No Apology Required Deconstructing BB10 CanSecWest 2014 Introduction Presentation is exploratory Research is on-going Body Level One Focused mostly on methodology, less on Body Level Two findings Body Level Three

slide-1
SLIDE 1

No Apology Required

Deconstructing BB10 CanSecWest 2014

slide-2
SLIDE 2

Introduction

  • Body Level One
  • Body Level Two
  • Body Level Three
  • Body Level Four
  • Body Level
  • Presentation is exploratory
  • Research is on-going
  • Focused mostly on

methodology, less on findings

  • Feel free to chat after

(since we may run out of time)

  • Title is because

stereotypical Canadians apologize for everything

slide-3
SLIDE 3

Introduction

  • Body Level One
  • Body Level Two
  • Body Level Three
  • Body Level Four
  • Body Level
  • Presentation is exploratory
  • Research is on-going
  • Focused mostly on

methodology, less on findings

  • Feel free to chat after

(since we may run out of time)

  • Title is because

stereotypical Canadians apologize for everything

slide-4
SLIDE 4

Introduction

Ben Nell
 bNull


  • Sr. Security Consultant


Accuvant Labs Zach Lanier
 quine


  • Sr. Security Researcher


Duo Security

Presentation foul:
 <--- mixing memes --->

slide-5
SLIDE 5

Why this matters

slide-6
SLIDE 6

Why this matters

slide-7
SLIDE 7

Why this matters

You’re an appsec consultant and your customer asks you if BlackBerry Balance solves BYOD

slide-8
SLIDE 8

Agenda

  • Previous Research
  • Platform Overview
  • Methodology
  • Attack Surface
  • Future Work
slide-9
SLIDE 9

Previous Research

slide-10
SLIDE 10

Our PlayBook stuff

  • Targeted predecessor of BB10

— TabletOS on BB PlayBook

  • Discovered AuthZ token

disclosure for Bridge/Balance (steal all the corporate data)

  • RE’d firmware
  • Mirrored all of AppWorld (steal

all the premium apps)

  • And more...
slide-11
SLIDE 11

Our PlayBook stuff (cont’d)

  • Discovered that native apps

can exec*() / spawn*() and

  • pen AF_INET sockets

unfettered (no perm’s req’d)

  • Still true in BB10, but (even

detached) child procs killed when app/parent ends

  • “Headless Apps” allow for

background services, but special perms required

  • Granting of perms is

contingent upon approval from RIM/BB signing service

slide-12
SLIDE 12

Others

  • Julio Cesar Fort’s QNX

research

  • SEC Consult BB10 paper
  • RPW’s BB10 preso (BH

USA ’13)

  • Tim Brown’s various

QNX/TabletOS/BB10 works

slide-13
SLIDE 13

Platform Overview

slide-14
SLIDE 14

Overview

  • ARM-based SoCs (Z10, Q10, and Z30

all Snapdragon S4 SoC)

  • BB10 (based on QNX Neutrino RTOS

8.0.0)

  • Major components (as of 10.2.1.1925):
  • WebKit (537.10 / 10.2.1.66)
  • Adobe Flash (11.1.121.199)
  • Adobe AIR (3.1.0.230)
  • BlackBerry Balance (isolated,

corporate PIM)

slide-15
SLIDE 15

QNX

  • Microkernel, only truly trusted

component

  • Userspace kernel and

process manager - procnto

  • Separation of network,


I/O, HMI, etc. into separate components

  • Messaging layer provides

IPC (QNX message passing + POSIX IPC abstraction)

  • Prev. public bugs disclosed

by Ilja van Sprundel, Tim Brown, Julio Cesar Fort, cenobite, and others

slide-16
SLIDE 16

Security Controls / Mitigations

  • OpenBSD NetBSD pf
  • POSIX (filesystem) ACLs
  • Compiler & linker protections for native

apps

  • Usual suspects: XN, ASLR, ProPolice,

PIE + full RELRO

slide-17
SLIDE 17

QDE/Momentics default build options

slide-18
SLIDE 18

Security Features

  • Blackberry Balance
  • Encrypted, FACL’d “container”
  • a.k.a. “perimeter”
  • BES policy enforcements
  • DISA STIGs guide these
slide-19
SLIDE 19

authman & permissions

  • authman service - maps app permissions

to system resources

  • Filesystem permissions + POSIX ACLs, PF

rules

  • Shell script and Python glue to bind it all

together

slide-20
SLIDE 20

authman & permissions

  • /dev/authman: resource manager “dispatch”

path (QNX IPC endpoint)

  • /etc/authman: configs
  • Pair of files (".res" & ".acl"), named for profile type
slide-21
SLIDE 21

authman & permissions

  • Controls access to

app permissions (allow, prompt, deny)

  • Sets FACLs on

filesystem objects based on app permission requested

  • Also sets process

capabilities for certain permission types (e.g. “Headless apps”)

slide-22
SLIDE 22

authman & pf

  • authman handles

setting up (app) GID:rule mapping

  • Ex: limiting access

to SapphireProxy (for BB Bridge) on 127.0.0.2

slide-23
SLIDE 23

Dec 06 01:53:04 5 41 0 authman: RX euid=89/egid=0, 'defapp ext __def personal dual 100001000 100001000 sys.browser.gYABgJYFHAzbeFMPCCpYWBtHAm0 "Browser" "Research In Motion Limited" "gYAAgNpMbwE-h W4khx0h8BidUeI" run_when_backgrounded manage_certificates access_location_services use_camera record_audio access_shared access_internet post_notification gain_oma_fl_group access_oma_fl_write_personal acce ss_oma_fl_write_enterprise access_bbjma_data access_carrier_browser access_cclagent_service use_certmgr_server access_wifi_limited run_native permanent access_perimeter_personal' Dec 06 01:53:04 5 41 0 authman: Requested caps: Dec 06 01:53:04 5 41 0 authman: req:Allow execute Dec 06 01:53:04 5 41 0 authman: Applying execute Dec 06 01:53:04 5 41 0 authman: pf_remove_gid: scanning anchors for gid=100001000 Dec 06 01:53:04 5 41 0 authman: Requested caps: Dec 06 01:53:04 5 41 0 authman: req:Allow run_when_backgrounded Dec 06 01:53:04 5 41 0 authman: req:Allow manage_certificates Dec 06 01:53:04 5 41 0 authman: req:Allow access_location_services Dec 06 01:53:04 5 41 0 authman: req:Allow use_camera Dec 06 01:53:04 5 41 0 authman: req:Allow record_audio Dec 06 01:53:04 5 41 0 authman: req:Allow access_shared Dec 06 01:53:04 5 41 0 authman: req:Allow access_internet Dec 06 01:53:04 5 41 0 authman: req:Allow gain_oma_fl_group Dec 06 01:53:04 5 41 0 authman: req:Allow access_oma_fl_write_personal Dec 06 01:53:04 5 41 0 authman: req:Allow access_oma_fl_write_enterprise Dec 06 01:53:04 5 41 0 authman: req:Allow access_bbjma_data Dec 06 01:53:04 5 41 0 authman: req:Allow access_carrier_browser Dec 06 01:53:04 5 41 0 authman: req:Allow access_cclagent_service Dec 06 01:53:04 5 41 0 authman: req:Allow use_certmgr_server Dec 06 01:53:04 5 41 0 authman: req:Allow access_wifi_limited Dec 06 01:53:04 5 41 0 authman: req:Allow run_native Dec 06 01:53:04 5 41 0 authman: req:Allow permanent Dec 06 01:53:04 5 41 0 authman: req:Allow access_perimeter_personal Dec 06 01:53:04 5 41 0 authman: Applying run_when_backgrounded Dec 06 01:53:04 5 41 0 authman: Applying manage_certificates Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=060, /pps/services/certmgr/control Dec 06 01:53:04 5 41 0 authman: Applying access_location_services Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=040, /pps/services/cellular/radioctrl/status_cell_cdma_private Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=040, /pps/services/cellular/radioctrl/status_cell_private Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=040, /pps/services/cellular/radioctrl/status_private Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=040, /pps/services/radioctrl/modem0/status_private Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=060, /pps/services/geolocation/geomonitor/control Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=050, /pps/services/geolocation/geomonitor Dec 06 01:53:04 5 41 0 authman: set_acl_group_perms: gid=100001000, perms=060, /pps/services/geolocation/control

“Capabilities” based

  • n permissions

ACLs based on permissions pf rule(s)

  • utput from sloginfo (tool to print system log)
slide-24
SLIDE 24

PPS

  • “Persistent Publish / Subscribe”
  • Implemented by pps manager process
  • Simple interface for sharing data,

notifications/eventing via filesystem objects

slide-25
SLIDE 25

IPC

  • IPC is key in QNX
  • “Message passing” & signals implemented

in microkernel

  • Other IPC (POSIX-compatible) mechanisms

implemented by manager processes

Message passing

Shared memory Pipes FIFOs Message copying Simple messages Channels Events (pulses, signals, unblocks) Typed memory

Signals

Kernel Kernel External process/manager

slide-26
SLIDE 26

Application Model

  • Native
  • WebWorks / Cordova
  • Adobe AIR
  • Android

C/C++

Flash/AS/ HTML/JS

HTML/JS Java/DEX

20 app perms documented 340 unique app & sys perms observed

slide-27
SLIDE 27

Application Model

  • App processes run with same UIDs, but separate

GIDs (incl. supplemental GIDs)

  • Apps have separate data stores/”sandboxes”
  • With Balance/corporate separation, additional data

stores

  • Production apps are signed by BB/RIM signing server
slide-28
SLIDE 28

Our Approach to the Platform

meth·od·ol·o·gy

/ ˌmeTHəӚˈdäləӚjē/

( )

slide-29
SLIDE 29

Testing Limitations

slide-30
SLIDE 30

Testing Limitations

  • General lack of enthusiasm for BB10 as a

target

  • General lack of public information about

the system

  • Effective security controls
  • We’re left looking at a black box
slide-31
SLIDE 31

OSINT

Just ask the internet!

slide-32
SLIDE 32

OSINT

Existing previous work

  • Our PlayBook work
  • SEC Consult paper
  • Works by RPW, Tim Brown,

Julio Cesar Fort, etc.

  • Not a ton of stuff out there

https://www.sec-consult.com/fxdata/seccons/prod/downloads/sec_consult_vulnerability_lab_blackberry_z10_initial_analysis_v10.pdf

slide-33
SLIDE 33

OSINT

QNX Foundry

  • Man pages for QNXisms
  • Downloads
  • Forums
  • Wiki
  • Google dorks are

golden…

slide-34
SLIDE 34

OSINT

Speaking of Google dorks…

slide-35
SLIDE 35

OSINT

Some random RIM employee’s file dump? Upcoming product feature assessment

hardware code names

Upcoming project effort estimations/ release dates

slide-36
SLIDE 36

OSINT

  • Body Level One
  • Body Level Two
  • Body Level Three
  • Body Level Four
  • Body Level Five

Some random RIM employee’s file dump? Internal bug tracker

internal URL

slide-37
SLIDE 37

OSINT

Some random RIM employee’s file dump? Pre-release BB10 developer image for Winchester/PlayBook

slide-38
SLIDE 38

Dynamic Analysis

Watch it work and try to understand “why”

slide-39
SLIDE 39

Dynamic Analysis

RIM wants to get your hacking^Wdevelopment
 projects up and running as quickly as possible! Lots of SDK stuff, including a native SDK, giving us:

  • libc, libcurl, OpenSSL, V8,

and tons more

  • Easy cross-compilation
slide-40
SLIDE 40

Dynamic Analysis

Development Tools Sample code

slide-41
SLIDE 41

Dynamic Analysis

Momentics target navigator Proc/thread mem info FS nav, etc. Controller app Controls NFC, Camera, geoloc, etc. for Simulator

slide-42
SLIDE 42

Dynamic Analysis

  • Momentics provides QNX-specific versions/

builds of the typical toolchain

  • gdb
  • also objdump, nm, readelf, gcc, etc.
slide-43
SLIDE 43

Dynamic Analysis

Blackberry Simulator QNX Software Dev Platform (SDP)

  • Gives us something similar

to the real thing

  • We can have root access*
  • Access to tools relevant to

the real thing

  • MDS Simulator
  • It’s like the non-official

“platform” debug tool

  • A fully accessible QNX

environment

* - with a bit of work

slide-44
SLIDE 44

Dynamic Analysis

Just another box on the network

  • Testing harness
  • Wireshark
  • Proxy (Burp and

friends)

  • nmap
  • Various fizzers
  • Custom stuff
slide-45
SLIDE 45

Dynamic Analysis

There are lots of network services Twist:

BB10 network services

slide-46
SLIDE 46
slide-47
SLIDE 47

Dynamic Analysis

  • Unsurprisingly, logs => info
  • slogger (app event logger) and slogger2 (system event logger)
  • Readable on simulator with sloginfo and slog2info
  • slog* devices not readable on device :(

Dec 07 16:14:20.041 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 [ServiceManager] refreshing accounts list Dec 07 16:14:20.042 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 Calling AccountServicePrivate::accounts for service "contacts" Dec 07 16:14:20.042 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 Calling AccountServicePrivate::accounts Dec 07 16:14:20.044 sys.pim.messages.gYABgJ8jn83Ok_NEWYplPYozt5w.3567740 default 9000 MNH(93): handleAccountUpdated accountId 4 Dec 07 16:14:20.045 sys.pim.messages.gYABgJ8jn83Ok_NEWYplPYozt5w.3567740 default 9000 Calling AccountServicePrivate::account for AccountKey = 4 Dec 07 16:14:20.052 sys.pim.messages.gYABgJ8jn83Ok_NEWYplPYozt5w.3567740 default 9000 GET 0x13 Dec 07 16:14:20.052 sys.pim.messages.gYABgJ8jn83Ok_NEWYplPYozt5w.3567740 default 9000 URL Buffer: http://127.0.0.1:8888/ accounts/4

  • Dec 07 16:14:20.066 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 GET 0x1

Dec 07 16:14:20.066 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 URL Buffer: http://127.0.0.1:8888/ accounts

  • Dec 07 16:14:20.072 sys.pim.messages.gYABgJ8jn83Ok_NEWYplPYozt5w.3567740 default 9000 Curl Easy perform

Dec 07 16:14:20.080 sys.pim.contacts.gYABgGsAOuzqCT1fu5Zx4sqrJdY.28930195 default 9000 Curl Easy perform Dec 07 16:14:20.081 menu_service.2830447 menu_svc_logs 0 MS PIMCORE: command: GET method: /accounts URL:http:// 127.0.0.1:8888/accounts Dec 07 16:14:20.082 phone.3567743 phone 0 [ I][18][PlatformContact:lookupByPhoneNu| 107] ContactService returns 0 contacts for number '1212xxxxx40'.

slide-48
SLIDE 48

Dynamic Analysis

Debugging is a breeze

slide-49
SLIDE 49

Target Host

slide-50
SLIDE 50

Fuzzing…

slide-51
SLIDE 51

Static Analysis

For the things that can’t be watched

slide-52
SLIDE 52

Static Analysis

Installation bundles

  • BAR format (hurr durr)
  • De-facto standard for any

non-factory packages

  • META-INF directory
  • Code signatures and app

info

  • “assets”

% zipinfo -l1 ./Gooby/arm/o.le-v7/Gooby-1_0_0_1.bar META-INF/MANIFEST.MF META-INF/AUTHOR.SF META-INF/AUTHOR.EC META-INF/RDK.SF META-INF/RDK.EC native/bar-descriptor.xml native/icon.png native/assets/main.qml native/qm/Gooby.qm native/Gooby.so native/GoobyService native/assets/.assets.index

slide-53
SLIDE 53

Static Analysis

MANIFEST.MF: Package Meta Info

slide-54
SLIDE 54

Static Analysis

MANIFEST.MF: Application Meta Info

slide-55
SLIDE 55

Static Analysis

MANIFEST.MF: Entry Point Info

slide-56
SLIDE 56

Static Analysis

MANIFEST.MF: Entry Point Info

slide-57
SLIDE 57

Static Analysis

Getting Firmware

  • MITM the CDN downloads
  • The “community” has built

some good tools

http://forums.crackberry.com/bb10-leaked-beta-os-f395/sachesi-firmware-extractor-searcher-installer-825409/

slide-58
SLIDE 58

Static Analysis

Getting Into the Firmware

  • “pbtools”
  • Mount the firmware in Simulator or SDP
  • SCP the files back out

https://github.com/intrepidusgroup/pbtools

slide-59
SLIDE 59

Static Analysis

Shell Scripts

  • /base/scripts/
  • Easy to read
  • grep-fu for great

success! from “startup.sh”

slide-60
SLIDE 60

Static Analysis

Python: For everything important on BB10 that isn’t written in bash

  • Most of it is compiled

Python (bytecode; *.pyc)

  • unpyc3.py

https://code.google.com/p/unpyc3/

slide-61
SLIDE 61

Static Analysis

ActionScript

  • Decompile with Sothink / whatever
  • Most ActionScript apps handle front-end stuff

qnx.AIRServices.ota.OtaUpdate

slide-62
SLIDE 62

Static Analysis

Compiled binaries

  • IDA cleanly disassembles
  • ARM / x86
  • Without a public root,

disassembly might be your best/only bet for dorking with many network services

slide-63
SLIDE 63

Attack Surface

http://www.harkavagrant.com/?id=250

slide-64
SLIDE 64

Entry Points

Where the device accepts data

slide-65
SLIDE 65

IPC

  • Numerous IPC endpoints available
  • QNX channels particularly

caught our eye

  • Wrote some horrible IPC

scanners / fuzzers

  • Problem: not always sure WTF is
  • n the other end of a channel

(or able to attach to channel but unable to send)

  • Also DoS’d/froze device multiple

times during mass channel scans

$ ./scanchan.py 643092 Could not find platform independent libraries <prefix> Consider setting $PYTHONHOME to <prefix>[:<exec_prefix>] [+] PID: 643092 - Connected to channel: 2 [-] PID: 643092 - Error for channel 6: [Errno 1] Operation not permitted

$ ./fchan1.py 1019928 16 [+] PID: 1019928 - Connected to channel: 16 (48, b"AAAAAAAAAAAAAAAA(coid, b'Hello!')\n c \x01\x00\x00\x00\x00\x00\x00\x00\x03\x00\x00\x00\x02\x0 0\x00\x00O\x00\x00\x00s\x16\x00\x00\x00|\x01\x00| \x00\x00_\x00\x00|\x02\x00|\x00\x00_\x01\x00d \x00\x00S(\x01\x00\x00\x00N(\x02\x00\x00\x00u \x04\x00\x00\x00argsu\x06\x00\x00\x00…

slide-66
SLIDE 66

Network Services

  • Samba!
  • WWW!
  • WebDAV!
  • Proxies!
  • SSH!
  • Other stuff!
slide-67
SLIDE 67

Network Services

Local-hosted CGI scripts are used for device management “stuff”

  • Backup & restore
  • Application installation
  • Device reset
  • Limited logging control
  • Limited PIM management
  • Enterprise registration
  • Etc
slide-68
SLIDE 68

WiFi

  • Many device management

functions happen over HTTP/ SMB with the option of

  • perating over WiFi
  • Handset acts as an UPnP

gateway

  • There are some real

problematic areas observable

  • ver WiFi
slide-69
SLIDE 69

USB

  • Mass storage? Nay,

Ethernet!

  • Similar to WiFi

(WWW/SMB), with additional capabilities

slide-70
SLIDE 70

Bluetooth

  • Tether your handset to your

tablet

  • SapphireProxy (get it?)
  • WebDAV
  • HTTP proxy
  • Protected by pf

BlackBerry “Bridge” / SapphireProxy

This service has had problems in the past… *

* Barely recognizable BattleStar reference

slide-71
SLIDE 71

NFC

It works and there are no security problems?

  • Haven’t really

explored this

  • urselves.
  • Biggest concern

likely bad NDEF message parsing by 3rd party native apps

slide-72
SLIDE 72

Local Application

  • Malware / Client-

side attacks

  • Insufficient controls
  • n sensitive local

file and network resources

  • Privilege

escalations are like gold

slide-73
SLIDE 73

Balance

  • An attempt at solving BYOD
  • “Perimeters” manage the

separation between personal and enterprise applications, data, and network resources

  • Enterprise perimeter security is

controlled by BES and enforced locally

slide-74
SLIDE 74

Balance

Concerned Consumer: Sounds great. How does it work? I am familiar with the iOS security model and might expect to see some sort of sandboxing technology to enforce this separation.

slide-75
SLIDE 75

Balance

RIM: I don’t want to say that it’s all based on file permissions… …but it’s all based on file permissions

slide-76
SLIDE 76

Future Work

slide-77
SLIDE 77

TODO

  • Further (re-)exploration of...
  • authman
  • system IPC endpoints
  • Balance
  • Android support
  • Radio (NFC, Cell/BB, BT)
  • HDMI, USB
slide-78
SLIDE 78

Conclusion

slide-79
SLIDE 79

Questions / Contact

  • https://twitter.com/quine


zach@n0where.org
 zach@duosecurity.com


  • https://twitter.com/bnull


[NO_EMAIL_PROVIDED]

<--shameless plug
