABOUT MIRICO

3

  • Developer of rugged, high performance spectrometers for gas analysis
  • Space science technology developed at Rutherford Appleton Labs
  • Instruments offer precision, sensitivity, accuracy, and reliability
  • Headquarters in Oxford, UK

Robust Space Technology

Rugged & High performance Analysers for the field Serving Multiple Industries

slide-4
SLIDE 4

LASER DISPERSION SPECTROSCOPY

4

I0 It

  • Signal encoded in intensity of

emitted beam

  • Non linear after 10% absorbance
  • Useful signal limited by intensity –

susceptible to dust, water vapour, etc.

  • Signal encoded in phase of beam
  • Linear response over broad dynamic range
  • Maintains sensitivity in “dirty”

environments

  • Immune to intensity fluctuations

ABSORBTION LDS

slide-5
SLIDE 5

LASER DISPERSION SPECTROSCOPY

5 QCL/ICL Mid-infrared laser Acousto-optic modulator (AOM) Detector

  • Each frequency experiences

different refracted index

  • Results in different propagation

time to detector

Absorption LDS

slide-6
SLIDE 6

SET-UP

6 LDS 1 100 OP OP prototyp ype CH CH4 Tr Tripod-mounted c corner cube re retro re reflector 500 m 500 m

  • 1 km

km t tot

  • tal

al p path-len ength ( (transmit a and return)

  • Manual

al align gnmen ent using v g visible l e laser

  • ~1

1 hour d dep eployment p t process ss

slide-7
SLIDE 7

7

SIMPLE CASE OF POINT EMITTER TEMPORAL EVOLUTION OF CH4

OPEN-PATH LDS – CH4 MAPPING

slide-8
SLIDE 8

OPEN-PATH LDS – CH4 MAPPING

8

SIMPLE CASE OF POINT EMITTER TEMPORAL EVOLUTION OF CH4

slide-9
SLIDE 9

MULTI-PATH CH4 EMISSIONS MAPPING

9

Laser AOM Fast galvo mirror Detector

slide-10
SLIDE 10

MULTI-PATH CH4 EMISSIONS MAPPING

10

  • 19 releases of ~1 hour each
  • 2x2m diffuse area sources at ground level
  • four release schemes of 1 or 2 sources
  • emission rates: 1.2 to 1.6 kg/hr per source
  • <2m/sec wind -data excluded
  • 1 minute data averaging used
slide-11
SLIDE 11

MULTI-PATH CH4 EMISSIONS MAPPING

11

slide-12
SLIDE 12

MULTI-PATH CH4 EMISSIONS MAPPING

12

Wind direction

Release Location 2

7 min background 7 min background 40 min release

             

Paths 5, 6, and 7 upwind so no reaction to release

 

Path switching 10 milliseconds ~200 meters 0-14 ppm

Temporal evolution of integrated CH4 concentration over 7 paths 1s resolution - ~10 ppb precision - ~1 ppm.m/√Hz (1 of 5 datasets used for analysis)

120 ms/beam

slide-13
SLIDE 13

MULTI-PATH CH4 EMISSIONS MAPPING

13

Location 1 1.35kg/hr actual Location 3&4 2x 1.24 kg/hr actual Location 2 1.38 kg/hr actual Location 3 1.47 kg/hr actual

slide-14
SLIDE 14

NPL TRIAL

14

Purpose: Test at different heights, emission scenarios and release rates.

slide-15
SLIDE 15

NPL TRIAL

15

slide-16
SLIDE 16

CONCLUSIONS

16

  • Suc

Succes essfully t y tak aken LDS f S from l laboratory to fiel eld

  • Co

Confirmed ed pa path th-leng ngth a and s nd sensitivity

  • Co

Confirmed ed o

  • per

perati tion in n variable a e atmosp spher eric condi nditions

  • De

Demons nstrated s ed scanni nning ng techni hniqu que f for l large-area ea mapp pping ng

slide-17
SLIDE 17

ACKNOWLEDGEMENTS

17

slide-18
SLIDE 18

THANK YOU

QUESTI TIONS? graham@mirico.co.uk +44 7715 676751 www.mirico.co.uk
